Pulsar ISF108 User manual

1
ISF108
v1.0
Industrial switch ISF108 (8xPoE, 2xCombo)
PL
Edition: 1 z dnia 16.01.2020
Supercedes the edition: --------------- EN
Features:
10 ports switch
8 PoE ports 10/100Mb/s, (1÷8 ports) (data and power
supply)
2 ports 10/100/1000Mb/s (G1/TP, G2/TP ports ) (UpLink)
2 ports 10/100/1000Mb/s SFP (G1/SFP, G2/SFP ports)
30 W for each PoE port, supports devices complaint with
the IEEE802.3af/at standard
Supports auto-learning and auto-aging of MAC addresses
(16K size)
Possibility of redundant power supply
Mounting on a DIN rail (TH35)
LED indication
warranty –2 year from the production date
Example of use.
1. Technical description
1.1. General description.
ISF108 is a 10-ports PoE switch designed to supply IP cameras operating in IEEE 802.3af/at standard.
Automatic detection of any devices powered in the PoE standard is enabled at the 1 –8 ports of the switch. The G1/TP and
G2/TP ports is used for connection of another network device via RJ45 connector. The switch is fitted with SFP slots (marked as
G1/SFP and G2/SFP), the use of fiber optic module (GBIC) allows fiber optic transmission. Device has solutions that allow it to
be powered from two sources (emergency power supply, redundant power supply) –in case of a failure of one source, it
immediately switches to backup one.
The LEDs at the front panel indicate the operation status (description in the table 3). The PoE technology ensures a
network connection and reduces installation costs by eliminating the need to supply a separate power cable for each device.
This method allows supplying other network devices, such as IP phone, wireless access point or router.

2
1.2 Block diagram.
Fig. 1. Block diagram.
1.3 Description of components and connectors.
Table 1. (See Fig. 2)
Component No.
(Fig. 2)
Description
[1]
8 x PoE ports (1÷8)
[2]
2 x UPLINK ports (G1/TP, G2/TP)
[3]
2 x UPLINK ports (G1/SFP, G2/SFP)
[4]
Power Socket (V1/V2)
[5]
Holder for DIN rail
Fig. 2. The view of the switch.

3
1.4 Technical parameters
Table 2.
Ports
8 x PoE (10/100 Mb/s) (RJ-45)
2 x UPLINK (10/100/1000 Mb/s) (RJ-45)
2 x UPLINK (10/100/1000 Mb/s) (SFP)
with connection speed auto-negotiation and MDI/MDIX Auto Cross)
PoE power supply
IEEE 802. 3af/at (1÷8 ports), 52 V DC / 30 W at each port *
Protocols, Standards
IEEE802.3, 802.3u, 802.3x CSMA/CD, TCP/IP
Bandwidth
5,6 Gbps
Transmission method
Store-and-Forward
Optical indication of
operation
Switch power supply;
Link/Act;
PoE Status
Power supply
Switch: 12-57 V DC; 2,3 A max.
PoE: 48-57 V DC; 2,3 A max.
Self-power consumption
5 W max.
Operating conditions
temperature -30°C ÷ 70°C,
relative humidity 5% - 90%, no condensation
Dimensions
W=54, H=176, H1=10, D=153, D1=8 [+/- 2 mm]
Gross/Net weight
0,9/1,1 kg
Protection class
EN 60950-1:2007
I (first)
Storage temperature
-30°C ÷ 70°C
Declarations
CE
*The given value of 30 W per port is the maximum value. The total power consumption should not exceed 120 W.
2. Installation
2.1. Requirements
The unit should be mounted in confined spaces, in accordance with the 2nd environmental class, with normal relative
humidity (RH=90% maximum, without condensation) and temperature from -30°C to +70°C. Ensure the free flow of air around
the unit. The PSU shall work in a vertical position that guarantees sufficient convectional air-flow through ventilating holes of the
enclosure.
The switch load balance should be done before installation. Depending on application, appropriate power supply should
be selected, PoE available only at 48-57 V (52 V recommended). The given value of 30 W per port is the maximum value
referring to a single output. The total power consumption should not exceed 120 W. The increased demand for power is
particularly evident in the case of cameras with heaters or infrared illuminators - when launching these features, the power
consumption increases rapidly, which may adversely affect the operation of the switch. As the device is designed for a
continuous operation and is not equipped with a power-switch, therefore an appropriate overload protection in the power supply
circuit should be provided. The electrical system shall be made in accordance with applicable standards and regulations.
2.2. Installation procedure
1. Connect switch to power supply unit(s), paying attention to polarization and other parameters.
2. Connect the power supply(s) to the 230 V socket.
3. Connect the camera wires to the RJ45 connectors (sockets RJ45 from 1 to 8).
4. Connect the remaining LAN devices to RJ45 connectors or SFP socket (G1/TP and G1/SFP or G2/TP and G2/SFP)
CAUTION! G1/TP and G1/SFP or G2/TP and G2/SFP connectors can not operate simultaneously!
5. Check the optical indication of switch operation (see Table 3).

4
Connection schemes
3. Operation indication (see Table 3).
Table 3. Operation indication
OPTICAL INDICATION OF THE SWITCH's POWER SUPPLY
GREEN LED LIGHT (Power)
Indication of the switch's power
supply
OFF –no power supply of the switch
ON –power supply on, normal operation
OPTICAL INDICATION AT THE PoE PORTS (1÷8)
GREEN LED LIGHT (PoE)
Indication of the PoE power supply
at the RJ45 ports
OFF- no power supply at the RJ45 port (the device is not connected or not compliant with
the IEEE802.3af/at standard)
ON –power supply
Blinking –short-circuit or output overload
YELLOW LED LIGHT (LINK)
The connection status of LAN
devices 10/100Mb/s
and data transmission
OFF- no connection
ON - the device is connected 10/100Mb/s
Blinking –data transmission
OPTICAL INDICATION AT THE UP LINK PORTS (G1/TP, G2/TP, G1/SFP, G2/SFP)
YELLOW
LED LIGHT
(LINK)
OFF- no connection
ON - the device is connected
Blinking –data transmission
CAUTION! The operating status of the G1/TP, G1/SFP, G2/TP and G2/SFP slots is shown
on the LEDs located near the RJ45 connector (see below).
CAUTION! G1/TP and G1/SFP or G2/TP and G2/SFP sockets can not operate
simultaneously.
These are COMBO type sockets.
GREEN
LED LIGHT
(SPEED)
OFF –connection 10Mb/s or 100Mb/s
ON - connection 1000Mb/s
CAUTION! The operating status of the G1/TP, G1/SFP, G2/TP and G2/SFP slots is shown
on the LEDs located near the RJ45 connector (see below).
CAUTION! G1/TP and G1/SFP or G2/TP and G2/SFP sockets can not operate
simultaneously.
These are COMBO type sockets.

5
WEEE LABEL
Waste electrical and electronic equipment must not be disposed of with normal household waste.
According to the European Union WEEE Directive, waste electrical and electronic equipment should be
disposed of separately from normal household waste .
