General Intro
LED is the acronym for “Light Emitting Diode”. LED technology is based on
the electroluminescence generated by the emission of photons. Unlike
common light bulbs whose fi laments work at very high temperatures
and feature a remarkable thermal inertia, an LED emits cold light. The
LEDs that we are interested in are those that emit red, orange, yellow, or
green light. In relatively recent times the creation of a blue LED was also
achieved. This development is very important as a blue LED combined
with green and red radiations allows the creation of a white light sour-
ce and also of all those colours allowed by an RGB (additive synthesis)
combination. In recent years LED technology has been the choice in all
applications requiring high reliability, long life span and top effi ciency.
Some of its main applications are:
• Decoration and signage
• Variable message LED Walls
• Entertainment and architectural lighting
LED technology is employed more and more in architectural and enter-
tainment lighting instead of more traditional light sources, but its low
power prevents it from replacing them completely. Basically, its main
drawback is the amount of emitted light (fl ux of light expressed in lu-
mens) which ranges up to 120 lm for the most recent professional mo-
dels, whereas a 60W incandescence light bulb emits a light fl ux of about
550 lumens.
The advantages in the use of LED technology for lighting are:
• Long life span (high emission LED can last up to 50,000 hours)
• No maintenance costs
• High performance (if compared to incandescent light bulbs or
halogen lights)
• Non polluting, as it does not include IR or UV components
• Sharp spot eff ect (highly specifi c point source)
• Safety, as it works with very low voltage (normally around 24 Vdc)
• No sensitivity to humidity or vibrations
• No mercury
Finally, the commercial strength of such equipment lies in its brightness
(four times brighter than fl uorescent lights and tungsten fi lament lights),
low price, high effi ciency and reliability. Furthermore, an LED can last a
lot longer than any classic light source (especially if under mechanical
stress) and its very low absorption allows it to be used anywhere.

5
Architectural LED
Entertainment LED 6
23
Made in Italy LED 29
LED Tubes 45
Index
5

6
Moving Heads
90 high power RGBW LED Moving Head
Power supply: 100-240V 50/60Hz
Rated Power: 550W
LED: 90 (18Rx2W – 24Gx5W – 24Bx5W – 24Wx5W)
Eff ects: RGBW Colour Mixing, Built-in Programs, Strobe, White Balance, RGB Calibra-
tion, Dimmer, Colour Macros.
Control: DMX 10/14 channels – Stand Alone – Master/Slave
Movements: 540° Pan – 270° Tilt – adjustable speed
IP rating: IP20
This unit complies with CE directives
2
0.23
4
0.44
6
0.68
8
1.01
10
1.44
650LUX
Distance (m)
Diameter (m)
180 86 51 35
BLUE
15°
2
0.23
4
0.46
6
0.69
8
0.95
10
1.40
6930LUX
Distance (m)
Diameter (m)
1850 860 500 330
GREEN
15°
2
0.20
4
0.39
6
0.56
8
0.81
10
1.42
3750LUX
Distance (m)
Diameter (m)
945 407 228 139
RED
15°
2
0.22
4
0.43
6
0.67
8
0.82
10
1.14
10800LUX
Distance (m)
Diameter (m)
2830 1320 743 514
RGB
15°
2
0.22
4
0.42
6
0.65
8
0.94
10
1.26
19300LUX
Distance (m)
Diameter (m)
5030 2300 1302 880
RGB+WHITE
15°
2
0.22
4
0.42
6
0.62
8
0.83
10
1.25
8720LUX
Distance (m)
Diameter (m)
2260 1040 590 394
WHITE
15°
14 channels DMX PLLEDHTML
100
75
50
25
0
0° - 540°
Min
Max Macro
Macro
DMX Pan Tilt
fine
Pan/Tilt
speed Macro
Value Ch1
0° - 280°
Tilt
Ch2 Ch4
Pan
fine
Ch3 Ch5 Ch10
Slow
Fast
Strobe
Ch12
Red
Ch6
Green
Ch7
Blue
Ch8
White
Ch9
Dimmer
Ch11
Dimmer
speed
Ch13
Control
Ch14
Min
Max
Power : 100 - 240V 50/60Hz
LED: 90 RGBW - (18x2WR - 24x5WG - 24x5WB - 24x5WW)
Size: L433xW320xH462 mm
Weight: 20,3 Kgs
6
5
0
1
8
0
8
6
5
1
3
5
6
9
3
0
L
U
X
G
R
E
E
N
PLLEDHTML

7
Moving Heads
LED moving head with RGB technology. This projector provides illumination via 36
high-effi ciency LEDs (12 red, 12 green, 12 blue) off ering high luminous output as well
as infi nite RGB colour mixing.
LED WASH MOVING HEAD
Input Voltage: 230V / 50Hz - 120V / 60Hz (selectable with onboard switch)
High Power 1W LEDs: 12 red, 12 green, 12 Blue -1,4W over 50000 hours rated life
Beam angle: 15 degree
Movements: 540 degree PAN and 270 degree
Colours & rainbow eff ect: pre-programmed
Electronic dimmer for light output adjustment: from 0 to 100% (no colour varia-
tion) Flash rate 1-25 fps
Protocol: DMX512 - 10 ch (12 Ch in 16 bit mode)
Fuse: T2A Max.
Power Consumption: 70VA
10 channels DMX PLLEDMLBG
100
75
50
25
0
0° - 540°
Macro
Macro
DMX Pan Tilt
fine
Macro
Value Ch7
0° - 270°
Tilt
Ch8 Ch10
Pan
fine
Ch9
Ch5
Slow
Fast
Strobe
Ch1
Red
Ch2
Green
Ch3
Blue
Ch4
Macro
speed
Ch6
Min
Max
Power: 230V 50Hz - 120V 60Hz
LED: 36: 12R - 12G - 12B
Size: mm. 300L x 290W x 350H
Weight: 9,8 Kgs
PLLEDMLBG

8
Moving Heads
RGB LED Spot Moving Head
Power supply: 230V 50Hz - 120V 60HZ
Rated Power: 50W
LED: 1 x 15W RGB full colour LED
Gobo wheel: 9 fi xed gobos + white
Eff ects: Dimmer, Strobe, Colour Macros.
Control: 13-channel DMX – Stand Alone – Master/Slave – Sound Mode
Movements: 540° Pan – 270° Tilt - adjustable speed
IP rating: IP20
This unit complies with CE directives
13 channels DMX PLLEDMLSUS
100
75
50
25
0
0° - 540°
Macro
Macro
DMX Pan Tilt
fine Macro
Value Ch1
0° - 270°
Tilt
Ch3 Ch4
Pan
fine
Ch2 Ch10
Gobo
Ch13
Red
Ch7
Green
Ch8
Blue
Ch9
Pan / Tilt
speed
Ch5
Min
Max OFF
ON
Lamp
ON/OFF
Ch6
Macro
Macro
Macro
speed
Ch11
Music
mode
Ch12
ON
OFF
Power : 230V 50Hz - 120V 60Hz
LED: 1 RGB full colour - 15W
Size: L177xW177xH250 mm
Weight: 4,5 Kgs
PLLEDMLS

9
Moving Heads
RGB LED Wash Moving Head
Power supply: 230V 50Hz 120V 60Hz
Rated Power: 50W
LED: 1 x 15W RGB full colour LED
Eff ects: Dimmer, Strobe, Colour Macros, Macro Speed.
Control: 13-channel DMX – Stand alone – Master/Slave – Sound Mode
Movements: 540° Pan – 270° Tilt – adjustable speed
IP rating: IP20
This unit complies with CE directives
12 channels DMX PLLEDMLWUS
100
75
50
25
0
0° - 540°
Macro
Macro
DMX Pan Tilt
fine Macro
Value Ch1
0° - 270°
Tilt
Ch3 Ch4
Pan
fine
Ch2 Ch10
Red
Ch7
Green
Ch8
Blue
Ch9
Pan / Tilt
speed
Ch5
Min
Max OFF
ON
Lamp
ON/OFF
Ch6
Macro
Macro
Macro
speed
Ch11
Music
mode
Ch12
ON
OFF
Power : 230V 50Hz - 120V 60Hz
LED: 1 RGB full colour - 15W
Size: L177xW177xH250 mm
Weight: 4,5 Kgs
PLLEDMLW

10
Colour Changers
RGB LED WASHER
LEDs: 54 LEDs 1W (18 Red – 18 Green – 18 Blue)
Power supply: 230V/50HZ
Colours System: RGB (Red, Green, Blue) blending system to obtain an infi nite series
of colour nuances.
Control: 12 DMX control channels, Stand alone and Master/Slave
Housing Protection: IP 65.
This unit complies with CE directives.
RGB MUTIPAR LED
LEDs: 36 LEDs 1W (12 Red – 12 Green – 12 Blue)
Power supply: 230V/50HZ
Colours System: RGB (Red, Green, Blue) blending system to obtain an infi nite series
of colour nuances.
Control: 9 DMX control channels, Stand alone and Master/Slave
Housing Protection: IP 33.
This unit complies with CE directives.
Recommended remote controller (optional)
DMX, auto programs
Recommended remote controller (optional)
DMX, auto programs
2
(0.9x0.5)
4
(1.4x1.0)
6
(2.0x1.6)
8
(2.5x2.1)
10
(3.0x2.6)
307LUX
Distance (m)
Area (sqm)
98 56 27 22
BLUE
15°
2
(0.9x0.5)
4
(1.4x1.0)
6
(2.0x1.6)
8
(2.5x2.1)
10
(3.0x2.6)
1763LUX
Distance (m)
Area (sqm)
570 270 159 128
GREEN
15°
2
(0.9x0.5)
4
(1.4x1.0)
6
(2.0x1.6)
8
(2.5x2.1)
10
(3.0x2.6)
1130LUX
Distance (m)
Area (sqm)
360 167 97 78
RED
15°
2
(0.9x0.5)
4
(1.4x1.0)
6
(2.0x1.6)
8
(2.5x2.1)
10
(3.0x2.6)
2970LUX
Distance (m)
Area (sqm)
950 450 266 218
RGB 100%
15°
2
0.52
4
1.05
6
1.57
8
2.10
10
2.60
300LUX
Distance (m)
Diameter (m)
76 35 20 15
BLUE
15°
2
0.52
4
1.05
6
1.57
8
2.10
10
2.60
1780LUX
Distance (m)
Diameter (m)
460 210 120 90
GREEN
15°
2
0.52
4
1.05
6
1.57
8
2.10
10
2.60
1145LUX
Distance (m)
Diameter (m)
290 130 72 50
RED
15°
2
0.52
4
1.05
6
1.57
8
2.10
10
2.60
2750LUX
Distance (m)
Diameter (m)
700 320 190 145
RGB 100%
15°
12 channels DMX 9 channels DMX
Power: 230V/50Hz
Size: L510xW480Xh210mm
Weight: 8,3 Kg
LED: 54 LEDs W (18 Red – 18 Green – 18 Blue)
Power: 230V/50Hz
Size: L310xW340xH220mm
Weight: 5 Kg
LED: 36 LEDs 1W (12 Red – 12 Green – 12 Blue)
Housing Protection:
IP 65.
This unit complies with CE directives.
Control:
Housing Protection:
This unit complies with CE directives.
9 DMX control channels, Stand alone and Master/Slave
This unit complies with CE directives.
PLHT3LED PLHTLED
PLLEDCKT PLLEDCKT

11
Colour Changers
Outdoor RGB LED Projector
Power supply: 230V – 50Hz
Rated Power: 65W
LED: 36 1W RGB LEDs (12R – 12G – 12B)
Beam opening: 15°
Eff ects: Dimmer, Strobe, Colour Macros, Macro Speed
Control: 6-channel DMX – Stand Alone – Master/Slave
IP rating: IP65
This unit complies with CE directives
12 channels DMX
100
75
50
25
0
Macro
Macro
DMX Macro
Value Ch4
Red
Ch1
Green
Ch2
Blue
Ch3
Slow
Fast
Strobo Dimmer
Ch5 Ch6
Power : 230V 50Hz
LED: 36 RGB - 1W (12R - 12G - 12B)
Size: L200xW290xH230 mm
Weight: 4,5 Kgs
PLLEDCC

12
Colour Changers
Outdoor RGB LED Projector
Power supply: 230V – 50Hz
Rated Power: 80W
LED: 54 x 1W RGB LED (18R – 18G – 18B)
Eff ects: Dimmer, Strobe, Colour Macros, Macro Speed
Control: 6-channel DMX – Stand Alone – Master/Slave
IP rating: IP65
This unit complies with CE directives
12 channels DMX
Power : 220V 50Hz
LED: 54 RGB - 1W (18R - 18G - 18B)
Size: L350xW30xH150 mm
Weight: 7,5 Kgs
100
75
50
25
0
Macro
Macro
DMX Macro
Value Ch4
Red
Ch1
Green
Ch2
Blue
Ch3
Slow
Fast
Strobo Dimmer
Ch5 Ch6
PLLEDHTBG

13
Colour Changers
ARCHITECTURAL STAGE LED
Our SCENO LED follows in the footsteps of our architectural NIGHTWAVE LED, but it is parti-
cularly suited for stage backdrops. Like the NIGHTWAVE LED, it also uses RGB LED technolo-
gy, which allows an unprecedented control of chromatic synthesis and colour temperature.
Its high protection factor suits it to a variety of applications, both indoors and outdoors. Our
SCENO LED uses 36 RGB triads of high power LEDs 1,2W.
ARCHITECTURAL MODULAR LED
Our NIGHTWAVE LED can be considered a major advancement over traditional colour chan-
ging systems. Its modular compact and elegant housing hosts an RGB LED technology
which allows an unprecedented control of chromatic synthesis and colour temperature.
Its’ very high protection factor makes it ideal for many applications, both indoors and ou-
tdoors.
NIGHTWAVE LED features 12 RGB triads of high power LEDs 1,2W.
ARCHITECTURAL MODULAR LED
Power supply: 230V - 50Hz
Power consumption: 50W
LED: 36 led 1,2W RGB (12R - 12G - 12B)
Eff ects: Dimmer, strobe, colour macro
Control: DMX 3 channels
IP rating: IP65
This unit complies with CE directives
ARCHITECTURAL MODULAR LED
Power supply: 230V - 50Hz with PLLEDATPW
Power consumption: 110W
LED: 108 led 1,2W RGB (36R - 36G - 36B)
Eff ects: Dimmer, strobe, colour macro
Control: DMX 3/9 channels
IP rating: IP65
This unit complies with CE directives
DMX channel addresser for
PLLEDAT E PLLEDAT2
Power supply for 3 PLLEDAT2 Extension cable 5m for PLLEDAT2
3 channels DMX
9 channels DMX
Power: 230V 50Hz
LED: 36: 12R - 12G - 12B
Size: mm. 300L x 188W x 200H
Weight: 15 Kgs
Power: 230V 50Hz
LED: 108: 36R - 36G - 36B
Size: mm. 900L x188W x 200H
Weight: 25 Kgs
PLLEDAT
PLLEDAT2
PLLEDATPR PLLEDATPW PLLEDATC5

14
Colour Changers
INDOOR LED PANEL
Input Voltage: AC 110-230V 50/60Hz
648 LEDs: 216 R, 216 G, 216 B - Ø5mm
Protocol: DMX512 - 6 / 12 / 24 / 48 channels
Operation modes: DMX512, built-in programs, Master/slave, music mode It is possi-
ble to divide the projector into 2, 4 or 8 independent zones
LED WALL WASHER
Input Voltage: AC 110-230V 50/60Hz
648 LEDs: 216 R, 216 G, 216 B - Ø5mm
Protocol: DMX512 - 6 / 12 / 24 / 48 channels
Operation modes: DMX512, built-in programs, Master/slave, music mode It is possi-
ble to divide the projector into 2, 4 or 8 independent zones
6/12/24/48 channels DMX PLLEDPN3B
PLLEDPN3W
6/12/24/48 channels DMX PLLEDRBB
PLLEDRBW
Power: 230V 50Hz
LED: 648: 216R - 216G - 216 B
Size: mm. 430L x 78W x 236H
Weight: 5 Kgs
Power: 230V 50Hz - 120V 60Hz
LED: 648: 216R - 216G - 216 B
Size: mm. 430L x 78W x 236H
Weight: 5 Kgs
Power: 230V 50Hz
LED: 648: 216R - 216G - 216 B
Size: mm. 860L x 78W x 117H
Weight: 5,5 Kgs
Power: 230V 50Hz
LED: 648: 216R - 216G - 216 B
Size: mm. 860L x 78W x 117H
Weight: 5,5 Kgs
PLLEDPN3B / PLLEDPN3W
PLLEDRBB / PLLEDRBW

15
Colour Changers
Outdoor RGB LED Projector
Power supply: 230V 50Hz - 120V 60Hz
Rated Power: 150W
LED: 36 1W RGB LEDs (12R – 12G – 12B)
Beam opening: 25°
Eff ects: Dimmer, Strobe, Colour Macros, Macro Speed
Control: 6-channel DMX – Stand Alone – Master/Slave
IP rating: IP65
This unit complies with CE directives
6 channels DMX PLLEDATBKUS
100
75
50
25
0
Macro
Macro
DMX Macro
Value Ch4
Red
Ch1
Green
Ch2
Blue
Ch3
Slow
Fast
Strobo Dimmer
Ch5 Ch6
Power : 230V 50/60Hz
LED: 36 RGB - 3W (12R - 12G - 12B)
Size: L440xW295xH655 mm
Weight: 14,5 Kgs
PLLEDATBK

16
Ambient Eff ects
LED FLASH LIGHT
Input Voltage: AC 230V 50Hz
252 LEDs: 84 R, 84 G, 84 B - Ø10mm
Protocol: DMX512 - 4 channels
Operation modes: built-in programs, Master/slave, music mode
Max. Power Consumption: 34W
RGB LED BAR
Input Voltage: 230V/50Hz
312 LEDs: 104 R, 104 G, 104 B - Ø5mm
Protocol: DMX512
Operation modes: built-in programs, Master/slave, music mode.
Max. Power Consumption: 26W
Not included
4 channels DMX
Power: 230V 50Hz
LED: 312: 104R - 104G - 104B
Size: mm. 380L x 90H x 65W
Weight: 1.6 Kgs
Power: 230V 50Hz
LED: 252: 84R - 84G - 84B
Size: mm. 500L x 200W x 255H
Weight: 5 Kgs
PLLEDST
PLLEDBFDMX
SPSK310BK
PLADT01

17
Ambient Eff ects
DOUB 4 - LED BLINDER
Input Voltage: 230V 50Hz
220 High Power LEDs: 18x4 R, 18x4 G, 19x4 B - Ø10mm
Beam angle: 20 degree
Protocol: DMX512 - selectable 5/8/14 channels for diff erent applications
Programmable speed variation, variable fade time (2s - 2min), fl ashes
Operation modes: 14 built-in programs, Master/slave, music mode
LCD: 2x16 character
Max. Power Consumption: 53W
DOUB 8 - LED BLINDER
Input Voltage: 230V 50Hz
440 High Power LEDs: 18x8 R, 18x8 G, 19x8 B - Ø10mm
Beam angle: 20 degree
Protocol: DMX512 - selectable 5/8/14/26 channels for diff erent applications Program-
mable speed variation, variable fade time (2s - 2min), fl ashes
Operation modes: 14 built-in programs, Master/slave, music mode
LCD: 2x16 character
Max. Power Consumption: 103W
5/8/14 channels DMX
5/8/14/26 channels DMX
Power: 230V 50Hz
LED: 440:18x8R - 18x8G - 19x8B
Size: mm. 440L x 150W x 820H
Weight: 10.1 Kgs
Power: 230V 50Hz
LED: 220:18x4R - 18x4G - 19x4B
Size: mm. 440L x 150W x 530H
Weight: 6.8 Kgs
PLLEDAB4
PLLEDAB8

18
Ambient Eff ects
LIN 8 – LED FOOTLIGHT
Input Voltage: 230V 50Hz
440 High Power LEDs: 18x8 R, 18x8 G, 19x8 B - Ø10mm
Beam angle: 20 degree
Protocol: DMX512 - selectable 5/8/14/26 channels for diff erent applications
Programmable speed variation, variable fade time (2s - 2min), fl ashes
Operation modes: 14 built-in programs, Master/slave, music mode
LCD: 2x16 character
Max. Power Consumption: 103W
LIN 4 – LED FOOTLIGHT
Input Voltage: 230V 50Hz
220 High Power LEDs: 18x4 R, 18x4 G, 19x4 B - Ø10mm
Beam angle: 20 degree
Protocol: DMX512 - selectable 5/8/14 channels for diff erent applications
Programmable speed variation, variable fade time (2s - 2min), fl ashes
Operation modes: 14 built-in programs, Master/slave, music mode
LCD: 2x16 character
Max. Power Consumption: 53W
5/8/14/26 channels DMX
5/8/14 channels DMX
Power: 230V 50Hz
LED: 440:18x8R - 18x8G - 19x8B
Size: mm. 1310L x 145W x 230H
Weight: 7.4 Kgs
Power: 230V 50Hz
LED: 220: 18x4R - 18x4G - 19x4B
Size: mm. 710L x 145W x 230H
Weight: 4.3 Kgs
PLLEDRB8
PLLEDRB4

19
Ambient Eff ects
4 RGB LED Laser
Power supply: 90-230V – 50/60Hz
Rated Power: 10W
LED: 4x64 RGB LEDs (4x16R – 4x16G – 4x16B – 4x8W – 4x8Y)
Eff ects: Strobe
Control: 6-channel DMX – Stand Alone – Sound Mode
IP rating: IP20
This unit complies with CE directives
Moon LED
Power supply: 230V 50Hz – 120V 60Hz
Rated Power: 35W
LED: 392 led RGBW (140R – 105G – 84B – 63W)
Control: DMX 3 channels, Stand alone, sound mode
IP rating: IP20
This unit complies with CE directives
6 channels DMX
6 channels DMX PLLEDMOONUS
PLLEDWD
Power : 90 - 230V - 50/60Hz
LED: 4x64 RGBWY - (4x16R – 4x16G – 4x16B – 4x8W – 4x8Y)
Size: L935xW150xH140 mm
Weight: 5,2 Kgs
Power : 230V 50Hz - 120V 60Hz
LED: 392 RGBW - (140R – 105G – 84B – 63W)
Size: L250xW290xH250 mm
Weight: 5 Kgs
Eff ects:
Strobe
Control:
6-channel DMX – Stand Alone – Sound Mode
IP rating:
IP20
This unit complies with CE directives
PLLEDWD
PLLEDMOON

20
Ambient Eff ects
Double beam RGB LED Projector
Power supply: 230V 50Hz - 120V 60Hz
Rated Power: 15W
LED: 80 RGB LEDs
Eff ects: Strobe
Control: 2-channel DMX – Stand Alone – Master/Slave – Sound Mode
IP rating: IP20
This unit complies with CE directives
Mini RGB LED Scanner
Power supply: 230V – 50Hz
Rated Power: 5W
LED: 18 RGB LEDs (6R – 6G – 6B)
Control: Sound Mode
IP rating: IP20
This unit complies with CE directives
2 channels DMX PLLEDBOOUS
Power : 230V - 50Hz
LED: 18 RGB - (6R - 6G - 6B)
Size: L220xW230xH350 mm
Weight: 1,5 Kgs
Power : 230V 50Hz - 120V 60Hz
LED: 80 RGB
Size: L280xW280xH160 mm
Weight: 2,5 Kgs
PLLEDBOO
PLLEDSC
