Promax TM-20 User manual

TM-20/40
Table Top Vacuum Tumbling Machine
Operation Manual
Version 6.9.1
1915 E. Acacia Street, Ontario, CA91761, U.S.A
TEL : [phone]
FAX : [phone]
http://www.promarksvac.com
S/N: QCSIGNATURE:

INDEX
1.Installation ............................................................................................................ 2
2.Maintenance .......................................................................................................... 2
3.Functions and operations ...................................................................................…2
4.Machine diagram .................................................................................................. 3
5.Electrical diagram ................................................................................................ 4
6.Explosive diagram & parts list .........................................................................5-8

2
1. INSTALLATION.
Please check the electric power listed on the vacuum pump and install the vacuum pump
correctly, ground line must on the floor.
2. MAINTENANCE.
A. To ensure vacuum pump works smoothly suggest change the vacuum oil every
500 working hours or every a half year.
B. Check water filter bottle everyday, as soon as the water over a half of the bottle
please cleans it.
3. FUNCTIONS AND OPERATIONS.
Vacuum pump – turn the selection switch to vacuum pump position to start vacuum
function.
Mixing motor – turn the selection switch to mixing motor to start tumbling the drum.
Total time – total time should be adjusted according to different products..
Inverter – adjust tumbling speed.
First, please turn the speed button to “0” , then adjust the speed gradually to avoid
bringing large instant current to make the controler damaged.
First, stand up the drum body and feeding material then cover outer lid and pull out
the vacuum, finally install the drum body on the machine.
※ During operation, when the vacuum inside the drum is under the vacuum condition,
and you turn the vacuum pump off to keep tumbling. Afterwards, you may find the
vacuum pump is not vacuuming when you turn it on.
If this situation happens, please turn the vacuum pump off, close the valve on the lid,
and remove the air tube which is connected to the drum.
Then re-connect the air tube to the drum, open the valve on the lid, and turn the
vacuum pump on then the machine can keep vacuuming again.

3
4.Machine Diagram
A
B
C

4
5. ELECTRICAL DIAGRAM

5



TM04100P00
NO. PART NO. DESCRIPTION QTY NOTES
TM02101001 FRAME,F/TM-20 1
TM04101001 FRAME,F/TM-40 1
TM02102001 PLATE, SUPPORT, RIGHT, ROLLER, F/TM-20 1
TM04102001 PLATE, SUPPORT, RIGHT, ROLLER, F/TM-40 1
TM02103001 PLATE, SUPPORT, LEFT, ROLLER, F/TM-20 1
TM04103001 PLATE, SUPPORT, LEFT, ROLLER, F/TM-40 1
4 TM04104000 HOLDER,FILTER 1
5 TM04106001 SHAFT,TRANSMISSION,REDUCER 1
6 TM04114000 PLATE,HOLDING,REDUCER 1
7 TM04116000 ROLLER 2
8 TM04117000 SHAFT,HOLDING ,TUBE 1
9 TM04119001 COVER,REAR 1
10 VA04120001 FOOT, RUBBER 4
11 TM04118000 WASHER,TRANSMISSION SHAFT 1
12 27280191 BEARING, BALL 608ZZ 4
13 27401644 O RING P35 (NBR) 2
14 29135564 PRESSURE GAUGE 2"x760mmHg 1
2961081 VACUUM PUMP UC-UN-40V-110V 1
2961082 VACUUM PUMP UC-UN-40V-220V 1
16 2883134 LATCH, DOOR 1
2814822 Motor MV-40090A 110V 1
2814821 Motor MV-40090A 220V 1
2814820 REDUCER, GEAR, WS-040-080-F 1
18 2940011 SEPARATOR, WATER 1
2801680 SPEED GOVERNOR W/GENERATOR 220V 1
2801681 SPEED GOVERNOR W/GENERATOR 110V 1
20 2832020 TIMER RELAY,IDEC,GE1A-B30HA220 1
21 2871220 SWITCH, SELECTOR, YW1S-2E10P 2
22 2700420 SCREW, HEX HD M8x40 (S) 6
23 2707203 NUT,ST. M8 4
24 2700462 SCREW, HEX HD M6x30 (S) 5
25 2705151 WASHER, FLAT M6 SUS 4
26 2705152 WASHER, FLAT, M8 ST 4
27 29091754 FITTING, COPPER, 90°, 1/4PTx1/4H 2
28 27121921 HINGE, CL-226-3 2
Option1
Option2
3 Option
15 Option
19 Option
17 Option
6

7
2
3
4

TM04200000
NO. PART NO. DESCRIPTION QTY NOTES
TM02201000 DRUM,F/TM-20 1
TM04201000 DRUM,F/TM-40 1
TM02202000 BLADE, MIXING, FRUM, F/TM-20
TM04202001 BLADE MIXING, FRUM, F/TM-40
TM02203000 SILICONE CIRCLE, F/TM-20 1
TM04203000 SILICONE CIRCLE, F/TM-40 1
TM02204002 LID,DRUM , F/TM-20 1
TM04204002 LID,DRUM, F/TM40 1
5 2921180 FITTING, ROTARY KSL08-02S 1
6 2921178 VALVE, PISCO BVU 20-0808 1
Option1
3
4
Option
Option
2 2 Option
8
