Quadra-Fire 4300 Series User manual

www.quadrafire.com 7037-135L August 3, 2015
DO NOT DISCARD THIS MANUAL
CAUTION
• Important operating
and maintenance in-
structions included.
• Leave this manual with
party responsible for
use and operation.
• Read, understand and
follow these instructions
for safe installation and
operation.
WARNING
If the information in these instruc-
tions is not followed exactly, a fire
may result causing property dam-
age, personal injury, or death.
• Do not store or use gasoline or other flam-
mable vapors and liquids in the vicinity of
this or any other appliance.
• Do not overfire - If heater or chimney con-
nector glows, you are overfiring. Overfiring
will void your warranty.
• Comply with all minimum clearances to
combustibles as specified. Failure to
comply may cause house fire.
Fire Risk.
WARNING
For use with solid wood fuel only.
Other fuels may overfire and generate
poisonous gases (i.e. carbon monoxide).
Installation and service of this appliance should
be performed by qualified personnel. Hearth &
Home Technologies recommends NFI certified
professionals, or technicians supervised by an
NFI certified professional.
WARNING
Hot glass will cause burns.
• Do not touch glass until it is cooled
• NEVER allow children to touch glass
• Keep children away
• CAREFULLY SUPERVISE children in same room
as fireplace.
• Alert children and adults to hazards of high
temperatures.
High temperatures may ignite clothing or other
flammable materials.
• Keep clothing, furniture, draperies and other
flammable materials away.
HOT SURFACES!
Glass and other surfaces are
hot during operation AND
cool down.
To obtain a French translation of this manual, please
contact your dealer or visit www.quadrafire.com
Pour obtenir une traduction française de ce manuel,
s’il vous plaît contacter votre revendeur ou visitez
www.quadrafire.com
NOTE
4300 WOOD STOVE SERIES
Automatic Combustion Control (ACC)
Owner’s Manual
Installation and Operation
Models:
43M-ACC-MBK
43ST-ACC Millennium Model
Step Top Uni-Body Model
(Pedestal Model Shown)

Page 2 7037-135L August 3, 2015
4300 Wood Stove Series (ACC)
Hearth & Home Technologies welcomes you to our tradi-
tion of excellence! In choosing a Quadra-Fire appliance,
you have our assurance of commitment to quality, durabil-
ity, and performance.
This commitment begins with our research of the market,
including ‘Voice of the Customer’ contacts, ensuring we
make products that will satisfy your needs. Our Research
and Development facility then employs the world’s most
advanced technology to achieve theoptimum operation of
our stoves, inserts and fireplaces. And yet we are old-fash-
ioned when it comes to craftsmanship. Each unit is meticu-
lously fabricated and surfaces are hand-finished for lasting
beauty and enjoyment. Our pledge to quality is completed
as each model undergoes a quality control inspection.
We wish you and your family many years of enjoyment in
the warmth and comfort of your hearth appliance. Thank
you for choosing Quadra-Fire.
Serial No.
Model Name
Test Lab &
Report No.
Mfg. Date
SAMPLE OF SERIAL NUMBER / SAFETY LABEL
LOCATION: BACK OF APPLIANCE
SAMPLE
NOTE: Clearances may only be reduced by means
approved by the regulatory authority having jurisdiction

August 3, 2015 7037-135L Page 3
4300 Wood Stove Series (ACC)
Section 1: Listing and Code Approvals
A. Appliance Certifications ......................4
B. Mobile Home Approved ......................4
C. Glass Specifications............................4
D. BTU & Efficiency Specifications..........4
Section 2: Getting Started
A. Design, Installation & Location
Considerations....................................5
B. Fire Safety ..........................................5
C. Negative Pressure..............................6
D. Flue Draft Considerations...................7
E. Venting Systems.................................7
F. Tools and Supplies Needed................7
G. Inspect Appliance & Components.......7
H. Typical Stove System.........................8
Section 3: Dimensions & Clearances
A. Appliance Dimensions ........................9-10
B. Clearances to Combustibles...............11
Section 4: Installation Consideration
A. Hearth Requirements.........................12-13
B. Outside Air Kit Installation...................14
C. Blower Installation...............................15
Section 5: Chimney Requirements
A. Venting Components..........................16
B. Chimney Systems...............................16-18
C. Installing Chimney Components .........18
D. Chimney Termination Requirements ..19
E. 2-10-03 Rule........................................19
Section 6: Mobile Home...............................20
Section 7: Appliance Set-Up
A. Pedestal & Ash Removal System
(ARS) Installation...............................21-22
B. Leg Kit & Ash Removal System
(ARS) Installation...........................23
C. Door Handle Assembly.......................24
D. Blower Speed Adjustment ..................24
Section 8: Operating Instructions
A. Over-Firing Your Appliance.................25
B. Wood Selection & Storage..................25
C. Burning Process..................................25-26
D.
Automatic Combustion Control (ACC) ....26
E. Air Controls.........................................26-27
F. Burn Rates & Operating Efficiency .....27
G. Building A Fire.....................................28
H. Correct Baffle & Blanket Placement....29
I. Blower Operating Instructions.............29
J. Opacity (Smoke).................................29
K. Frequently Asked Questions...............30
Section 9: Maintaining & Servicing Appliance
A. Quick Reference Maintenance Quide.31
B. General Maintenance & Cleaning.......32-33
C. Glass Replacement.............................34
D. Firebrick Replacement........................35
E. Baffle Removal....................................36
F. Snap Disc Replacement .....................36
G. Tube Channel Replacement...............37
Section 10: Troubleshooting........................38
Section 11: Reference Material
A. Exploded Drawing (Millennium)..........39
B. Service Parts & Accessories (Mill)......40-43
C. Exploded Drawing (Step Top).............44
D. Service Parts & Accessories (ST).......45-49
E. Warranty Policy...................................50-51
F. Contact Information.............................52
TABLE OF CONTENTS
Safety Alert Key:
• DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury.
• WARNING! Indicates a hazardous situation which, if not avoided could result in death or serious injury.
• CAUTION! Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.
• NOTICE: Indicates practices which may cause damage to the fireplace or to property.

Page 4 7037-135L August 3, 2015
4300 Wood Stove Series (ACC)
1Listing and Code Approvals
A. Appliance Certification
C. Glass Specifications
D. BTU & Efficiency Specifications
This stove is equipped with 5mm ceramic glass. Replace
glass only with 5mm ceramic glass. Please contact your
dealer for replacement glass.
This appliance is approved for mobile home installations
when not installed in a sleeping room and when an outside
combustion air inlet is provided. The structural integrity of
themobilehome floor,ceiling,and wallsmust bemaintained.
The appliance must be properly grounded to the frame of
the mobile home and use only listed double-wall connector
pipe. Outside Air Kit, part OAK-ACC must be installed in a
mobile home installation
B. Mobile Home Approved
Model: 4300 Millennium & Step Top (ACC)
Uni-Body
Laboratory: OMNI Test Laboratories, Inc.
Report No & Date: 061-S-67-6
Type: Listed Room Heater, Solid Fuel Type
Standard: UL1482 and ULC S627-00 and
(UM) 84-HUD, Mobile Home
Approved.
NOTE: Hearth & Home Technologies, manufacturer of
this appliance, reserves the right to alter its products,
their specifications and/or price without notice.
• Installation and use of any damaged appliance.
• Modification of the appliance.
• Installation other than as instructed by Hearth & Home
Technologies.
• Installationand/oruseof any component part not approved
by Hearth & Home Technologies.
• Operating appliance without fully assembling all
components.
• Operating appliance without legs attached (if supplied with
unit).
• DoNOTOverfire-Ifapplianceorchimneyconnector glows,
you are overfiring.
Any such action that may cause a fire hazard.
WARNING
Fire Risk.
Hearth & Home Technologies disclaims any
responsibility for, and the warranty will be
voided by, the following actions:
NOTE: This installation must conform with local codes. In the
absence of local codes you must comply with the UL1482, (UM)
84-HUD and NPFA211 in the U.S.A. and the ULC S627-00 and
CAN/CSA-B365 Installation Codes in Canada.
Quadra-Fire is a registered trademark of Hearth & Home
Technologies.
EPA Certification #: 656
EPA Certified Emissions: 1.00 grams per hour
*LHV Tested Efficiency: 80.2 %
**HHV Tested Efficiency: 74.2 %
***EPA BTU Output: 11,800 to 38,300 / hr.
****Peak BTU/Hour Output: 63,700
Vent Size: 6 inches
Firebox Size: 2.3 cubic feet
Recommended Wood Length: 18 inches
Fuel Orientation: Front-to-Back
Fuel Seasoned Cord Wood
* Weighted average LHV efficiency using Douglas Fir dimension-
al lumber and data collected during EPA emissions test.
**Weighted average HHV efficiency using Douglas Fir dimen-
sional lumber and data collected during EPA emissions test.
***A range of BTU outputs based on EPA Default Efficiency and
the burn rates from the low and high EPA tests, using Douglas
Fir dimensional lumber.
****Apeak BTU out of the unit calculated using the maximum first
hour burn rate from the High EPA Test and the BTU content of
cordwood (8600) times the efficiency.
The Quadra-Fire 4300 Wood Stove (ACC) meets the U.S.
Environmental ProtectionAgency’s cribwood emission limits
for wood heaters sold after May 15, 2015.
This wood heater needs periodic inspection and repair for
proper operation. It is against federal regulations to operate
this wood heater in a manner inconsistent with operating
instructions in this manual.

August 3, 2015 7037-135L Page 5
4300 Wood Stove Series (ACC)
2Getting Started
A . Design, Installation & Location Consider ations
Consideration must be given to:
• Safety
• Convenience
• Traffic flow
• Chimney and chimney connector required
Itisagoodideatoplanyourinstallationon paper,using exact
measurements for clearances and floor protection, before
actually beginning the installation. If you are not using an
existing chimney, place the appliance where there will be a
clear passage for a factory-built listed chimney through the
ceiling and roof.
We recommend that a qualified building inspector and your
insurance company representative review your plans before
and after installation
If this appliance is in an area where children may be near it
isrecommendedthat youpurchaseadecorative barriertogo
in front of the appliance.
Remember to always keep children
away while it is operating and do not let anyone operate
this appliance unless they are familiar with these operating
instructions.
WARNING
• DO NOT CONNECT THIS UNIT TOA CHIM-
NEY FLUE SERVICING ANOTHER APPLI-
ANCE.
• DO NOT CONNECT TO ANY AIR DISTRIBU-
TION DUCT OR SYSTEM.
May allow flue gases to enter the house.
Asphyxiation Risk.
Fire Risk.
WARNING
• Do not operate appliance before reading and
understanding operating instructions.
• Failure to operate appliance properly may
cause a house fire.
Check building codes prior to installation.
• Installation MUST comply with local, regional, state and
national codes and regulations.
• Consult insurance carrier, local building, fire officials or
authorities having jurisdiction about restrictions, installation
inspection, and permits.
CAUTION
NOTE: Service Space:
In order to replace the tube channel a clearance of 19
inches (483mm) is required on the right side of stove in
order to remove the tubes with the stove in place.
If space is not available, the stove will have to be discon-
nected from the chimney to proceed with the tube replace-
ment. See page 36.
B. Fire Safety
To provide reasonable fire safety, the following should be
given serious consideration:
1. Install at least one smoke detector on each floor of
your home to ensure your safety. They should be
located away from the heating appliance and close
to the sleeping areas. Follow the smoke detector
manufacturer’s placement and installation instructions,
and be sure to maintain regularly.
2. A conveniently located Class A fire extinguisher to
contend with small fires resulting from burning embers.
3. A CO detector should be installed in the room with the
appliance.
4. A practiced evacuation plan, consisting of at least two
escape routes.
5. A plan to deal with a chimney fire as follows:
In the event of a chimney fire:
a Evacuate the house immediately
b. Notify fire department.

Page 6 7037-135L August 3, 2015
4300 Wood Stove Series (ACC)
Figure 6.1
C. Negative Pressure
Draft is the pressure difference needed to vent appliances
successfully. Considerations for successful draft include:
• Preventing negative pressure
• Location of appliance and chimney
Negative pressure results from the imbalance of air avail-
able for the stove to operate properly. Causes for this imbal-
ance include:
• Exhaust fans (kitchen, bath) etc.)
• Range hoods
• Combustion air requirements for furnaces, water
heaters and other combustion appliances
• Clothes dryers
• Location of return-air vents to furnace or air condi-
tioning
• Imbalances of HVAC air handling system
• Upper level air leaks
• Recessed lighting
• Attic hatch opening
• Duct leaks
To minimize the affects of negative air pressure the following
must be considered:
• Install the outside air kit. Install the intake on the
side of the house towards prevailing winds during the
heating season.
• Ensure adequate outdoor air is supplied for combus-
tion appliances and exhaust equipment.
• Ensure furnace and air conditioning return vents are
not located in the immediate vicinity of the appli-
ance,
• Avoid installing the appliance near doors, walkways
or small isolated spaces.
• Recessed lighting should be of “sealed can” design;
attic hatches weather stripped or sealed; and attic
mounted duckwork and air handler joints and seams
taped or sealed.
WARNING
• Negative pressure can cause spillage of com-
bustion fumes, soot and carbon monoxide.
• Appliance needs to draft properly for safety.
Asphyxiation Risk.

August 3, 2015 7037-135L Page 7
4300 Wood Stove Series (ACC)
Exterior conditions such as roof line, surrounding trees,
prevailing winds and nearby hills can influence stove
performance. Yourlocaldealeristheexpertinyourgeographic
area and can usually make suggestions or discover solutions
that will easily correct your flue problem.
D. Flue Draft Considerations
Location of the appliance and chimney will affect perfor-
mance. As shown in
Figure 6.1 on page 6 the chimney
should:
• Be installed through the warm spaceenclosed by the
building envelope. This helps to produce more draft,
especially during lighting and die down of the fire.
• Penetrate the highestpart of the roof. This minimizes
the affects of wind turbulence and down drafts.
• Consider the appliance location in order to avoid
floor and ceiling attic joists and rafters.
E. Venting Systems
The venting system consists of a chimney connector (also
known as stove pipe) and a chimney. These get extremely
hotduringuse. Temperaturesinsidethechimneymayexceed
2000F (1100C) in the event of a creosote fire. To protect
againstthepossibility ofa house fire,the chimneyconnector
and chimney must be properly installed and maintained.
An approved thimble must be used when a connection is
made through a combustible wall to a chimney.
Achimneysupport packagemustbe usedwhenaconnection
is made through the ceiling to a prefabricated chimney.
These accessories are absolutely necessary to provide
safe clearances to combustible wall and ceiling material.
Follow venting manufacturer’s clearances when installing
venting system.
T
o be sure that your appliance burns properly, the chimney
draft (static pressure) should be approximately -.04 inch water
column (W.C.) during a low burn and -.10 inch W.C. during a
high burn, measured 6 inches (152mm) above the top of the
appliance after one hour of operation at each burn setting.
NOTE: These are guidelines only, and may vary somewhat
for individual installations.
F. Tools And Supplies Needed
Before beginning the installation be sure that the following
tools and building supplies are available.
Reciprocating saw
Pliers
Hammer
Phillips Head Screwdriver
Flat Blade Screwdriver
Plumb Line
Level
Tape Measure
Framing Material
Hi-Temp Caulking Material
Gloves
Framing Square
Electric Drill & Bits (1/4”)
Safety Glasses
1/2 in. - 3/4 in. length, #6 or
#8 self drilling screws (need 3
per pipe section connection)
G. Inspect Appliance & Components and
Pre-Burn Check List
1. Place the appliance in a location near the final
installation area and follow the procedures below:
2. Open the appliance and remove all the parts and
articlespackedinsidethe Component Pack. Inspect
alltheparts and glassforshipping damage. Contact
your dealer if any irregularities are noticed.
3. All safety warnings have been read and followed.
4. This Owner’s Manual has been read.
5. Floor protection requirements have been met.
6. Venting is properly installed.
7. Theproper clearances from theapplianceand chim-
ney to combustible materials have been met.
8. Themasonry chimney is inspectedby a professional
and is clean, or the factory built metal chimney is
installed according to the manufacturer’s instruc-
tions and clearances.
9. The chimney meets the required minimum height.
10.
All labels have been removed from the glass door.
11. Plated surfaces have been wiped clean, if appli-
cable.
12. A power outlet is available nearby if installing
optional blower assembly.
WARNING
• DO NOT CONNECT THIS UNIT TO A CHIM-
NEY FLUE SERVICING ANOTHER APPLI-
ANCE.
• DO NOT CONNECT TO ANY AIR DISTRIB-
UTON DUCT OR SYSTEM.
May allow flue gases to enter the house.
Asphyxiation Risk. Inspect appliance and components for damage.
Damaged parts may impair safe operation.
WARNING
• Do NOT install damaged components.
• Do NOT install incomplete components.
• Do NOT install substitute components.
Report damaged parts to dealer.
Fire Risk.

Page 8 7037-135L August 3, 2015
4300 Wood Stove Series (ACC)
Figure 8.3 Interior Prefabricated ChimneyFigure 8.2 Exterior Prefabricated Chimney
Figure 8.1 Masonry Chimney
H. Typical Stove Systems
Stove system with masonry chimney
consists of:
• Stove
• Chimney Connector (stove pipe)
• Thimble
• Masonry Chimney
• Hearth Pad Floor Protection
• Stove
•
Chimney Connector
(stove pipe)
• Thimble (for exterior
chimney)
• Firestops
• Insulations Shields
• Storm Collar and Flashing
• Termination Cap
• Hearth Pad Floor Protec-
tion
Stove system with prefabricated
metal chimney consists of:

August 3, 2015 7037-135L Page 9
4300 Wood Stove Series (ACC)
3Dimensions and Clearances
A. Appliance Dimensions
Figure 9.1 Front View
Figure 9.2 Side View
NOTE: Flue Collar size is 6 inch
(152mm) diameter (ID)
Millennium Model

Page 10 7037-135L August 3, 2015
4300 Wood Stove Series (ACC)
Appliance Dimensions (Cont’d)
Figure 10.1
Figure 10.2
Figure 10.3
Figure 10.4
4300 Step Top Pedestal Model 4300 Step Top Leg Model

August 3, 2015 7037-135L Page 11
4300 Wood Stove Series (ACC)
B. Clearances to Combustibles (UL and ULC)
NOTE: Clearances may only be reduced by means
approved by the regulatory authority having jurisdiction
Fire Risk.
• Comply with all minimum clearances to
combustibles as specified.
• Failure to comply may cause house fire.
WARNING NOTE: Service Space
In order to replace the tube channel assembly a clearance
of 19 inches (483mm) is required on the right side of stove in
order to remove the tubes with the stove in place.
If space is not available, the stove will have to be discon-
nected from the chimney to proceed with the tube replace-
ment.
NOTE: A, C and F measurements
are to center of flue AB C D E F GH
INSTALLATION: Full Vertical or Horizontal with Vertical Rise
SINGLE WALL PIPE - A, B, C and D dimensions are based off of standard 18” stove pipe clearances to combustibles or unit certified clearances,
whichever is greater
Millennium 18-1/2 [470] 11-3/4 [298] 27-1/2 [699] 14-1/2 [368] 10 [254] 20-1/2 [521] 53-1/2 [1359] 12 [305]
Step Top 18-1/2 [470] 11-3/4 [298] 27-1/2 [699] 14-1/2 [368] 2 [51] 15 [381] 49-1/2 [1283] 12 [305]
DOUBLE WALL PIPE - A, B, C and D dimensions are based off of certification clearances. Stove pipe manufacture clearances MUSt be adhered to if
they exceed certified unit clearances.
Millennium 12 [305] 5-1/4[133] 27-1/2 [699] 14-1/2 [368] 10 [254] 20-1/2 [521] 53-1/2 [1359] 12 [305]
Step Top 10-1/2 [267] 3-3/4 [95] 25 [635] 11-3/4 [298] 2 [51] 15 [381] 49-1/2 [1283] 5 [127]
INSTALLATION - 90°Elbow off top of stove through backwall
DOUBLE WALL PIPE
Millennium 11-1/2 [292] 6 [152] 27-1/2 [699] 15 [381] 10 [254] 20-1/2 [521] 53-1/2 [1359] N/A
Step Top 10-1/2 [267] 4 [102] 22 [559] 9 [229] 2 [51] 15 [381] 49-1/2 [1283] N/A
INSTALLATION: ALCOVE - Six inch (6”) [152] diameter listed DOUBLE WALL air insulated connector pipe with UL 103 HT listed factory-built Class “A”
chimney, or a masonry chimney. (Mobile Home must be equipped with a spark arrestor.) Maximum depth of Alcove shall be no more than 48” [1220]
with a minimum height of 48” [1092] to top of unit, and the referenced clearances. Canada must comply with CAN/ULC-S269 M87 for the 650°factory
built chimney
DOUBLE WALL PIPE
Millennium 16 [406] 10 [254] 27 [686] 14-1/2 [368] N/A N/A 53-1/2 [1359] 12 [305]
Step Top 10-1/2 [267] 3-3/4 [95] 25 [635] 11-3/4 [298] N/A N/A 49-1/2 [1283] 5 [127]
* If H = N/A, follow Pipe
Manufacturer’s clearances

Page 12 7037-135L August 3, 2015
4300 Wood Stove Series (ACC)
A. Hearth Protection Requirements
FLOOR PROTECTION: Floor protector must be non-com-
bustible material, extending beneath heater and to the front,
sides and rear as indicated. The floor must be non-com-
bustible or otherwise adequately protectedfrom radiant heat
given off by the unit and from sparks and falling embers. A
layer of thin brick or ceramic tile over a combustible floor is
not sufficient.
For US installations,i
tis necessaryto installa floorprotector
of a minimum of 3/8 inch (9.5mm) thick metal clad millboard
or equivalent a minimum of 16
inches (406mm) in front of
glass and 8 inches (203mm) toboth sides of the fuel loading
door. Open the door and measure 8 inches (203mm) from
the side edge of the opening in the face of the appliance.
*See exception.
In Canada, similar floor protection must be provided 18
inches (457mm) in front and 8 inches (203mm) from the
sides and rear of the stove. *See exception.
*EXCEPTION: Non-combustible floor protections must
extend beneath the flue pipe when installed with horizontal
venting and extend 2 inches (51mm) beyond each side.
See Figure 12.4.
Figure 12.3
4Installation
Figure 12.1
Figure 12.2
Millennium Model
USA
USA
CANADA
Corner hearth pad dimensions with
single wall and double wall pipe

August 3, 2015 7037-135L Page 13
4300 Wood Stove Series (ACC)
NOTE: •Illustrations and photos reflect typical installations and are FOR DESIGN PURPOSES ONLY.
•Illustrations/diagrams are not drawn to scale.
•Actual installation may vary due to individual design preference
•Hearth & Home Technologies reserves the right to alter its products.
Figure 13.3
Figure 13.1
Figure 13.2
Step-Top Uni-Body Model
USA
USA
CANADA
A. Hearth Protection Requirements (Cont’d)
Corner hearth pad dimensions with
single wall and double wall pipe

Page 14 7037-135L August 3, 2015
4300 Wood Stove Series (ACC)
B. Outside Air Kit Installation
1. Remove all materials from packing box.
2. Usinga #2Phillipsscrew driverattachthe flexadapter
to the stove using 4 screws. Figure 14.1.
3. For floor installations r
emove circular” knock-out” in the
base of the pedestal.
4. Floor & Rear Installation: Cut a 4 inch (102mm)
hole in outside wall or floor to accommodate outside
airpiping. Use4 inch(102mm)aluminummetal flex or
rigid piping to directly connect outside air to appliance
intake. Use the suppliedtermination cap witha rodent
screen. Seal between the wall (or floor) and the pipe
with silicone to prevent moisture penetration.
Items Needed for Installation (not supplied)
• 4inchflexaluminumpipe,orifusingalternatematerial,
then it shall be made from durable, non-combustible,
heat resistant material up to 350oF. Cut the pipe to
the required length for your installation.
• Phillips head screw driver
• Silicone sealant
• Drills and saws necessary for cutting holes through
the wall or flooring in your home.
Figure 14.1 - Floor & Rear Installation
Asource of air (oxygen) is necessary inorder for combus-
tion to take place. Whatever combustion air is consumed
by the fire must be replaced. Air is replaced via air leak-
agearoundwindows and underdoors. In homesthathave
tightly sealed doors and windows, an outside air source is
needed. An optional OutsideAir Kit is avail
able.
WARNING
Do not draw outside combustion air from:
• Wall, floor or ceiling cavity
• Enclosed space such as an attic or garage
• Close proximity to exhaust vents or
chimneys
Fumes or odor may result
Fire Risk.
Asphyxiation Risk.
Asphyxiation Risk.
Outside air inlet must be located to prevent block-
age from:
• Leaves
• Snow or ice
• Other debris
Block may cause combustion air starvation
Smoke spillage may set off alarms or irritate sensi-
tive individuals.
WARNING
Asphyxiation Risk.
Length of outside air supply duct shall NOT exceed
the length of the vertical height of the exhaust flue.
• Fire will not burn properly
•Smoke spillage occurs when door is opened due
to air starvation.
WARNING
Included in OAK-ACC: Termination cap, (2) wire ties, flex
adapter, and fasteners
Included in SRV7033-041:Cover plate and sealing rope (see
Floor Installation Alternative below,
Figure 14.2)
Figure 14.2 - Floor Installation Alternative
5. Floor Installation Alternative: Insome instancesyou may
not be able to install the flex pipe as show in
Figure 14.1.
If that is the case, you will need to order SRV7033-041
which includes a cover plate and sealing rope as shown in
Figure 14.2. The goal is to seal the pedestal so no room
air can leak into the pedestal or cold air infiltration.

August 3, 2015 7037-135L Page 15
4300 Wood Stove Series (ACC)
C. Blower (Optional)
NOTE: The blower cord is equipped with a 3 pronged
(grounding) plug for your protection against shock hazard.
Do not remove.
1. Remove the 3 bolts (1/4”-20 Phillips head) on the outer
skin at the bottom rear of appliance.
2. Align holes in mounting flange of blower with bolt holes in
appliance. Blower should be positioned at bottom of rear
outer skin as shown in Figure 15.1.
3. Re-insert and tighten bolts, securing blower onto outer
wall of appliance.
4.
Place the bracket containing the snap disc and magnet
under the bottom left rear corner as shown in
Figure 15.1 .
See page 30 for detailed operating instructions for the
blower and snap disc.
Figure 15.1
Shock Risk.
• Do NOT remove grounding prong from plug.
• Plug directly into properly grounded 3 prong
receptacle.
• Route cord away from appliance.
•
Do NOT route cord under or in front of appliance..
CAUTION
Figure 15.2

Page 16 7037-135L August 3, 2015
4300 Wood Stove Series (ACC)
NOTE: In Canada when using a factory-built chimney it must
be safety listed, Type UL103 HT (2100oF) CLASS “A” or
conforming to CAN/ULC-S629M, STANDARD FOR 650oC
FACTORY-BUILT CHIMNEYS.
5Chimney Requirements
Figure 16.1 Prefabricated Exterior Chimney Figure 16.2 - Prefabricated Interior Chimney
A. Venting Components
Chimney Connector:
It is also known as flue pipe or stove pipe. The chimney
connector joins the stove to the chimney. It must be a 6 inch
(152mm) minimum diameter 24 gauge mild steel black or
26 gauge blued steel, or an approved air-insulated double
wall venting pipe.
Thimble:
A manufactured or site-constructed device installed in
combustible walls through which the chimney connector
passes to the chimney. It is intended to keep the walls
from igniting. Site constructed thimbles must meet
NFPA 211 Standards. Prefabricated must be suitable
for use with selected chimney and meet UL103 Type HT
Standards. Followinstructionsprovidedbythemanufacturer
for manufactured thimbles for masonry chimney and
prefabricated chimneys.
Chimney:
Thechimneycanbeneworexisting,masonryorprefabricated
andmustmeetthefollowingminimumrequirementsspecified
in Section 5B.
B. Chimney Systems
• Must be minimum 6 inch (152mm) diameter (ID) high
temperature chimney listed to UL 103 HT (2100oF) or
ULC S629M.
• Must use components required by the manufacturer for
installation.
• Must maintain clearances required by the manufacturer
for installation.
• Refer to manufacturers instructions for installation.
Prefabricated Metal Chimney

August 3, 2015 7037-135L Page 17
4300 Wood Stove Series (ACC)
Thimble
Site constructed for masonry chimney installation:
Components
• A minimum length of 12 inches [305mm] (longer for
thicker walls) of solid insulated factory-built chimney
length constructed to UL 103 Type HT 6 inch (152mm)
inside diameter. Chimney needs to extend a minimum
of 2 inches (51mm) from the interior wall and a mini-
mum of 1 inch (25mm) from the exterior wall.
• Wall spacer, trim collar and wall band to fit solid pack
chimney selected.
• Minimum 8 inch (203mm) diameter clay liner section (if
not already present in chimney) and refractory mortar.
Air Clearances
• Masonry chimney clearance must meet NFPA211 mini-
mum requirement of 2 inches (51mm) to sheet metal
supports and combustibles.
• Minimum of 1 inch (25mm) clearance around the chim-
ney connector.
• Top of wall opening is a minimum of 13-1/2 inches
(343mm) from ceiling or 4-1/2 inches (114mm) below
minimum clearance specified by chimney connector
manufacturer. NFPA211 minimum vertical clearance of
18 inches (457mm) from chimney connector and ceil-
ing or minimum recommended by chimney connector
manufacturer. Figure 17.1.
Instructions:
1. Open inside wall at proper height for the chimney con-
nector to entry the masonry chimney. Figure 17.1.
2. Entry hole to masonry chimney must be lined with an 8
inch (203mm) minimum diameter clay liner, or equiva-
lent, secured with refractory mortar.
3. Construct a 17 inch x 17 inch (432mm x 432mm) out-
side dimension frame from 2 x 2 framing lumber to
fit into wall opening. Inside opening of frame should
be no less than 14 inch x 14 inch (356mm x 356mm).
Figure 17.1.
4. Attach the wall spacer to the chimney side of the
frame.
5. Nailtheframe intothewall opening. Thespacershould
be on the chimney side.
6. Insert the section of the solid insulated chimney into
the outer wall of the masonry chimney.
7. Tightly secure the length of the solidinsulated chimney
with the wall band to the masonry chimney.
8. Insert a section of chimney connector into the chimney.
Make sure it does not protrude past the edge of the
clay chimney liner inside the chimney.
9. Seal the end of the chimney connector to the clay liner
with refractory mortar.
10.
Install trim collar around the sold pack chimney section .
Figure 17.1
Solid Pack Chimney with Metal Supports as a Thimble
Figure 17.2
Fire Risk.
Do NOT pack insulation or other combustibles between
spacers.
• ALWAYS maintain specified clearances around vent-
ing and spacers.
• Install spacers as specified.
Failure to keep insulation or other material away from
vent pipe may cause fire.
WARNING

Page 18 7037-135L August 3, 2015
4300 Wood Stove Series (ACC)
Chimney Height / Rise and Run
Thisproductwasdesignedforandtestedona6inch(152mm)
chimney, 14 to 16 feet (420-480cm) high, (includes stove
height)measuredfromthebaseof the appliance. The further
your stack height or diameter varies from this configuration,
the possibility of performance problems exists.
Chimney height may need to be increased by 2
- 3% per
each 1000 feet above sea level. It is not recommended to
useoffsets or elbowsat altitudesabove 4000feetabovesea
level or when there are other factors that affect flue draft.
C. Installing Chimney Components
Chimney Connector
Single wall connector or stove pipe.
This must be at least 24 gauge mild steel or 26 gauge blue
steel. Thesections mustbe attachedtotheapplianceandto
each other with the crimped (male) end pointing toward the
stove. All joints, including the connection at the flue collar,
should be secured with 3 sheet metal screws. Make sure
to follow the minimum clearances to combustibles. Where
passage through the wall, or partition of combustible con-
struction is desired inCanada, the installation shall conform
to CAN/CSA-B365.
Factory-built listed chimney connector (vented).
Alistedconnector(vented)mustbe usedwhen installingthis
unit in a mobile home. The listed connectors must conform
to each other to ensure a proper fit and seal.
Figure 18.2 Chimney Connector (Stove Pipe)
Improper installation, adjustment, alteration, service or
maintenance can cause injury or property damage. Refer
to the owner’s information manual provided with this appli-
ance. For assistance or additional information consult a
qualified installer, service agency or your dealer.
WARNING
Fire Risk.
Inspection of Chimney:
• Chimney must be in good condition.
• Meets minimum standard of NFPA 211
• Factory-built chimney must be 6 inch
(152mm) UL103 HT.
WARNING WARNING
ONLY use connector:
• Within the room, between appliance and ceiling or wall.
Connector shall NOT pass through:
• Attic or roof space
• Closet or similar concealed space
• Floor or ceiling
Maintain minimum clearances to combustibles
Fire Risk.
Follow Chimney Connector Manufacturer’s
Instructions for Proper Installation.
Figure 18.1
Solid Pack Chimney with Metal Supports as a
Thimble (Cont’d)
WARNING
• DO NOT CONNECT THIS UNIT TO A CHIM-
NEY FLUE SERVICING ANOTHER APPLI-
ANCE.
• DO NOT CONNECT TO ANY AIR DISTRIB-
UTON DUCT OR SYSTEM.
May allow flue gases to enter the house.
Asphyxiation Risk.

August 3, 2015 7037-135L Page 19
4300 Wood Stove Series (ACC)
D. Chimney Termination Requirements
Follow manufacturers instructions for clearance, securing,
flashing and terminating the chimney.
•Must have an approved and listed cap
•Must not be located where it will become plugged by
snow or other material
• Must terminate at least 3 feet (91cm) above the roof
and at least 2 feet (61cm) above any portion of the
roof within 10 feet (305cm)
• Must be located away from trees or other struc-
tures
These are safety requirements and are not meant to assure proper flue draft.
Figure 19.1
E. 2-10-3 Rule
Figure 19.2
NOTE:
• Chimney performance may vary.
• Trees, buildings, roof lines and wind conditions affect
performance.
• Chimney height may need adjustment if smoking or
overdraft occurs.
Pitched Roof

Page 20 7037-135L August 3, 2015
4300 Wood Stove Series (ACC)
6Mobile Home Installation
10. Burn wood only. Other types of fuels may generate
poisonous gases (e.g., carbon monoxide).
11. If unit burns poorly while an exhaust blower is on in
home, (i.e., range hood), increase combustion air.
12. Installationshallbe inaccordance withthe Manufacturers
Home & Safety Standard (HUD) CFR 3280, Part 24.
1. Anoutsideair inletmustbe providedforcombustion See
page 14 for installation information.
2. Appliance must be secured to the mobile home structure
by bolting the pedestal through hearth pad and into
floor.
3. Appliance must be grounded with #8 solid copper
grounding wire or equivalent and terminated at each end
with N.E.C. approved grounding device.
4. Appliance must be installed with an approved UL103 HT
ventilated chimney connector, UL103 HT chimney, and
terminal cap with spark arrestor. Never use a single wall
connector (stove pipe) in a mobile homeinstallation. Use
only double-wall connector pipe, Dura-Vent DVL, Selkirk
metalbestos DS or Security DL double-wall connector or
any listed double-wall connector pipe.
5.
In Canada, this appliance must be connected to a 6 inch
(152mm) factory-built chimney conforming to CAN/ULC-
629M, STANDARD FOR FACTORY BUILT CHIMNEYS.
6. Follow thechimneyandchimneyconnectormanufacturer’s
instructions when installing the flue system for use in a
mobile home.
7. Maintain clearance to combustibles.
8. Floor protection requirements must be followed
precisely.
9. Use silicone to create an effective vapor barrier at the
locationwherethe chimneyorother componentpenetrates
to the exterior of the structure.
NOTE: Offsets from the vertical, not exceeding 45°, are
allowed per Section 905(a) of the Uniform Mechanical Code
(UMC). Offsets greater than 45° are considered horizontal
and are also allowed, providing the horizontal run does not
exceed 75% of the vertical height of the vent. Construction,
clearance and termination must be in compliance with the
UMCTable9C.Thisinstallationmust also comply with NFPA
211.
NOTE: Top sections of chimney must be removable to allow
maximum clearance of 13.5 feet (411cm) from ground level
for transportation purposes.
Figure 20.1
CAUTION
THE STRUCTURAL INTEGRITY OF THE MOBILE HOME
FLOOR, WALLAND CEILING/ROOF MUST BE MAIN-
TAINED
Do NOT cut through:
• Floor joist, wall, studs or ceiling trusses.
• Any supporting material that would affect the structural
integrity.
NEVER INSTALL IN A SLEEPING ROOM.
Consumes oxygen in the room.
WARNING
Asphyxiation Risk.
You must use a Quadra-Fire Outside Air Kit Part
OAK-ACC and (depending on floor installation)
Part SRV7033-041 for installation in a mobile
home.
