QEP TC620 Maintenance and service guide

TC620 - 800W Bridge Saw
Owner’s Safety and Operating Manual
103620
Read manual before use. Keep hands arms and face clear
of blade whilst in use. Always have safety guard in place
when machine is switched on at the mains.
Always wear Vitrex Protective Equipment when using
hand or power tools.
Safety First

02 03
Contents
Safety Instructions ...................................................3
Machine Specication & Electrical Requirements ......4
Assembly & Operating Instructions ...................... 5-7
Maintenance ...........................................................7
Warranty ................................................................8
Tel: [phone] Tel: [phone]
TC620 - 800W Bridge Saw
Owner’s Safety and Operating Manual

02 03
Contents
Safety Instructions ...................................................3
Machine Specication & Electrical Requirements ......4
Assembly & Operating Instructions ...................... 5-7
Maintenance ...........................................................7
Warranty ................................................................8
TC620 - 800W Bridge Saw
Safety Instructions
To use this tool correctly, you must
observe the Safety Regulations, the
Assembly Instructions and the Operation
Instructions contained in this Manual.
All persons who use and service the
machine must be acquainted with this
Manual and must be informed about any
potential hazards.
Children and inrm people must not use
this tool. Children must be supervised at
all times if they are in the area in which
the tool is being used.
It is also imperative that you observe the
accident prevention regulations in force in
your area. The same applies for general
rules of occupational health and safety.
• Make sure that the cutting disc is correctly
screened by the guard.
• Never remove the riving knife. The distance
between the cutting disc and the riving knife
should not exceed 5 mm.
• Do not use cutting discs which are bent,
deformed or otherwise damaged.
• Do not use cutting discs which do not comply
with the specications stated in this manual.
• Never start cutting tiles before the machine
reaches full speed.
• Never attempt to cut extremely
small workpieces.
• Do not leave the work area until the
machine has been switched off and the cutting
disc has come to a complete standstill.
• Never attempt to stop the cutting disc by
exerting pressure on the side of the disc.
• Before use check the pump for damage.
Should the pump be damaged, it must not be
used.
• Never let the pump run dry.
• Never lift the pump by the mains cable or
hose, but only by the housing.
• Always unplug the machine before
performing any maintenance.
• Do not use the machine before it has been
completely assembled and installed
according to the instructions.
• Do not perform any design, assembly or
construction activities on the table while the
machine is switched on.
• Unplug the machine and clean the table
before leaving the work area.
Tel: [phone] Tel: [phone]
TC620 - 800W Bridge Saw
Owner’s Safety and Operating Manual

04 05
Machine Specication & Electrical Requirements
Power Supply
Motor
RPM (No load)
Maximum Sound Level*
Blade size
Maximum Depth of Cut (with new blade)
Maximum Depth of Cut at 45O (with new blade)
Mitre Cutting Angle
Cutting Angles
Machine & Accessories packed weight
*Note: If the sound intensity level exceeds 85 db (A) ear protection should be worn by the operator.
230v/50Hz
800W
2950 RPM
84.2 dB (A)
200mm x 22.2mm bore
35mm
30mm
0O-45Odegrees
0O-45O degrees
34.5 kg
• Ensure that the mains voltage corresponds
to the instruction plate - a single phase
socket with two contacts and an earth is
obligatory.
• Use an approved RCD circuit breaker
between the machine and the electrical
power point.
• To reduce the risk of unintentional starting,
make sure that the switch is in the OFF
position before plugging in.
• Repair or replace damaged or worn cable
immediately after rst disconnecting from
mains supply.
• Electrical faults must only be carried out by
a qualied electrician.
• Immediately switch off the saw in the
case of:
- Excessive sparking of the brushes
- Malfunction of the main plug, socket
or damaged cables
- Broken switch
- Smoke or smell caused by scorched
insulation
• WARNING-To reduce the risk of electrocution,
keep all connections dry. Do not touch the plug with
wet hands. Ensure that water cannot run back along
the cable from the machine and into the plug socket.
The contents of the box should include the following:
• TC620 - 800W Bridge Saw
• 200mm Diamond Blade
• Wrenches
• Water Pump and Tray
• Owner’s Safety & Operating Manual
IMPORTANT
For best results with your new TC620 - 800W
Bridge Saw allow the blade to do the work, rather
than forcing the tile through the machine. Should
the blade stop, simply ease the tile away and
then continue cutting using slightly less pressure.
Tel: [phone] Tel: [phone]

04 05
Assembly & Operation Operating Instructions
Remove the saw from its carton, lay carefully on
its side.
Unfasten blade carriage retaining bolt.
To switch the machine on, set the on/off
switch to ‘-’.
To switch the machine off, set the on/off switch
to ‘O’.
Push the blade carriage to its furthest point away
from the operator. Place the tile in position on the
cutting table so that it rests against the measuring
scale and mitre guide.
Set the size of cut required on the measuring
scale and lock the mitre guide.
Switch on the machine.
Pull the blade carriage steadily towards you,
cutting through the tile. When the cut is complete,
switch off the machine, removing the cut tile
pieces and any debris.
Straight Cuts
Switching on and off
Always use the following procedure, in the order
given, when assembling the water reservoir.
Mount the rst table leg in place. Mount the rst
cushion in the leg. Mount the water reservoir.
Mount the other 3 legs according to the same
instructions. Tighten all parts.
Put the water reservoir straight up.
Tel: [phone] Tel: [phone]
TC620 - 800W Bridge Saw

Place the tile in position on the cutting table so
that it rests against the measuring scale and the
mitre guide.
Tilt the bridge to the desired angle (up to 45O) and
re-tighten.
Loosen the winged screw on the mitre guide and
set the angle of cut required.
Place the tile in position on the cutting table so
that it rests against the measuring scale and mitre
guide.
Pull the blade carriage steadily towards you,
cutting through the tile.
When the cut is complete, switch off the machine,
removing the cut tile pieces and any debris. Switch on the machine. Pull the blade carriage
steadily towards you, cutting through the tile.
When the cut is complete, switch off the machine,
removing the cut tile pieces and any debris.
Loosen the two knobs at either end of the bridge
Angular Cuts Mitre Cuts
Tel: [phone] Tel: [phone]
06 07

Whilst holding the shaft with the spanner wrench,
turn the blade retaining nut clockwise to release
using the hex wrench.
Ensure that the new blade is correctly seated
against the shaft and that the directional arrow
matches that on the blade guard. Replace the
ange and nut, taking care not to overtighten.
Rotate blade to ensure correct alignment.
Replace the blade guard and tighten all parts.
Remove the cover retaining screws and take off
the blade guard.
To empty the water remove the plug at the
bottom of the water tray.
Blade Replacement
Emptying water from tray
Tel: [phone] Tel: [phone]
TC620 - 800W Bridge Saw
06 07
Maintenance
• The machine does not require any special
maintenance.
• Regularly remove grindings from the
housing and the covers.
• The unit must not be operated if the mains
connection lead is not in perfect condition.
• Replacement mains connection leads
must not differ from the versions indicated
by the manufacturer Mains connection
cable: (H05 RN-F 3x1.0 mm²).
• Do not operate a defective unit.
• Servicing only by an authorized
after-sales service point.
• Use only for operations for which the unit
is intended.

Everest Road
Lytham St Annes
Lancashire
FY8 3AZ
Tel: [phone]
Fax: [phone]
Consumer Advice
• Do not dispose of electrical products with your normal household waste.
• Always use recycling facilities whenever possible.
• Additional recycling information can be found through your local Authority or Retailer.
Q.E.P. Co UK Ltd is committed to a continuing program of product improvement.
Consequently, please be advised that specications, performance, appearance,
and dimensions of QEP/Vitrex products are subject to change without notice. For
more up-to-date information about our range of products, please contact our
Customer Service Ofce on [phone] or your local distributor.
• For further information or advice,
please call the Technical Helpline on
[phone].
This electric tile cutter has been manufactured to a high quality standard. It is guaranteed against faulty materials and
workmanship for 12months from the date of purchase. Any claim must be accompanied by a valid till receipt as proof of purchase.
A faulty machine will either be repaired or replaced free of charge. If a direct replacement is not available, an alternative to the
same or greater value/specication will be offered.
This guarantee does not cover machine defects caused by or resulting from:
a) Misuse, abuse or neglect, b) Trade, Professional or hire use, c) Repairs attempted by anyone other than our authorised repair
agent, d) Ingress of foreign objects, substances or accident
In the unlikely event of a fault occurring, contact should be made through the Vitrex Technical Helpline [phone]
The above guarantee is only valid within the UK and does not affect your statutory rights.
The guarantor is Q.E.P. Co. UK Ltd., Everest Road, Lytham St. Annes, Lancashire, FY8 3AZ (Registered No. 04988177 England).
