Pulsar VD57 User manual

CAL. V657, VD57
CHRONOGRAPH
ENGLISH
TIME/CALENDAR
CHRONOGRAPH
●Hour, minute and second hands
●Date displayed in numerals
●Measures up to 60 minutes in 1/10 second increments.
●Split time measurement

English
2a: Normal position c: Second click
a b c
b: First click
CHRONOGRAPH
second hand
DISPLAY AND CROWN/BUTTONS
CROWN
B
CHRONOGRAPH
minute hand
Second hand
Date
A
Minute hand
CHRONOGRAPH
1/10-second hand
Hour hand

English
3
SCREW DOWN CROWN
[for models with screw down crown]
Locking the crown
1Turn Crown counterclockwise until you no
longer feel the threads turning.
2Crown can be pulled out.
1Push Crown back in to normal position.
2Turn Crown clockwise while pressing it lightly
until tight.
Unlocking the crown

English
4
●Before setting the time, be sure to check that the CHRONOGRAPH hands are in
“0” position when the chronograph is reset. (For resetting the chronograph, see
“CHRONOGRAPH” on page 6)
ADJUSTING CHRONOGRAPH HAND POSITION
* If any of the CHRONOGRAPH hands do not return to “0” position, follow the
procedure below to reset the hands.
Pull out to second click.
CROWN
CROWN Push back in to normal
position.
B
A
CROWN
Press repeatedly to reset
CHRONOGRAPH 1/10-
second hand to “0” position.
BPress repeatedly to reset
CHRONOGRAPH second
and minute hands to “0”
position.
A
▲
▲
▲

English
5
TIME/CALENDAR SETTING
123
4
5
1Pull out to first click, and turn clockwise until the previous day’s date
appears.
2Pull out to second click when Second hand is at the 12 o’clock position.
3Turn clockwise until the desired date appears.
4Turn to set Hour and Minute hands.
5Push back in to normal position in accordance with a time signal.
CROWN

English
6
CHRONOGRAPH
CHRONOGRAPH
minute hand
✩After the measurement exceeds 1 minute, the CHRONOGRAPH 1/10-
second hand stays at “0” position.
When the measurement is stopped, it will move to indicate the elapsed 1/10
seconds.
CHRONOGRAPH
1/10-second hand AStart / Stop / Restart
CHRONOGRAPH
second hand BReset /
Split /Split release
Ex.: 15 minutes and 10.6 seconds
✩

English
7
1Use the stopwatch to determine
how many seconds it takes to go
1 km or 1 mile.
2Locate the second marker on the
main dial that corresponds to the
measured seconds, and the
tachymeter scale it indicates gives
the average speed per hour.
TACHYMETER
[for models with tachymeter scale on the dial]
To measure the hourly average speed of a vehicle
▲
Ex. 1
“90” (tachymeter scale figure) x
1 (km or mile) = 90 km/h or mph
Tachymeter
scale: “90”
Tachymeter scale can be used only when the time required is less than 60 seconds.
Ex. 2: If the measuring distance is extended to 2 km or miles or shortened to
0.5 km or miles and CHRONOGRAPH second hand indicates “90” on
CHRONOGRAPH
second hand:
40 seconds

English
8
To measure the hourly rate of operation
1Use the stopwatch to measure the
time required to complete 1 job.
2Locate the second marker on the
main dial that corresponds to the
measured seconds, and the
tachymeter scale it indicates gives
the average number of jobs
accomplished per hour.
Ex. 1
▲
“180” (tachymeter scale figure) x
1 job = 180 jobs/hour
CHRONOGRAPH
second hand:
20 seconds
Tachymeter
scale: “180”
Ex. 2: If 15 jobs are completed in 20 seconds:
“180” (tachymeter scale figure) x 15 jobs = 2700 jobs/hour
tachymeter scale:
“90” (tachymeter scale figure) x 2 (km or mile) = 180 km/h or mph
“90” (tachymeter scale figure) x 0.5 (km or mile) = 45 km/h or mph

English
9
ADJUSTING CHRONOGRAPH HAND POSITION
●The “0” position of the CHRONOGRAPH 1/10-second hand differs depending on the
models.
NOTES ON OPERATING THE WATCH
●The CHRONOGRAPH minute hand moves correspondingly with the CHRONOGRAPH
second hand.
●The hands move quickly if the respective buttons are kept pressed.
TIME/CALENDAR SETTING
●Do not set the date between 9:00 p.m. and 1:00 a.m. Otherwise, the date may not
change properly.
●When setting the hour hand, be sure to check that AM/PM is correctly set. The watch
is so designed that the date changes once in 24 hours.
* Turn the hands past the 12 o’clock marker to determine whether the watch is set for
the A.M. or P.M. period. If the date changes, the time is set for the A.M. period. If
not, the time is set for the P.M. period.
* Some models have the “0” position of the CHRONOGRAPH 1/10-second hand at 3
and 9 o’clock sides of the small dial. In that case, check if the hand is level with its
both ends pointing to those “0” positions.
●When setting the minute hand, first advance it 4 to 5 minute ahead of the desired time
and then turn it back to the exact minute.

English
10
●While the crown is at the second click, do not press the buttons. Otherwise, the
CHRONOGRAPH hands will move. To reset them to “0” position, see “ADJUSTING
CHRONOGRAPH HAND POSITION” on page 4.
CHRONOGRAPH
●While the chronograph is counting, do not pull out the crown to set the time. Otherwise,
the chronograph operation cannot be made.
●The CHRONOGRAPH 1/10-second scale and hand differ in design and shape depending
on the models.
* Some models have the CHRONOGRAPH 1/10-second scale graduated on the upper
half of the small dial and the hand which is so designed that both ends can indicate
the elapsed 1/10 second. In that case, read the marker on the scale where either end
of the hand points to.
