Prolux MATRIX BAR 6 IP User manual

http://prolux.net.ua
1
MATRIX BAR 6 IP
USER MANUAL

http://prolux.net.ua
2
1 SUMMARIZE
Thank you for purchasing our Light MATRIX BAR 6. Please read these instructions carefully
before begin and operate the fixtures according to these instructions to avoid any
possible damages and accidents causes by misusage.
Product introduction
This LED wall washer is designed in a fashion of hydrodynamic form. It uses high power
RGBW 5-in-1 25W COB LEDs, means each led is made of R,G,B,A,W five led chips. It
performs long lifetime, low power consumption, high brightness stable capability and
colorful. The built-in program includes dimmer, strobe, water, gradual change, fading and
so on. It has the function of low weight, low power consumption and stable. International
standard DMX 512 signal is requested.
Packing list
Content
Quantity
MATRIX BAR 6
1
Power Cable
1
DMX Signal cable
1
The use manual
1
2 SAFETY INFORMATION
Safety Notes
Enquire the skilled people before any repair;
Always make sure disconnect from the power source before setting up,
serving and moving;
Avoid direct eye exposure to the fixture when it is on;
Safety instruction
Make sure the power supply voltage is consistent with this lights, Ensure the use of
voltage is in the range of the request technical parameter.

http://prolux.net.ua
3
Before the installation, please check the light’s fasteners and mechanical structure have
been received in good condition and appear no damage.
This light is designed for indoor or outdoor, working temperature should be lower than
50 degrees.
The fixtures should be mounted in any position provided there is adequate room for
ventilation. Make sure there are no inflammable and explosive items (ornaments) in 0.5
meters away.
Yellow / green cabling earthling safety; no flicker when the fixture is working on.
3 DIMENSION DIAGRAM
4 MAIN FUNCTION
Input voltage: AC 100V-264V/47-63HZ
Consume: 150W
Lamp Type: 25W LED 5-in-1 R、G、B、A、W (6PCS)
Life span: 50000~100000hours
PWM Dimmer: 1500HZ (16666 grades)
Control Signal: DMX512
Control mode: Standalone / Master slave mode
Channel: 38CH, 30CH, 23CH, 23CH-2, 18CH, 18CH-2, 11CH, 6CH, 5CH
Function Effect: Smooth dimmer, strobes, gradual change, rainbow effect, autoes, auto
programming

http://prolux.net.ua
4
Built-in temperature control measurement function, when LED work overheated,
intelligent reduce LED output power, current power output could be checked
Cooling mode: Fan cooling Convection, Fan speed can be set to reduce noise
Beam Angle: 30° (60° Optional)
Anti-electricity intension: 1.5KV
Insulation Resistance: >2MΩ
Size: 766 x 108 x 213 mm
Net Weight: 5.1 Kg
IP Protection: IP65
5 DMX CONTROL FUNCTION
DMX Channels
38 / 30Ch
23Ch
23-2Ch
18Ch
18-2Ch
11 / 6 / 5Ch
Illustrations: The same numbers represent the same group.

http://prolux.net.ua
5
38 Channel Mode
30 Channel Mode
Channel
Name
Channel
Name
1
Dim all
1
R1
2
R1
2
G1
3
G1
3
B1
4
B1
4
A1
5
A1
5
W1
6
W1
6
R2
7
R2
7
G2
8
G2
8
B2
9
B2
9
A2
10
A2
10
W2
11
W2
11
R3
12
R3
12
G3
13
G3
13
B3
14
B3
14
A3
15
A3
15
W3
16
W3
16
R4
17
R4
17
G4
18
G4
18
B4
19
B4
19
A4
20
A4
20
W4
21
W4
21
R5
22
R5
22
G5
23
G5
23
B5
24
B5
24
A5
25
A5
25
W5
26
W5
26
R6

http://prolux.net.ua
6
27
R6
27
G6
28
G6
28
B6
29
B6
29
A6
30
A6
30
W6
31
W6
32
Strobe
33
Effect
34
Auto speed
35
Virtual color wheel
36
Dimmer mode
37
Id function
38
Id address
23 Channel Mode
18 Channel Mode
Channel
Name
Channel
Name
1
Dim all
1
Dim all
2
R1
2
R1
3
G1
3
G1
4
B1
4
B1
5
A1
5
A1
6
W1
6
W1
7
R2
7
R2
8
G2
8
G2
9
B2
9
B2
10
A2
10
A2
11
W2
11
W2
12
R3
12
Strobe
13
G3
13
Effect
14
B3
14
Auto speed
15
A3
15
Virtual color wheel
16
W3
16
Dimmer mode

http://prolux.net.ua
7
17
Strobe
17
Id function
18
Effect
18
Id address
19
Auto speed
20
Virtual color wheel
21
Dimmer mode
22
Id function
23
Id address
11 Channel Mode
6 Channel Mode
5 Channel Mode
Channel
Name
Channel
Name
Channel
Name
1
Dim all
1
Dim all
1
R
2
R1
2
R1
2
G
3
G1
3
G1
3
B
4
B1
4
B1
4
W
5
A1
5
A1
5
A
6
W1
6
W1
7
Strobe
8
Effect
9
Auto speed
10
Virtual color wheel
11
Dimmer mode
Name
Value
Function
Dim all
0-255
From dark to light
Red
0-255
From dark to light
Green
0-255
From dark to light
Blue
0-255
From dark to light
Amber
0-255
From dark to light
White
0-5
From dark to light
Strobe
0-5
No strobe
6-20
Not synchronous strobe (slow to fast)

http://prolux.net.ua
8
21-60
Synchronous strobe (slow to fast)
61-100
Electronic sine wave (slow to fast)
101-140
Random strobe (slow to fast)
141-180
Opening pulse (slow to fast)
181-220
Closing pulse (slow to fast)
221-255
Electronic square wave (slow to fast)
Effect
0-5
No effect
6-10
Ct01 (call custom color ct01)
11-15
Ct02
16-20
Ct03
21-25
Ct04
26-30
Ct05
31-35
Ct06
36-40
Ct07
41-45
Ct08
46-50
Ct09
51-55
Ct10
56-60
Auto 1 (0-255s)
61-65
Auto 2 (0-255s)
66-70
Auto 3 (0-255s)
71-75
Auto 4 (0-255s)
76-80
Auto 5 (0-255s)
81-85
Auto 6 (0-127.5s)
86-90
Auto 7 (0-25.5s)
91-95
Auto 8 (0-12.25s)
96-100
Auto 9 (0-17s)
101-105
Auto 10 (0-25.5s)
106-110
Auto 11 (0-25.5s)
111-115
Auto 12 (0-25.5s)
116-120
Auto 13 (0-17s)
121-125
Auto 14 (0-17s)

http://prolux.net.ua
9
126-130
Auto 15 (0-12.25s)
131-135
Auto 16 (0-12.25s)
136-140
Auto 17 (0-25s)
141-145
Auto 18 (0-25s)
146-150
Auto 19 (0-25.5s)
151-155
Auto 20 (0-255s)
156-160
Auto 21 (0-25.5s)
161-165
Auto 22 (0-12.25s)
166-170
Auto 23 (0-17s)
171-175
Auto 24 (0-25.5s)
176-180
Auto 25 (0-25.5s)
181-185
Auto 26 (0-25.5s)
186-190
Auto 27 (0-17s)
191-195
Auto 28 (0-17s)
196-200
Auto 29 (0-12.25s)
201-205
Auto 30 (0-12.25s)
206-210
Auto 31 (0-25s)
211-215
Auto 32 (0-25s)
216-220
Auto 33 (0-255s)
221-225
Chase1
226-230
Chase2
231-235
Chase3
236-240
Sound 1: sound change color
241-245
Sound 2: sound strobe (white color only)
246-255
Reserved
Auto speed
0-255
Auto speed, from fast to slow
Virtual color wheel
0-10
No effect
(RGB color mixing
instead of RGB channels
but a w channels not
affected)
11
Blue (blue=full, red+green+white=0) (step)
12-50
Red=0, green->up, blue =full, white=0 (proportional)

http://prolux.net.ua
10
51
Light blue (red=0, green=full, blue =full, white=0)
(step)
52-90
Red=0, green=full, blue->down, white=0
(proportional)
91
Green (red=0, green=full, blue =0, white=0) (step)
92-130
Red->up, green=full, blue=0, white=0 (proportional)
131
Yellow (red=full, green=full, blue=0, white=0) (step)
132-170
Red=full, green->down, blue=0, white=0
(proportional)
171
Red (red=full, green=0, blue=0, white=0) (step)
172-210
Red=full, green=0, blue->up, white=0 (proportional)
211
Magenta (red=full, green=0, blue=full, white=0) (step)
212-250
Red -> down, green=0, blue=full, white=0
(proportional)
251-255
Blue (red=0, green=0, blue=full, white=0) (step)
Dimmer mode
0-10
Use the dimmer mode which menu had set up
11-20
Linear curve and not smooth
21-30
Square law curve and not smooth
31-40
Inverse square law curve and not smooth
41-50
S-curve and not smooth
51-60
Linear curve and smooth
61-70
Square law curve and smooth
71-80
Inverse square law curve and smooth
81-90
S-curve and smooth
91-255
Use the dimmer mode which menu had set up
ID function
0-10
Id disable
10-20
Id enable
21-30
Id address channel divided by 10 and enable
31-255
Reserved
ID address
0-255
Id address
Auto
Effect

http://prolux.net.ua
11
1
R,G,B,A,W,RG,RB,GB,AW,RGBA,RGBW,RGBAW
2
R↑,R↓,G↑,G↓,B↑,B↓,A↑,A↓,W↑,W↓
3
R↑G↑,R↓G↓,R↑B↑,R↓B↓,B↑G↑,B↓G↓
4
R↑G↑B↑W↑,R↓G↓B↓W↓
5
B,BG↑,BG,B↓G,G,GR↑,GR,G↓R,R,RB↑,RB,R↓B(Rainbow effect)
6
One piece running from 1 to 6 then change color continue
7
2 Amber step running
8
3 Orange running with fade
9
3 Pink step running
10
2 Red running on Green
11
2 Green running on Blue
12
2 Yellow running on Pink
13
1 Red step running
14
1 Yellow step running
15
3 Yellow running with fade
16
3 Pink running with fade
17
Yellow open from 1 to 6 then dark
18
Blue open from 1 to 6 then dark
19
Each piece change with RGBYPC
20
Inverse direction AUTO 6
21
Inverse direction AUTO 7
22
3 White running with fade
23
3 Cyan step running
24
Inverse direction AUTO 10
25
Inverse direction AUTO 11
26
Inverse direction AUTO 12
27
Inverse direction AUTO 13
28
Inverse direction AUTO 14
29
Inverse direction AUTO 15
30
Inverse direction AUTO 16

http://prolux.net.ua
12
31
Inverse direction AUTO 17
32
Inverse direction AUTO 18
33
Each piece rainbow effect
6 DISPLAY OPERATION INSTRUCTION
MENU: access the menu or return to a previous menu option
ENTER: select the current menu option
UP: menu selection or parameter increments
DOWN: menu selection or parameters decrease

http://prolux.net.ua
13
Menu Tree:
Tab
Level 1
Level 2
Level 3
Level 4
Addr (address)
001-512
Stat (static control)
R1
0-255 *
G1
0-255 *
B1
0-255 *
A1
0-255 *
W1
0-255 *
R2
0-255 *
G2
0-255 *
B2
0-255 *
A2
0-255 *
W2
0-255 *
R3
0-255 *
G3
0-255 *
B3
0-255 *
A3
0-255 *
W3
0-255 *
Shut
0-255 *
Set (set)
Cal (calibration)
R
0-255
G
0-255
B
0-255
A
0-255
W
0-255
Use
Yes/No
Chmd (channel
mode)
38ch
30ch
23ch
23ch.

http://prolux.net.ua
14
18ch
18ch
11ch
6ch
5ch
Dim (dimming
mode)
Lin/sqr/isqr/scur/
lin.
/sqr./isqr/scur.
Disp (display set)
On (permanent
on)
2min (2 minutes
off)
Fan (fan speed)
High (high)
Mid (middle)
Low(low)
Ctst (custom color
set)
Ct01
R
0-255
.
G
0-255
.
B
0-255
.
A
0-255
.
W
0-255
Ct10
Auto (auto)
At01
Run.. *
. .
Run.. *
. .
Run.. *
. .
Run.. *
At33
Run.. *
Atsp (auto speed)
0-255
Chs1 (chase 1)
Run.. *
Chs2 (chase 2)
Run.. *
Chs3 (chase 3)
Run.. *
Sou1
Run.. *(sound
change color)

http://prolux.net.ua
15
Sou2
Run.. * (sound
strobe, white
color only)
Prog (program)
Chs1 (chase 1)
Sc01 (scene 1)
R1
0-255
.
.
G1
0-255
.
.
B1
0-255
.
.
A1
0-255
.
.
W1
0-255
.
.
R2
0-255
.
.
G2
0-255
.
.
B2
0-255
.
.
A2
0-255
.
.
W2
0-255
.
.
R3
0-255
.
.
G3
0-255
.
.
B3
0-255
.
.
A3
0-255
.
.
W3
0-255
.
.
Shut
0-255
.
.
Auto
None, at01-at33
.
.
Atsp
0-255(s)
.
.
Time
0-255(s)
.
.
Wait
0-25.5(s)
.
.
Use
Yes/No
.
Sc20 (scene 20)
Chs3 (chase 3)
Info (information)
Soft (software
version)
Vx.x
Pow (power
reduction)
100%/80%/50%
Load (load)
St l (setting load)
Yes/No
Pr l (program
load)
Yes/No

http://prolux.net.ua
16
Send (send)
Yes/No
ID
0-255
Illustrations: When enter to the “*” position displayed on the LED, the projector will
automatically set as master and send data to external. Other projectors will
synchronously be running without manually set as slaver. When power cycle it will jump
to the “*” position and running again.
6.1 DMX ADDRESS SETTING
1) Press the 【ENTER】button in 【ADDR】menu, then enter to the DMX address
setting.
2) Press the【UP/DOWN】button to select【1-512】numerical value.
3) Press the【ENTER】button to escape and save.
6.2 STATIC SETTING
1) Press the【ENTER】button in 【STAT】menu, then enter to the static setting.
2) Press the【UP/DOWN】button to select 【RED1】，【GREEN1】，【BLUE1】，
【AMBER1】, 【WHITE1】…【SHUT】.
3) Press the【UP/DOWN】button to set up the【0-255】numerical value.
4) Press the【ENTER】button to escape and save.
6.3 COLOR CAST CALIBRATION SETTING
1) Press the【ENTER】button in 【CAL】menu, then enter to the color cast calibration
setting.
2) Press the【UP/DOWN】button to select 【RED】，【GREEN】，【BLUE】，【
AMBER】, 【WHITE】
3) Press the【UP/DOWN】button to set up the【0-255】numerical value.
4) On the【USE】interface, pressing【YES】button means valid, 【NO】means invalid.
5) Press the【ENTER】button to escape and save.

http://prolux.net.ua
17
Illustrations: When pressing the【YES】button which means valid on the【USE】
interface, the actual output value of RED，GREEN，BLUE，AMBER, WHITE, UV is output
in accordance with the percentage which the color cast calibration value divides 255.
6.4 CHANNEL MODE SETTING
1) Press the【ENTER】button in 【CHMD】menu, then enter to the channel mode
setting.
2) Press the【UP/DOWN】button to select【68CH】，【60CH】，【28CH】，【
28CH.】，【23CH】，【23CH.】，【18CH】，【11CH】，【6CH】，【5CH.】
3) Press the【ENTER】button to escape and save.
6.5 DIMMING MODE SETTING
1) Press the【ENTER】button in【DIM】menu, then enter to the dimming mode setting.
2) Press the【UP/DOWN】button to select【LIN】，【SQR】，【ISQR】，【SCUR】
，【LIN.】，【SQR.】，【ISQR】and【SCUR.】.
3) Press the【ENTER】button to escape and save.
Illustrations：When setting【LIN.】，【SQR.】，【ISQR.】and 【SCUR.】in 【DIM】
menu, there will be added a little delay dimming effect for smooth.
Dimming curve:
Linear curve: Square law curve: Inverse Square law curve: S-curve:
6.6 DISPLAY SETTING
1) Press the【ENTER】button in【DISY】menu, then enter to the display setting.
2) Press the【UP/DOWN】button to select【ON】，【2 MINITES OFF】
3) Press the【ENTER】button to escape and save.

http://prolux.net.ua
18
6.7 SET MAXMUN FAN SPEED
1) Press the【ENTER】button in【FAN】menu, then enter to the maximum fan speed
setting.
2) Press the【UP/DOWN】button to select【HIGH】，【MIDDLE】, 【LOW】
3) Press the【ENTER】button to escape and save.
6.8 CUSTOM COLOR SETTING
1) Press the 【ENTER】button in 【CTST】menu, then enter to the custom color setting.
2) Press the 【UP/DOWN】select 【CT01】…【CT10】
2) Press the【UP/DOWN】button to select【1-512】numerical value.
3) Press the【ENTER】button to escape and save.
6.9 AUTO RUN, SELF-PROGRAM RUN
1)Press the【ENTER】button in【AUTO】menu, then enter to the auto run, self-
program run.
2)Press the【UP/DOWN】button to select【AT01】…【AT33】，【SPEED】，【
CHASE01】…【SOUND2】
3)Press the【ENTER】button to start running.
6.10 EDIT SELF-PROGRAM
1) Press the【ENTER】button in【PROG】menu, then enter to the edit self-program.
2) Press the【UP/DOWN】button to select【CHASE01】…【CHASE03】
3) Press the【ENTER】button for confirmation and enter to the next menu.
4) Press the【UP/DOWN】button to select【SCENE01】…【SCENE20】
5) Press the【ENTER】button for confirmation and enter to the next menu.
6) Then press the【UP/DOWN】button to select【RED1】…【SHUT】，【TIME】，【
WAIT】，【USE】
7) Press the【UP/DOWN】button to set up the parameter which are needed.

http://prolux.net.ua
19
8) Press the【ENTER】button to escape and save.
Illustrations：When【USE】is set to be【NO】，or the parameter of【TIME】is 0, it
will not run this scene. When 【WAIT】is set to be FADE time, the running process is as
the following chart showing.
6.11 CHECK THE LIGHTING INFORMATION
1) Press the【ENTER】button in【INFO】menu, then enter to the checking the lighting
information.
2) 【SOFT】button is for software version information.
3) 【POW】button is for the current information of power reduction. It is 100% output
in normal conditions, but 80% or 50% output in over temperature protection situation.
6.12 LIGHTING SETTING PARAMETER RESET
1) Press the【ENTER】button in【ST L】menu, then enter to the lighting setting
parameter reset.
2) Press the【UP/DOWN】button to select【YES】.
3) Press the【ENTER】button to escape and save.
Illustrations：“ADDR” “CTST” and “PROG” are not reset, the others reset to the
underlined value of the word.
6.13 【PROG】SELF-PROGRAMMING PARAMETER RESET
1) Press the【ENTER】button in【PR L】menu, then enter to the【PROG】self-
programming parameter reset.
2) Press the【UP/DOWN】button to select【YES】.
3) Press the【ENTER】button to escape and save.

http://prolux.net.ua
20
6.14 LIGHTING PARAMETER DOWNLOADING EACH OTHER VIA DMX CABLE
1) Press the【ENTER】button in【SEND】menu, then enter to sending parameter to
other lightings.
2) Press the【UP/DOWN】button to select【YES】.
3) Press the【ENTER】button to confirm sending.
Illustrations：
1)Please disconnect the connection of projector and DMX console before sending the
parameter.
2)The information of【ADDR】、【CAL】、【ID】can’t be sent, can’t be downloaded
each other.
3)There will be an automatic reset of the other projectors after receiving parameter
correctly.
6.15 ID ADDRESS SETTING
1) Press the 【ENTER】button in 【ID】menu, then enter to the ID address setting.
2) Press the【UP/DOWN】button to select【0-255】numerical value.
3) Press the【ENTER】button to escape and save.
Illustrations：
1)When ID FUNCTION in channel profile is 10-20, the ID ADDRESS in fixture setting must
equal to the ID ADDRESS in channel profile setting then the fixture will be active.
2)When ID FUNCTION in channel profile is 21-30, the ID ADDRESS in channel profile
setting will be divided by 10 then ignore the fractional part, if the result is equal to the ID
ADDRESS which set in 【ID】menu, the fixture will be active. For example, if the fixture
ID ADDRESS is 3 now, the valid value in the channel profile setting is 30-39. Similarly,
when 15 the valid value is 150-159.
7 TROUBLESHOOTING
Problem
Reason and action
The lighting can’t be
started normally
Check the power connection is correct or not.
Please detect the voltage.
Power supply is damaged or incorrect connected. Call a qualified
personnel to fix it.
