Pulseeight Neo 1-2 User manual

B C

HDMI Output - Connect the appropriate high speed HDMI cable to each output. These cables should then be

directly connected to each Sink device. (TV/Ampliﬁer etc.)

5V DC is used with the supplied power adapter to connect the power.

HDMI Input: Connect the appropriate high speed HDMI cable to the input. This cable should then be

connected to the Source device. (Blu-Ray player etc.)

QUICK START GUIDE

neo 1-2 HDMI Splitter (P8-HDMI-SP2)

CHECK WHAT’S INSIDE THE BOX

IMPORTANT!

• 1 x neo:1-2 HDMI Splitter • 1 x Power Supply Adapter • 1 x Quick Start Guide

• Please read the instructions before attempting to install or operate this equipment.

• Visit the help.pulse-eight.com to download the latest product manual, additional documentation, and

conﬁguration tools.

PANEL DESCRIPTIONS

This installation guide helps you to install and use your Pulse-Eight neo 1-2 HDMI

Splitter for the ﬁrst time.

Go to help.pulse-eight.com for additional information on this product including

important technical information not provided in this document and warranty terms

& conditions.

SCAN FOR HELP

1. Connect the HDMI cable from your video source (e.g. Blu-Ray player) to the HDMI input of the neo HDMI splitter.

2. Connect sink devices directly (i.e. TV) to the HDMI Outputs via high speed HDMI cables.

3. Insert the supplied power adapter to the neo HDMI splitter and plug it into the AC mains.

4. Ensure the sink devices are powered on before powering on the splitter.

5. Turn ON the AC mains.

Please read the full manual instructions before attempting to install or operate this equipment.

Please keep the following in mind as you unpack and install this equipment:

• Always follow basic safety precautions to reduce the risk of ﬁre, electrical shock, and injury.

• To prevent ﬁre or shock hazards, do not expose the unit to rain, or moisture or install this product near water.

• Never spill liquid of any kind on or into this product.

• Where possible, install the splitter towards the top of the rack to avoid the unit overheating.

• Only use the supplied IEC cable.

• Never push any objects into this product through any openings or empty slots in the unit as you may damage parts inside

and/or cause an electrical shock.

• Do not allow anything to rest on the power cabling and avoid putting the weight of any kind on it.

• To protect the unit from overheating do not block any vents or openings in the unit housing that provides ventilation. Allow

suﬃcient space for air to circulate around the unit.

• This product is intended for use in a clean (dust-free) residential environment.

INSTALLATION

SAFETY PRECAUTION
