ProMinent DULCOMETER D1C User manual

mA
12.3
%
START
STOP
DULCOMETER
Operating Instructions
DULCOMETER®D1C
Part 2: Adjustment and Operation,
Measured Variable Standard Signal
DIN EN ISO 9001
70 100 M 502
ProMinent®
D1C2-mA-001-D
Part no. 987528 ProMinent Dosiertechnik GmbH ·D-69123 Heidelberg ·Germany BA DM 066 02/00 GB
Please completely read through operating instructions! ·Do not discard!
The warranty shall be invalidated by damage caused by operating errors!

2
D1C A DULCOMETER®Controller Series D1C / Version A
Type of mounting
D Control panel installation 96 x 96 mm
W Wall mounting
Operating voltage
0 230 V 50/60 Hz
1 115 V 50/60 Hz
2 200 V 50/60 Hz (only with panel installation)
3 100 V 50/60 Hz (only with panel installation)
4 24 V AC/DC
Measured variable
S Standard signal 0/4-20 mA
Connection of measured variable
1 Terminal, standard signal 0/4-20 mA
Correction variable
0 None
Feed forward control
0 None
1 As standard signal 0/4-20 mA
2 As frequency 0-500 Hz
3 As frequency 0-10 Hz
Control input
0 None
1 Pause
Signal output
0 None
1 Standard signal 0/4-20 mA measured value
2 Standard signal 0/4-20 mA control variable
4 2 standard signal 0/4-20 mA output, free programmable
Power control
A Alarm relay
G Alarm and 2 limit value relays
M Alarm and 2 solenoid valve relays
R Alarm relay and servomotor with feedback
Pump control
0 None
2 Two pumps
Control characteristics
0 None
1 Proportional control
2 PID control
Log output
0 None
Language
D German
E English
F French
I Italian
N Dutch
S Spanish
P Polish
A Swedish
B Portuguese
U Hungarian
G Czech
1 Device Identification / Identity Code
D1C A S 0 E
Please enter the identity code of your device here!

3
2 Contents / General User Information
Page
Device Identification / Identity Code ............................................................................................................. 2
General User Information ............................................................................................................................... 3
Device Overview / Controls ........................................................................................................................... 4
Functional Description ................................................................................................................................... 5
Display Symbols ............................................................................................................................................. 6
Operation ........................................................................................................................................................ 7
Restricted Operating Menu ............................................................................................................................ 8
Overview ................................................................................................................................................ 8
General Layout ...................................................................................................................................... 9
Description .......................................................................................................................................... 10
Complete Operating Menu ........................................................................................................................... 13
Overview .............................................................................................................................................. 13
Description .......................................................................................................................................... 14
Troubleshooting ........................................................................................................................................... 23
General User Information
These operating instruction describe the technical data and function of the series DULCOMETER®D1C
controller, provide detailed safety information and are divided into clear steps. The activities to be carried
out are identified by bold bullets (•).
IMPORTANT:
Please observe the parts of these operating instructions applicable to your particular
version! This is indicated in the Section “Device Identification / Identity Code”!
IMPORTANT:
Correct measuring and dosing is only possible in the case of impeccable operation of the
probe. The probe has to be calibrated / checked regularly!

4
UP menu button
To increase a displayed numerical value
and to change variables (flashing
display)
BRANCH BACK menu button
Back to permanent display or to start
of relevant setting menu.
DOWN menu button
To decrease a displayed numerical
value and to change variables (flashing
display).
CHANGE DISPLAY menu button
To change over within a menu level
and to change from one variable to
another within a menu point.
START/STOP menu button
Start/stop of control and metering
function.
ENTER menu button
To accept, confirm or save a displayed
value or status. For alarm acknow-
ledgement.
3 Device Overview / Controls
D1C2-mA-002-GB
STOP
START
®
DULCOMETER®
STOP
START
Graphic display
Push-button
"Start/stop"
Push-button
"Enter"
Push-button
"Up"
Push-button
"Change display"
Push-button
"Down"
Push-button
"Branch back"
Display field
Measured variable
Standard signal
(0/4–20 mA)
mA

5
4 Functional Description
NOTE
Please refer to the description of the complete operating menu in Section 8 for a detailed
description of the individual characteristics of the D1C controller!
4.1 Operating Menu
The D1C controller permits settings to be made in two different menus. All values are preset and can be
changed in the complete operating menu.
The controller is delivered with a restricted operating menu so that the D1C controller can be used
effectively in many applications from the very onset. If adaptations prove to be necessary, all relevant
parameters can then be accessed by switching over to the complete operating menu.
4.2 Access Code
Access to the setting menu can be prevented by setting up an access code. The D1C controller is supplied
with the access code 5000 which permits free access to the setting menu. The calibration menu remains
freely accessible even when access to the setting menu is blocked by the code.
4.3 Control
The D1C can operate as a proportional controller or as a PID controller - dependent on the device version
(see identity code) and the setting.
The controlled variable is recalculated every second. Control procedures which require rapid correction of
setpoint deviations (less than approx. 30 seconds) cannot be processed with this controller. The cycle
times must be taken into consideration when activating solenoid valves (pulse length) in the same way as
their running times when activating servomotors (3-point).
Via the control input pause, the control function (selection of controlled variable) can be switched off. The
calculation of the controlled variable starts again after cessation of "pause".
4.4 Feed Forward Control
The D1C controller can process a signal of a feed forward control. Depending on the device version (see
identity code) and the setting, this signal can be obtained in any form of a 0–20 mA or 4–20 mA signal or as
a digital contact signal with the maximum frequencies 10 Hz or 500 Hz.
During start-up, the zero point has to be checked. The multiplicative feed forward control is not designed
for switching off permanently the actuating variable (signal ≈0).
This signal can be used, for example, for flow-proportional metering (multiplicative effect) or feedforward-
dependent basic load metering (additive effect). The result of control variable calculation from the
proportional or PID control is multiplied by or added to the feedforward signal. A multiplicative feedforward
variable at the level of the set rated value carries over the calculated control variable unchanged into the
controlled variable:
Controlled variable = Feedforward variable/rated value x calculated control variable
An additive feedforward variable at the level of the rated value results in maximum controlled variable:
Controlled variable (max. 100 %) = Feedforward variable/rated value x max. controlled variable +
calculated control variable
4.5 Error Messages
Error messages and information are indicated on the bottom line in the permanent display 1. Errors to be
acknowledged (acknowledgement switches off the alarm relay) are indicated by the " ". Errors/notes
which still apply after acknowledgement are indicated alternately. During correction variable processing
(temperature for correction of pH-value), the value is indicated in the same line as the error/note. Faults
which are rectified of their own accord due to changed operating situations are removed from the
permanent display without the need for acknowledgement.

6
The display of the D1C controller uses the following symbols:
Description Comment Symbol
Limit value transgression Symbol
Relay 1, upper left
Symbol
Relais 1, lower left
Symbol
Relais 2, upper right
Symbol
Relais 2, lower right
Metering pump 1 Symbol
Control OFF left
Symbol
Control ON left
Metering pump 2 Symbol
Control OFF right
Symbol
Control ON right
Solenoid valve 1 Symbol
Control OFF left
Symbol
Control ON left
Solenoid valve 2 Symbol
Control OFF right
Symbol
Control ON right
Servomotor
Control, open relay
Control, close relay
Without control
The bar increases
Position feedback from left to right
during opening
Stop button pressed
Manual metering
Fault
5 Display Symbols

7
NOTE
Access to the setting menus can be barred with the access code!
The number and scope of setting menus is dependent on the device version!
If the access code is selected correctly in a setting menu, then the following setting menus are also
accessible!
If within a period of 10 minutes no button is pushed, the unit automatically branches back from the
calibrating menu or a setting menu to the permanent display 1.
6 Operation
Access code, correct
Parameter
setting
Permanent
display 1
Various
Access code
Setting menus
D1C2-mA-007-GB
The various menus are selected with
the CHANGE button
The menus is started with
the ENTER button
BRANCH BACK to permanent display
or to relevant setting menu
Permanent
display 2
D1C2-mA-008-GB
CHANGE from selection to selection
Change numbers or
settings of selection
Variables flash
ENTER and save setting,
continue to next menu
BRANCH BACK without
saving setting
BRANCH BACK to
start of setting
Text 1
Text 2
Selection 1
Selection 2
Text 1
Text 2
Selection 1
Selection 2

8
7 Restricted Operating Menu / Overview
The restricted operating menu permits simple operation of the most important parameters. The following
overview shows the settings which can be selected:
Number and scope of setting menus
is dependent on the device
Access to setting menus can
be blocked with access code
Only with control
Control
setting ?
General setting
information
Limits
setting ?
D1C2-mA-009-GB
w:
mea val.
Permanent display 1
Permanent display 2
only with control
(w=setpoint)
fd. fwd.:
reg. val.:
12.3 %
50 %
70 %
59 %
100 %
Calibration
zero-p.:
Slope: 4.0 mA
12.3
%

9
Restricted Operating Menu / Layout
Control
Current regulat.
value: 30 %
Control
Current regulat.
30 %
value:
D1C2-mA-010-GB
50 %
1000 s
Ti =
Td =
xp =
0 s
10 %
xp = 10 %
30 %
15 %
DxSxxxxxxxxxx
D1C-B1 FW-xx.x =
=
5000
26.0 % 30.0 %
30 %
28 %
Limit 1 lower Limit 2 upper
Limits
setting ?
Control
settings ?
Only with control
Control
positive
regulated value:
negative
Control
Current regulat.
value:
normal
Control with dead zone
For normal control
PID control
Proportional control
Setpoint
Setpoint 2 upper Ctrl. parameter
Setpoint 1 lower
Ctrl. parameter
Manual dosing
regulated range
General setting
information Ident-Code: D1CA
Software version
Alarm relay Access c.:
Operating menu:
active English
Restricted
Permanent display 1
w:
mea val.
Permanent display 2
only with control
(w=setpoint)
fd. fwd.:
reg. val.:
Positive values of setting variable:
Negative values of setting variable:
12.3 %
50 %
70 %
59 %
100 %
Calibration
zero-p.:
Slope: 4.00 mA Calibration
zero-p.:
Slope: 4.00 mA
12.3
%
Calibration
meas. value
14.5 % 100 %
with dead zone
manual

10
Calibration the Standard Signal (zero-point calibration):
During calibration, the control function persists. The standard signal of the output (measured value)
remains unchanged. The measured value registered during the start of the calibration is proposed as value;
this value is adjustable.
CAUTION:
A change of the measuring unit (see page 15) must be done before calibration!
Restricted Operating Menu / Description
D1C2-mA-011-GB
Permanent display 1
w:
mea val. Permanent display 2
only with control
(w=setpoint)
fd. fwd.:
reg. val.:
Positive values of setting variable:
Negative values of setting variable:
12.3 %
50 %
70 %
59 %
12.3
%
Possible Values
Initial value Increment Lower value Upper value Remarks
Measured value 0.1 % –5 % 105 %
0.01 mA –1.00 mA 21.00 mA
0.01 m 0 m 31.50 m 30.00 m
0.1 % 0 % 105 % 100 %
0.001 bar 0 bar 1.050 bar 1.000 bar
0.001 bar 0 bar 5.250 bar 5.000 bar
0.01 bar 0 bar 10.50 bar 10.00 bar
0.1 bar 0 bar 105 bar 100.0 bar
0.1 psi 0 psi 105 psi 100 psi
1 psi 0 psi 1050 psi 1000 psi
0.001 m
3
/h 0 m
3
/h 9.999 m
3
/h 9.999 m
3
/h
0.1 m
3
/h 0 m
3
/h 105 m
3
/h 100 m
3
/h
1 m
3
/h 0 m
3
/h 1050 m
3
/h 1000 m
3
/h
0.1 gal/h 0 gal/h 105 gal/h 100 gal/h
1 gal/h 0 gal/h 1050 gal/h 1000 gal/h
1 ppm 0 ppm 1050 ppm 1000 ppm
0.1 %RF 0 %RF 105 %RF 100 %RF
0.01 mA 0/4 mA 21 mA 20 mA
0.1 % 0 % 105 % 100 %
100 %
Calibration
zero-p.:
Slope: 4.00 mA Calibration
zero-p.:
Slope: 4.00 mA
Calibration
meas. value
14.5 % 100 %
D1C2-mA-029-GB
Access to all setting menus can be blocked with an access code !
Permanent display 1

11
Restricted Operating Menu / Description
Limits
Possible Values
Initial value Increment Lower value Upper value Remarks
Type of limit Trans- upper Limit transgression
gression Limit 1: lower lower when exceeding or
Limit 2: upper off *) dropping below value
*) only with limit value relay
Limit value Limit 1: 0 % 0.1 % –5 % 105 % measuring unit %
Limit 2: 100 % 0.1 % –5 % 105 %
Limit 1: 0.00 mA 0.01 mA –1.00 mA 21 mA measuring unit mA
Limit 2: 20.00 mA 0.01 mA –1.00 mA 21 mA
Control
D1C2-mA-014-GB
Access to all setting menus can be blocked with an access code !
Limit 1 lower Limit 2 upper
Limits
setting ? 26.0 % 30.0 %
Control
Current regulat.
value: -30 %
Control
Current regulat.
-30 %
value:
D1C2-mA-015-GB
1000 s
Ti =
Td =
xp =
0 s
10 %
xp = 10 %
30 %
15 %
Access to all setting menus can be blocked with an access code !
Only with control
Note: The controlled variable is recalculated every second. Only
suitable for processes with time constants greater than 30 s !
Control
settings ? Control
regulated value:
Control
Current regulat.
value:
Control with dead zone
For normal control
PID control
Proportional control
Setpoint
Setpoint 2 upper Ctrl. parameter
Setpoint 1 lower
Ctrl. parameter
Manual dosing
regulated range
50 %
30 %
28 %
Positive values of setting variable:
Negative values of setting variable:
positive
negative
normal
with dead zone
manual

12
Restricted Operating Menu / Description
Possible Values
Initial value Increment Lower value Upper value Remarks
Setpoint 50 % 0.1 % –5.0 % 105 % measuring unit: %
10.00 mA 0.01 mA –1.00 mA 21 mA measuring unit: mA
2 setpoints necessary
for control with dead zone.
Setpoint 1 > setpoint 2
Adjustment of measuring
on page 14
Control parameter xp 10 % 1 % 1 % 500 % xp referred to measuring
Control parameter Tn off 1 s 1 s 9999 s range
Control parameter Tv off 1 s 1 s 2500 s Function off = 0 s
Manual metering 0 % 1 % –100 % +100 % Function off = 0 s
General Settings
Possible Values
Initial value Increment Lower value Upper value Remarks
Alarm relay active active
not active
Access code 5000 1 1 9999
Language as per identity German
code English
French
Italian
Spanish
Dutch
Polish
Swedish
Portuguese
Czech
Hungarian
Operating menu restricted restricted
complete
D1C2-mA-016-GB
DxSxxxxxxxxxx
D1C-B1 FW-xx.x =
=
5000
General setting
information Ident-Code: D1CA
Software version
Alarm relay Access c.:
Operating menu:
active English
restricted
Access to all setting menus can be blocked with an access code !

13
8 Complete Operating Menu / Overview
All parameters of the controller can be set in the complete operating menu. The following overview shows
the settings which can be selected:
D1C2-mA-017-GB
w:
Permanent display 1
mea val. Permanent display 2
only with control
(w = setpoint)
fd. fwd.:
reg. val.:
Only with
solenoid valve relay
Only with servomotor
Only with control
Only with pumps
Measured value
setting ?
Measuring unit
setting ?
Pumps
setting ?
Relays
setting ?
Limits
setting ?
Servomotor
setting ?
Control
setting ?
Number and scope of setting menus
is dependent on the device
Access to setting menus can
be blocked with access code
12.3 %
50 %
70 %
59 %
100 %
Calibration
zero-p.:
Slope: 4.0 mA
12.3
%
Only with feed
forward control
Feed forward ctrl.:
setting ?
Signal output
mA setting ?
General setting
information
Only with standard
signal output

14
Complete Operating Menu / Overview
Calibration the Standard Signal (two-point calibration)
During calibration, metering is reduced to the set basic load. The standard signal of the output (measured
value) is reduced to 0 mA or 4 mA. As value the measured value is proposed; this value is adjustable. (The
slope is indicated as deviation measured slope to norm slope).
Error message Condition Effect
Value distance too small ∆value > 5.0 % measured value deleted
∆value > 1.00 mA repeat calibration
Possible Values
Initial value Increment Lower value Upper value Remarks
Measured 0.1 % –5 % 105 % *for possible measuring
value* 0.01 mA –1.00 mA 21.00 mA values see page 10
D1C2-mA-018-GB
Permanent display 1
w:
mea val. Permanent display 2
only with control
(w=setpoint)
fd. fwd.:
reg. val.:
12.3 %
50 %
70 %
59 %
12.3
%
Positive values of setting variable:
Negative values of setting variable:
D1C2-mA-030-GB
value1:
value2:
Calibration Calibration
value accept ?
meas. value 1
14.5 %
value1:
value2:
Calibration Calibration
value accept ?
meas. value 2
76.6 %
14.5 %
76.6 %
14.5 %
Calibration
Slope
100 %
4.0 mA
zero-pt.:
Slope
zero-pt.:
Calibration
100 %
4.0 mA
Permanent display 1

15
Complete Operating Menu / Overview
Measuring Unit
When changing the measuring unit the settings must be checked in all menues!
Possible Values
Initial value Increment Lower value Upper value Remarks
Measuring variable Measurement Level
signal Pressure
Water flow rate
Turbidity
Humidity
Measurement
signal
Measuring unit 0 - 100 % 0 - 30 m Level
0 - 100 %
0 - 1.000 bar Pressure
0 - 5.000 bar
0 - 10.00 bar
0 - 100.0 bar
0 - 100.0 psi
0 - 1000 psi
0 - 9.999 m
3
/h Water flow rate
0 - 100.0 m
3
/h
0 - 1000 m
3
/h
0 - 100.0 gal/h
0 - 1000 gal/h
0 - 1000 ppm Turbidity
0 - 100.0 %RH Humidity
0/4 - 20 mA Measurement signal
0 - 100 %
D1C2-mA-019-GB
measuring unit
percent [%]
Access to all setting menus can be blocked with an access code !
measuring unit
setting ?
Permanent display 1

16
Complete Operating Menu / Overview
Measured value
When changing the range adjustment, the adjustments in all menus have to be checked!
Pumps
Possible values
Initial value Increment Lower value Upper value Remarks
Max. stroke/minute of 120 1 1 500 off = 0 strokes/min
pumps 1 and 2
Possible Values
Initial value Increment Lower value Upper value Remarks
Standard signal input 4 mA 0 mA
lower signal limit 4 mA
Allocated measuring
range* 0–100.0 % 0.1 % –5 % 105 % Measurement signal
0–20.00 mA 0.01 mA –1.00 mA 21.00 mA *for other measuring ranges
see page 10
Checkout time off 1 s 1 s 9999 s Constant measurement signal
results in message and alarm.
Function off = 0 s
D1C2-mA-020-GB
4 mA 20 mA=
Access to all setting menus can be blocked with an access code !
Standard signal input mA
Measured value
range adjustment Measured value
range adjustment
Measured value
Checkout time
measured value
off
Measured value
setting ? = 0.0 % 100.0 %
D1C2-mA-022-GB
120
120
Access to all setting menus can be blocked with an access code !
Only with pumps for control
Pumps
setting ? Dosing pump max.
pump1:
pump2:
Control
pump1
pump2 pulse/minute

17
Complete Operating Menu / Overview
Relay for solenoid valve activation
Limits
Possible values
Initial value Increment Lower value Upper value Remarks
Type of limit trans- Limit transgression when
gression Limit 1: lower upper exceeding or dropping
Limit 2: upper lower below value
off *) *) only with limit value relay
Possible Values
Initial value Increment Lower value Upper value Remarks
Relay adjustment as per identity *When the setting is
Relay 1 code Solenoid valve 1 „Limit” the relays will
Limit value 1* not be disable during the
Actuator 1 pause or in case of a fault.
off
Relay 2 Solenoid valve 2
Limit value 2*
Actuator 2
off
Period 10 s 1 s 10 s 9999 s
min. time 1 s 1 s 1 s period/2
D1C2-mA-023-GB
10 s
1 s 10 s 1 s
Access to all setting menus can be blocked with an access code !
Only with relay activation
Relays
setting ?
Solenoid valve 2Solenoid valve 1
period
min. time period min. time
Relay adjustment
Relay1:
Relay2:
Control
Solenoid valves: SV1
SV2
SV1
SV2
D1C2-mA-024-GB
1 s
1 s 1 s
1 s
300 s
28.0 % 30.0 %
28.0 % 30.0 %
0.2 %
Access to all setting menus can be blocked with an access code !
Only with limit value relay
Limit 1 lower
Limit 1 lower
∆t on
∆t off
Limit 2
Limit 2
upper
upper
∆t on
∆t off
Limits
setting ? Hysteresis
limits:
Checkout time
limits:

18
Servomotor
Activation of the servomotor must be carried out with the same meticulous care as taken when calibrating
a measuring probe. The operating range is defined by the total resistance range of the feedback
potentiometer. The maximum limit of the range actually used is set by defining the control range.
CAUTION:
To ensure correct operation, the activation time of the actuator used should not be less
than 25 seconds for the control range from 0…100 %!
Complete Operating Menu / Overview
Possible values
Initial value Increment Lower value Upper value Remarks
Limit value Limit 1: 0 % 0.1 % –5 % 105 % measuring unit percent
Limit 2: 100 % 0.1 % –5 % 105 %
Limit 1: 0 mA 0.01 mA –1.00 mA 21 mA measuring unit milliampere
Limit 2: 20 mA 0.01 mA –1.00 mA 21 mA
Switch-on delay ∆t ON 0 s 1 s 0 s 9999 s
Switch-off delay ∆t OFF 0 s 1 s 0 s 9999 s
Hysteresis limits 0.2 % 0.1 % 0.1 % 105 %
0.04 mA 0.01 mA 0.02 mA 21.00 mA
Checkout time limits off 1 s 1 s 9999 s Results in message and
alarm. Off = 0 s:
Function switched off,
no message, no alarm
Access to all setting menus can be blocked with an access code !
Servomotor
setting ?
Dosing:
Control range:
0 % to
operating range
100 %
Only with servomotor
Current position:
Servomotor
open ? Servomotor
Please wait !
open
Servomotor
Please wait !
close
Servomotor
Value take over ?
opened !
Servomotor
Value take over ?
closed !
Servomotor
close ?
Servomotor
Current position:
OK
= automatic timing
D1C2-mA-025-GB
Servomotor
setting

19
Complete Operating Menu / Overview
Possible values
Initial value Increment Lower value Upper value Remarks
Servomotor Setting Setting
OK
off
Controll direction
Control range 100 % 1 % 10 % 100 % in % of
operating range
Control
Possible values
Initial value Increment Lower value Upper value Remarks
Control normal normal When controlling with dead zone,
with dead zone the feed forward control is not
manual used for measured values within
the dead zone.
Setpoint 1.0 ppm 0.01 ppm –3 ppm 63 ppm When measuring range
10 % 0.1 % –30 % 630 % concentration
When measuring range
saturation
2 setpoints necessary for
control with dead zone.
Setpoint 1 > setpoint 2
Control
Current regulat.
value: -30 %
Control
Current regulat.
-30 %
value:
D1C2-mA-026-GB
1000 s
Ti =
Td =
xp =
0 s
10 %
xp = 10 %
30 %
15 %
Access to all setting menus can be blocked with an access code !
Only with control
Note: The controlled variable is recalculated every second. Only
suitable for processes with time constants greater than 30 s !
Control
settings ? Control
regulated value:
Control
Current regulat.
value:
Control with dead zone
For normal control
PID control
Proportional control
Setpoint
Setpoint 2 upper Ctrl. parameter
Setpoint 1 lower
Ctrl. parameter
Manual dosing
regulated range
50 %
30 %
28 %
Positive values of setting variable:
Negative values of setting variable:
positive
negative
normal
manual
with dead zone
10 %
Add. basic load
regulated range

20
Complete Operating Menu / Overview
Possible values
Initial value Increment Lower value Upper value Remarks
Control parameter xp 10 % 1 % 1 % 500 % xp referred to measuring range
Control parameter Tn off 1 s 1 s 9999 s Function off = 0 s
Control parameter Tv off 1 s 1 s 2500 s Function off = 0 s
Additional load 0 % 1 % –100 % +100 %
Manual metering 0 % 1 % –100 % +100 %
Feed forward control
Initial value Increment Lower value Upper value Remarks
Feed forward control as per identity None Signal processing:
(Flow) code 10 Hz Signal <0.02 Hz = No flow
500 Hz Signal <0.2 Hz = No flow
Standard signal 0…20 mA Signal <0.2 mA = No flow
4–20 mA 4…20 mA Signal <4.2 mA = No flow
Feed forward control 10 Hz 0.01 Hz 0.1 Hz 10 Hz Depended on signal type.
rated value 500 Hz 1 Hz 5 Hz 500 Hz Maximum limitation
20 mA 0.1 mA 0.4 mA 20 mA of range used.
Feed forward control multiplicative multiplicative
Feed forward control effect additive
Feed forward control
add. regulated value 100 % 1 % –500% +500% only with add. feed forward control
Standard Signal Output 1
D1C2-mA-031-GB
Feed forward ctrl.:
setting ? Feed forward ctrl.:
Hz/mA
10 Hz
Feed forward ctrl.:
max. additive
regulated value:
Feed forward ctrl.:
rated value
10.00 Hz
Feed forward ctrl.:
disturb. variable
100 %
multiplicative
D1C2-mA-027-GB
0…20 mA
100 %
0 mA=
20 mA=
0%
0 mA =
20 mA = 100%
0.0 %
Access to all setting menus can be blocked with an access code !
Control with standard signal
signal output 1
mA setting ?
Only with standard signal output
signal output 1
mA
Control
regulated value: signal output 1
regulated value
signal output 1
measured value
Measured value
positive
negative
