protech BC-2602 Series User manual

USER
MANUAL
BC-2602
Industrial Rack Mount System
with Intel®9th /8th Gen. Core™
i7 / i5 /i3/ Pentium®/Celeron®/
Xeon®E-2200 /2100 CPU
BC-2602 M1

BC-2602
Industrial Rack Mount System with Intel®9th/
8th Gen. CoreTM i7/i5/i3/ Pentium®/ Celeron®
/ Xeon® E-2200 / 2100 CPU Processor
COPYRIGHT NOTICE & TRADEMARK
All trademarks and registered trademarks mentioned herein are the
property of their respective owners.
This manual is copyrighted in Jun. 2020. You may not reproduce or
transmit in any form or by any means, electronic, or mechanical,
including photocopying and recording.
DISCLAIMER
This user’smanual is meant to assist users in installing and setting up
the system. The information contained in this document is subject to
change without any notice.
CE NOTICE
This is a class A product. In a domestic environment this product may
cause radio interference in which case the user may be required totake
adequate measures.

FCC NOTICE
This equipment has been tested and found to comply with the limits for
a Class A digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is
likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
You are cautioned that any change or modifications to the equipment
not expressly approve by the party responsible for compliance could
void your authority to operate such equipment.
CAUTION: Danger of explosion may occur when the battery
is incorrectly replaced. Replace the battery
only with the
same or equivalent type recommended by the manufacturer.
Dispose of used batteries according to the manufacturer’s
instructions.
CAUTION:
Always touch the board components by the
edges. Never touch components such as a processor by its
pins. Take special cares while you are holding electronic
circuit boards by the edges only. Do not touch the board
components.
WARNING: Some internal parts of the board may have high
electrical voltage. We strongly recommend that only qualified
engineers are allowed to service
and disassemble the
system. If any damages should occur and are caused by
unauthorized servicing, it will not be covered by the product
warranty.

i
Contents
1Introduction ......................................................................................... 1-1
1.1 About This Manual .................................................................... 1-2
2Getting Started .................................................................................... 2-1
2.1 Package List.............................................................................. 2-2
2.2 System Overview ...................................................................... 2-3
2.2.1 Front View ......................................................................... 2-3
2.2.2 Rear View .......................................................................... 2-3
2.2.3 Side View........................................................................... 2-4
2.2.4 Quarter View...................................................................... 2-4
2.3 BC-2602 System Specifications ................................................ 2-5
2.4 Safety Precautions .................................................................... 2-8
3Hardware Configuration ..................................................................... 3-1
3.1 External I/O Ports Diagram ....................................................... 3-2
3.2 Jumper & Connector Quick Reference Table............................ 3-3
3.3 Main Board Component Locations............................................ 3-5
3.3.1 Top View ............................................................................ 3-5
3.3.2 Main Board Jumper Setting............................................... 3-6
3.3.3 Main Board Bottom View................................................... 3-7
3.3.4 Main Board I/O View.......................................................... 3-8
3.4 How To Set Jumpers ................................................................. 3-9
3.5 Setting Connectors and Jumpers............................................ 3-11
3.5.1 COM1 and COM2 Port (COM1, COM2).......................... 3-11
3.5.2 COM3, COM4, COM5, COM6 Connector (COM3 ~ COM6)
......................................................................................... 3-12

ii
3.5.3 COM3 and COM4 Pin9 Definition Selection Guide (JPCOM3,
JPCOM4)......................................................................... 3-13
3.5.4 Programmable GPIO Pin Header (JDIO1) ......................3-14
3.5.5 PS/2 Keyboard & Dual USB 2.0 Port (KB_MS_USB) ..... 3-15
3.5.6 DisplayPort (DP1, DP2)...................................................3-16
3.5.7 VGA (Video Graphics Array) Port (VGA1) ....................... 3-17
3.5.8 Front Panel Connector (JFP1) ........................................3-18
3.5.9 LAN & USB Port (LAN1_USB1, LAN2_USB2)................3-19
3.5.10 Line In, Line Out, Mic In Port (AUDIO1) .......................... 3-22
3.5.11 Embedded Display Port (EDP) Connector (EDP1) ......... 3-23
3.5.12 Front Panel Audio Connector (JAUDIO1) .......................3-24
3.5.13 Hardware Power Failure Selection (JP_AT1).................. 3-25
3.5.14 PCH Configuration / Recovery Selection (JP2)...............3-26
3.5.15 Flash Descriptor Override Selection (JP3) ......................3-27
3.5.16 VCCIO Voltage Selection (JP6).......................................3-28
3.5.17 USB Standby +5V / Normal Power Selection (JP7) ........3-29
3.5.18 Parallel Port (LPT) Connector (LPT1) ............................. 3-30
3.5.19 I2C Wafer (JI2C1, JI2C2) ................................................ 3-31
3.5.20 Case Open Connector (JP5) ........................................... 3-31
3.5.21 Mini PCI Express Slot (For C246/Q370 Only) (M_PCIE1)
......................................................................................... 3-32
3.5.22 M.2 M-Key Slot (M2_SSD) .............................................. 3-33
3.5.23 PCIE Bus (PCI_E1 (x16), PCI_E2 (x4), PCI_E3 (x4), PCI_E4
(x4), PCI_E5 (x1))............................................................3-35
3.5.24 PCI Bus Slot (PCI1, PCI2)...............................................3-45
3.5.25 CPU / System Fan Connector (CPU_FAN1, SYS_FAN1,
SYS_FAN2) ..................................................................... 3-47
3.5.26 Serial ATA (SATA) Connector (SATA1 ~ SATA6).............3-48
3.5.27Internal USB 3.1 Connector (USB1)................................ 3-50

iii
3.5.28 Internal USB 2.0 Connector (USB2, USB3, USB4)......... 3-51
3.5.29 Speaker Connector (JSPK1) ...........................................3-52
3.5.30 Power Input Connector (ATX_PWR1, ATX_PWR2)........ 3-53
3.5.31 Low Pin Count (LPC) Connector (JLPC1).......................3-54
3.5.32 Clear Cmos Data Selection (JCMOS1) ........................... 3-55
3.5.33 NMI Header (JNMI1) ....................................................... 3-55
3.5.34 Flash Bios Header (JSPI_1)............................................ 3-56
3.5.35 APS Header (JAPS1) ......................................................3-56
3.5.36 Micro SIM Card Socket (SIM1)........................................ 3-57
4Software Utilities ................................................................................. 4-1
4.1 Introduction................................................................................ 4-2
4.2 Installing Intel®Chipset Software Installation Utility .................. 4-3
4.3 Installing Graphics Driver Utility ................................................ 4-4
4.4 Installing LAN Driver Utility........................................................ 4-5
4.5 Installing Sound Driver Utility .................................................... 4-6
4.6 Intel®Management Engine Components Driver Installer
Installation ................................................................................. 4-7
4.7 Installing RAID Utility (Only for C246/Q370, Optional).............. 4-8
4.8 Installing Intel®Serial I/O Driver Utility .................................... 4-13
5BIOS SETUP ........................................................................................ 5-1
5.1 Introduction................................................................................ 5-2
5.2 Accessing Setup Utility.............................................................. 5-3
5.3 Main........................................................................................... 5-6
5.4 Advanced .................................................................................. 5-8
5.4.1 Advanced – CPU Configuration ........................................ 5-9

iv
5.4.2 Advanced – PCH-FW Configuration................................5-10
5.4.3 Advanced – Trusted Computing ...................................... 5-11
5.4.4 Advanced – ACPI Settings ..............................................5-12
5.4.5 Advanced – Hardware Monitor........................................ 5-13
Smart Fan Mode Configuration ...................................................5-14
5.4.6 Advanced – Super IO Watchdog .....................................5-15
5.4.7 Advanced – S5 RTC Wake Settings................................5-16
5.4.8 Advanced – Super IO Configuration................................5-17
Super IO Configuration – Serial Port 1 Configuration ................. 5-18
Super IO Configuration – Serial Port 2 Configuration .................5-19
Super IO Configuration – Serial Port 3 Configuration ................. 5-20
Super IO Configuration – Serial Port 4 Configuration .................5-21
Super IO Configuration – Serial Port 5 Configuration (For
Q370/C246 SKU Only) ................................................................5-22
Super IO Configuration – Serial Port 6 Configuration (For
Q370/C246 SKU Only) ................................................................5-23
Super IO Configuration – Parallel Port Configuration .................5-24
5.4.9 Advanced – USB Configuration....................................... 5-25
5.4.10 Advanced – NVMe Configuration .................................... 5-26
5.4.11 Advanced – Network Stack Configuration....................... 5-27
5.5 Chipset .................................................................................... 5-29
5.5.1 Chipset – System Agent (SA) Configuration ...................5-30
System Agent (SA) Configuration – Memory Configuration ........ 5-31
System Agent (SA) Configuration – Graphics Configuration.......5-32
System Agent (SA) Configuration – PEG Port Configuration...... 5-33
5.5.2 Chipset – PCH IO Configuratioin.....................................5-34
PCH-IO Configuration – PCI Express Configuration................... 5-35
PCH-IO Configuration – PCI Express Configuration – PCI Express
x4 – SLOT#2 (For Q370 / C246 SKU Only) ................................ 5-36

v
PCH-IO Configuration – PCI Express Configuration – PCI Express
x4 – SLOT#3(For Q370 / C246 SKU Only) ................................ 5-37
PCH-IO Configuration – PCI Express Configuration – PCI Express
x4 – SLOT#4 ............................................................................... 5-38
PCH-IO Configuration – PCI Express Configuration – PCI Express
x1 – SLOT#5(For Q370 / C246 SKU Only) ................................ 5-40
PCH-IO Configuration – PCI Express Configuration – Mini PCI
Express x1 Slot (For Q370 / C246 SKU Only) ............................5-41
PCH-IO Configuration – PCI Express Configuration – SATA
Configuration ............................................................................... 5-42
5.6 Security ................................................................................... 5-44
5.7 Boot ......................................................................................... 5-46
5.8 Save & Exit.............................................................................. 5-47
Appendix A Technical Summary ................................................A-1
BA-2602 Block Diagram ...........................................................................A-2
Interrupt Map ............................................................................................A-3
I/O MAP ..................................................................................................A-16
Memory Map...........................................................................................A-18
DMA Map ................................................................................................A-19
Configuring WatchDog Timer .................................................................A-20
Flash BIOS Update.................................................................................A-22

vi
Revision History
The revision history of BC-2602 User Manual is described below:
Version No.
Revision History
Date
M1
Initial Release
2020/06/04

BC-2602 SERIES USER MANUAL
Page: 1-1
1 Introduction
This chapter provides the introduction for the BC-2602
system as well as the framework of the user manual.
The following topic is included:
•About This Manual

Chapter 1 Introduction
BC-2602 SERIES USER MANUAL
Page: 1-2
1.1 About This Manual
Thank you for purchasing our BC-2602 system. The BC-2602 provides faster
processing speed, greater expandability and can handle more tasks than before. This
manual is designed to assist you how to install and set up the whole system. It
contains 5 chapters and 1 appendix. Users can configure the system according to their
own needs. This user manual is intended for service personnel with strong hardware
background. It is not intended for general users.
The following section outlines the structure of this user manual.
Chapter 1 Introduction
This chapter provides the introduction for the BC-2602 system as well as the
framework of the user manual.
Chapter 2 Getting Started
This chapter describes the package contents and outlines the system specifications.
Read the safety reminders carefully on how to take care of your system properly.
Chapter 3 Hardware Configuration
This chapter provides the external I/O Ports diagram, outlines the locations of the
mainboard components and their respective functions. You will learn how to set the
jumpers and configure the system to meet your own needs.
Chapter 4 Software Utilities
This chapter contains helpful information for proper installations of the Intel Chipset
Software Installation Utility, Graphics Driver Utility, LAN Driver Utility, Sound
Driver Utility, Intel®Management Engine Components Driver Installer, Intel®Rapid
Storage Utility and Intel®Serial I/O Driver Utility.
Chapter 5 BIOS Setup
This chapter indicates you how to change the BIOS configurations.
Appendix A Technical Summary
This appendix provides the information about the allocation maps for the block
diagram, system resources, Watchdog Timer Configuration and Flash BIOS Update.

BC-2602 SERIES USER MANUAL
Page: 2-1
2 Getting Started
This chapter provides the information for the BC-2602
system. It describes the package contents and outlines the
system specifications.
The following topics are included:
•Package List
•System Overview
•System Specification
•Safety Precautions
Experienced users can go to Chapter 3 Hardware
Configuration on page 3-1 for a quick start.

Chapter 2 Getting Started
BC-2602 SERIES USER MANUAL
Page: 2-2
2.1 Package List
If you discover any of the items listed below are damaged or lost,
please contact your local distributor immediately.
Item
Q’ty
BC-2602
1
Quick Reference Guide
1
Manual / Driver DVD
1
Mini Jumper (2 mm)
6

Chapter 2 Getting Started
BC-2602 SERIES USER MANUAL
Page: 2-3
2.2 System Overview
2.2.1 Front View
2.2.2 Rear View

Chapter 2 Getting Started
BC-2602 SERIES USER MANUAL
Page: 2-4
2.2.3 Side View
Unit: mm
2.2.4 Quarter View
177

Chapter 2 Getting Started
BC-2602 SERIES USER MANUAL
Page: 2-5
2.3 BC-2602 System Specifications
System
CPU Support LGA1151 socket for Intel®9th / 8th Gen. Core™ i7 / i5 /
i3 / Pentium®/ Celeron®desktop CPU
Xeon®E-2200 / E-2100 server CPU
CPU List Xeon
®
: E-2278GE(GEL), E-2276GE, E-2176G,
E-2124G
9th CoreTM:i7-9700E(TE), i5-9500E(TE), i3-9100E(TE)
8th CoreTM:i7-8700(T), i5-8500(T), i3-8100(T)
Pentium®:G5400, G5400T
Celeron®:G4900, G4900T
Chipset Intel®C246 (supports Xeon®/ Core™ / Pentium®/
Celeron®CPU)
Intel®Q370 / H310 (supports Core™ / Pentium®/
Celeron®CPU)
Memory Support
4 x DIMM sockets, supporting 2400/2666MHz DDR4
(up to 64GB) (C246/Q370)
2 x DIMM sockets, supporting 2400/2666MHz DDR4
(up to 32GB) (H310)
Supports ECC (C246)/non-ECC (C246/Q370/H310)
BIOS AMI UEFI BIOS
Power Supply ATX 500W power
Dimensions 430 x 331.3 x 177mm (W x D x H)
O.S. Support Windows®10 IoT Enterprise
Certifications CE / FCC
I/O Ports
SATA Interface
C246 and Q370 SKU: 6 x SATA III (6.0Gb/s) with
RAID 0,1,5,10
H310 SKU: 4 x SATA III (6.0Gb/s) without RAID
USB
C246/Q370 H310
Total (Max.) 12 10
I/O LAN1_USB1 2xUSB 3.1 Gen2 2xUSB 3.1 Gen1
LAN2_USB2 2xUSB 3.1 Gen1 2xUSB 2.0
KB_MS_USB 2xUSB 2.0 2xUSB 2.0
Internal USB_1 2xUSB 3.1 Gen1 2xUSB 3.1 Gen1
USB_2 2xUSB 2.0 2xUSB 2.0
USB_3 2xUSB 2.0 N/A

Chapter 2 Getting Started
BC-2602 SERIES USER MANUAL
Page: 2-6
Serial Ports
C246/Q370 H310
Total 6 4
I/O,
D-sub COM1 RS232
COM2 RS232/422/485 selectable under BIOS
Internal,
Pitch
2.0mm
header
COM3 5V and 12V selectable by jumper
COM4
COM5 RS232 N/A
COM6
Parallel Port 1 x LPT connector
LAN
Dual LAN (2 x RJ45)
LAN1: Intel®PHY 219LM (GbE)
LAN 2: Intel®LAN 211AT (GbE)
Supports Wake-On-LAN & PXE
FAN 1 x CPU fan, 2 x system fans
Keyboard / Mouse
1 x PS/2 Combo connector for keyboard & mouse
Note: PS/2 Keyboard can work alone. If customer intends to insert
PS/2 Keyboard and Mouse simultaneously, the enclosed PS/2
extension cable in the package must be used.
Audio Mic In / Line In / Line Out
Expansion Bus
C246/Q370 H310
1st slot PCIeX16 PCIeX16
2nd slot PCIeX4 N/A
3rd slot PCIeX4 N/A
4th slot PCIeX4 PCIeX4
5th slot PCIeX1 N/A
6th slot PCI PCI
7th slot PCI PCI
M_PCIE1 Mini PCIe N/A
M.2 Slot 1 x M.2 slot, NVMe up to PCIeX4, support 2242 &
2260, Co-lay with 4th PCIe slot
SIM Slot 1 x SIM slot, to be used together with 3G or 4G/LTE
M.2 module. Support Micro SIM card
LPC 1 x LPC pin header for TPM module

Chapter 2 Getting Started
BC-2602 SERIES USER MANUAL
Page: 2-7
Display
Flexible Display
Standard SKU: 1 x VGA, 2 x DP
C246/Q370 support triple independent display
H310 supports dual independent display
VGA

1 x VGA up to 1920 x 1200 @60Hz (default)
DP
2 x DP up to 4096 x 2304 @60Hz (default)
Others
I2C
2 x I2C 4-pin wafer
Front Panel LED Indicator

HDD LED, Power LED, Power Switch
TPM on board (option)
Co-lay TPM1.2 / TPM2.0 chip (optional)
Shock

15G peak-to-peak, 11ms duration, non-operation
Vibration
Non-operation: 2G, 5-200Hz, X, Y, Z axis
Environment
Operating Temp.
0°C ~ 40°C (32°F ~ 104°F)
Storage Temp.

-40°C ~ 85°C (-40°F ~ 185°F)
Operation Humidity
20%~ 90% (non-condensing)

Chapter 2 Getting Started
BC-2602 SERIES USER MANUAL
Page: 2-8
2.4 Safety Precautions
Before operating this system, read the following information carefully to protect your
systems from damages, and extend the life cycle of the system.
1. Check the Line Voltage
•The operating voltage for the power supply should be within the range of
100V to 240V AC; otherwise, the system may be damaged.
2. Environmental Conditions
•Place your BC-2602 on a sturdy, level surface. Be sure to allow enough
space around the system to have easy access needs.
•Avoid installing your BC-2602 system in extremely hot or cold places.
•Avoid direct sunlight exposure for a long period of time (for example, in a
closed car in summer time. Also avoid the system from any heating device.).
Or do not use BC-2602 when it has been left outdoors in a cold winter day.
•Avoid moving the system rapidly from a hot place to a cold place, and vice
versa, because condensation may occur inside the system.
•Protect your BC-2602 from strong vibrations which may cause hard disk
failure.
•Do not place the system too close to any radio-active device. Radio-active
device may cause signal interference.
•Always shut down the operating system before turning off the power.
3. Handling
•Avoid placing heavy objects on the top of the system.
•Do not turn the system upside down. This may cause the hard drive to
malfunction.
•Do not allow any objects to fall into this device.
•If water or other liquid spills into the device, unplug the power cord
immediately.
4. Good Care
•When the outside case gets stained, remove the stains using neutral washing
agent with a dry cloth.
•Never use strong agents such as benzene and thinner to clean the surface of
the case.
•If heavy stains are present, moisten a cloth with diluted neutral washing
agent or alcohol and then wipe thoroughly with a dry cloth.
•If dust is accumulated on the case surface, remove it by using a special
vacuum cleaner for computers.
