QTORQ TPW25 User manual

© The Kennedy Group Ltd. 02/05
AVAILABLE FROM YOUR DISTRIBUTOR
Foot Kilo-gram Newton Newton Foot Kilo-gram Kilo-gram Newton Foot
Pounds Metres Metres Metres Pounds Metres Metres Metres Pounds
(ft. lbs) (Kgm or (Nm) (Nm) (ft. lbs) (Kgm or (Kgm or (Nm) (ft. lbs)
mkp) mkp) mkp)
5.00 0.69 6.78 10.00 7.38 1.02 1.00 9.81 7.23
10.00 1.38 13.56 20.00 14.75 2.04 2.00 19.61 14.47
15.00 2.07 20.34 30.00 22.13 3.06 3.00 29.42 21.70
20.00 2.76 27.12 40.00 29.50 4.08 4.00 39.23 28.93
25.00 3.46 33.90 50.00 36.88 5.10 5.00 49.04 36.17
30.00 4.15 40.68 60.00 44.26 6.12 6.00 58.84 43.40
35.00 4.84 47.46 70.00 51.63 7.14 7.00 68.65 50.63
40.00 5.53 54.24 80.00 59.01 8.16 8.00 78.46 47.87
45.00 6.22 61.02 90.00 66.38 9.18 9.00 88.26 65.10
50.00 6.91 67.80 100.00 73.76 10.20 10.00 98.07 72.33
55.00 7.60 74.58 110.00 81.14 11.22 11.00 107.88 79.57
60.00 8.29 81.36 120.00 88.51 12.24 12.00 117.68 86.80
65.00 8.98 88.14 130.00 95.89 13.26 13.00 127.49 94.03
70.00 9.67 94.92 140.00 103.26 14.28 14.00 137.30 101.27
75.00 10.37 101.70 150.00 110.64 15.30 15.00 147.11 108.50
80.00 11.06 108.48 160.00 118.02 16.32 16.00 156.91 115.74
85.00 11.75 115.26 170.00 125.39 17.34 17.00 166.72 122.97
90.00 12.44 122.04 180.00 132.77 18.36 18.00 176.53 130.20
95.00 13.13 128.82 190.00 140.14 19.38 19.00 186.33 137.43
100.00 13.82 135.60 200.00 147.52 20.40 20.00 196.14 144.67
105.00 14.51 142.38 210.00 154.90 21.42 21.00 205.95 151.90
110.00 15.20 149.16 220.00 162.27 22.44 22.00 215.75 159.13
115.00 15.89 155.94 230.00 169.65 22.46 23.00 225.37 166.37
120.00 16.58 162.72 240.00 177.02 24.48 24.00 235.37 173.60
125.00 17.28 169.50 250.00 184.40 25.50 25.00 245.18 180.84
130.00 17.97 176.28 260.00 191.78 26.52 26.00 254.98 188.08
135.00 18.66 183.06 270.00 199.15 27.54 27.00 264.79 195.30
140.00 19.35 189.84 280.00 206.53 28.56 28.00 274.60 202.54
145.00 20.04 196.62 290.00 213.91 29.58 29.00 284.41 209.77
150.00 20.73 203.40 300.00 221.29 30.60 30.00 294.22 217.00
155.00 21.42 210.18 310.00 228.67 31.62 31.00 304.03 224.23
160.00 22.11 216.96 320.00 236.05 32.64 32.00 313.84 231.46
165.00 22.80 223.74 330.00 243.43 33.66 33.00 323.65 238.69
170.00 23.49 230.52 340.00 250.81 34.68 34.00 333.46 245.92
175.00 24.19 237.70 350.00 258.30 35.70 35.00 343.35 253.05
180.00 24.88 244.08 360.00 265.68 36.72 36.00 353.16 260.28
185.00 25.57 250.86 370.00 273.06 37.74 37.00 362.97 267.51
190.00 26.26 257.64 380.00 280.44 38.76 38.00 372.78 274.74
195.00 26.59 264.42 390.00 287.82 39.78 39.00 382.59 281.97
200.00 27.64 271.20 400.00 295.20 40.80 40.00 392.40 289.20
205.00 28.33 277.98 410.00 302.58 41.82 41.00 402.21 296.43
210.00 29.02 284.76
215.00 29.71 291.54
220.00 30.40 298.32
225.00 31.09 305.10
230.00 31.78 311.88
235.00 32.47 318.66
240.00 33.16 325.44
245.00 33.85 332.22
250.00 34.54 339.00
260.00 35.88 352.56
270.00 37.26 366.12
280.00 38.64 379.68
290.00 40.02 393.24
300.00 41.40 406.80
Made in England.
CONVERSION TABLE
KENNEDY TOOLS
Wigston Works, Leicester, England.
Made in England
OPERATORS MANUAL
TPW25 KEN-555-4100K SPW25 KEN-555-4050K
SPW55 KEN-555-4070K MPW125 KEN-555-4000K
PRODUCTION SLIP
WRENCHES

2
OPERATING INSTRUCTIONS
3
QUALITY GUARANTEE & WARRANTY
Q-TORQ PRODUCTS carry one years manufacturers warranty.
Q-TORQ PRODUCTS are designed & manufactured to the highest standards & specifications
Assuring the quality and performance required by all sectors of industry.
Q-TORQ PRODUCTS are fully guaranteed against faulty materials & workmanship
Should they be found to be defective, they will either be repaired or replaced free of charge
(fair wear and tear and/or misuse excepted).
Please retain supplier invoice as proof of purchase.
All Q-TORQ tools are supplied with a calibration certificate valid for 12 months from date of
purchase. (Please retain invoice as proof of purchase.)
Accuracy: = ±6% of the reading within the effective working
range of the tool. *
* ISO6789: 1992 states the effective working range of the
tool is from 20% to 100% of its maximum torque value.
You have purchased a Q-TORQ product that is designed for high performance and a long service
life. If safety and maintenance procedures are followed and the tool is used correctly it will last
for many years.
SAFETY & MAINTENANCE
Always follow instructions for assembly before operation.
Ensure your workpiece is firmly held or fixed before commencing work.
When using torque tools it is possible that fasteners may break or slip. Always stand with
both feet on the floor and avoid applying torque in awkward positions.
The drive part of the tool and any accessories should always be in line with the fastener.
Misalignment and uncontrolled movement will affect accuracy.
Only use the tool on the job that it has been designed for.
Keep the tool clean by wiping. Never dip in cleaning fluid.
Always store tools away from dirt, oil and swarf as this can damage mechanisms.
We recommend that your torque tool be calibrated annually.
RECOMMENDED CALIBRATION SERVICE PROVIDER
CROMWELL METROLOGY
Telephone: [phone]
Fax: [phone]
Email:
[email protected]
www.cromwell.co.uk
Remove the end cap by turning
counterclockwise with a hex
wrench.
Position torque key onto the
adjustment locking device
inside driver.
Use an appropriate torque
analyzer to set torque. When
torque value required is
reached, repeat five more
torque motions to verify torque
setting. Re-install end cap
Adjust torque by applying axial
force to key before and whilst
rotating the screw.
To increase torque, turn key
clockwise. To decrease torque,
turn key counterclockwise.
Apply torque with a smooth consistent motion parallel to fastener
axis. The wrench ‘slips’ when predetermined torque setting is
reached - completely eliminating overtightening.
1
4
2 3
5
6
((( )))
SPECIFICATIONS
Model Order Code Range (ISO) Range (Imperial) Length Ratchet
TPW25 KEN-555-4100K 3 - 25 N.m 2 - 18 lbf.in 216mm (81/2”) 1/4”
SPW25 KEN-555-4050K 3 - 25 N.m 2 - 18 lbf.in 216mm (81/2”) 3/
8”
SPW55 KEN-555-4070K 15 - 55 N.m 10 - 40 lbf.in 324mm (123/
4”) 3/ 8”
MPW125 KEN-555-4000K 40 - 125 N.m 30 - 90 lbf.in 460mm (181/4”) 1/2”
CONTENTS
A Calbration Certificate that is
traceable to International
Standards and valid for 12
months from date of purchase.
(Please retain invoice as proof of
purchase).
A Torque
Key
For
adjusting
the torque
