Pyle PCLSB1BK User manual

PortableWirelessBTStreamingMiniSpeaker
IPX7 Waterproof Wireless Speaker, Supports Micro SD Card
and FM Radio for Outdoor Play, Built-in Microphone
PCLSB1BK

WIRELESS BT CONNECTION
Step 1 Power ON
Press and hold " " button for 2 seconds then
you will hear a power ON prompt tone.
After that, the blue indicator light will dash
quickly and enter into the Wireless BT pairing
status.
www.PyleUSA.com2
Indicator light
Power button/Multi-function button

Step 2 Choose the device
Find "PYLEUSA" in your Wireless BT list and
select it.
www.PyleUSA.com 3
PYLEUSA
My Device

Step 3 Pairing Successfull
The indicator light will stay blue once pairing
is done, then you can play music.
TWS FUNCTION
www.PyleUSA.com4
Indicator light
TWS

www.PyleUSA.com 5
Operation Instruction
1. Turn on the two speakers, blue indicators
will ash.
2. Short press "+-" button at same time from
one speaker only, they will enter into tws
pairing mode with sound notication.
3. After 1-2 seconds, the two speakers will pair
automatically.There will be a "du" sound
notication when two speakers successfully
connected, Meanwhile, sub-master speaker
will stay blue and the master speaker will
keep ashing.
4. Open the setting and nd "PYLEUSA" from
your mobile, click it and your mobile will
pair with the two speakers.
5. Short press "+-" button again to disconnect
TWS.
Notice:
For TWS pairing, let the two speakers connect
rst, then connect the speakers with your
mobile phone.

BASIC OPERATION
2. Power/Multifunction Button
• Press and hold 2for 2s to power ON/OFF
• Short press 2to answer an incoming call/end a
call conversation. Short press 2twice to reject
the call.
• Short press 2to play/pause while music is playing
• Short press 2twice to disconnect BT.
1 & 3. Volume Buttons/Previous & Next track
Buttons
• Short press 1to turn volume down in each mode.
Press and hold 1to switch to previous track in
BT and TF card (Micro SD) mode.
Press and hold 1switch to previous radio in FM
mode
• Short press 3to turn volume up in each mode
Press and hold 3to switch to next track in BT
and TF card (Micro SD) mode.
Press and hold 3to switch to next radio in FM
mode.
www.PyleUSA.com6
23 14

4. Mode Button
• Short press 4to switch between BT/FM/TF mode.
Press and hold 4to search radio during FM mode
How to operate the FM function
Short press "M" button to switch to FM mode, you
will hear a prompt tone with "FM mode" Press and
hold "M" to start searching channels.
Press " " button to pause channel searching and
will start to play radio. Press and hold "+-" to switch
channels from the ones you searched earlier.
INTERFACE INSTRUCTIONS
www.PyleUSA.com 7
Micro USBMicro SD
(TF) card
Indicator light

Power ON
Blue indicator light will be ashing when powered
ON.
Wireless BT mode
• Blue indicator light be ON once connected
successfully.
• Blue indicator light keeps ashing if your BT
device is out of range. Speaker will turn OFF
automatically if no connection in 10 mins.
Micro SD (TF card) mode
Insert micro SD card, blue indicator light will ash
slowly during playing; blue indicator will stay lit
when the music is paused.
FM mode
• Blue indicator light will ash quickly during
channels searching.
• Blue indicator light will ash slowly during radio
playing.
• Blue indicator light will keep on when pause.
Charging mode
Red indicator light will stay ON when charging,
Red indicator light will turn OFF when charging is
done.
www.PyleUSA.com8

Low battery
You will hear an alert tone, LED indicator will stay
solid Blue.
Technical Specs:
• Construction Material: ABS
• Play Time: 4~6 hours at 70% Volume Level,
12~14 hours at 70% Volume Level
• Speaker Unit: 5W/4Ω
• Power Cable Length: 2.13 ft.
• Battery Type: Lithium Battery, Rechargeable
• Impedance: 4Ohms
• Frequency response: 70Hz-18kHz
• Battery Capacity: 3.7V/1200mAh
• S/N ratio: ≥70dB
• Charging Time: 2~3 hours
• Working Time: 4~6 hours (70% volume level)
• Charging Current: 5V/0.5A
• Product Dimensions (L x W x H):
5.65'' x 3.73'' x 1.8'' -inches
www.PyleUSA.com 9

Features:
• Support Micro SD or TF Cards / Line-In for MP3
Songs
• Compatible with Audio Output Devices
• Works as Loudspeaker Via Audio Cable
• With 3.5mm Audio Interface
• 40mm Full Rare-earth High Magnetic Speaker
• Clear High-pitched Sound
• Pure Alto Sound, Vigorous Bass
• Built-in Lithium Battery
• Built-in Microphone
• Supports Handsfree Function
• Ideal for Use at the Oce, Home, and Outdoor
What's in the Box:
• Wireless BT Mini Speaker
• Micro-USB Cable
• 3.5mm AUX Cable
Wireless BT Connectivity:
• Includes Wireless BT Audio Control Receiver
• Works with All of Today’s Latest Devices
(Smartphone, Tablet, Laptop, Computer, etc.)
• Wireless BT Network Name: ‘PYLEUSA’
• Wireless BT Version: 5.0
• Wireless Range: 32.8’ft.
www.PyleUSA.com10
