P8-HDMI2-4KDS
INSTALLATION GUIDE
HDMI UHD 18GBPS
DOWNSCALER

The 4K Downscaler downscales video from 4K to 1080p. It can be
used with a video matrix or splitter where there are 4K sources and
a mix of 4K and 1080p TVs.
HDMI UHD 18GBPS DOWNSCALER
P8-HDMI2-4KDS
INSTALLATION
1Connect a HDMI cable between Downscaler “HDMI OUT” and TV.
2Connect a HDMI cable between Downscaler “HDMI IN” and Video
Source.
3For S/PDIF audio output, connect an Optical cable between the
“Optical Out” port and Audio device.*
4Plug in power jack to “DC 5V” port.
5Power on power adapter.
* Optical Audio will not output if audio has more than 6 channels.
STATUS LED INDICATOR
Red Powering on. This may take a few seconds.
Yellow Detected a change in the video signal and conguring
Green Congured and healthy. Video and audio will be output.
EDID CONTROL
The rotating switch controls the functionality of the Downscaler.
To set a particular mode:
1Power OFF the Downscaler.
2Using a small at head screwdriver, turn the arrow to the
desired mode number.
3Power ON the Downscaler.
0Use saved EDID after copying from a TV using mode 1
1Copy EDID from a TV and save it. Switch to 0 after saving EDID
2Use EDID prole 4K, HDR, 8 Channel Audio
3Use EDID prole 4K, HDR, 6 Channel Audio
4Use EDID prole 4K, HDR, 2 Channel Audio
5Use EDID prole 4K, No HDR, 8 Channel Audio
6Use EDID prole 4K, No HDR, 6 Channel Audio
7Use EDID prole 4K, No HDR, 2 Channel Audio
8-F Reserved. No function.
* Optical Audio will not output if audio has more than 6 channels.
TECHNICAL
ASelector Wheel
BHDMI In
C5V Power
DOptical Out
EHDMI Out
FLED Indicator
A
F
B
E
C
D

SAFETY PRECAUTIONS
• Please read all instructions before attempting to install or operate this
equipment.
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury.
• To prevent re or shock hazard, do not expose the unit to rain, moisture
or install this product near water and never spill liquid of any kind on or
into this product.
•Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts inside
the unit. Do not allow anything to rest on the power cabling or allow
any weight to be placed upon it.
• Use only the supplied power supply unit (PSU). Do not use the PSU if it
is damaged.
DISCLAIMERS
The information in this manual has been carefully checked and is believed
to be accurate, however, Pulse-Eight Limited assumes no responsibility
for any inaccuracies that may be contained in this document. Pulse-Eight
Limited also makes no commitment to update or to keep current the
information contained in this document. Pulse-Eight Limited reserves the
right to make improvements to this document and/or product at any time
and without notice. Pulse-Eight Limited assumes no responsibility for any
infringements of patents or other rights of third parties which may result
from its use.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted, transcribed,
stored in a retrieval system, or any of its part translated into any language
or computer le, in any form or by any means (electronic, mechanical,
magnetic, optical, chemical, manual, or otherwise) without express written
permission and consent from Pulse-Eight Limited.
© Copyright 2018 Pulse-Eight Limited. All Rights Reserved.
TRADEMARK ACKNOWLEDGEMENTS
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.
