Promax OD-603 User manual

OD-603
OD-606
DIGITAL OSCILLOSCOPE
Version Date Software Version
1.3 June 2016 2.1.0.3
- 0 MI2009 -
Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176 - TestEquipmentDepot.com

June 2016
SAFETY RULES
* The safety can turn compromised if there are not applied the instructions
given in this Manual.
* Use the equipment only on systems or devices to measure the negative connected
to ground potential or off-grid.
* This is a class I equipment, for safety reasons plug it to a supply line with the
corresponding ground terminal.
* This equipment can be used in Over-Voltage Category II installations and
Pollution Degree 1 environments (see 2.3.-).
* When using some of the following accessories use only the specified ones to
ensure safety:
Power cord
Probes
* Observe all specified ratings both of supply and measurement.
* Remember that voltages higher than 70V DC or 33V AC rms are dangerous.
* Use this instrument under the specified environmental conditions.
* The user is only authorized to carry out the following maintenance operations:
Replace the mains fuse of the specified type and value.
On the Maintenance paragraph the proper instructions are given.
Any other change on the equipment should be carried out by qualified
personnel.
* The negative of measure is at ground potential.
* Do not obstruct the ventilation system.
* Follow the cleaning instructions described in the Maintenance paragraph.

June 2016
* Symbols related with safety:
Specific Precautions
Radio interference
ATTENTION
This is a product of class A. In a domestic environment can
produce radio interference, in which case the user should take
appropriate measures.
Descriptive Examples of Over-Voltage Categories
Cat I Low voltage installations isolated from the mains.
Cat II Portable domestic installations.
Cat III Fixed domestic installations.
Cat IV Industrial installations.

June 2016
TABLE OF CONTENTS
1 INTRODUCTION ..........................................................................................1
1.1 General Characteristics...................................................................... 1
2 JUNIOR USER GUIDEBOOK...........................................................................2
2.1 Introduction to the Structure of the Oscilloscope ................................... 2
2.1.1 Front Panel ..................................................................................2
2.1.1 Right Side Panel ...........................................................................4
2.1.3 Rear Panel ...................................................................................5
2.1.4 Control (key and knob) Area .......................................................... 6
2.2 User Interface Introduction ................................................................ 7
2.3 How to Implement the General Inspection............................................ 9
2.4 How to Implement the Function Inspection......................................... 10
2.5 How to Implement the Probe Compensation ....................................... 11
2.6 How to Set the Probe Attenuation Coefficient...................................... 12
2.7 How to Use the Probe Safely ............................................................ 13
2.8 How to Implement Self-calibration .................................................... 13
2.9 Introduction to the Vertical System ................................................... 14
2.10 Introduction to the Horizontal System ............................................... 15
2.11 Introduction to the Trigger System.................................................... 16
3 ADVANCED USER GUIDEBOOK.................................................................... 17
3.1 How to Set the Vertical System ........................................................ 17
3.1.1 Use Mathematical Manipulation Function ........................................ 22
3.1.2 Using FFT function ...................................................................... 24
3.2 Use VERTICAL POSITION and VOLTS/DIV Knobs ................................. 28
3.3 How to Set the Horizontal System..................................................... 29
3.3.1 Main Time Base .......................................................................... 30
3.3.2 Set Window ............................................................................... 31
3.3.3 Window Expansion ...................................................................... 31
3.4 How to Set the Trigger System ......................................................... 32
3.4.1 Single Trigger............................................................................. 34
3.4.2 Alternate Trigger (OD-603 does not support alternate trigger)........... 38
3.5 How to Operate the Function Menu ................................................... 43
3.5.1 How to Implement Sampling Setup ............................................... 43
3.5.2 How to Set the Display System ..................................................... 45
3.5.3 How to Save and Recall a Waveform.............................................. 49
3.5.3.1 Save and Recall the Waveform .................................................. 51
3.5.4 How to Record/Playback Waveforms .............................................. 53
3.5.5 How to Implement the Auxiliary System Function Setting ................. 56
3.5.6 How to Measure Automatically ...................................................... 62
3.5.6.1 The automatic measurement of voltage parameters...................... 64
3.5.6.2 The automatic measurement of time parameters.......................... 65
3.5.7 How to Measure with Cursors ....................................................... 66
3.5.7.1 The Cursor Measurement for normal mode .................................. 66
3.5.7.2 The Cursor Measurement for FFT mode....................................... 68
3.5.8 How to Use Autoscale .................................................................. 70

June 2016
3.5.9 How to Use Built-in Help .............................................................. 73
3.5.10 How to Use Executive Buttons ...................................................... 73
4 COMMUNICATION WITH PC ........................................................................ 75
4.1 Using USB Port............................................................................... 75
4.2 Using LAN Port ............................................................................... 76
4.2.1 Connect directly.......................................................................... 76
4.2.2 Connect through a router............................................................. 78
4.3 Using COM Port .............................................................................. 80
5 DEMONSTRATION ..................................................................................... 81
5.1 Example 1: Measurement a Simple Signal .......................................... 81
5.2 Example 2: Gain of a Amplifier in a Metering Circuit ............................ 82
5.3 Example 3: Capturing a Single Signal ................................................ 84
5.4 Example 4: Analyze the Details of a Signal......................................... 86
5.5 Example 5: Application of X-Y Function.............................................. 87
5.6 Example 6: Video Signal Trigger ....................................................... 89
6 TROUBLESHOOTING.................................................................................. 91
7 SPECIFICATIONS ................................................................................. 93
8 MAINTENANCE .................................................................................... 97
8.1 General Care.................................................................................. 97
8.2 Cleaning........................................................................................ 97

June 2016 Page 1
DIGITAL OSCILLOSCOPES
OD-603 / OD-606
1 INTRODUCTION
1.1 General Characteristics
Bandwidth: OD-603 30 MHz, 2 CH.
OD-606 60 MHz, 2 CH.
Sample rate: OD-603 Dual CH 250 MS/s.
Single CH 500 MS/s.
OD-606 Dual CH 250 MS/s.
Single CH 500 MS/s.
1M record length (10M optional); (10K for OD-603)
8 inch high def TFT display;
Ultra-thin body;
Pass / Fail function;
Waveform record and replay function;
Add / Remove measure function and user-defined measurement menu;
VGA (optional), USB, LAN interface.

Page 2 June 2016
2 JUNIOR USER GUIDEBOOK
This chapter deals with the following topics mainly:
► Introduction to the structure of the oscilloscope.
► Introduction to the user interface.
► How to implement the general inspection.
► How to implement the function inspection.
► How to make a probe compensation.
► How to set the probe attenuation coefficient.
► How to use the probe safely.
► How to implement an auto-calibration.
► Introduction to the vertical system.
► Introduction to the horizontal system.
► Introduction to the trigger system.
2.1 Introduction to the Structure of the Oscilloscope
When you get a new-type oscilloscope, you should get acquainted with its front
panel at first and the digital storage oscilloscope is no exception. This chapter
makes a simple description of the operation and function of the front panel of the
oscilloscope, enabling you to be familiar with the use of the oscilloscope in the
shortest time.
2.1.1 Front Panel
The oscilloscope offers a simple front panel with distinct functions to users for
their completing some basic operations, in which the knobs and function
pushbuttons are included. The knobs have the functions similar to other
oscilloscopes. The 5 buttons (F1 ~ F5) in the column on the right side of the
display screen or in the row under the display screen (H1 ~ H5) are menu
selection buttons, through which, you can set the different options for the current
menu. The other pushbuttons are function buttons, through which, you can enter
different function menus or obtain a specific function application directly.

June 2016 Page 3
Figure 1. Front Panel
Power on/off.
Display area.
Control (key and knob) area.
Probe Compensation: Measurement signal(5V/1KHz) output.
EXT Trigger Input.
Signal Input Channel.
Menu off.

Page 4 June 2016
2.1.2 Right Side Panel
Figure 2. Right Side Panel
USB Host port: It is used to transfer data when external USB equipment
connects to the oscilloscope regarded as "host device". For example: use
this port to save waveform file into USB flash disk.
USB Device port: It is used to transfer data when external USB
equipment connects to the oscilloscope regarded as "slave device". For
example: to use this port when connect PC to the oscilloscope by USB.
COM / VGA port (Optional): To connect the oscilloscope with external
equipment as serial port, or to connect the oscilloscope with a monitor or a
projector as VGA output.
The port of trigger signal output & Pass/Fail output.
LAN port: the network port which can be used to connect with PC.

June 2016 Page 5
2.1.3 Rear Panel
Figure 3. Rear Panel
Handle
Air vents
AC power input jack
Fuse
Foot stool (which can adjust the tilt angle of the oscilloscope)

Page 6 June 2016
2.1.4 Control (key and knob) Area
Figure 4. Keys Overview
Menu option setting: H1~H5.
Menu option setting: F1~F5.
Menu off: turn off the menu.
M knob (Multipurpose knob): when a symbol appears in the menu, it
indicates you can turn the M knob to select the menu or set the value. You
can press it to close the menu on the left.
Function key area: Total 12 keys.
Vertical control area with 3 keys and 4 knobs.
"CH1 MENU" and "CH2 MENU" correspond to setting menu in CH1 and CH2,
"Math" key refer to math menu, the math menu consists of six kinds of
operations, including CH1-CH2, CH2-CH1, CH1+CH2, CH1*CH2, CH1/CH2
and FFT. Two "VERTICAL POSITION" knob control the vertical position of
CH1/CH2, and two "VOLTS/DIV" knob control voltage scale of CH1, CH2.

June 2016 Page 7
Horizontal control area with 1 key and 2 knobs.
"HORIZONTAL POSITION" knob control trigger position, "SEC/DIV" control
time base, "HORIZ MENU" key refer to horizontal system setting menu.
Trigger control area with 3 keys and 1 knob.
"TRIG LEVEL" knob is to adjust trigger voltage. Other 3 keys refer to
trigger system.
2.2 User Interface Introduction
Figure 5. Illustrative Drawing of Display Interfaces (take OD-603) for instance)
Waveform Display Area.
The state of trigger, including:
Auto: Automatic mode and acquire waveform without triggering.
Trig: Trigger detected and acquire waveform.
Ready: Pre-triggered data captured and ready for a trigger.
Scan: Capture and display the waveform continuously.
Stop: Data acquisition stopped.

Page 8 June 2016
The purple T pointer indicates the horizontal position for the trigger.
The pointer indicates the trigger position in the internal memory.
The two yellow dotted lines indicate the size of the viewing expanded
window.
It shows present triggering value and displays the site of present window
in internal memory.
It shows setting time.
It indicates that there is a U disk connecting with the oscilloscope.
The waveform of CH1.
The purple pointer shows the trigger level position for CH1.
The positions of two purple dotted line cursors measurements.
The waveform of CH2.
The frequency of the trigger signal of CH1.
It indicates the current function menu.
Current trigger type:
Rising edge triggering.
Falling edge triggering.
Video line synchronous triggering.
Video field synchronous triggering.
The reading shows the trigger level value of the corresponding channel.
The reading shows the window time base value.
The reading shows the setting of main time base.
The readings show current sample rate and the record length.
It indicates the measured type and value of the corresponding channel. "F"
means frequency, "T" means cycle, "V" means the average value, "Vp" the
peak-peak value, "Vk" the root-mean-square value, "Ma" the maximum
amplitude value, "Mi" the minimum amplitude value, "Vt" the Voltage value
of the waveform's flat top value, "Vb" the Voltage value of the waveform's
flat base, "Va" the amplitude value, "Os" the overshoot value, "Ps" the
Preshoot value, "RT" the rise time value, "FT" the fall time value, "PW" the
+D width value, "NW" the –D Width value, "+D" the +Duty value, "-D" the
-Duty value, "PD" the Delay A→B value and "ND" the Delay A→B value.

June 2016 Page 9
The readings indicate the corresponding Voltage Division and the Zero
Point positions of the channels.
The icon shows the coupling mode of the channel.
"—" indicates direct current coupling.
"
∼" indicates AC coupling.
"
" indicates GND coupling.
It is cursor measure window, showing the absolute values and the readings
of the two cursors.
The yellow pointer shows the grounding datum point (zero point position)
of the waveform of the CH2 channel. If the pointer is not displayed, it
shows that this channel is not opened.
The red pointer indicates the grounding datum point (zero point position)
of the waveform of the CH1 channel. If the pointer is not displayed, it
shows that the channel is not opened.
2.3 How to Implement the General Inspection
After you get a new oscilloscope, it is recommended that you should make a
check on the instrument according to the following steps:
► Check whether there is any damage caused by transportation.
If it is found that the packaging carton or the foamed plastic protection
cushion has suffered serious damage, do not throw it away first till the
complete device and its accessories succeed in the electrical and mechanical
property tests.
► Check the Accessories
The supplied accessories have been already described in the
"SPECIFICATIONS" of this Manual. You can check whether there is any loss
of accessories with reference to this description. If it is found that there is
any accessory lost or damaged, please get in touch with the distributor of
PROMAX responsible for this service or the PROMAX local offices.
► Check the Complete Instrument
If it is found that there is damage to the appearance of the instrument, or
the instrument can not work normally, or fails in the performance test,
please get in touch with the PROMAX distributor responsible for this
business or the PROMAX local offices. If there is damage to the instrument
caused by the transportation, please keep the package. With the
transportation department or the PROMAX distributor responsible for this
business informed about it, a repairing or replacement of the instrument will
be arranged by the PROMAX.

Page 10 June 2016
2.4 How to Implement the Function Inspection
Make a fast function check to verify the normal operation of the instrument,
according to the following steps:
► Connect the power cord to a power source. Push down the button of
the " " signal on the top.
The instrument carries out all self-check items and shows the Boot Logo.
Press the "Utility" button, then, press H1 button to get access to the
"Function" menu. Turn the M knob to select Adjust and press H3 button
to select "Default". The default attenuation coefficient set value of the
probe in the menu is 10X.
► Set the Switch in the Oscilloscope Probe as 10X and Connect the
Oscilloscope with CH1 Channel.
Align the slot in the probe with the plug in the CH1 connector BNC, and then
tighten the probe with rotating it to the right side.
Connect the probe tip and the ground clamp to the connector of the probe
compensator.
► Press the "Autoset" Button.
The square wave of 1 KHz frequency and 5V peak-peak value will be
displayed in several seconds (see Figure 6).
Figure 6. Auto set.
Check CH2 by repeating Step 2 and Step 3.

June 2016 Page 11
2.5 How to Implement the Probe Compensation
When connect the probe with any input channel for the first time, make this
adjustment to match the probe with the input channel. The probe which is not
compensated or presents a compensation deviation will result in the measuring
error or mistake. For adjusting the probe compensation, please carry out the
following steps:
Set the attenuation coefficient of the probe in the menu as 10X and that
of the switch in the probe as 10X (see “How to Set the Probe Attenuation
Coefficient”), and connect the probe with the CH1 channel. If a probe
hook tip is used, ensure that it keeps in close touch with the probe.
Connect the probe tip with the signal connector of the probe compensator
and connect the reference wire clamp with the ground wire connector of
the probe connector, and then press the button "Autoset".
Check the displayed waveforms and regulate the probe till a correct
compensation is achieved (see Figure 7 and Figure 8).
Overcompensated Compensated correctly Under compensated
Figure 7. Displayed Waveforms of the Probe Compensation.
Repeat the steps mentioned if needed.
Figure 8. Adjust Probe.

Page 12 June 2016
2.6 How to Set the Probe Attenuation Coefficient
The probe has several attenuation coefficients, which will influence the vertical
scale factor of the oscilloscope.
To change or check the probe attenuation coefficient in the menu of oscilloscope:
Press the function menu button of the used channels (CH1 MENU or
CH2 MENU).
Press H3 button to display the Probe menu; select the proper value
corresponding to the probe.
This setting will be valid all the time before it is changed again.
CAUTION: The default attenuation coefficient of the probe on the instrument is
preset to 10X. Make sure that the set value of the attenuation switch
in the probe is the same as the menu selection of the probe
attenuation coefficient in the oscilloscope.
The set values of the probe switch are 1X and 10X (see Figure 9).
Figure 9. Attenuation Switch.
CAUTION: When the attenuation switch is set to 1X, the probe will limit the
bandwidth of the oscilloscope in 5MHz. To use the full bandwidth of
the oscilloscope, the switch must be set to 10X.

June 2016 Page 13
2.7 How to Use the Probe Safely
The safety guard ring around the probe body protects your finger against any
electric shock, shown as Figure 10.
Figure 10. Finger Guard.
CAUTION: To avoid electric shock, always keep your finger behind the safety guard
ring of the probe during the operation. To protect you from suffering
from the electric shock, do not touch any metal part of the probe tip
when it is connected to the power supply. Before making any
measurements, always connect the probe to the instrument and connect
the ground terminal to the earth.
2.8 How to Implement Self-calibration
The self-calibration application can make the oscilloscope reach the optimum
condition rapidly to obtain the most accurate measurement value. You can carry
out this application program at any time. This program must be executed
whenever the change of ambient temperature is 5 ºC or over.
Before performing a self-calibration, disconnect all probes or wires from the input
connector. Press the "Utility" button, then, press H1 button to call out the
Function menu; turn the M knob to choose Adjust. Press H2 button to choose
the option "Self Cal"; run the program after everything is ready.

Page 14 June 2016
2.9 Introduction to the Vertical System
As shown in Figure 11, there are a few of buttons and knobs in VERTICAL
CONTROLS. The following practices will gradually direct you to be familiar with
the using of the vertical setting.
Figure 11. Vertical Control Zone.
Use the button "VERTICAL POSITION" knob to show the signal in the
center of the waveform window. The "VERTICAL POSITION" knob
functions the regulating of the vertical display position of the signal.
Thus, when the "VERTICAL POSITION" knob is rotated, the pointer of
the earth datum point of the channel is directed to move up and down
following the waveform.
► Measuring Skill
If the channel is under the DC coupling mode, you can rapidly
measure the DC component of the signal through the observation of
the difference between the wave form and the signal ground.
If the channel is under the AC mode, the DC component would be
filtered out. This mode helps you display the AC component of the
signal with a higher sensitivity.

June 2016 Page 15
Change the Vertical Setting and Observe the Consequent State
Information Change.
With the information displayed in the status bar at the bottom of the
waveform window, you can determine any changes in the channel
vertical scale factor.
Turn the vertical "VOLTS/DIV" knob and change the "Vertical
Scale Factor (Voltage Division)", it can be found that the scale
factor of the channel corresponding to the status bar has been
changed accordingly.
Press buttons of "CH1 MENU", "CH2 MENU" and "Math", the
operation menu, symbols, waveforms and scale factor status
information of the corresponding channel will be displayed in the
screen.
2.10
Introduction to the Horizontal System
Shown as Figure 12, there are a button and two knobs in the "HORIZONTAL
CONTROLS". The following practices will gradually direct you to be familiar with
the setting of horizontal time base.
Figure 12. Horizontal Control Zone.
Use the horizontal "SEC/DIV" knob to change the horizontal time base
setting and observe the consequent status information change. Rotate
the horizontal "SEC/DIV" knob to change the horizontal time base, and
it can be found that the "Horizontal Time Base" display in the status
bar changes accordingly.
