Q-See QCW3MP1B User manual

WI-FI SECURITY BULLET CAMERA
QUICK START GUIDE
ENGLISH

WELCOME!
Congratulations on your latest purchase and welcome to the Q-See family.
This guide includes everything you will need to help get your camera up and
running right out of the box. We are excited to have you on board and thank
you for choosing Q-See!

Camera
Wi-Fi Antenna
Mounting Hardware
Also included: 1 power supply & 1 weather seal (seal is for custom installs)
WHAT’S INCLUDED
Grommet
4

FEATURES
BEST IN CLASS
Setting the resolution
bar higher than 1080p
MOTION ALERT
Get alerts about
important activity
NIGHT VISION
See what’s happening in
pitch dark
MICRO SD CARD SUPPORT
Internal back up memory for
video storage
EASY SETUP
Less fuss, more
monitoring
ADD-ON
Expand your current
surveillance system
with ease
5

6

GET CONNECTED
Find the desired location for your camera to be placed. If you are going to be mounting the
camera, please use the included mounting hardware to secure the camera rmly to the wall.
Please make sure that you test the system completely before mounting the cameras.
• Slide the included rubber grommet onto
the antenna stem of the camera
• Screw the supplied Wi-Fi antenna on to
the bullet camera
• Plug in the included power supply to a
surge protector and plug in the power
supply to the Wi-Fi bullet camera.
You are now ready to setup the camera.
7

8
STEP 1
REGISTRATION
Before installing, please register your device at www.q-see.com/register on the Q-See
Support Portal to receive critical updates and support for your system. Registering will also
help us to assist you with any technical or warranty issues if ever necessary.
Please be sure to keep a record of your model number(s) and to save this guide, as
you will need this information if you are ever in need of technical or warranty support.
NOTE : Your username and password used to register your device are not the same as those you use to log in to
your system. Please write down your username, password, and model number(s) in the spaces provided below:
Name:
Password:
Model #:

NOTE: Ensure that your mobile device is connected to
the Wi-Fi network you wish to use for your camera.
Download the QC View
App from the App Store on
your mobile device. Once
the App has been installed
select the Menu button in the top left corner, followed
by Device Manager.
STEP 2
DOWNLOAD & INSTALL THE QC VIEW APP
9
NOTE: If you already have a Wi-Fi NVR this camera will
automatically try to connect to it. Start using the NVR quick
start guide to complete setup. If you would like to use this
as a standalone device, disconnect or power o your Wi-Fi
NVR before proceeding.
*All screenshots in guide are
from QC View app on iOS.

10
STEP 3
ADD A NEW DEVICE
In Device Manager, Click “+” to add a new device.
Select “Wi-Fi conguration” and create a name
for your camera. Tap the QR code icon in the
SN eld and then scan the QR code located on
the back camera panel (see photo below). Once
the QR code has been scanned, complete the
remaining username
and password elds
and hit next:
Username: admin
Password: admin

Congure the network settings by entering the password of
your Wi-Fi network.
STEP 4
ADD A WI-FI DEVICE
NOTE: The Wi-Fi network should be the same one used by your
mobile device.
11
STEP 5
START LIVE PREVIEW
Once your device has been added successfully, select Start
Live Preview to view the feed from your camera.

12
STEP 6
VIEW THE LIVE VIDEO FEED
ADJUST THE BULLET CAMERA SHADE
Your camera has been set up successfully. You
can now access your camera feed anytime and
anywhere using the QC View App.
You can adjust the bullet camera shade according
to your lighting requirements.

13
If you would like to add this camera to your existing QC Series NVR, login to your NVR and go to
Remote Devices. Select your camera from the device list and click Add. The camera feed will
appear on your NVR. The NVR has to be connected to the same network as your mobile device
for the initial setup process. Visit www.q-see.com/support to verify if your system is compatible.
*This screenshot is from a QC Series NVR.
STEP 7
ADD TO AN EXISTING QC NVR SYSTEM

The micro SD memory card slot is located under
the bottom panel of the camera. Push the card
in rmly to load the card. To eject, press the card
rmly again. Some units will include an SD card.
If you wish to change the existing Wi-Fi network
to a dierent network, while the camera is
powered on, hold the reset button for 15
seconds and setup your camera again.
14
ADDITIONAL FEATURES
MICRO SD MEMORY CARD CAMERA RESET BUTTON
NOTE: SD memory card slot and reset button can both be accessed by removing the bottom panel
from the camera with a standard screwdriver. Reattach panel before mounting cameras.

Q-See is always here to answer your questions and take your valued suggestions.
Our focus is providing excellent customer support and always working to improve our
customers’ experience.
Please do not hesitate to call us at 1-877-998-3440 Monday-Friday 6:00 AM - 7:00 PM PST.
Visit us at www.q-see.com/support for 24/7 support and access to our Support Portal.
Please do not worry about the additional
network cable on your bullet camera. This
network cable can alternatively be used to hard-
wire the camera using an Ethernet cable instead
of a Wi-Fi connection. Please make sure that this
cable is never exposed to moisture.
WARRANTY & SUPPORT
15
NETWORK CABLE

Rev. 5/1/17, QCW4, QCK81, QC826, QC838, QC838B, QC858, QC8116, QC8816, QC8832, QC8916, QC8932
