ProMinent DULCOMETER User manual

DULCOMETER®, Compact Controller
Measurement: Inductive conductivity
Assembly and operating instructions
A1860
EN
Part number: 984705 Version: BA DM 231 11/18 EN
Please carefully read these operating instructions before use. · Do not discard.
The operator shall be liable for any damage caused by installation or operating errors.
The latest version of the operating instructions are available on our homepage.

General non-discriminatory approach In order to make it easier to read, this
document uses the male form in grammat‐
ical structures but with an implied neutral
sense. It is aimed equally at both men and
women. We kindly ask female readers for
their understanding in this simplification of
the text.
Supplementary information
Please read the supplementary information in its entirety.
Information
This provides important information relating to the correct operation of the unit or
is intended to make your work easier.
Warning information
Warning information includes detailed descriptions of the hazardous situation, see
Ä Chapter 3.1 ‘Labelling of Warning Information’ on page 11 .
The following symbols are used to highlight instructions, links, lists, results and other ele‐
ments in this document:
Tab. 1: More symbols
Symbol Description
Action, step by step.
⇨Outcome of an action.
Links to elements or sections of these instructions or other applicable
documents.
nList without set order.
[Button] Display element (e.g. indicators).
Operating element (e.g. button, switch).
Supplemental directives
2

Symbol Description
‘Display /GUI’ Screen elements (e.g. buttons, assignment of function keys).
CODE Presentation of software elements and/or texts.
Supplemental directives
3

Table of contents
1 Identity code........................................................................................................... 7
2 Introduction............................................................................................................. 9
2.1 Measured variables........................................................................................ 9
3 Safety and responsibility....................................................................................... 11
3.1 Labelling of Warning Information.................................................................. 11
3.2 General Safety Information.......................................................................... 12
3.3 Intended Use................................................................................................ 14
3.4 User qualification.......................................................................................... 15
4 Functional description........................................................................................... 17
5 Assembly and installation..................................................................................... 18
5.1 Scope of delivery.......................................................................................... 18
5.2 Assembly and installation............................................................................. 18
5.3 Assembly (mechanical)................................................................................ 20
5.3.1 Wall mounting............................................................................................ 20
5.3.2 Pipe mounting........................................................................................... 21
5.3.3 Control panel mounting............................................................................. 22
5.4 Installation (electrical)................................................................................... 30
5.4.1 Cable Cross-Sections and Cable End Sleeves......................................... 31
5.4.2 Electrical connection of the conductivity sensor........................................ 31
5.4.3 Terminal diagram / wiring.......................................................................... 32
5.4.4 Installation (electrical)................................................................................ 39
5.5 Switching of inductive loads......................................................................... 40
6 Sensor connector.................................................................................................. 42
7 Commissioning..................................................................................................... 45
7.1 Initial commissioning.................................................................................... 45
7.2 Setting the control during commissioning..................................................... 45
7.3 Selecting the sensor type ............................................................................ 46
7.4 Temperature compensation and reference temperature.............................. 48
8 Operating diagram................................................................................................ 50
8.1 Overview of equipment/Operating elements................................................ 50
8.2 Entering values............................................................................................. 51
8.3 Adjusting display contrast............................................................................. 52
8.4 Continuous display....................................................................................... 53
Table of contents
4

8.5 Information display....................................................................................... 54
8.6 Password...................................................................................................... 55
9 Operating menus.................................................................................................. 56
9.1 Calibrating [CAL] the conductivity sensor..................................................... 56
9.1.1 Calibration of the cell constant.................................................................. 58
9.1.2 Calibration of the temperature coefficient.................................................. 61
9.1.3 Calibrating the zero point.......................................................................... 64
9.2 Setting limit values [LIMITS] ........................................................................ 66
9.3 Setting the control [CONTROL] ................................................................... 69
9.4 Setting inputs [INPUT] ................................................................................. 72
9.5 Setting the [MANUAL] sensor in the [INPUT] menu..................................... 77
9.6 Setting outputs [OUTPUT] ........................................................................... 81
9.7 Setting the [DEVICE] .................................................................................... 85
10 Control parameters and functions......................................................................... 87
10.1 DULCOMETER® Compact Controller function states ............................... 87
10.2 [STOP/START] key.................................................................................... 89
10.3 Priming [PRIME] ......................................................................................... 90
10.4 Hysteresis limit value.................................................................................. 91
10.5 Temperature correction variable................................................................ 92
10.6 Checkout time for measured variable and correction variable................... 93
10.7 Checkout time control................................................................................. 93
10.8 Power relay "P-REL" as limit value relay.................................................... 94
10.9 Setting and functional description of "Relay Used as a Solenoid Valve" .. 95
10.10 Alarm relay............................................................................................... 97
10.11 "Error logger" operating mode.................................................................. 97
11 Maintenance......................................................................................................... 98
11.1 Error messages ......................................................................................... 98
11.2 Changing the fuse, DULCOMETER® Compact Controller....................... 102
12 Technical data on DULCOMETER® Compact Controller.................................... 103
12.1 Permissible ambient conditions................................................................ 103
12.2 Dimensions and weights.......................................................................... 103
12.3 Material data............................................................................................. 104
12.4 Chemical Resistance................................................................................ 104
12.5 Sound Pressure Level.............................................................................. 104
13 Electrical data..................................................................................................... 105
Table of contents
5

14 Spare parts and accessories.............................................................................. 109
15 Replacing spare part units ................................................................................. 110
15.1 Replacing the top part of the housing....................................................... 110
15.2 Replacing the lower part of the housing (wall/tube retaining bracket)...... 112
15.3 Replacing the lower part of the housing (control panel installation)......... 115
16 Standards complied with and Declaration of Conformity.................................... 118
17 Disposal of used parts........................................................................................ 119
18 Index................................................................................................................... 120
Table of contents
6

1 Identity code
DCCa DULCOMETER® Compact,
Mounting type
E Spare part units
W Wall/pipe mounting IP 67
S With fitting kit for control panel mounting IP 54
Design
00 With ProMinent® logo
E1 Spare part unit, controller housing lower part (processor/PCB), fully
assembled
E2 Spare part unit, controller housing top part (processor/PCB), fully
assembled
Operating voltage
6 90 … 253 V, 48/63 Hz
Measured variable
C0 Free chlorine
NG pH/ORP (switchable)
L3 Conductive conductivity (designation: COND_C)
L6 Inductive conductivity (designation: COND_I)
Hardware extension
0 None
Approvals
01 CE (Standard)
Certificates
0 None
Operating instructions language
EN German KR Korean
Identity code
7

DCCa DULCOMETER® Compact,
EN English LT Lithuanian
ES Spanish LV Latvian
IT Italian NL Dutch
FR French PL Polish
FI Finish PT Portuguese
BG Bulgarian RO Romanian
ZH Chinese SV Swedish
CZ Czech SK Slovakian
EL Greek SL Slovenian
HU Hungarian RU Russian
YES Japanese TH Thai
Identity code
8

2 Introduction
Data and functions
These operating instructions describe the
technical data and functions of the
DULCOMETER® Compact Controller,
measured variable: Inductive conductivity
2.1 Measured variables
The controller can process the following
measured variables:
nInductive conductivity
[ConI]
nResistance [RES]
nTDS value [TDS]
nSalinity [SAL]
Switching between measured variables
Use the key to switch between the con‐
troller's measured variables [ConI] , [RES] ,
[TDS] and [SAL] in the continuous display.
Depending on the measured variable set,
the settings of variables are changed or
the variables are hidden completely in the
[INPUT Ø TCOMP] menu and in the
[LIMIT] menu.
Measured variable: Inductive conductivity
[ConI]
Symbol displayed in the controller's dis‐
play: [ConI]
Units of measurement: μS/cm, mS/cm ,
S/cm. The measuring range is automati‐
cally detected and switched by the con‐
troller
Physical variable: specific electrical con‐
ductivity (K). Only this measured variable
and the correction variable
‘Temperature’
are emitted at the mA output, independ‐
ently of the measured variable set on the
controller. The setting of the measured
variable on the controller only affects the
layout of the display and not the output at
the mA output.
Measured variable: Resistance [RES]
Symbol displayed in the controller's dis‐
play: [RES]
Units of measurement: MΩcm, kΩcm,
Ωcm. The measuring range is automati‐
cally detected and switched by the con‐
troller
Physical variable: specific electrical resist‐
ance.
Calculating the specific resistance: ρ (Tref)
= 1/K (Tref)
Introduction
9

Measured variable: TDS value
Symbol displayed in the controller's dis‐
play: [TDS] (total dissolved solids)
Unit of measurement: ppm (mg/l)
Physical variable: Total of all inorganic
and organic substances dissolved in a sol‐
vent
Display range: 0 …. 2000 ppm
Temperature range: 0 … 35 °C
[TLIMIT↑] : ≤ 40 °C
Setting the TDS value displayed: You can
set a multiplicative factor
[TDS] in the
[INPUT] menu, with which the TDS value
displayed can be changed.
Displayed TDS value
[ppm] = К (25 °C)
[uS/cm] * TDS factor
Setting range of TDS factor: 0.400 …
1.000 (Default: 0.640)
Temperature compensation is always
linear on the TDS display with a reference
temperature of 25 °C.
Measured variable: Salinity (SAL)
Symbol displayed in the controller's dis‐
play: [SAL] units: ‰ (g/kg)
Physical variable: Mass of salts in one kg
of water given in PSU (practical salinity
units).
The salinity is derived from the conduc‐
tivity measured, with a specified non-
linear temperature compensation and a
reference conductivity (KCL).
Display range: 0 …. 70.0 ‰
Temperature range: 0 … 35 °C
[TLIMIT↑] : ≤ 35 °C
The salinity [SAL] is calculated based on
the
[Practical Salinity Scale 1978 (PSS-78)]
Introduction
10

3 Safety and responsibility
3.1 Labelling of Warning Infor‐
mation
Introduction
These operating instructions provide infor‐
mation on the technical data and functions
of the product. These operating instruc‐
tions provide detailed warning information
and are provided as clear step-by-step
instructions.
The warning information and notes are
categorised according to the following
scheme. A number of different symbols
are used to denote different situations.
The symbols shown here serve only as
examples.
DANGER!
Nature and source of the danger
Consequence: Fatal or very
serious injuries.
Measure to be taken to avoid this
danger.
Description of hazard
– Denotes an immediate threat‐
ening danger. If the situation is
disregarded, it will result in
fatal or very serious injuries.
WARNING!
Nature and source of the danger
Possible consequence: Fatal or
very serious injuries.
Measure to be taken to avoid this
danger.
– Denotes a possibly hazardous
situation. If the situation is dis‐
regarded, it could result in fatal
or very serious injuries.
CAUTION!
Nature and source of the danger
Possible consequence: Slight or
minor injuries. Material damage.
Measure to be taken to avoid this
danger.
– Denotes a possibly hazardous
situation. If the situation is dis‐
regarded, it could result in
slight or minor injuries. May
also be used as a warning
about material damage.
Safety and responsibility
11

NOTICE!
Nature and source of the danger
Damage to the product or its sur‐
roundings.
Measure to be taken to avoid this
danger.
– Denotes a possibly damaging
situation. If the situation is dis‐
regarded, the product or an
object in its vicinity could be
damaged.
Type of information
Hints on use and additional infor‐
mation.
Source of the information. Addi‐
tional measures.
– Denotes hints on use and
other useful information. It
does not indicate a hazardous
or damaging situation.
3.2 General Safety Information
WARNING!
Live parts!
Possible consequence: Fatal or
very serious injuries
– Measure: Disconnect the
mains power supply prior to
opening the housing
– De-energise damaged, defec‐
tive or manipulated units by
disconnecting the mains plug
WARNING!
Unauthorised access!
Possible consequence: Fatal or
very serious injuries
– Measure: Ensure that there
can be no unauthorised
access to the unit
Safety and responsibility
12

WARNING!
Operating errors!
Possible consequence: Fatal or
very serious injuries
– The unit should only be oper‐
ated by adequately qualified
and technically expert per‐
sonnel
– Please also observe the oper‐
ating instructions for control‐
lers and fittings and any other
component groups, such as
sensors, measuring water
pumps ...
– The operator is responsible for
ensuring that personnel are
qualified
CAUTION!
Electronic malfunctions
Possible consequence: Material
damage to destruction of the unit
– The mains connection cable
and data cable should not be
laid together with cables that
are prone to interference
– Measure: Take appropriate
interference suppression
measures
NOTICE!
Correct and proper use
Damage to the product or its sur‐
roundings
– The unit is not intended to
measure or regulate gaseous
or solid media
– The unit may only be used in
accordance with the technical
details and specifications pro‐
vided in these operating
instructions and in the oper‐
ating instructions for the indi‐
vidual components
NOTICE!
Correct sensor operation / Run-in
time
Damage to the product or its sur‐
roundings
– Correct measuring and dosing
is only possible if the sensor is
working perfectly
– It is imperative that the run-in
times of the sensors are
adhered to
– The run-in times should be
allowed for when planning ini‐
tial operation
– It may take a whole working
day to run-in the sensor
– Please read the operating
instructions for the sensor
Safety and responsibility
13

NOTICE!
Correct sensor operation
Damage to the product or its sur‐
roundings
– Correct measuring and dosing
is only possible if the sensor is
working perfectly
– Check and calibrate the
sensor regularly
NOTICE!
Compensation of control deviations
Damage to the product or its sur‐
roundings
– This controller cannot be used
in control circuits which require
rapid compensation (< 30 s)
3.3 Intended Use
NOTICE!
Intended Use
The device is designed to measure
and regulate liquid media. The
designated measured variable is
detailed on the controller and is
absolutely binding.
The unit should only be used in
accordance with the technical data
and specifications provided in
these operating instructions and in
the operating instructions for the
individual components (such as
sensors, fittings, calibration
devices, metering pumps etc.).
Any other uses or modifications
are prohibited.
NOTICE!
Compensation for control devia‐
tions
Damage to the product or its sur‐
roundings
– The controller can be used in
processes, which require com‐
pensation of > 30 seconds
Safety and responsibility
14

3.4 User qualification
WARNING!
Danger of injury with inadequately qualified personnel
The operator of the system / equipment is responsible for ensuring that the qualifi‐
cations are fulfilled.
If inadequately qualified personnel work on the unit or loiter in the hazard zone of
the unit, this could result in dangers that could cause serious injuries and material
damage.
– All work on the unit should therefore only be conducted by qualified per‐
sonnel.
– Unqualified personnel should be kept away from the hazard zone.
The pertinent accident prevention regulations, as well as all other generally
acknowledged safety regulations, must be adhered to.
Training Definition
Instructed personnel An instructed person is deemed to be a person who has been
instructed and, if required, trained in the tasks assigned to him
and possible dangers that could result from improper behav‐
iour, as well as having been instructed in the required protective
equipment and protective measures.
Trained user A trained user is a person who fulfils the requirements made of
an instructed person and who has also received additional
training specific to the system from the manufacturer or another
authorised distribution partner.
Trained, qualified
personnel
A trained, qualified employee is deemed to be a person who is
able to assess the tasks assigned to him and recognize pos‐
sible hazards based on his training, knowledge and experience,
as well as knowledge of pertinent regulations. A trained, quali‐
fied employee must be able to perform the tasks assigned to
him independently with the assistance of drawing documenta‐
tion and parts lists. The assessment of a person's technical
training can also be based on several years of work in the rele‐
vant field.
Safety and responsibility
15

Training Definition
Electrical technician An electrical technician is able to complete work on electrical
systems and recognise and avoid possible dangers independ‐
ently based on his technical training and experience as well as
knowledge of pertinent standards and regulations. An electrical
technician must be able to perform the tasks assigned to him
independently with the assistance of drawing documentation,
parts lists, terminal and circuit diagrams. The electrical techni‐
cian must be specifically trained for the working environment in
which the electrical technician is employed and be conversant
with the relevant standards and regulations.
Service The Service department refers to service technicians, who have
received proven training and have been authorised by the man‐
ufacturer to work on the system.
Safety and responsibility
16

4 Functional description
Brief functional description
The controller for the measured variable
inductive conductivity provides the basic
functions for water treatment applications.
The controller has a fixed configuration
with the following features:
nLanguage-independent operation.
Use of abbreviations, such as:
–
[INPUT]
– [OUTPUT]
– [CONTROL]
– [ERROR]
nIlluminated display
n3 LEDs indicate the operating sta‐
tuses:
–
[f-REL] , active
– [P-REL] , active
– Error
nControl characteristics:
– P, or
– PID
nSelectable control direction:
– Raise measured value, or
– Lower measured value
nPulse frequency relay
[f-REL] for con‐
trol of the metering pump
nOutput relay
[P-REL] , configurable as:
– Alarm
– Limit value
– Pulse width-modulated (PWM)
control output for metering pumps
nAnalog output 0/4…20 mA, configu‐
rable:
– Measured value (conductivity
only), or
– Correction variable
nPriming function for all actuators
nDigital input to switch off the controller
or to process a sample water limit
contact by remote control
nTemperature sensor input (Pt 100 or
Pt 1000) for temperature compensa‐
tion
nDegree of protection
– IP67 (wall / pipe mounting)
– IP54 (control panel mounting)
Applications:
nBleeding of for example air scrubbers
and chillers
nGeneral water treatment, for instance,
the monitoring of rinsing baths
Functional description
17

5 Assembly and installation
5.1 Scope of delivery
The following parts belong to the standard scope of delivery of a DULCOMETER® Com‐
pact Controller.
Description Quantity
Assembled device 1
Cable connection set DMTa/DXMa (metr.) 1
Operating instructions 1
5.2 Assembly and installation
nUser qualification, mechanical instal‐
lation: trained qualified personnel, see
Ä Chapter 3.4 ‘User qualification’
on page 15
nUser qualification, electrical installa‐
tion: Electrical technician, see
Ä Chapter 3.4 ‘User qualification’
on page 15
CAUTION!
Possible consequence: Material
damage.
The hinge between the front and
rear part of the housing cannot
absorb high levels of mechanical
loading. When working on the con‐
troller, hold the top section of the
controller housing firmly.
NOTICE!
Mounting position and conditions
– Only carry out the (electrical)
installation after the (mechan‐
ical) installation
– Ensure that there is unim‐
peded access for operation
– Ensure safe and low-vibration
fixing
– Avoid direct sunlight
– Permissible ambient tempera‐
ture of the controller at the
installation location: - 10 ...
60℃ at max. 95 % relative air
humidity (non-condensing)
– Take into consideration the
permissible ambient tempera‐
ture of the sensors connected
and other components
Assembly and installation
18

Read-off and operating posi‐
tion
– Install the unit in a favourable
position for reading and opera‐
tion (preferably at eye level)
Mounting position
– Leave sufficient free space for
the cables
Packaging material
Dispose of packaging material in
an environmentally responsible
way. All packaging components
carry the corresponding recycling
code .
Assembly and installation
19

5.3 Assembly (mechanical)
The DULCOMETER® Compact Controller is suitable for mounting on a wall, pipe or con‐
trol panel.
Tab. 2: Mounting materials (contained in the scope of delivery):
Description Quantity
Wall/tube retaining bracket 1
Half-round head screws 5x45 mm 2
Washer 5.3 2
Rawlplug Ø 8 mm, plastic 2
5.3.1 Wall mounting
Mounting (mechanical)
2
1
A0273
Fig. 1: Removing the wall/pipe bracket
1. Remove the wall/pipe bracket. Pull
the two snap-hooks (1) outwards
and push upwards
2. Fold out the wall/pipe bracket (2)
and pull out in a downwards direc‐
tion
3. Mark two drill holes diagonal to
each other by using the wall/pipe
bracket as a drilling template
4. Drill holes: Ø 8 mm, d = 50 mm
A0274
Fig. 2: Screwing on the wall/pipe bracket
using washers
Assembly and installation
20
