superbrightleds MWP-40K20 User manual

Mini LED Wall Pack
Important: Read all instructions prior to installation. MWP-40K20, MWP-40K20-S
MWP-50K20, MWP-50K20-S
User Manual
Part Number:
Wall and Conduit Installation Instructions
Rev Date: V1 10/13/2017Rev Date: V1 10/13/2017
Mini LED Wall Pack
User Manual
Part Number:
5yr
1. Remove power from circuit.
2. Remove 2 plastic thumb screws from both sides of the light. Remove
mounting bracket from light. Peel adhesive  lm from Foam Gasket and
stick to mounting bracket, while lining up the cut-outs.
3. Drill 2 holes on the wall using bracket as a guide for holes. Drive wall anchors
into holes. Attach mounting bracket to wall using 2 screws (not provided).
4. Remove knockout from bottom of light. Pull wires from conduit through
knockout and make wire connections to main supply. Attach conduit
onto light.
5. Attach light to bracket and
tighten 2 plastic thumb screws.
8.61in
218.81mm
5.33in
135.48mm
.84in
21.34mm
2.90in
73.72mm
5.05in
128.19mm
4.84in
122.94mm
MWP-40K20, MWP-40K20-S, MWP-50K20, MWP-50K20-S

MWP-40K20, MWP-40K20-S
MWP-50K20, MWP-50K20-S
MWP-40K20, MWP-40K20-S
MWP-50K20, MWP-50K20-S
User Manual
Part Number:
User Manual
Part Number:
J-Box Installation Instructions
Mini LED Wall Pack Mini LED Wall Pack
Important: Read all instructions prior to installation. Important: Read all instructions prior to installation.
1. Remove power from circuit.
2. Remove 2 plastic thumb screws from both sides of the light. Remove
mounting bracket from light. Peel adhesive lm from Foam Gasket and
stick to mounting bracket, lining up the cut-outs.
Specications
Included Parts Dimensional Drawings
Wire Diagram
Warnings
1 - Mini LED Wall Pack
1 - Foam Gasket
Bracket Dimensions
Mini Wall Pack Dimensions
THIS FIXTURE MUST BE WIRED IN
ACCORDANCE WITH THE NATIONAL
ELECTRIC CODE AND APPLICATION
LOCAL CODES OR ORDINANCES.
ALL WORK SHOULD BE PERFORMED
BY A QUALIFIED ELECTRICIAN.
Rev Date: V1 10/13/2017Rev Date: V1 10/13/2017
MWP-40K20 / MWP-40K20-S /
MWP-50K20 / MWP-50K20-S
Intensity 2300 lm
Operating Voltage Range 100~277 VAC
Total Power Consumption 20 Watts
Current Draw 200mA @ 120VAC
Color Temperature 4000K,5000K
Beam Angle 110 degree
CRI >80
IP Rating IP65
Power Factor >0.90
Dimmable No
Weight 1.81 lbs (0.82kg)
Standards And Certications UL
Warranty 5 year
3. Mount bracket to J-box with 2 screws
(not included). Pull wires from J-box
through bracket.
4. Use slots to temporarily hang light on
mounting bracket to J-box. Make wire
connections to main supply. Push connected
wires through bracket into J-box.
Note: Wire connections can stay within light.
5. Mount light on bracket. Secure with 2
plastic thumb screws on both sides.
8.61in
218.81mm
5.33in
135.48mm
.84in
21.34mm
2.90in
73.72mm
5.05in
128.19mm
4.84in
122.94mm
8.61in
218.81mm
5.33in
135.48mm
.84in
21.34mm
2.90in
73.72mm
5.05in
128.19mm
4.84in
122.94mm
1.23in
31.24mm
.74in
18.80mm
5.13in
130.18mm
.66in
16.80mm
.20in
4.96mm
1.25in
31.75mm
2.72in
69.08mm
3.46in
87.88mm
3.94in
100mm
Line
Neutral
Ground
Black
L L
N N
GND GND
White
Green
