PureLink PureMedia PM-CT101-U User manual

PureMedia 4K CATx (HDBaseT)
Extenders Owner’s Manual
PureMedia CATx (HDBaseT) Standalone and Wall-plate type Extender
PureLinkTM
535 East Crescent Ave
Ramsey, NJ 07446
Tel: [phone]
Fax: [phone]
Website : www.purelinkav.com
E-mail : [e-mail]
For Technical Support, contact us at
: [e-mail]

PureLink by Dtrovision
2
TABLE OF CONTENTS
Chapter 1. Introduction
1.1 Safety Precautions --------------------------------------------------------------------------- 3
1.2 Product Introduction -------------------------------------------------------------------------- 4
1.3 Package Contents ----------------------------------------------------------------------------- 4
Chapter 2. Features and Specifications
2.1 Features ----------------------------------------------------------------------------------------- 5
2.2 Transmitter Specifications ------------------------------------------------------------------ 7
PM-CT101-U-------------------------------------------------------------------------------------- 7
PM-CT102-U--------------------------------------------------------------------------------------- 9
PM-CT103-U---------------------------------------------------------------------------------------11
PM-CT104-U-------------------------------------------------------------------------------------- 13
Transmitters Compatibility Chart -----------------------------------------------------------15
2.3 Receiver Specifications ---------------------------------------------------------------------- 17
PM-CR101-U-------------------------------------------------------------------------------------- 17
PM-CR102-U-------------------------------------------------------------------------------------- 19
PM-CR103-U-------------------------------------------------------------------------------------- 21
PM-CR104-U-------------------------------------------------------------------------------------- 23
Receivers Compatibility Chart ------------------------------------------------------------- 25
2.4 Operation and Reliability Specification ---------------------------------------------------26
Chapter 3. Installation and Operating Instruction
3.1Installation --------------------------------------------------------------------------------------- 27
3.2Operating Instruction -------------------------------------------------------------------------- 27
3.3Cable Termination ----------------------------------------------------------------------------- 28
3.4Connector Pin Assignment ------------------------------------------------------------------ 29
Chapter 4. Additional Information
4.1 Warranty ------------------------------------------------------------------------------------------32
4.2 FCC/CE Statement ---------------------------------------------------------------------------33

PureLink by Dtrovision
3
Chapter 1. Introduction
1.1 Safety Precautions
When using and installing Dtrovision PureLink product, adhere to the following basic safety precautions.
Read and understand all instructions before using and installing this product.
The safety and operating instructions should be retained for future reference.
Always use the correct external power supply (indicated on the product label) when operating this
unit.
Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol
cleaners. Use a damp cloth for cleaning.
Mishandling of this product may lead to a fire or explosion hazard.
Do not place any heavy objects or equipment on top of the product.
Keep away from wet, magnetic, and flammable surfaces or substances.
Air vents should be kept clean and unobstructed at all times.
Any external impact may cause damage to the operation of this unit.
Be sure this product is properly grounded (earthed) in order to prevent the risk of electrical shock.
Turn off and unplug power before adding or removing Input/Output Boards.
Input/Output Boards may be damaged when they are replaced with power turned on.
Use surge protectors and/or AC line conditioners when powering this product.
Only use a fuse(s) with the correct fuse rating in your enclosure.
Make sure the product is on or attached to a stable surface.
If you experience any malfunctioning of product or have any question as to operation of
the product, please contact our customer service center.
Dtrovision LLC
Tel: [phone]
Email: [e-mail]

PureLink by Dtrovision
4
Welcome!
Congratulations on your purchase of the PureLink PureMedia CATx (HDBaseT) extender.
This manual contains information that will assist you in installing and operating the product.
1.2 Product Introduction
Single CATx (HDBaseT) cable for video, audio and control signal with POE
PureMedia CATx (HDBaseT) extension system is designed to transmit video (DVI, HDMI or VGA),
audio (Embedded or analog stereo audio), control (RS232), and power over a single CATx cable
for long distance up to 330ft. This CATx connection enables to minimize electrical noise and EMI
free that is ideal for long distance extension of high definition HDMI/DVI or VGA video signal, HDMI
embedded audio or 3.5mm stereo analog audio, and control signal with POE.
1.3 Package Contents
Please make sure all of the following items are included in the package:
1) One of PM-CT101-U, CT102-U, CT103-U,CT104-U Transmitter Module or
2) One of PM-CR101-U, CR102-U, CR103-U,CR104-U Receiver Module
3) 3pin Phoenix Connector for RS-232
4) DC 12V Power Supply Unit with a Power Cord
5) User’s Manual
6) Option Product:
- TWC6 (PureLink’s certified CATx cable with TotalWire Technology)
- PI (PureLink’s PureInstall HDMI cable with TotalWire Technology)

PureLink by Dtrovision
5
Chapter 2. Features and Specifications
2.1 Features
Zero loss & Zero noise delivery
Zero loss & zero noise delivery of digital high definition video and audio signal using
UTP connection, PureMedia CATx (HDBaseT) extender delivers HD signals over
CAT5/6/7-type cables without loss or digital interference maintaining the clarity and
colors. Noise cancellation and error correction logic enhances HD video and audio
signals over long distance.
Compact and Robust enclosure design
Compact and robust enclosure design allows for discreet installation behind a flat-panel display.
Designed based on HDBaseT Technology
Designed based on HDBaseT Technology, supporting support Deep Color and full 3D
support plus DTS-HD and Dolby TrueHD over a single low cost CATx interface with up to 330ft
(100m) at Ultra HD (4K) or 1920x1200 resolution.
Uncompressed high definition video up to 4K2K@30Hz@48bits and 3D
Bi-Directional RS232 interface
Commands and data can flow in both directions via RS232, allowing status requests
and control of the destination unit.
Max. Data Rate- 10.2 Gbps
HDCP (High-bandwidth Digital Content Protection) Support
Audio transmission support LPCM 7.1@192KHz, Dolby TrueHD, DTS-HD MA
Transmitters directly compatible with PureMedia CATx (HDBaseT) Input Board
PureMedia CATx (HDBaseT) Transmitters can send signal directly to PureMedia Matrix
Switcher's CATx (HDBaseT) Input Board, eliminating the need of matching Receiver.

PureLink by Dtrovision
6
Receivers directly compatible with PureMedia CATx (HDBaseT) Output Board
PureMedia CATx (HDBaseT) Receivers can receive signal directly from PureMedia Matrix
Switcher's CATx (HDBaseT) Output Board, eliminating the need of matching Transmitter.
HDMI v1.4, 3D Support
Adopting latest HDMI version 1.4 enables to support 3D, 48-Bit Deep Color, 4K x 2K resolution
and 7.1 Channel Dolby TruHD & DTS MasterHD
Real Time EDID
PureLink's real time EDID features failsafe, constant and continuous EDID for source devices.
Various Transmitter and Receiver Choices
There are three different type of transmitters and three different type of receivers to make
today's sophisticated digitalAV environment simple and flexible.
RF 1RU Rack Mountable Version Available
PM-CT101-U, PM-CT102-U, PM-CR101-U, and PM-CR102-U are also available in PureLink's
popular RF Rack Mountable Extension Center Modules.
Analog Support (VGA and Component)
On PM-CT102-U and PM-CT103-U series, there are two video inputs; DVI/HDMI and VGA,
which are selectable via front panel button or serial command when it is connected PureMedia
Matrix Switcher. VGA port is designed to take component (YPbPr) signal with appropriate
adapters or cables.
USB Firmware Update
Long Distance Transmission up to 330ft (100 m)
Plug-N-Play
POE
Only one power supply is necessary to power both devices.
When PureMedia CATx (HDBaseT) extenders are used with PureMedia Matrix Switcher CATx
(HDBaseT) Input and Output board, they can receive power from the Matrix Switcher.

PureLink by Dtrovision
7
2.2 Specifications
Transmitters :
PM-CT101-U : Standalone type
Input : HDMI + 3.5mm stereo audio (x1) + RS-232
Output : CATx (HDBaseT)
POE, 330ft, Compatible with PM-CIS4-U input board
PM-CT101-U : PureMedia HDMI to CATx (HDBaseT) Extender Transmitter
Front Connection Ports:
Power S/W: Power On/Off switch
Signal LED: Video signal presence indicator
Link LED: Link Status indicator
Firmware: USB firmware update port
Back Connection Ports:
HDMI/DVI In: HDMI/DVI input port
Audio In: Stereo audio input port
CATx: HDBaseT output port
RS-232: RS-232 communication port
DC In: DC 12V Power port

PureLink by Dtrovision
8
Model Name
PM-CT101-U
Input Signal
DVI / HDMI (TMDS),3.5mm stereo audio
Output Signal
HDBaseT0,1,2,3+/-
Data Transmission Speed
3.4 Gbps/ch, Total 10.2 Gbps Max
Supporting Display Resolutions
PC: VGA~ WUXGA (up to 1920 x 1200 @60Hz)
HDTV: 480i ~ 1080p,
Up to Ultra HD 4K
4096 x 2160 @ 24/25/30Hz
(RGB/YCbCr 4:4:4 8 bits, YCbCr 4:2:2 8/10/12 bits)
4096 x 2160 @50/60Hz (YCbCr 4:2:0 8 bits)
Max. Distance
1920 x 1200 @ 60Hz or at 1080p, Ultra HD 4K : 330 ft. (100m)
Connector Type
DVI 29P/HDMI 19P Female (x 1)
3.5mm Stereo Jack (x 1)
RJ-45 Jack
3P /3.5MM Terminal Block (for Power)
3P /3.5MM Terminal Block (for RS-232)
Conformations
DVI 1.0 , HDMI 1.4b, HDBaseT
HDCP Compliance
Yes, HDCP version 2.0
Power Rating
DC +12V, 10Watts Max
Dimensions (W x D x H)
5.75" x 4.5" x 1.25" (144.78 x 114.3 x 31.75 mm)
Weight
0.5 lbs. (0.23 Kg)

PureLink by Dtrovision
9
PM-CT102-U : Standalone type (2x1 switch)
Input : Selectable HDMI/DVI or VGA + 3.5mm stereo audio (x1) + RS-232
Output : CATx (HDBaseT)
POE, 330ft, Compatible with PM-CIS4-U input board
PM-CT102-U : PureMedia HDMI/VGA to CATx (HDBaseT) Extender Transmitter
Front Connection Ports:
Power S/W: Power On/Off switch
Signal LED: Video signal presence indicator
Link LED: Link Status indicator
HDMI LED: HDMI signal indicator
VGA LED: VGA (or component) signal indicator
VGA EDID : EDID save button for VGA input port
Firmware: USB firmware update port
Back Connection Ports:
HDMI/DVI In: HDMI/DVI input port
VGA In: VGA (or component) input port
Audio In: Stereo audio input port
CATx: HDBaseT output port
RS-232: RS-232 communication port
DC In: DC 12V Power port

PureLink by Dtrovision
10
Model Name
PM-CT102-U
Input Signal
DVI / HDMI (TMDS), VGA(supports YPbPr component)
3.5mm stereo audio
Output Signal
HDBaseT0,1,2,3+/-
Data Transmission Speed
3.4 Gbps/ch, Total 10.2 Gbps Max
Supporting Display Resolutions
PC: VGA~ WUXGA (up to 1920 x 1200 @60Hz)
HDTV: 480i ~ 1080p,
Up to Ultra HD 4K
4096 x 2160 @ 24/25/30Hz
(RGB/YCbCr 4:4:4 8 bits, YCbCr 4:2:2 8/10/12 bits)
4096 x 2160 @50/60Hz
(YCbCr 4:2:0 8 bits)
Max. Distance
1920 x 1200 @ 60Hz or at 1080p, Ultra HD 4K : 330 ft. (100m)
Connector Type
DVI 29P/HDMI 19P Female (x 1)
VGA Female
3.5mm Stereo Jack (x 1)
RJ-45 Jack
3P /3.5MM Terminal Block (for Power)
3P /3.5MM Terminal Block (for RS-232)
Conformations
DVI 1.0 , HDMI 1.4b, HDBaseT
HDCP Compliance
Yes, HDCP version 2.0
Power Rating
DC +12V, 10Watts Max
Dimensions (W x D x H)
5.75" x 4.5" x 1.75" (144.78 x 114.3 x 44.45 mm)
Weight
1.0 lbs. (0.46 Kg)

PureLink by Dtrovision
11
PM-CT103-U : Wall plate type (2x1 switch), 2 Gang Decora style, white finish.
Input : Selectable HDMI or VGA + 3.5mm stereo audio (x1) + RS-232
Output : CATx (HDBaseT)
POE, 330ft, Compatible with PM-CIS4-U input board
PM-CT103-U : PureMedia HDMI/VGA to CATx (HDBaseT) Extender Transmitter, Wall plate
Front Connection Ports:
Power LED: Power status indicator
Status LED: Video signal presence indicator
HDMI LED: HDMI signal indicator
VGA LED: VGA (or component) signal indicator
HDMI/DVI In: HDMI/DVI input port
VGA In: VGA (or component) input port
Audio In: Stereo audio input port
RS-232: RS-232 communication port
Back Connection Ports:
CATx: HDBaseT output port
DC In: DC 12V Power port

PureLink by Dtrovision
12
Model Name
PM-CT103-U
Input Signal
DVI / HDMI (TMDS), VGA(supports YPbPr component)
3.5mm stereo audio
Output Signal
HDBaseT0,1,2,3+/-
Data Transmission Speed
3.4 Gbps/ch, Total 10.2 Gbps Max
Supporting Display Resolutions
PC: VGA~ WUXGA (up to 1920 x 1200 @60Hz)
HDTV: 480i ~ 1080p,
Up to Ultra HD 4K
4096 x 2160 @24/25/30Hz
(RGB/YCbCr 4:4:4 8 bits, YCbCr 4:2:2 8/10/12 bits)
4096 x 2160 @50/60Hz
(YCbCr 4:2:0 8 bits)
Max. Distance
1920 x 1200 @ 60Hz or at 1080p, Ultra HD 4K : 330 ft. (100m)
Connector Type
HDMI 19P Female
VGA Female
3.5mm Stereo Jack (x 1)
RJ-45 Jack
3P /3.5MM Terminal Block (for Power)
3P /3.5MM Terminal Block (for RS-232)
Conformations
DVI 1.0 , HDMI 1.4b, HDBaseT
HDCP Compliance
Yes, HDCP version 2.0
Power Rating
DC +12V, 10Watts Max
Dimensions
2 Gang Decora style, actual dimension will be updated
Weight
0.5 lbs. (0.23 Kg)

PureLink by Dtrovision
13
PM-CT104-U : Standalone type
Input : HDMI (x1) + RS-232
Output : CATx (HDBaseT)
POE, 330ft, Compatible with PM-CIS4-U input board
PM-CT104-U : PureMedia HDMI to CATx (HDBaseT) Extender Transmitter
Front Connection Ports:
HDMI LED: Video signal presence indicator
Link LED: Link Status indicator
Back Connection Ports:
HDMI/DVI In: HDMI/DVI input port
CATx: HDBaseT output port
RS-232: RS-232 communication port
DC In: DC 12V Power port

PureLink by Dtrovision
14
Model Name
PM-CT104-U
Input Signal
DVI / HDMI (TMDS)
Output Signal
HDBaseT0,1,2,3+/-
Data Transmission Speed
3.4 Gbps/ch, Total 10.2 Gbps Max
Supporting Display Resolutions
PC: VGA~ WUXGA (up to 1920 x 1200 @60Hz)
HDTV: 480i ~ 1080p,
Up to Ultra HD 4K
4096 x 2160 @ 24/25/30Hz
(RGB/YCbCr 4:4:4 8 bits, YCbCr 4:2:2 8/10/12 bits)
4096 x 2160 @50/60Hz
(YCbCr 4:2:0 8 bits)
Max. Distance
1920 x 1200 @ 60Hz or at 1080p, Ultra HD 4K : 330 ft. (100m)
Connector Type
DVI 29P/HDMI 19P Female
RJ-45 Jack
3P /3.5MM Terminal Block (for RS-232)
DC 12V (Power Port)
Conformations
DVI 1.0 , HDMI 1.4b, HDBaseT
HDCP Compliance
Yes, HDCP version 2.0
Power Rating
DC +12V, 10Watts Max
Dimensions (W x D x H)
4.45”x 2.87" x 1.14" (113 x 73 x 29 mm)
Weight
0.7 lbs. (0.3 Kg)

PureLink by Dtrovision
15
Transmitter Input Signal Characteristics
Input Signal
Description
Unit
Min
Typical
Max
Remarks
DC input
DC Voltage
VDC
11.5
12
12.5
Power Consumption
Watts
13.5
13.8
14.4
DVI input
(29Pin DVI)
Differential Output
mVp-p
450
510
570
TMDS
Interface
HDMI input
(19Pin)
Differential Output
mVp-p
400
600
TMDS
Interface
Transmitter Output Signal Characteristics
Output Signal
Description
Unit
Min
Typical
Input Signal
Remarks
CAT5/e/6 LINK
Differential Output
mVp-p
400
AVcc
600
HDBaseT
Interface
Analog Video Signal Supported Resolution
- 640*480 60Hz
- 1024*768 60Hz
- 720*480p 60Hz
- 640*480 72Hz
- 1024*768 70Hz
- 720*576p 50Hz
- 640*480 75Hz
- 1024*768 75Hz
- 1280*720p 60Hz
- 640*480 85Hz
- 1024*768 85Hz
- 1280*720p 50Hz
- 800*600 56Hz
- 1280*1024 60Hz
- 1920*1080i 60Hz
- 800*600 60Hz
- 1280*1024 75Hz
- 1920*1080i 50Hz
- 800*600 72Hz
- 1280*1024 85Hz
- 1920*1080p 60Hz
- 800*600 75Hz
- 1600*1200 60Hz
- 1920*1080p 50Hz
- 800*600 85Hz
- 1920*1200 60Hz

PureLink by Dtrovision
16
Digital Video Signal Supported Resolution:
- PC resolution: VGA ~ WUXGA@ 60Hz (1920 x 1200 @ 60Hz)
- HDTV resolution: 480i ~ 1080p @ 60Hz, 4K2K
PureMedia CATx Transmitter Compatibility Chart
Transmitters
Compatibility
PM-CT101-U
PM-CT102-U
PM-CT103-U
PM-CT104-U
PureMedia Modular
Extender
Compatibility
PM-CR101-U
PM-CR102-U
PM-CR103-U
PM-CR104-U
PM-CR101-U
PM-CR102-U
PM-CR103-U
PM-CR104-U
PM-CR101-U
PM-CR102-U
PM-CR103-U
PM-CR104-U
PM-CR101-U
PM-CR102-U
PM-CR103-U
PM-CR104-U
PureMedia RF
Extender
Compatibility
PM-CR101-U-RF
PM-CR102-U-RF
PM-CR104-U-RF
PM-CR101-U-RF
PM-CR102-U-RF
PM-CR104-U-RF
PM-CR101-U-RF
PM-CR102-U-RF
PM-CR104-U-RF
PM-CR101-U-RF
PM-CR102-U-RF
PM-CR104-U-RF
PureMedia Matrix
Board
Compatibility
PM-CIS4-U
PM-CIS4-U
PM-CIS4-U
PM-CIS4-U

PureLink by Dtrovision
17
Receivers :
PM-CR101-U : Standalone type.
Input : CATx (HDBaseT)
Output : HDMI + 3.5mm stereo audio + RS-232
POE, 330ft, Compatible with PM-COS4-U output board
PM-CR101-U : PureMedia CATx (HDBaseT) to HDMI Extender Receiver
Front Connection Ports:
Power S/W: Power On/Off switch
Signal LED: Video signal presence indicator
Link LED: Link Status indicator
Firmware: USB firmware update port
Back Connection Ports:
HDMI/DVI Out: HDMI/DVI output port
Audio Out: Stereo audio output port
CATx: HDBaseT Input port
RS-232: RS-232 communication port
DC In: DC 12V Power port

PureLink by Dtrovision
18
Model Name
PM-CR101-U
Input Signal
HDBaseT 0,1,2,3+/-
Output Signal
DVI / HDMI (TMDS), 3.5mm stereo audio
Data Transmission Speed
3.4 Gbps/ch, Total 10.2 Gbps Max
Supporting Display Resolutions
PC: VGA~ WUXGA (up to 1920 x 1200 @60Hz)
HDTV: 480i ~ 1080p,
Up to Ultra HD 4K
4096 x 2160 @ 24/25/30Hz
(RGB/YCbCr 4:4:4 8 bits, YCbCr 4:2:2 8/10/12 bits)
4096 x 2160 @50/60Hz (YCbCr 4:2:0 8 bits)
Max. Distance
1920 x 1200 @ 60Hz or at 1080p, Ultra HD 4K : 330 ft. (100m)
Connector Type
DVI 29P/HDMI 19P Female (x 1)
3.5mm Stereo Jack
RJ-45 Jack
3P /3.5MM Terminal Block (for Power)
3P /3.5MM Terminal Block (for RS-232)
Conformations
DVI 1.0 , HDMI 1.4b, HDBaseT
HDCP Compliance
Yes, HDCP version 2.0
Power Rating
DC +12V, 10Watts Max
Dimensions (W x D x H)
5.75" x 4.5" x 1.25" (144.78 x 114.3 x 31.75 mm)
Weight
0.5 lbs. (0.23 Kg)

PureLink by Dtrovision
19
PM-CR102-U : Standalone type. Built-in auto scaler
Input : CATx (HDBaseT)
Output : HDMI + 3.5mm stereo audio + RS-232
330ft, Compatible with PM-COS4-U output board
PM-CR102-U : PureMedia CATx (HDBaseT) to HDMI Extender Receiver w/Scaling
Front Connection Ports:
Power S/W: Power On/Off switch
LCD Display: 16x2 LCD Display
Back Connection Ports:
Signal LED: Video signal presence indicator
Link LED: Link Status indicator
Firmware: USB firmware update port
HDMI Out: HDMI output port
Audio Out: Stereo audio output port
RS-232: RS-232 communication port
DC In: DC 12V Power port
Model Name
PM-CR102-U
Input Signal
HDBaseT 0,1,2,3+/-
Output Signal
DVI / HDMI (TMDS), 3.5mm stereo audio
Data Transmission
Speed
3.4 Gbps/ch, Total 10.2 Gbps Max
Supporting Display
Resolutions
PC: VGA ~ WUXGA
(up to 1920 x 1200 @60Hz)
HDTV: 480i ~ 1080p,
Up to Ultra HD 4K
4096 x 2160 @24/25/30Hz

PureLink by Dtrovision
20
(RGB/YCbCr 4:4:4 8 bits, YCbCr 4:2:2 8/10/12 bits)
4096 x 2160 @50/60Hz (YCbCr 4:2:0 8 bits)
Max. Distance
1920 x 1200 @ 60Hz or at 1080p, Ultra HD 4K : 330 ft. (100m)
Connector Type
DVI 29P/HDMI 19P Female (x 1)
3.5mm Stereo Jack
RJ-45 Jack
3P /3.5MM Terminal Block (for Power)
3P /3.5MM Terminal Block (for RS-232)
Conformations
DVI 1.0 , HDMI 1.4b, HDBaseT
Image Scaler
TDB
HDCP Compliance
Yes, HDCP version 2.0
Power Rating
DC +12V, 10Watts Max
Dimensions (W x D x H)
7.5" x 6.0" x 1.65" (190 x 150 x 42 mm)
Weight
1.5 lbs. (0.68 Kg)
4K Scaling For PureMedia
Scaler Output Resolutions
4096x2160 @50/60Hz
YCbCr 4:2:0 8bits
SXGA (1280x1024 @85Hz)
1080p (50Hz)
4096x2160 @24/25/30Hz
RGB/YCbCr 4:4:4 8bits
YCbCr 4:2:2 8/10/12 bits
SXGA (1280x1024 @75Hz)
1080i (60Hz)
3480x2160 @30Hz
SXGA (1280x1024 @60Hz)
1080i (59Hz)
2560x1600 @60Hz
XGA (1024x768 @85Hz)
1080i (59Hz)
1920x1200 @60Hz
XGA (1280x1024 @75Hz)
1080i (50Hz)
1400x900 @60Hz
XGA (1280x1024 @60Hz)
720p (60Hz)
1366x768 @60Hz
SVGA(800x600 @75Hz)
720p (59Hz)
1360x768 @60Hz
SVGA(800x600 @60Hz)
720p (50Hz)
UXGA (1600x1200 @60Hz)
1080p (60Hz)
576p (50Hz)
1080p (59Hz)
480p (60Hz)
