Q-See QC3016-12E4-1 User manual

16 Channel DVR | 2CIF Resolution | 700TVL Cameras
QC3016-12E4-1
The Q-See Lite QC3016-12E4-1 surveillance system with twelve 700TVL bullet cameras is equipped with state-of-the-art features that
are perfect for keeping a close eye on your home and family. Whether you want to make sure your child got home from school, see
what the dogs are up to, verify a package delivery or deter theft, this system is built to keep you connected with and protect what
is most important. Q-See’s twelve 700TVL bullet cameras with 648x488 effective pixels produce quality surveillance images and are
capable of up to 100 feet of night vision to ensure your entire family is clearly covered both day and night. This DVR comes packed
with state-of-the-art features:
• Footage is captured in 2CIF on each channel, which results in a wider 704x240 resolution video image for improved recognition.
• Q-See’s start-up wizard advances through the setup process step-by-step making complete protection quicker than ever.
• Real-time recording accommodates up to 30 frames per second on each of the 16 channels in order to produce smooth,
continuous and uninterrupted video that reveals details not visible to the naked eye.
This DVR’s remote monitoring capabilities keep you connected, enabling you to keep an eye on your home from anywhere at any
time. Simply download the free Q-See Apps and access live or previously recorded video via iPhone, iPad, Android, or Windows
Phone. Instantly receive email alerts with incident snapshots when motion is detected or in the event a camera becomes disabled.
As the frontrunner in innovation, Q-See is the trusted leader in surveillance solutions for home and business, delivering peace of
mind anywhere, anytime.
FEATURES:
• Sixteen Channel 2CIF DVR
• Twelve 700TVL Cameras
• Weatherproof Cameras for Indoor and Outdoor Use
• 30 Frames Per Second Recording on Each Channel
• Remote Monitoring Via Free Apps
• Compatible with Mac and PC
•
•
Connect up to 4 More Cameras
1TB Hard Drive
SPECIFICATIONS:
DVR
Model QC3016(DVR)
Video Compression Advanced H.264
Max Hard Drive Storage Supports 1 SATA HDD up to 4 TB ( 1TB Included )
Backup Via PC, Flash Drive, USB Hard Drive
Power DC 12V / 2A (Adapter Included)
Recording Option NTSC: other: Real Time: 2CIF Resolution 702,
other Recording Option
Resolution NTSC: other (480FPS/ 30FPS Per Second),
Recording Mode Motion Detection, Time Schedule, Manual
USB Interface USB Mouse, USB Backup
Video Inputs/Outputs 16 BNC Input(s) / 1 VGA Output(s) / 1 HDMI Output(s)
Network Interface RJ-45 for Router Connection Enabling Remote Monitoring
DVR Dimensions/Weight 10.75 x 8 x 2 in / 1.1 lbs
Cameras
Camera Model QM7008B
Weatherproof Weatherproof Indoor & Outdoor

Horizontal Resolution 700 TV Lines
Image Sensor 1/3, CMOS, Color
Night Vision Range Up to 100 ft
Lens 4.6mm lens 50°-55° field of view
Mount 3-Axis Stands
Camera Cables 60 Feet of Cable with Each Camera
Viewing
NTSC
Live Display Resolution 704x480, 1920x1080
Display Modes Single Camera, Split Screen Multi-Camera, Auto-Sequence
Video Search Time, Motion Detection, Manual
Compatibility
Computer System Support
Windows XP Vista 7 8
Mactonish 10.7 10.8 10.9
Compatible Browsers
Browsers Chrome (w/ IE plugin) Explorer Firefox
Mobile Phone Support
iPhone / iPad
Android
Windows Phone 7.5/8
www.Q-See.com
