PureLink PM Series User manual

PM Series Fiber Optic Extenders
Owner’s Manual
PM Series Fiber Optic Standalone and Wall-plate type Extender
PureLinkTM
535 East Crescent Ave
Ramsey NJ 07446, USA
Tel: [phone]
Fax: [phone]
Website : www.purelinkav.com
E-mail : [e-mail]
For Technical Support, contact us at
[e-mail]

PureLink by Dtrovision
2
TABLE OF CONTENTS
Chapter 1. Introduction
1.1 Safety Precautions --------------------------------------------------------------------------- 3
1.2 Product Introduction -------------------------------------------------------------------------- 4
1.3 Package Contents ----------------------------------------------------------------------------- 4
Chapter 2. Features and Specifications
2.1 Features ----------------------------------------------------------------------------------------- 5
2.2 Transmitter Specifications ------------------------------------------------------------------ 6
PM-FT101 --------------------------------------------------------------------------------------- 6
PM-FT102 --------------------------------------------------------------------------------------- 8
PM-FT103 --------------------------------------------------------------------------------------- 9
Transmitters Compatibility Chart ----------------------------------------------------------- 12
2.3 Receiver Specifications ---------------------------------------------------------------------- 13
PM-FR101 -------------------------------------------------------------------------------------- 13
PM-FR102 -------------------------------------------------------------------------------------- 14
PM-FR103 -------------------------------------------------------------------------------------- 16
Receivers Compatibility Chart ------------------------------------------------------------- 19
2.4 Operation and Reliability Specification --------------------------------------------------- 20
Chapter 3. Installation and Operating Instruction
3.1Installation --------------------------------------------------------------------------------------- 21
3.2Operating Instruction -------------------------------------------------------------------------- 21
3.3Cable Termination ----------------------------------------------------------------------------- 23
3.4Connector Pin Assignment ------------------------------------------------------------------ 24
Chapter 4. Additional Information
4.1 Warranty ------------------------------------------------------------------------------------------ 26
4.2 FCC/CE Statement --------------------------------------------------------------------------- 27

PureLink by Dtrovision
3
Chapter 1. Introduction
1.1 Safety Precautions
When using and installing Dtrovision PureLink product, adhere to the following basic safety
precautions.
Read and understand all instructions before using and installing this product.
The safety and operating instructions should be retained for future reference.
Always use the correct external power supply (indicated on the product label) when
operating this unit.
Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners
or aerosol cleaners. Use a damp cloth for cleaning.
Mishandling of this product may lead to a fire or explosion hazard.
Do not place any heavy objects or equipment on top of the product.
Keep away from wet, magnetic, and flammable surfaces or substances.
Air vents should be kept clean and unobstructed at all times.
Any external impact may cause damage to the operation of this unit.
Be sure this product is properly grounded (earthed) in order to prevent the risk of
electrical shock.
Turn off and unplug power before adding or removing Input/Output Boards.
Input/Output Boards may be damaged when they are replaced with power turned on.
Use surge protectors and/or AC line conditioners when powering this product.
Only use a fuse(s) with the correct fuse rating in your enclosure.
Make sure the product is on or attached to a stable surface.
If you experience any malfunctioning of product or have any question as to operation
of the product, please contact our customer service center.
PureLinkTM
Tel: [phone]
Email: [e-mail]

PureLink by Dtrovision
4
1.2Product Introduction
Pure fiber optic cable for video, audio, and control signal
PM series Fiber Optic (2 LC) extension system is designed to transmit video (DVI, HDMI
or VGA), audio (Embedded or analog stereo audio), control (RS232/422 and IR) over a
pure LC to LC fiber optic cable for long distance up to 6,600ft. This optical connection
enables to minimize electrical noise and EMI free that is ideal for long distance extension
of high definition HDMI/DVI or VGAvideo signal, HDMI embedded audio or 3.5mm
stereo analog audio, and control signal.
1.3Package Contents
Please make sure all of the following items are included in the package:
1) One of PM-FT101, FT102, FT103 Transmitter Module or
2) One of PM-FR101, FR102, FR103 Receiver Module
3) 5pin Phoenix Connector for RS-232/422
4) DC 12V Power Supply Unit with a Power Cord

PureLink by Dtrovision
5
Chapter 2. Features and Specifications
2.1Features
▶Transmitters directly compatible with PM Fiber Optic Input Board
PM Fiber Optic (2 LC) Transmitters can send signal directly to PM series Matrix
Router's Fiber Optic Input Board, eliminating the need of matching Receiver.
▶Receivers directly compatible with PM Fiber Optic Output Board
PM Fiber Optic (2 LC) Receivers can receive signal directly from PM series Matrix
Router's Fiber Optic Output Board, eliminating the need of matching Transmitter.
▶HDMI v1.4, 3D Support
Adopting latest HDMI version 1.4 enables to support 3D, 48-Bit Deep Color, 4K x 2K
resolution and 7.1 Channel Dolby TruHD & DTS MasterHD
▶Auto-EDID (EDID Library, Emulation)
PureLink's EDID library and emulation features failsafe EDID capture & storage to
provide constant and continuous EDID for source devices.
▶HDCP Compliant
▶Various Transmitter and Receiver Choices
There are three different type of transmitters and three different type of receivers to
make today's sophisticated digital AV environment simple and flexible.
▶RF6 1RU Rack Mountable Version Available
PM-FT101, PM-FT102, PM-FR101, and PM-FR102 are also available in PureLink's
popular RF6 Rack Mountable Extension Center Modules.
▶Analog Support (VGA and Component)
On PM-FT102 and PM-FT103 series, there are two video inputs; DVI/HDMI and VGA,
which are selectable via front panel button or serial command when it is connected PM
series Matrix Router. VGA port is designed to take component (YPbPr) signal with
appropriate adapters or cables.
▶USB Firmware Update
▶Long Distance Transmission up to 6,600ft (2,000 m)

PureLink by Dtrovision
6
▶Plug-N-Play
▶Resolutions up to WUXGA 1920x1200, HD 1080p @ 60Hz, and 4K2K
▶Integrated Noise-cancellation and Error-correct Logic for both Input and Output
Ports to prevent any damage caused by Electrical Noise.
2.2Specifications
Transmitters :
PM-FT101 : Standalone type (Loop Through)
Input: HDMI + 3.5mm stereo audio (x1) + RS-232/422
Output: Fiber Optic (2 LC) and HDMI Loop-Through
6,600ft, Compatible with PM-FIS4 input board
Front Connection Ports:
Power S/W: Power On/Off switch
Power LED: Power status indicator
Status LED: Video signal presence indicator
HDMI LED: HDMI signal indicator
EDID save S/W: EDID save button
EDID select S/W: EDID library function selection rotary switch
Firmware: USB firmware update port

PureLink by Dtrovision
7
Back Connection Ports:
HDMI/DVI In: HDMI/DVI input port
HDMI/DVI Out: HDMI/DVI Loop-thru output port
Audio In: Stereo audio input port
2 LC: Fiber Optic output port
RS-232/422: RS-232/422 communication port
DC In: DC 12V Power port
Model Name
PM-FT101 (HDMI version), PM-FT102-D (DVI version)
Input Signal
DVI / HDMI (TMDS)
3.5mm stereo audio
Output Signal
Fiber Optical Output ( > -10dbm (after 6,600ft (2km) transmission))
DVI / HDMI (Loop-thru)
Extinction Ratio
> 4db (after 6,600ft (2km) transmission)
Data Transmission
Speed
3.4 Gbps/ch, Total 10.2 Gbps Max
Supporting Display
Resolutions
PC: VGA ~ WUXGA
(up to 1920 x 1200 @60Hz)
HDTV: 480i ~ 1080p, 2K4K
Max. Distance
Single Mode Fiber: 1920 x 1200 @ 60Hz or at 1080p : 6,600 ft (2km)
Multi Mode Fiber: 1920 x 1200 @ 60Hz or at 1080p : 1,650 ft (500m)
Connector Type
DVI 29P/HDMI 19P Female (x 2)
3.5mm Stereo Jack
2 LC Optical Connector
3P /3.5MM Terminal Block (for Power)
5P /3.5MM Terminal Block (for RS-232/422)
Mini USB (for firmware update)
Conformations
DVI 1.0 , HDMI 1.4
HDCP Compliance
Yes
Power Rating
DC +12V, 4Watts Max
Dimension
6.3' x 4.4' x 1.7' (160 x 112 x 42 mm)
Weight
1.43 lbs (0.65 Kg)

PureLink by Dtrovision
8
PM-FT102 : Standalone type (2x1 switch)
Input: Selectable HDMI/DVI or VGA + 3.5mm stereo audio (x2) +
RS-232/422
Output: Fiber Optic (2 LC)
6,600ft, Compatible with PM-FIS4 input board
Front Connection Ports:
Power S/W: Power On/Off switch
Power LED: Power status indicator
Status LED: Video signal presence indicator
HDMI LED: HDMI signal indicator
VGA LED: VGA(or component) signal indicator
EDID save S/W: EDID save button
EDID select S/W: EDID library function selection rotary switch
Firmware: USB firmware update port
Back Connection Ports:
HDMI/DVI In: HDMI/DVI input port
VGA In: VGA (or component) input port
Audio In: Stereo audio input port
2 LC: Fiber Optic output port
RS-232/422: RS-232/422 communication port
DC In: DC 12V Power port

PureLink by Dtrovision
9
Model Name
PM-FT102 (HDMI version), PM-FT102-D (DVI version)
Input Signal
DVI / HDMI (TMDS), VGA (supports YPbPr component)
3.5mm stereo audio
Output Signal
Fiber Optical Output ( > -10dbm (after 6,600ft (2km) transmission))
Extinction Ratio
> 4db (after 6,600ft (2km) transmission)
Data Transmission
Speed
3.4 Gbps/ch, Total 10.2 Gbps Max
Supporting Display
Resolutions
PC: VGA ~ WUXGA
(up to 1920 x 1200 @60Hz)
HDTV: 480i ~ 1080p, 2K4K
Max. Distance
Single Mode Fiber: 1920 x 1200 @ 60Hz or at 1080p : 6,600 ft (2km)
Multi Mode Fiber: 1920 x 1200 @ 60Hz or at 1080p : 1,650 ft (500m)
Connector Type
DVI 29P/HDMI 19P Female (x 2)
3.5mm Stereo Jack
2 LC Optical Connector
3P /3.5MM Terminal Block (for Power)
5P /3.5MM Terminal Block (for RS-232/422)
Mini USB (for firmware update)
Conformations
DVI 1.0 , HDMI 1.4
HDCP Compliance
Yes
Power Rating
DC +12V, 4Watts Max
Dimension
6.3' x 4.4' x 1.7' (160 x 112 x 42 mm)
Weight
1.43 lbs (0.65 Kg)
PM-FT103 : Wall plate type (2x1 switch), 2 Gang Decora style, white finish.
Input: Selectable HDMI or VGA + 3.5mm stereo audio (x1) + RS-232
Output: Fiber Optic (2 LC)
6,600ft, Compatible with PM-FIS4 input board

PureLink by Dtrovision
10
Front Connection Ports:
Power LED: Power status indicator
Status LED: Video signal presence indicator
HDMI LED: HDMI signal indicator
VGA LED: VGA(or component) signal indicator
EDID save S/W: EDID save button
EDID select S/W: EDID library function selection rotary switch
HDMI/DVI In: HDMI/DVI input port
VGA In: VGA (or component) input port
Audio In: Stereo audio input port
RS-232: RS-232 communication port
Back Connection Ports:
2 LC: Fiber Optic Output Port
DC In: DC 12V Power port
Model Name
PM-FT103
Input Signal
DVI / HDMI (TMDS), VGA (supports YPbPr component)
3.5mm stereo audio
Output Signal
Fiber Optical Output ( > -10dbm (after 6,600ft (2km) transmission))

PureLink by Dtrovision
11
Extinction Ratio
> 4db (after 6,600ft (2km) transmission)
Data Transmission
Speed
3.4 Gbps/ch, Total 10.2 Gbps Max
Supporting Display
Resolutions
PC: VGA ~ WUXGA
(up to 1920 x 1200 @60Hz)
HDTV: 480i ~ 1080p, 2K4K
Max. Distance
Single Mode Fiber: 1920 x 1200 @ 60Hz or at 1080p : 6,600 ft (2km)
Multi Mode Fiber: 1920 x 1200 @ 60Hz or at 1080p : 1,650 ft (500m)
Connector Type
HDMI 19P Female
VGA Female
3.5mm Stereo Jack
2 LC Optical Connector
3P /3.5MM Terminal Block (for Power)
3P /3.5MM Terminal Block (for RS-232)
Conformations
DVI 1.0 , HDMI 1.4
HDCP Compliance
Yes
Power Rating
DC +12V, 4Watts Max
Dimension
2 Gang Decora style, actual dimension will be updated
Weight
TBD
Transmitter Input Signal Characteristics
Input Signal
Description
Unit
Min
Typical
Max
Remarks
DC input
DC Voltage
VDC
11.5
12
12.5
Power
Consumption
Watts
13.5
13.8
14.4
VGA input
(15Pin)
Video Level
mVp-p
700
DVI input
(29Pin DVI)
Differential
Output
mVp-p
450
510
570
TMDS
Interface
HDMI input
(19Pin)
Differential
Output
mVp-p
400
600
TMDS
Interface

PureLink by Dtrovision
12
Transmitter Output Signal Characteristics
Output Signal
Symbol
Unit
Min
Typical
Max
Remarks
Emission
Center
Wavelength
Λc1
Λc2
nm
1260
1480
1310
1550
1360
1580
Analog Video Signal Supported Resolution
- 640*480 60Hz
- 1024*768 60Hz
- 720*480p 60Hz
- 640*480 72Hz
- 1024*768 70Hz
- 720*576p 50Hz
- 640*480 75Hz
- 1024*768 75Hz
- 1280*720p 60Hz
- 640*480 85Hz
- 1024*768 85Hz
- 1280*720p 50Hz
- 800*600 56Hz
- 1280*1024 60Hz
- 1920*1080i 60Hz
- 800*600 60Hz
- 1280*1024 75Hz
- 1920*1080i 50Hz
- 800*600 72Hz
- 1280*1024 85Hz
- 1920*1080p 60Hz
- 800*600 75Hz
- 1600*1200 60Hz
- 1920*1080p 50Hz
- 800*600 85Hz
- 1920*1200 60Hz
Digital Video Signal Supported Resolution:
- PC resolution: VGA ~ WUXGA @ 60Hz (1920 x 1200 @ 60Hz)
- HDTV resolution: 480i ~ 1080p @ 60Hz, 4K2K
PM Fiber Optic Transmitter Compatibility Chart
Transmitters
Compatibility
PM-FT101
PM-FT102
PM-FT103
PM Extender Compatibility
PM-FR101
PM-FR102
PM-FR103
PM-FR101
PM-FR102
PM-FR103
PM-FR101
PM-FR102
PM-FR103

PureLink by Dtrovision
13
RF6 Compatibility
PM-FR101-RF6
PM-FR102-RF6
PM-FR101-RF6
PM-FR102-RF6
PM-FR101-RF6
PM-FR102-RF6
PM Matrix Board
Compatibility
PM-FIS4
PM-FIS4
PM-FIS4
Receivers :
PM-FR101 : Standalone type.
Input: Fiber Optic (2 LC)
Output: HDMI + 3.5mm stereo audio + RS-232/422
6,600ft, Compatible with PM-FOS4 output board
Front Connection Ports:
Power S/W: Power On/Off switch
Power LED: Power status indicator
Status LED: Video signal presence indicator
Firmware: USB firmware update port
Back Connection Ports:
HDMI/DVI Out: HDMI/DVI output port
Audio Out: Stereo audio output port
2 LC: Fiber Optic Input port
RS-232/422: RS-232/422 communication port
DC In: DC 12V Power port

PureLink by Dtrovision
14
Model Name
PM-FR101 (HDMI version), PM-FR101-D (DVI version)
Input Signal
Fiber Optical Output ( > -10dbm (after 6,600ft (2km) transmission))
Extinction Ratio
> 4db (after 6,600ft (2km) transmission)
Output Signal
DVI / HDMI (TMDS)
3.5mm stereo audio
Data Transmission
Speed
3.4 Gbps/ch, Total 10.2 Gbps Max
Supporting Display
Resolutions
PC: VGA ~ WUXGA
(up to 1920 x 1200 @60Hz)
HDTV: 480i ~ 1080p, 2K4K
Max. Distance
Single Mode Fiber: 1920 x 1200 @ 60Hz or at 1080p : 6,600 ft (2km)
Multi Mode Fiber: 1920 x 1200 @ 60Hz or at 1080p : 1,650 ft (500m)
Connector Type
DVI 29P/HDMI 19P Female
3.5mm Stereo Jack
2 LC Optical Connector
3P /3.5MM Terminal Block (for Power)
5P /3.5MM Terminal Block (for RS-232/422)
Mini USB (for firmware update)
Conformations
DVI 1.0 , HDMI 1.4
HDCP Compliance
Yes
Power Rating
DC +12V, 2.0 Watts Max
Dimension
6.3' x 4.4' x 1.7' (160 x 112 x 42 mm)
Weight
1.43 lbs (0.65 Kg)
PM-FR102 : Standalone type. Built-in auto scaler
Input: Fiber Optic (2 LC)
Output: HDMI + 3.5mm stereo audio + RS-232/422
6,600ft, Compatible with PM-FOS4 output board

PureLink by Dtrovision
15
Front Connection Ports:
Power S/W: Power On/Off switch
LCD Display: 16*2 LCD display
▲▼◀▶:Menu navigation button
MENU: Menu and Enter button
EXIT: Cancel and Exit button
Back Connection Ports:
HDMI/DVI Out: HDMI/DVI output port
Audio Out: Stereo audio output port
2 LC: Fiber Optic Input port
RS-232/422: RS-232/422 communication port
DC In: DC 12V Power port
Model Name
PM-FR102 (HDMI version), PM-FR102-D (DVI version)
Input Signal
Fiber Optical Output ( > -10dbm (after 6,600ft (2km) transmission))
Extinction Ratio
> 4db (after 6,600ft (2km) transmission)
Output Signal
DVI / HDMI (TMDS)
3.5mm stereo audio
Data Transmission
Speed
3.4 Gbps/ch, Total 10.2 Gbps Max
Supporting Display
Resolutions
PC: VGA ~ WUXGA
(up to 1920 x 1200 @60Hz)
HDTV: 480i ~ 1080p, 2K4K

PureLink by Dtrovision
16
Max. Distance
Single Mode Fiber: 1920 x 1200 @ 60Hz or at 1080p : 6,600 ft (2km)
Multi Mode Fiber: 1920 x 1200 @ 60Hz or at 1080p : 1,650 ft (500m)
Connector Type
DVI 29P/HDMI 19P Female
3.5mm Stereo Jack
2 LC Optical Connector
3P /3.5MM Terminal Block (for Power)
5P /3.5MM Terminal Block (for RS-232/422)
Mini USB (for firmware update)
Conformations
DVI 1.0 , HDMI 1.4
Image Scaler
Sigma Design GF9452A
HDCP Compliance
Yes
Power Rating
DC +12V, 4 Watts Max
Dimension
6.3' x 5.7' x 1.7' (160 x 145 x 42 mm)
Weight
1.77 lbs (0.80 Kg)
User Control
6 Buttons Control (LCD and OSD)
PM-FR103 : Wall plate type, 2 Gang Decora style, white finish.
Input: Fiber Optic (2 LC)
Output: HDMI + 3.5mm stereo audio + RS-232
6,600ft, Compatible with PM-FOS4 output board
Front Connection Ports:
Power LED: Power status indicator
Status LED: Video signal presence indicator

PureLink by Dtrovision
17
HDMI Out: HDMI output port
Audio Out: Stereo audio output port
RS-232: RS-232 communication port
Back Connection Ports:
2 LC: Fiber Optic Input port
DC In: DC 12V Power port
Model Name
PM-FR103
Input Signal
Fiber Optical Output ( > -10dbm (after 6,600ft (2km) transmission))
Extinction Ratio
> 4db (after 6,600ft (2km) transmission)
Output Signal
DVI / HDMI (TMDS)
3.5mm stereo audio
Data Transmission
Speed
3.4 Gbps/ch, Total 10.2 Gbps Max
Supporting Display
Resolutions
PC: VGA ~ WUXGA
(up to 1920 x 1200 @60Hz)
HDTV: 480i ~ 1080p, 2K4K
Max. Distance
Single Mode Fiber: 1920 x 1200 @ 60Hz or at 1080p : 6,600 ft (2km)
Multi Mode Fiber: 1920 x 1200 @ 60Hz or at 1080p : 1,650 ft (500m)
Connector Type
HDMI 19P Female
3.5mm Stereo Jack
2 LC Optical Connector
3P /3.5MM Terminal Block (for Power)
3P /3.5MM Terminal Block (for RS-232)
Conformations
DVI 1.0 , HDMI 1.4
Image Scaler
Sigma Design GF9452A
HDCP Compliance
Yes
Power Rating
DC +12V, 2 Watts Max
Dimension
2 Gang Decora style, actual dimension will be updated
Weight
TBD

PureLink by Dtrovision
18
Receiver Input Signal Characteristics
Input Signal
Description
(Symbol)
Unit
Min
Typical
Max
Remarks
DC input
DC Voltage
VDC
11.5
12
12.5
Power
Consumption
Watts
13.5
13.8
14.4
Emission
Center
Wavelength
Λc1
Λc2
nm
1260
1480
1310
1550
1360
1580
Receiver Output Signal Characteristics
Output Signal
Description
Unit
Min
Typical
Input Signal
Remarks
HDMI Output
(19Pin)
Differential
Output
mVp-p
400
600
TMDS
Interface
Scaling Receiver (PM-FR102/PM-FR102-D) Supported Output Resolution
- Auto Time Set
- 1920*1080p 50Hz
- 1280*1024 75Hz
- 720*483p 59.94Hz
- 1920*1080p 59.94Hz
- 1280*1024 85Hz
- 720*576p 50Hz
- 1920*1080p 60Hz
- 1360*768 60Hz
- 1280*720p 50Hz
- 800*600 60Hz
- 1366*768 50Hz
- 1280*720p 59.94Hz
- 800*600 75Hz
- 1400*900 60Hz
- 1280*720p 60Hz
- 1024*768 60Hz
- 1600*1200 60Hz
- 1920*1080i 25(50)Hz
- 1024*768 75Hz
- 1920*1200 60Hz
- 1920*1080i 29.7(59.94)Hz
- 1024*768 85Hz
- 1920*1080p 60Hz
- 1920*1080i 30(60)Hz
- 1280*1024 60Hz
Scaling Receiver's Output resolution can be set via front panel control button or serial
command from PM Series Matrix Router.
OE:Output Extender Scaler Timing Select
The "OE" is an initiation command for Output Extender Scaler timing selection. The
characters and numbers that follow the "OE" command tell the system, set scaling

PureLink by Dtrovision
19
timing on selected Output. The last character “!” is found at the end of a command
code which tells the system to execute the command. For a complete list of command
characters and their functions, see examples below.
OE command only applies to the HDMI with scaling Board and CAT5e/Fiber Output
Board with PM-CR102 (CAT5e) and PM-FR102 (Fiber) Extender Receiver.
T00
Auto
T09
1080p (50Hz)
T18
SXGA (1280x1024@75Hz)
T01
480p (60Hz)
T10
1080p (59Hz)
T19
SXGA (1280x1024@85Hz)
T02
576p (50Hz)
T11
1080p (60Hz)
T20
UXGA (1600x1200@60Hz)
T03
720p (50Hz)
T12
SVGA (800x600@60Hz)
T21
1360x768@60Hz
T04
720p (59Hz)
T13
SVGA (800x600@75Hz)
T22
1366x768@60Hz
T05
720p (60Hz)
T14
XGA (1024x768@60Hz)
T23
1440x900@60Hz
T06
1080i (50Hz)
T15
XGA (1024x768@75Hz)
T24
1920x1200@60Hz
T07
1080i (59Hz)
T16
XGA (1024x768@85Hz)
T08
1080i (60Hz)
T17
SXGA (1280x1024@60Hz)
Example:
Command Codes
Action
*255OEO01T00!
Set Output 1 Extender Scaler timing to Auto
*255OEO02T11!
Set Output 2 Extender Scaler timing to 1080p
PM Fiber Optic Receiver Compatibility Chart
Receivers
Compatibility
PM-FR101
PM-FR102
PM-FR103
PM Extender Compatibility
PM-FT101
PM-FT102
PM-FT103
PM-FT101
PM-FT102
PM-FT103
PM-FT101
PM-FT102
PM-FT103
RF6 Compatibility
PM-FT101-RF6
PM-FT102-RF6
PM-FT101-RF6
PM-FT102-RF6
PM-FT101-RF6
PM-FT102-RF6
PM Matrix Board
Compatibility
PM-FOS4
PM-FOS4
PM-FOS4

PureLink by Dtrovision
20
Operation and Reliability Specification
1. Operating Environment
Temperature : 50F ~ 104F (10℃~ 40℃)
Humidity : 10% ~ 80%
Altitude : 3,000m Max.
2. Transit Environment
Temperature : -13F ~ 140F (-25℃~ 60℃)
Humidity : 5% ~ 95%
Altitude : 15,000m Max.
3. Storage Environment
Temperature : -4F ~ -49F (-20℃~ 45℃)
Humidity : 5% ~ 95%
Altitude : 3,000m Max.
4. Reliability
MTBF: 90% at over 50,000 hours aging test
In compliance with LCD Monitor reliability test standard
