PROAIM MB 30 User manual

1
Please inspect the contents of your shipped package to ensure you have received everything that is listed
below.
Assembly Manua l
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,
electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright
statutes or in wring by the Publisher.
Mae Box
What’s In The Box
2 x 4 x 5.6" Filter Tray
124mm Fabric Knicker
15mm LWS Rod
Bracket
124-87mm Plasc
Adapter Ring 124mm
Metal Ring
(OD-87)-(ID-77) mm
Threaded Adapter Ring
(OD-87)-(ID-82)
mm Threaded
Adapter Ring
(OD-87)-(ID-72)
mm Threaded
Adapter Ring
T-Type Allen Key
(Size : 2.5mm)
L-Type
Allen Key
(Size : 2mm)
(OD-87)-(ID-67) mm
Threaded Adapter Ring
MB 30 SWING-AWAY Video Camera
Mae Box (P-MB-30)

2
MB 30 Mae Box Setup
• Release both the knobs on either side of the
mae box to insert the lter trays.
• Insert the lter trays and then ghten the
knobs.
• Use the Allen key to ax both the trays.
• Stretch the 124-87mm plasc adapter ring
and insert the 124mm metal ring into the
former, as shown in the image.
• The assembly will look like this.
Mae Box
Filter Tray
Adapter Rings

3
• Now, ghten the knob of the ring holder.
• Unlock the knob of your tripod (Not Included)
and press the quick release buon, as shown
in the image.
• Aach the removed plate to the boom of
the camera (Not Included), and then ghten it
with a screw.
• Now, loosen the knob of the conversion ring
holder and insert the plasc ring into it, as
shown in the image.
• Insert camera (Not Included) into the mae
box’s ring as shown in the image.
• Now remove the plate (by sliding) from the
tripod (Not Included) by pushing the quick
release buon.

4
• Then mount the assembly (Not Included) on
top of the tripod (Not Included) by sliding.
• Now, lock the knob of the tripod
(Not Included), as shown in the image.
• Open the carbon ber ag of the mae box.
• Loosen and remove both the screws of the
mae box using the T-Type Allen Key.
• Now, aach the 15mm LWS Rod Bracket to
the mae box.
Mae Box With Fabric Knicker Setup
15mm LWS Rod Bracket

5
• Screw the LWS Rod Bracket to the mae box
with the T-Type Allen key.
• Loosen the knob of the conversion ring holder
and insert the 124mm Metal Ring into it, as
shown in the image.
• Now, ghten the knob of the conversion ring
holder, as shown in the image.
• The mae box would look like this aer
following all the instrucons correctly.
• Cover the aached ring with the 124mm
fabric knicker and then ghten it.
• The mae box would look like this aer
following the above instrucons.
Fabric Knicker
Adapter Ring

6
• Now, loosen the quick-release knob of the
universal base plate to remove the dovetail
camera plate (Not Included).
• Aach the Dovetail camera plate to the
camera (Not Included) and secure it properly
using a screwdriver (Not Included).
• Insert 2 rods (Not Included) into the universal
base plate holes and then ax them with the
camera (Not Included) base by sliding.
• Then, lock the center knob to secure it.
• Loosen the knob of the 15mm LWS Rod
Bracket, and then insert the rods
(Not Included) into the LWS Rod Bracket.
Universal Base Plate

7
• Cover the camera lens (Not Included) with
the other end of the Fabric Knicker.
• Then, lock the knob of the LWS Rod Bracket.
• Mount the camera setup on the tripod
(Not Included) by sliding and secure it by
locking the knob of the tripod (Not Included).
• Aach the removed plate to the boom of
the universal base plate (Not Included) and
screw it ghtly.
• Remove the plate (by sliding) from the tripod
(Not Included) by pushing the quick-release
buon.

8
YOUR PROAIM MB 30 SWING-AWAY VIDEO CAMERA MATTE BOX
ALL DRESSED UP AND READY TO GO!
(SHOWN WITH OPTIONAL ACCESSORIES)
Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,
we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it
cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon and
evaluaon by us.
Liability: We are not liable for damage caused by products that we do not supply or from mishandling in
transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.
Contact Us: In case of any kind of dissasfacon, please Contact us immediately and we promise our utmost
support and care unl you use our product.
