SAFETY NOTES
Read the user’s manual before using the equipment, mainly " SAFETY RULES "
paragraph.
The symbol on the equipment means "SEE USER’S MANUAL". In this manual
may also appear as a Caution or Warning symbol.
WARNING AND CAUTION statements may appear in this manual to avoid injury
hazard or damage to this product or other property.
INFORMATION NOTE
This is a preliminary version of the RANGER/+ user manual. This version may
change according to new equipment updates or by corrections or suggestions for
improvement.

SAFETY RULES
* The safety could not be assured if the instructions for use are not closely
followed.
* Use this equipment connected only to systems with their negative of
measurement connected to ground potential.
* The AL-103 external DC charger is a Class I equipment, for safety reasons plug it
to a supply line with the corresponding ground terminal.
* This equipment can be used in Overvoltage Category I installations and
Pollution Degree 2 environments.
External DC charger can be used in Overvoltage Category II, installation and
Pollution Degree 1 environments.
* When using some of the following accessories use only the specified ones to ensure
safety.:
Rechargeable battery
External DC charger
Car lighter charger cable
Power cord
* Observe all specified ratings both of supply and measurement.
* Remember that voltages higher than 70 V DC or 33 V AC rms are dangerous.
* Use this instrument under the specified environmental conditions.
* When using the power adaptor, the negative of measurement is at ground
potential.
* Do not obstruct the ventilation system of the instrument.
* Use for the signal inputs/outputs, specially when working with high levels,
appropriate low radiation cables.
* Follow the cleaning instructions described in the Maintenance paragraph.

* Symbols related with safety:
Descriptive Examples of Over-Voltage Categories
Cat I Low voltage installations isolated from the mains.
Cat II Portable domestic installations.
Cat IIIFixed domestic installations.
Cat IV Industrial installations.

TABLE OF CONTENTS
SAFETY RULES................................................................................................. 1
Descriptive Examples of Over-Voltage Categories........................................... 2
1INTRODUCTION......................................................................................... 1-1
1.1 Description....................................................................................... 1-1
2SETTING UP.............................................................................................. 2-3
2.1 Package Content ............................................................................. 2-3
2.2 Power ............................................................................................ 2-4
2.2.1 First charge................................................................................. 2-4
2.2.2 Charging the battery .................................................................... 2-4
2.2.3 Charge / discharge times .............................................................. 2-5
2.2.4 Smart control battery................................................................... 2-5
2.2.5 Usage Tips.................................................................................. 2-6
2.3 Equipment Details ........................................................................... 2-7
2.4 Switching On / Off the equipment ...................................................... 2-9
2.5 Screen Icons and Dialog boxes ........................................................ 2-10
2.6 Menu Tree.................................................................................... 2-11
2.7 Controls ....................................................................................... 2-14
2.7.1 Joystick.................................................................................... 2-14
2.7.2 Keyboard shortcuts.................................................................... 2-15
2.7.3 Softkeys................................................................................... 2-19
3MEASUREMENT MODE .............................................................................. 3-20
3.1 Introduction ................................................................................... 3-20
3.2 Operation ...................................................................................... 3-21
4SPECTRUM ANALYSER MODE ..................................................................... 4-24
4.1 Introduction.................................................................................. 4-24
4.2 Mode of operation.......................................................................... 4-24
4.3 Description of the FULL SPECTRUM screen......................................... 4-28
4.4 JOYSTICK Operation in SPECTRUM ANALYSER mode........................... 4-29
4.5 Options Menu................................................................................ 4-30
4.5.1 F1: Tuning................................................................................ 4-31
4.5.2 F2: Signal Parameters ................................................................ 4-33
4.5.3 F3: Tools.................................................................................. 4-33
4.5.4 F4: Advanced............................................................................ 4-34
4.6 Location of a signal with the SPECTRUM ANALYZER ............................ 4-35
5TV MODE................................................................................................ 5-36
5.1 Introduction.................................................................................. 5-36
5.2 Operation..................................................................................... 5-36
5.3 Menu Options................................................................................ 5-40
5.3.1 ANALOGUE signal ...................................................................... 5-40
5.3.2 Terrestrial / Satellite Digital Signal ............................................... 5-40
5.3.2.1 F1: Number of Channel / Frequency tuned. ................................ 5-40
5.3.2.2 F2: Standard of the tuned signal............................................... 5-40
5.3.2.3 F3: Selected service name. ...................................................... 5-41
5.3.2.4 F4: Language of the selected service......................................... 5-41
August 2012

6TOOLS ................................................................................................... 6-42
6.1 Constellation .................................................................................. 6-42
6.1.1 Description.................................................................................. 6-42
6.1.2 Operation.................................................................................... 6-42
6.1.3 Menu Options .............................................................................. 6-44
6.2 LTE Ingress test.............................................................................. 6-44
6.2.1 Description.................................................................................. 6-44
6.2.2 Operation.................................................................................... 6-45
6.2.3 Options Menu .............................................................................. 6-46
6.3 Echoes .......................................................................................... 6-47
6.3.1 Description.................................................................................. 6-47
6.3.2 Operation.................................................................................... 6-47
6.3.3 Menu Options .............................................................................. 6-49
6.4 Installations Management ................................................................ 6-49
6.5 Installation Manager........................................................................ 6-50
7SPECIFICATIONS ..................................................................................... 7-53
7.1 Specifications HD RANGER+............................................................ 7-53
7.2 Specifications HD RANGER.............................................................. 7-61
8MAINTENANCE ........................................................................................ 8-67
8.1 Considerations about the Screen ....................................................... 8-67
8.2 Cleaning Recommendations.............................................................. 8-67
ANNEX 1 SIGNALS DESCRIPTION ....................................................................... 1
August 2012

TV & SATELLITE ANALYSER
HD RANGER/ +
1
1 INTRODUCTION
1.1
Description
The new
HD RANGER/ + is the fifth generation of field meters that PROMAX
launches. As each new generation, it represents an evolution from the previous,
since it integrates the latest technological innovations and develops applications
for the new demands and needs that have emerged in recent years.
The new
HD RANGER/ + has been created with the aim to make easy the user
experience. From its ergonomic design and stylized lines to the reduction of keys
and the easy use of its interface, everything has been designed so the user has a
simple tool to use but powerful and useful.
Figure 1.
The
HD RANGER/ + is a universal field meter that covers TV standards of the
DVB family, as well as formats such as MPEG-2 or MPEG-4 and Dolby audio.
There is also the possibility of an extension to work in fibre optics installations.
1Trademark of the DVB - Digital Video Broadcasting Project.
August 2012 1-1

Besides the basic functions of TV meter and spectrum analyser for terrestrial and
satellite band, it provides additional tools, such as the detection of 4G signal
interferences (some of its working frequencies are close to the TV bands), the
diagrams constellations or the echoes detection..
The
HD RANGER/ + has an application to manage data generated at each
installation.This feature helps the user to manage information generated so he
can access it at any time or download it to a PC for further analysis.
The
HD RANGER/ + has been designed and developed entirely in the European
Union. A multidisciplinary team of highly qualified professionals has dedicated
effort and commitment to the development of a powerful, efficient and reliable
tool. During the manufacturing process, all used materials have been subjected
to a strict quality control.
In an effort to facilitate its work to professionals, our long experience ensures an
after sales quality service, which includes updates and upgrades for free.
Figure 2.
1-2 August 2012

2 SETTING UP
2.1
Package Content
Check that your package contains the following elements:
HD RANGER/ + Field Meter.
External DC charger.
Mains cord for external DC charger.
Car lighter charger.
"F" Adapters (3 units).
• "F" / H - BNC / H Adapter.
• "F" / H - DIN / H Adapter.
• "F" / H - "F" / H Adapter.
Support belt and carrying bag.
USB On-the-go (A) Male - Mini USB (B) Male.
USB cable (A) Male - Mini USB (B) Male.
4V / RCA Jack Cable.
Transport suitcase *.
Quick Start Guide.
NOTE:Keep the original packaging, since it is specially designed to protect the
equipment. You may need it in the future to send the meter to be
calibrated.
*Supplied only with the
HD RANGER + model. Optional Accessory on request for
HD RANGER.
August 2012 2-3

2.2
Power
The
HD RANGER/ + is powered by a 7.2 V built-in rechargeable Li-Ion battery
of high quality and long duration.
The equipment can operate on battery or connected to the network using a DC
adapter. An adapter is also supplied to use with the power connector car
(cigarette lighter).
2.2.1 First charge
The equipment comes with the battery fully charged. Depending on the time
elapsed from first charge and environmental conditions may have lost some of
the charge. Check the battery level.
2.2.2 Charging the battery
Connect the DC power adapter (2) to the equipment through the power
connector on the left side panel (see figure 3).
Figure 3.
Then connect the DC power adapter to the mains via the mains cord (3).Ensure
that your mains voltage is compatible with the adapter voltage.
For a fast charging of the battery is necessary to switch off the equipment.
If the equipment is ON, the battery charging will be slower, depending on the
type of work you are doing. When connecting the equipment to the mains the
mains connected symbol ( ) appears inside the battery icon.
2-4 August 2012

When the computer is connected to the mains, the CHARGER indicator remains
on. This indicator changes its colour according to the percentage of battery
charge:
RED Less than 80% of charge.
ORANGE Between 80% and 90% of charge.
GREEN 100% full charge.
If the battery is weak, the battery disconnection circuit will prevent the
equipment starting up. In this case, please charge the battery immediately.
2.2.3 Charge / discharge times
Average charging time with the equipment off (fast charge):
3 hours to achieve an 80% charge.
5 hours to achieve a 100% charge.
With the equipment on (slow charge):
5 hours to achieve an 80% charge.
8 hours to achieve a 100% charge.
Average discharge time (with external supply disabled):
With the equipment full charge the average battery time is 5:30 hours.
With the equipment at 80% charge the average battery time is 4 h.
2.2.4 Smart control battery
The built-in battery of the equipment is of the "smart" type, which means that
reports its state of charge. This information is displayed inside the battery icon in
the form of the average time available. In this way the user can know at any
time the remaining battery level.
The remaining time charge that appears is calculated according to the work that
has been doing. If you activate the external supply of the equipment, the
average time would be reduced according to the increase in consumption that
occurs.
August 2012 2-5

2.2.5 Usage Tips
The battery is losing storage capacity as you go through its life. Contact your
PROMAX distributor when necessary to replace the battery.
To prolong battery life the user should follow these tips:
Proceed to charge the battery preferentially when fully discharged.
In case of providing a long inactivity period of the equipment is advisable
to store it fully charged at temperatures below 25 ° C.
It is advisable in these cases to make every 3 months a charge / discharge
cycle and a subsequent partial charge (50%).
2-6 August 2012

2.3
Equipment Details
Front View
Figure 4.
August 2012 2-7

Lateral view
Figure 5.
Top view
Figure 6.
* Optical Option.
2-8 August 2012

2.4
Switching On / Off the equipment
This field meter is designed for use as a portable equipment and it does not
require any previous installation.
►Switching On:
Slide up for a while the power slide switch located on the left side of the
equipment (approximately one second).
When all indicators light up at once release the switch, which returns to
its rest position.
The starting display picture appears and a progress bar that indicates the
system load.
After the system load the last screen before shutdown appears.
►Switching Off:
Slide up for a while the power slide switch located on the left side of the
equipment (approximately one second).
When the screen goes off release the switch, which returns to its rest
position.
The starting display picture appears and the progress bar showing the
system shutdown progress.
►Reset:
Press the F4 key for 5 seconds. The equipment automatically turns off.
Use only in case of system crash.
In the PREFERENCES menu (press 1s), APPEARANCE tab, option "Off" you
can activate the automatic shutdown option, selecting a waiting time (time
without pressing any key) after which the meter turns off automatically.
August 2012 2-9

2.5
Screen Icons and Dialog boxes
At the top of the screen there is the status bar. On the right are icons that
provide useful information to the user about the current status of the instrument.
Battery charging. USB flash drive inserted
Battery not charging.
Yellow level indicates
percent charge left LTE filter enabled.
Battery not charging,
time left indicator Current installation.
USB in serial port
mode Joystick multi-function
Enabled Two-letter code
indicates the exact function:
Satellite band.
Terrestrial band.
FR Frequency tuning
CH Channel tuning
SP SPAN change
MK Marker moving
2-10 August 2012

2.6
Menu Tree
SPECTRUM ANALYSER MENU
TV MENU
August 2012 2-11

MEASUREMENT MENU
SETTINGS MENU
2-12 August 2012
