Quadra-Fire GRAND-MBK-AU User manual

17 August, 20181 7075-177A
VOYAGEUR GRAND AUSTRALIAN
WOOD INSERT
AUTOMATIC COMBUSTION CONTROL
(ACC)
MODEL:
GRAND-MBK-AU
Installation Manual
Installation & Appliance Set-Up
INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
NOTICE: DO NOT DISCARD THIS MANUAL
HOT SURFACES!
Glass and other surfaces are hot during
operation AND cool down.
WARNING
Hot glass and appliance will cause burns.
• Do not touch glass until it is cooled
• Use leather gloves when reloading fuel
• NEVER allow children to touch glass
• Keep children away
• CAREFULLY SUPERVISE children in same room as
appliance.
• Alert children and adults to hazards of high
temperatures
• High temperatures may ignite clothing or other
ammable materials.
• Keep clothing, furniture, draperies and other
ammable materials away.
WARNING
Fire Risk.
For use with solid wood fuel only.
Other fuels may over re and generate poisonous
gases (i.e. carbon monoxide).
• Do not store or use gasoline or other ammable
vapors and liquids in the vicinity of this or any other
appliance.
• Do not over re - If appliance or chimney connector
glows, you are over ring. Over ring will void your
warranty.
• Comply with all minimum clearances to combustibles
as specied. Failure to comply may cause house re.
WARNING
If the information in these instructions
is not followed exactly, a re could result
causing property damage, personal injury,
or death.

17 August, 20182 7075-177A
VOYAGEUR GRAND AU
1 Important Safety Information.............3
A. Insert Certication .......................... 3
B. BTU & Efciency Specications ............... 3
C. Glass Specications ........................ 3
D. Non-Combustible Materials................... 3
E. Combustible Materials....................... 3
2 Getting Started ....................................4
A. Design and Installation Considerations .......... 4
B. Fire Safety ................................ 4
C. Negative Pressure.......................... 4
D. Tools And Supplies Needed .................. 5
E. Inspection of Appliance and Components ........ 5
F. Removal of Appliance from Shipping Materials .... 5
G. Install Checklist ............................ 6
3 Dimensions and Clearances..............7
A. Appliance Dimensions ......... 7
B. Clearances to Combustibles, ................. 9
4 Chimney Systems ............................. 11
A. Locating Your Appliance & Chimney ........... 11
B. Minimum Height of Flue System Exit .......... 12
C. Chimney Termination Requirements ........... 12
D. Venting Systems .......................... 13
E. Inspections .............................. 13
F. Larger Chimneys .......................... 13
G. Masonry Chimney ......................... 14
H. Prefabricated Metal Chimney ................ 15
I. Install into a Masonry Fireplace ............... 16
J. Install Into a Factory Built Fireplace............ 16
K. Securing Chimney Components .............. 16
L. Altering the Fireplace ....................... 16
M. Zero-Clearance Fireplace ................... 17
N. Ovalizing Round Stainless Steel Liners ........ 17
O. Chimney Height / Rise and Run .............. 17
5 Appliance Set-Up ..............................18
A. Outside Air Kit Installation ................... 18
B. Optional Offset Adapter Installation............ 19
C. Securing Stove Pipe/Liner to Flue Collar ....... 19
D. Leveling Legs ............................ 19
E. Securing Appliance to Stove Pipe/Liner ........ 20
F. Surround & Trim Kit Installation ............... 20
G. Standard Surround & Cast Trim Kit ........... 21
H. All Cast Surround Kit ...................... 22
I. Blower Cord Installation on Left Side ........... 22
6 Accessory List ..................................26
A. Accessory List ............................ 26
Quadra-Fire is a registered trademark of Hearth & Home Technologies.
TABLE OF CONTENTS
Safety Alert Key:
• DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury.
• WARNING! Indicates a hazardous situation which, if not avoided may result in death or serious injury.
• CAUTION! Indicates a hazardous situation which, if not avoided, may result in minor or moderate injury.
• NOTICE: Indicates practices which may cause damage to the appliance or to property.

317 August, 2018 7075-177A
VOYAGEUR GRAND AU
Model: Voyageur Grand AU Insert
Laboratory: Vipac Ltd.
Report No: 30A-13-0025-TRP-331382-0
Type: Hardwood only at 25% dry basis
Standard: AS/NZS4013 for Hardwood
The Quadra-Fire Voyageur Grand Australian Wood Insert is Hardwood Certied. Hardwood Particulate Emissions equaling
1.5 g/kg with a Space Heating Efciency of 65%.
Overall Average Efciency
Burning Hardwood (AS/NZS 4012) 62.8%
Average Particulate Emission
Factor Burning Hardwood (AS/
NZS 4013)
2.0 g/kg
Maximum Average Heat Output
Burning Hardwood 9.3 kW
Wetback
Wetbacks are
NOT an approved
option and must
be tted.
Vent Size: 6 inches
Firebox Size: 2.35 cubic feet
Recommended Wood Length: 18 inches
Fuel Orientation: Front-to-Back
Approved Fuel
Hardwood only
with a Moisture
content less than
25% (dry basis)
1 Important Safety Information
A. Insert Certication
B. BTU & Efciency Specications
This wood appliance needs periodic inspection and repair for proper operation. It is against federal regulations to operate
this wood appliance in a manner inconsistent with operating instructions in this manual.
NOTE: Hearth & Home Technologies, manufacturer of this appliance, reserves the right to alter its products, their
specications and/or price without notice.
Improper installation, adjustment, alteration, service or
maintenance can cause injury or property damage.
For assistance or additional information, consult a qualied
installer, service agency or your dealer.
Hearth & Home Technologies WILL NOT warranty
appliances that exhibit evidence of over-ring. Evidence
of over-ring includes, but is not limited to:
• Warped air tube
• Deteriorated refractory brick retainers
• Deteriorated bafe and other interior components
C. Glass Specications
This appliance is equipped with 5mm ceramic glass.
Replace glass only with 5mm ceramic glass. Please
contact your dealer for replacement glass.
D. Non-Combustible Materials
Material which will not ignite and burn, composed of any
combination of the following:
-Concrete
-Tile
-Glass
-Slate
-Steel
-Plaster
-Brick
-Iron
E. Combustible Materials
Material made of/or surfaced with any of the following
materials:
- Wood
- Compressed Paper
- Plant Fibers
- Plastic
- Plywood/OSB
- Sheet Rock (drywall)
Any material that can ignite and burn: ame proofed or not,
plastered or non-plastered.

17 August, 20184 7075-177A
VOYAGEUR GRAND AU
Install Guide
2 Getting Started
A. Design and Installation Considerations
Consideration must be given to:
• Safety
• Convenience
• Trafc ow
• Chimney and chimney connector required
It is a good idea to plan your installation on paper, using
exact measurements for clearances and oor protection,
before actually beginning the installation. If you are not
using an existing chimney, place the appliance where there
will be a clear passage for a factory-built listed chimney
through the ceiling and roof.
We recommend that a qualied building inspector and your
insurance company representative review your plans before
and after installation.
If this appliance is in an area where children may be near
it is recommended that you purchase a decorative barrier
to go in front of the appliance. Remember to always keep
children away while it is operating and do not let anyone
operate this appliance unless they are familiar with these
operating instructions.
To provide reasonable re safety, the following should be
given serious consideration:
1. Install at least one smoke detector on each oor of
your home to ensure your safety. They should be
located away from the heating appliance and close
to the sleeping areas. Follow the smoke detector
manufacturer’s placement and installation instructions,
and be sure to maintain regularly.
2. A conveniently located Class A re extinguisher to
contend with small res resulting from burning embers.
3. A CO detector should be installed in the room with the
appliance.
4. A practiced evacuation plan, consisting of at least two
escape routes.
5. A plan to deal with a chimney re as follows:
6. In the event of a chimney re:
a. Evacuate the house immediately
b. Notify re department.
C. Negative Pressure
Negative pressure results from the imbalance of air
available for the appliance to operate properly. It can be
strongest in lower levels of the house.
Causes include:
• Exhaust fans (kitchen, bath, etc.)
• Range hoods
• Combustion air requirements for furnaces, water
appliances and other combustion appliances
• Clothes dryers
• Location of return-air vents to furnace or air
conditioning
• Imbalances of the HVAC air handling system
• Upper level air leaks such as:
-Recessed lighting
-Attic hatch
-Duct leaks
B. Fire Safety
Check building codes prior to installation.
• Installation MUST comply with local, regional, state
and national codes and regulations.
• Consult insurance carrier, local building, re ofcials
or authorities having jurisdiction about restrictions,
installation inspection, and permits.
CAUTION
WARNING
Asphyxiation Risk.
• Do NOT connect this appliance to a
chimney ue servicing another appliance.
• Do NOT connect to any air distribution duct
or system.
May allow ue gases to enter the house.
Hearth & Home Technologies assumes no
responsibility for the improper performance of the
appliance system caused by:
• Inadequate draft due to environmental conditions
• Down drafts
• Tight sealing construction of the structure
• Mechanical exhausting devices
• Over drafting caused by excessive chimney heights
• Ideal performance is with height of chimney between
14-16 feet (4.26-4.88m) measured from the base of
the appliance.
NOTICE
WARNING
Asphyxiation Risk.
• Negative pressure can cause spillage
of combustion fumes, soot and carbon
monoxide.
• Appliance needs to draft properly for safety.

517 August, 2018 7075-177A
VOYAGEUR GRAND AU
Figure 5.1
1. Remove box and 51mm x 102mm structural boards
being careful not to damage product.
2. Using 7/16 socket or wrench remove one bolt located
inside front part of appliance (Figure 5.1).
3. Moving to the back of the appliance and using 7/16
socket or wrench remove two bolts (Figure 5.1).
4. Carefully pull appliance off of pallet and put in desired
location following Hearth Pad and Clearance to
Combustibles on pages 8 and 9.
F. Removal of Appliance from Shipping
Materials
2
3
D. Tools And Supplies Needed
Before beginning the installation be sure the following tools
and building supplies are available:
To minimize the effects of negative air pressure:
• Install optional outside air kit with the intake facing
prevailing winds during the heating season
• Ensure adequate outdoor air for all combustion
appliances and exhaust equipment
• Ensure furnace and air conditioning return vents are
not located in the immediate vicinity of the appliance
• Avoid installing the appliance near doors, walkways or
small isolated spaces
• Recessed lighting should be a “sealed can” design
• Attic hatches weather stripped or sealed
• Attic mounted duct work and air handler joints and
seams taped or sealed
• Basement installations should be avoided
Reciprocating saw
Pliers
Hammer
Phillips screwdriver
Flat blade screwdriver
Plumb line
Level
Misc. screws and nails
Framing material
High temp caulking material
Gloves
Framing square
Electric drill and bits
Safety glasses
Tape measure
7/16 socket or wrench
1/2-3/4 in. length, #6 or #8 self-drilling screws
• Installation and use of any damaged appliance.
• Modication of the appliance.
• Installation other than as instructed by Hearth &
Home Technologies.
• Installation and/or use of any component part not
approved by Hearth & Home Technologies.
• Operating appliance without fully assembling all
components.
• Operating appliance without legs attached (if
supplied with appliance).
• Do NOT Over re - If appliance or chimney
connector glows, you are over ring.
Any such action that may cause a re hazard.
WARNING
Fire Risk.
Hearth & Home Technologies disclaims any
responsibility for, and the warranty will be
voided by, the following actions:
• Remove appliance and components from packaging
and inspect for damage.
• Report to your dealer any parts damaged in shipment.
• Read all the instructions before starting the installation.
Follow these instructions carefully during the installation
to ensure maximum safety and benet.
E. Inspection of Appliance and Components
Fire Risk.
Inspect appliance and components for damage.
Damaged parts may impair safe operation.
• Do NOT install damaged components.
• Do NOT install incomplete components.
• Do NOT install substitute components.
Report damaged parts to dealer.
WARNING

17 August, 20186 7075-177A
VOYAGEUR GRAND AU
G. Install Checklist
ATTENTION INSTALLER:
Follow this Standard Work Checklist
This standard work checklist is to be used by the installer in conjuction with, not istead of, the instructions contained in this installation manual.
Customer:
Date Installe:
Lot / Address:
Location of Appliance:
Installer:
Dealer / Distributor Phone #:
Serial #:
Model:
WARNING! Risk of Fire or Exposion! Failure to install appliance according to these instruction can lead to a fire or explosion.
Appliance Install
Verified clearances to combustibles.
Appliance is leveled and connector is secured to appliance.
Hearth extension size/height decided.
Outside air kit installed.
Floor protection requirements have been met.
If appliance is connected to a masonry chimney, it should be cleaned and
inspected by a professional. If installed to a factory built metal chimney, the
chimney must be installed according to the manufacturer’s instructions and
clearances.
Chimney
Chimney configuration complies with diagrams.
Chimney installed, locked and secured in place with proper clearance.
Chimney meets recommended height requirements (14-16 feet).
Roof flashing installed and sealed.
Terminations installed and sealed.
Clearances
Combustible materials not installed in non-combustible areas.
Verified all clearances meet installation manual requirements.
Mantels and wall projections comply with installation manual requirements.
Protective hearth strips and hearth extension installed per manual requirements.
Appliance Setup
All packaging and protective materials removed.
Firebrick, baffle and ceramic blanket installed correctly.
All labels have been removed from the door.
All packaging materials are removed from inside/under the appliance.
Manual bag and all of its contents are removed from inside/under the appliance
and given to the party responsible for use and operation.
Hearth & Home Technologies recommends the following:
• Photographing the installation and copying this checklist for your file.
• That this checklist remain visible at all times on the appliance until the installtion is complete.
Comments: Further description of the issues, who is responsible (Installer/Builder/Other Trades, etc.) and corrective action needed:
Comments communicated to party responsible ____________________________ by _____________________ on ___________
(Builder / Gen. Contractor) (Installer) (Date)
_________________________________________________________________________________
______________________________________________________________________________
______________________________________________________________________________
________________________________________________________________________
___________________________________________________________________________________
___________________________________________________________________
___________________________________________________________________________________
____________________________________________________________________________________
YES IF NO, WHY?
______________________________________
______________________________________
______________________________________
______________________________________
______________________________________
______________________________________
______________________________________
______________________________________
______________________________________
______________________________________
______________________________________
______________________________________
______________________________________
______________________________________
______________________________________
______________________________________
______________________________________
______________________________________
______________________________________
______________________________________

717 August, 2018 7075-177A
VOYAGEUR GRAND AU
Figure 7.4 - Top View with Cast Surround
1118mm
838mm
321mm
565mm
1092mm
787mm
828mm
603mm
456mm
127mm
Figure 7.2 - Front View with Small Steel Surround
(SP-GRAND-STD and TRIMKIT-4331)
Figure 7.5 - Front View with Cast Surround (SP-GRAND-CC)
1295mm
864mm
Figure 7.3 - Front View with Large Steel Surround
(SP-GRAND-LRG and TRIMKIT-5134)
Figure 7.1 - Top View with Steel Surround
3 Dimensions and Clearances
A. Appliance Dimensions
124mm124mm
602mm
602mm
830mm
830mm
459mm
459mm
NOTE: Flue Collar size is 152mm inside diameter (ID)

17 August, 20188 7075-177A
VOYAGEUR GRAND AU
655mm
356mm
382mm
686mm
30°
30°
597mm
613mm
73mm
154mm
353in
15°
Figure 8.6 - Side View with Cast Surround and Optional 15
Degree Adapter (DV-6DLR-E15ADSS)
Figure 8.5 - Side View with Cast Surround and Optional 15
Degree Adapter (DV-6DLR-E15ADSS)
Figure 8.4 - Side View with Cast Surround
Figure 8.3 - Side View with Steel Surround and Optional 15
Degree Adapter (DV-6DLR-E15ADSS)
Figure 8.2 - Side View with Steel Surround and Optional 15
Degree Adapter (DV-6DLR-E15ADSS)
Figure 8.1 - Side View with Steel Surround
30°30° 686mm
686mm
385mm
385mm
655mm655mm
359mm
359mm
154mm154mm
73mm
73mm
597mm
597mm 613mm
613mm
15°
15°
357mm
357mm

917 August, 2018 7075-177A
VOYAGEUR GRAND AU
HEARTH EXTENSION
(MINIMUM REQUIREMENT)*
SIDE TRIM (76mm max depth)
SIDE WALL
TOP TRIM (19mm max depth)
572mm
1092mm
1176mm
896mm
HEARTH EXTENSION
(MINIMUM REQUIREMENT)*
FIREPLACE FRONT SURFACE
MANTEL
(305mm max depth)
MANTEL
DEFLECTOR
REQUIRED
1143 mm
572mm
Required Protection
Suggested Protection
NOTE: Keep Ashlip
Clear of Ashes
Figure 9.1
Figure 9.2
Figure 9.3
C
D
A
B
Minimum Opening Dimensions Millimeters
A Height 619
BFront Width (Steel Surround) 835
Front Width (Cast Surround) 835
CBack Width 610
DDepth (Steel Surround) 464
Depth (Cast Surround) 464
NOTE: If trim measurement is over 19mm in depth use
mantle or side clearances to combustibles.
NOTE: Minimum opening dimensions include a 6mm
clearance around unit.
Minimal requirement for extension protection*
The hearth thermal protection minimal requirement
is a minimum quantity of 2 -15mm compressed
cement sheets stacked on top of each other with a
thermal conductivity of 0.5 W/m°K.
NOTE: The replace is to be set on a non-combustible
surface.
B. Clearances to Combustibles,

17 August, 201810 7075-177A
VOYAGEUR GRAND AU
2 - 15mm layers of compressed
cement sheets with a thermal
conductivity of 0.5 W/m˚K.
127mm or more from bottom of
unit, ember protection only
required
NOTE: Hearth Rug may be used in Suggested Area.
Figure 10.1
Material
Thermal Resistance: R value
The R value is a measure of a material’s resistance to heat
transfer.
R value is convenient when more than one material is used
since you can add the R values together, whereas you can
not do this for k value.
The HIGHER the R factor means less heat is being
conducted through the non-combustible material to the
combustible material beneath it.
The R value of a material must be equal or larger then the
required R value to be acceptable.
Quadra-Fire Voyageur Grand ACC does not require a
insulating Floor Protector, as they are tested and comply
with the minimum Floor Protector requirements of AS/
NZS 2918:2001.
NOTE: Heat shield requirements for heat sensitive walls.
Clearances may be reduced by provision of an
appropriately located heat shield refer to AS/NZS
2918:2001 3.2.3.
NOTE: Clearances may only be reduced by means
approved by the regulatory authority having
jurisdiction
Fire Risk.
• Comply with all minimum clearances to
combustibles as specied.
• Failure to comply may cause house re.
WARNING

1117 August, 2018 7075-177A
VOYAGEUR GRAND AU
4 Chimney Systems
Recommended
Location
Marginal
Location
Location
Not
Recommended
Recommended
Location
Location NOT
Recommended
Multi-level Roofs
Windward
Leeward
Outside Air Kit Termination Cap
Figure 11.1
A. Locating Your Appliance & Chimney
Location of the appliance and chimney will affect
performance. As shown in Figure 11.1 the chimney should:
• Install through the warm space enclosed by the building
envelope. This helps to produce more draft, especially
during lighting and die down of the re.
• Penetrate the highest part of the roof. This minimizes
the affects of wind turbulence and down drafts.
• Consider the appliance location in order to avoid oor
and ceiling attic joists and rafters.
• Locate termination cap away from trees, adjacent
structures, uneven roof lines and other obstructions.
Your local dealer is the expert in your geographic area and
can usually make suggestions or discover solutions that will
easily correct your ue problem.

17 August, 201812 7075-177A
VOYAGEUR GRAND AU
C. Chimney Termination Requirements
Follow manufacturer’s instructions for clearance, securing ashing and terminating the chimney.
• Must have an approved and Listed cap
• Must not be located where it will become plugged by snow or other material
• Must terminate at least 91cm above the roof and at least 61cm above any portion of the roof within 305cm.
• Must be located away from trees or other structures
B. Minimum Height of Flue System Exit
Figure 12.1
increase as necessary until nothing
within 3000mm of fluetop
increase from
1000mm minimum
until clear within
3000mm of flue top
any nearby structure
3000mm
3000mm
3000mm
or less
more than 3000mm
600mm
minimum
NOTICE:
• Chimney performance may vary.
• Trees, buildings, roof lines and wind conditions affect
performance.
• Chimney height may need adjustment if smoking or
overdraft occurs.
NOTICE:
Locating the appliance in a basement or in a location
of considerable air movement can cause intermittent
smoke spillage from appliance. Do not locate
appliance near
• Frequently open doors
• Central heat outlets or returns
WARNING
Asphyxiation Risk.
• DO NOT CONNECT THIS Appliance TO A
CHIMNEY FLUE SERVICING ANOTHER
APPLIANCE.
• DO NOT CONNECT TO ANY AIR
DISTRIBUTION DUCT OR SYSTEM.
May allow ue gases to enter the house.
Improper installation, adjustment, alteration, service
or maintenance can cause injury or property damage.
Refer to the owner’s information manual provided with
this appliance. For assistance or additional information
consult a qualied installer, service agency or your dealer.
WARNING
WARNING
Fire Risk.
Follow Chimney Connector Manufacturer’s
Instructions for Proper Installation.
ONLY use connector:
• Within the room, between appliance and
ceiling or wall.
• Connector shall NOT pass through:
• Attic or roof space
• Closet or similar concealed space
• Floor or ceiling
Maintain minimum clearances to combustibles

1317 August, 2018 7075-177A
VOYAGEUR GRAND AU
D. Venting Systems
Chimney Connector:
It is also known as ue pipe or stove pipe. It must be
152mm minimum diameter stainless steel connector pipe.
Chimney:
The chimney can be new or existing, masonry or
prefabricated and must meet the following minimum
requirements as specied below.
E. Inspections
Existing chimneys should be inspected and cleaned by a
qualied professional prior to installation. The chimney must
not have cracks, loose mortar or other signs of deterioration
and blockage. Hearth & Home recommends a certied pro-
fessional or a technician, under the direction of a certied
professional.
F. Larger Chimneys
Hearth & Home recommended that chimneys with larger
diameters than 152mm be fully relined. An oversized ue
can affect draft and impair performance and will allow
increased build-up of creosote.
WARNING
Risk of Fire!
Follow venting manufacturer’s clearances and
instructions when installing venting system.
Fire Risk.
Inspection of Chimney:
• Chimney must be in good condition.
• Factory-built chimney must be 152mm.
WARNING
NOTICE: Check with your local building authorities.

17 August, 201814 7075-177A
VOYAGEUR GRAND AU
• Must have at least 16mm re clay lining joined with refractory cement.
G. Masonry Chimney
UL 1777 Insulated Stainless Steel
Liner or Other Approved Lining System
Follow Manufacturer’s Instructions
on Insulation and Support
For Zero or Other Non-Code Clearances,
Follow Approved Liner Manufacturer’s Specific
Insulation Requirements: Different Clearances
May Require Different Specifications
Masonry Chimney Must
Have Structural Integrity
UL 1777 Insulated Stainless Steel
Liner or Other Approved Lining System
Minimum 8 in. (203mm) Masonry
Thickness in Front of Smoke Chamber
Damper Plate Removed or
Fastened in Open Position
Seal with Non-Combustible Material
Minimum Clearance in Accordance
with Insert Listing
Floor Protection in
Accordance with Insert
Listing
Follow Manufacturer’s
Instructions for Maximum
Liner Extension Above
Chimney
Maximum 30 Degrees
Offset in Chimney
Combustible Floor
Figure 14.1
Generic Insert Model Shown in Illustration
NOTE: Installations into a clay ue without a stainless steel liner may reduce draw which affects performance, will
cause the glass to darken and produce excessive creosote and create start-up issues.
• The masonry wall of the chimney, if brick or modular block, must be a minimum of 102mm nominal thickness.
• A chimney of rubble stone must be at least 305mm thick.
• Should be lined with a 152mm stainless steel ue liner to improve performance and reduce creosote build-up.
• An equivalent liner must be a listed chimney liner system or other approved material.
• No dilution air is allowed to enter the chimney.
- Secure the replace damper in the open position. If this cannot be accomplished, it will be necessary to remove
the damper
-Seal damper area of chimney around chimney connector with a high temperature sealant or seal insert against
the face of the replace.
- Both methods must be removable and replaceable for cleaning and re-installation.
• When possible, install an airtight clean-out door to the rear of the smoke shelf.
NOTE: Masonry chimneys are signicantly less than ideal for venting solid fuel appliances. A masonry chimney is not
subject to any temperature limit test, therefore a full reline is strongly recommended.

1517 August, 2018 7075-177A
VOYAGEUR GRAND AU
Figure 15.1
The chimney can be new or existing, masonry or
prefabricated and must meet the following minimum
requirements:
• Must be minimum 152mm inside diameter of high
temperature chimney.
• Must use components required by the manufacturer for
installation.
• Must maintain clearances required by the manufacturer
for installation.
• Refer to manufacturers instructions for installation
• This insert is listed to UL 1482 Standard and is
approved for installation into listed factory-built zero
clearance replaces listed to UL 127 conforming to the
following specications and instructions:
- The original factory-built clearance replace
chimney cap must be re-installed after installing the
approved chimney liner meeting type UL 103 HT
requirements (2100°F) per UL 1777.
-If the chimney is not listed as meeting HT
requirements, or if the factory built replace was
tested prior to 1998, a full height listed chimney
liner must be installed from the appliance ue collar
to the chimney top.
- The liner must be securely attached to the insert
ue collar and the chimney top.
- The air ow of the factory-built zero-clearance
replace system must not be altered. The ue liner
top support attachment must not reduce the air
ow for the existing air-cooled chimney system.
-No dilution air is allowed to enter the chimney.
1. Secure the replace damper in the open position. If this
cannot be accomplished, it will be necessary to remove
the damper
2. Seal damper area of chimney around chimney
connector with a high temperature sealant or seal
insert against the face of the replace.
3. Both methods must be removable and replaceable for
cleaning and re-installation.
H. Prefabricated Metal Chimney
Minimum 203mm Masonry Thickness
in Front of Smoke Chamber
Damper Plate Removed or
Fastened in Open Position
Seal with Non-
Combustible Material
Minimum Clearance in Accordance with
Insert Listing
Floor Protection in
Accordance with Insert
Listing
Combustible Floor
Airtight Insulated Clean-Out
Stainless Steel Chimney Connector
Must Extend to Flue Liner
Flue Liner with Required Air Space
Generic Insert Model Shown in Illustration
NOTE: Refer to chimney liner manufacturer for
recommendations on supporting the liner.
Installation into replaces without a permit will
void the listing.
To maintain the functionality of the replace’s chimney
system you may use a Simpson Dura-Vent DuraLiner
Slip Hanger, Part # 4671, and attach to the bottom of the
replace chimney cap to support the liner. You have two
options to completing the installation.
Option one - Not required to use liner cap:
Re-attach the existing top of the chimney cap.
Option two - Using liner cap:
Re-attach the existing top of the chimney cap and install a
new storm collar and a new liner cap.
Risk of Fire!
Follow venting manufacturer’s clearances and
instructions when installing venting system
WARNING
Fire Risk.
When lining air-cooled factory-built chimneys:
• Run approved chimney liner
• Re-install original factory built chimney cap
ONLY
• DO NOT block cooling air openings in
chimney
• Blocking cooling air will overheat the chimney
WARNING

17 August, 201816 7075-177A
VOYAGEUR GRAND AU
The following parts may be removed:
Damper Smoke Shelf or Bafe
Ember Catches Fire Grate
Viewing Screen/Curtain Doors
• The replace must not be altered. Cutting any sheet
metal parts of the replace in which the replace insert
is to be installed is prohibited per ANSI Z21.88 except
that the damper may be removed to accommodate a
direct-connect starter pipe or chimney liner,
• External trim pieces which do not affect the operation
of the replace may be removed providing they can be
stored on or within the replace for reassembly if the
insert is removed.
• The permanent metal warning label provided in the
component pack must be attached to the back of the
replace, with screws or nails, stating that the replace
may have been altered to accommodate the insert,
and must be returned to original condition for use as a
conventional replace.
• If the hearth extension is lower than the replace
opening, the portion of the insert extending onto the
hearth must be supported.
• Manufacturer designed adjustable support kit can be
ordered from your dealer.
• Final approval of this installation type is contingent
upon the authority having jurisdiction.
LINER CONNECTOR
FLUE
GAS
DIRECTION
CRIMPED
END
TOWARDS
STOVE
Figure 16.1
L. Altering the Fireplace
K. Securing Chimney Components
All joints should be secured with 3 sheet metal screws or
rivets per pipe manufacturers instructions. The sections
must be attached to the insert and to each other with the
crimped (male) end pointing toward the insert (Figure
16.1).
The insert must be installed as per the requirements of
your local inspection authority. It is recommended to use
a full liner as it is the safest installation and provides the
most optimum performance. Your retailer should be able to
help you decide which system would be the best for your
application.
The use of this connection method not only increases
the safety of your insert by directing the hot gases up the
ue, but will also help increase the unit’s efciency and
decrease creosote deposits in the chimney.
When a connected ue or liner is in use, the insert is able
to “breathe” better by allowing a greater draft to be created.
This great draft can decrease problems such as difcult
start-ups, smoking out the door and dirty glass.
1. When installed in a factory built replace, a full
stainless steel rigid is mandatory, for both safety and
performance purposes. When a ue or liner is in use,
the insert is able to breathe better by allowing a great
draft to be created. The great draft can decrease
problems such as difcult start-ups, smoking out the
door, and dirty glass.
2. In order to position the ue liner, the existing rain cap
must be removed from your chimney system. In most
cases the ue damper should also be removed to allow
passage of the liner.
3. In most cases opening the existing spark screens fully
should give enough room for the insert installation. If it
does not, remove and store.
4. If the oor of your replace is below the level of the
replace opening, adjust the inserts leveling bolts
to accommodate the difference. When additional
shimming is required, use non-combustible masonry or
steel shims.
5. Measure approximately the alignment of the ue liner
with the position of the smoke outlet hole on the insert
to check for possible offset. If an offset is required, use
a proper stainless steel unit available with the chimney
liner.
6. Once the above items have been checked, slide your
insert into position after rst positioning the ue liner
and offset if required. (Re-install rain-cap at completion
of installation).
I. Install into a Masonry Fireplace
J. Install Into a Factory Built Fireplace
Risk of Fire!
Follow venting manufacturer’s clearances and
instructions when installing venting system
WARNING
The following modications of factory-built replaces are
permissible:

1717 August, 2018 7075-177A
VOYAGEUR GRAND AU
N. Ovalizing Round Stainless Steel Liners
Ovalizing round stainless steel liners to accommodate the
liner passing through the damper region of a replace is an
allowable and acceptable practice.
Ensure that the ovalization is minimized to the extent
required to t through the damper.
O. Chimney Height / Rise and Run
To be sure that your Quadra-Fire insert burns properly, the
chimney draft (static pressure) should be approximately
-2.54mm water column (W.C.) during a high burn and
-1.016mm W.C. during a low burn, measured 152mm
above the top of the insert after one hour of operation at
each burn setting.
M. Zero-Clearance Fireplace
A permit may be required for installations, nal approval is
contingent of the authority having local jurisdiction. Consult
insurance carrier, local building, re ofcials or authorities
having jurisdiction about restrictions, installation inspection,
and permits.
Inspect the existing replace and chimney for any damage
or aws such as burnouts, metal or refectory warping.
Inspection to a minimum of NFPA 211 Level II is
recommended. All repairs must be made prior to installing
an insert. The replace must be structurally sound and be
able to support the weight of the solid-fuel insert
The factory-built chimney must be listed per UL 127 or ULC
610-M87 for all installations. Install thermal protection per
this appliance listing requirements.
A full height 6 inch diameter stainless steel full height
listed chimney liner must be installed meeting type HT
(2100°F) requirements per UL 1777 (USA) or ULC S635
with “0” clearance to masonry (Canada). The full liner must
be attached to the insert ue collar and to the top of the
existing chimney.
The ue liner top support attachment must not reduce the
air ow for the existing air-cooled chimney system. Re-
install original factory-built chimney cap only (See Section
F., Prefabricated Metal Chimney).
To prevent room air passage to the chimney cavity of the
replace, seal either the damper area around the chimney
liner or the insert surround. Circulating air chamber (i.e. in a
steel replace liner or metal hearth circulatory) may not be
blocked. The air ow within and around the replace shall
not be altered, blocked by the installation of the insert. (i.e.
no louvers or cooling air inlet or outlet ports may be blocked
by the insert or the insert surround.
See “H. Altering the Fireplace” for modications allowed for
factory-built replaces.
WARNING
Risk of Asphyxiation!
• Do NOT connect this appliance to a chimney ue
servicing another appliance or to any air distribution
duct or system.
This may allow ue gases to enter the house.
NOTE: These are guidelines only, and may vary
somewhat for individual installations.
• This product was designed for and tested on a 152mm
chimney, 4.27-4.87m high, (includes appliance height)
measured from the base of the appliance.
• The further your stack height or diameter varies from
this conguration, the possibility of performance
problems exists.
• Chimney height may need to be increased by 2 - 3%
per each 304.8m above sea level.
• It is not recommended to use offsets or elbows at
altitudes above 1219.2m above sea level or when there
are other factors that affect ue draft.
Fire Risk.
This appliance relies upon natural draft to
operate properly.
• Chimney heights exceeding 7.62m from
base of appliance may create an over-draft
situation.
• Overdraft condition may create over-ring.
Over-ring may ignite creosote and/or damage
appliance and chimney
WARNING
Fire Risk.
Do NOT pack insulation or other combustibles
between spacers.
• ALWAYS maintain specied clearances
around venting and spacers.
• Install spacers as specied.
Failure to keep insulation or other material away
from vent pipe may cause re.
WARNING

17 August, 201818 7075-177A
VOYAGEUR GRAND AU
Figure 18.1
Grille hinges
downward
Remove Screws &
Pull Access Assembly
away from Insert Outside Cover
Plate A
Figure 18.2
Outside Air Cover
Plate B (Discard)
T
ermination
Cap
Flex Adapter
A. Outside Air Kit Installation
A source of air (oxygen) is necessary in order for
combustion to take place. Whatever combustion air is
consumed by the re must be replaced. Air is replaced via
air leakage around windows and under doors. In homes
that have tightly sealed doors and windows, an outside air
source is needed. An optional Outside Air Kit is available.
Items Needed for Installation (not supplied)
• 4 inch ex aluminum pipe, or if using alternate material,
then it shall be made from durable, non-combustible,
heat resistant material up to 350°F. Cut the pipe to the
required length for your installation.
• Phillips head screw driver
• 5/32 Allen Wrench
• Silicone sealant
5 Appliance Set-Up
Option One - Installation Instructions
1. Swing grille down to expose the two screws (Figure
18.1).
2. Remove the two screws and pull the access assembly
away from the appliance.
3. Assemble the outside air cover plate A supplied in
component pack.
4. Re-install the access assembly.
5. Remove the outside air cover plate B on outer can and
discard (Figure 18.2).
6. Install optional ex adapter to outer can.
NOTE: Do not use plastic wire ties that come with the
kit as they will melt. You may need to install
the ex pipe into the rebox rst depending on
installation. Attach ex to adapter with at least 2
screws.
7. Ensure existing access hole in replace is sufcient to
feed the 4 inch ex.
8. After sliding can into replace, feed ex into cut
opening to obtain outside combustion air.
9. Level outer can and install appliance.
Option Two - Installation Instructions
10. Swing grille down to expose the two screws (Figure
18.1).
11. Remove the two screws and pull the access assembly
away from the appliance.
12. Assemble the outside air cover plate A supplied in
component pack.
13. Re-install the access assembly.
14. Remove the outside air cover plate B on outer can and
discard (Figure 18.2).
15. Ensure existing access hole in replace will not be
covered by the outer can. Existing outside air intake
hole may be under at the rear or side of outer can.
Outside air may also enter down existing chimney
chase in some situations.
16. Level outer can and install appliance. After installing
the appliance in the outer can, seal the replace
opening and trim package with insulation to prevent air
leakage into the room.
WARNING
Fire Risk.
Asphyxiation Risk.
Do not draw outside combustion air from:
• Wall, oor or ceiling cavity
• Enclosed space such as an attic or garage
• Close proximity to exhaust vents or
chimneys
Fumes or odor may result
Asphyxiation Risk.
Outside air inlet must be located to prevent
blockage from:
- Leaves, snow, ice or other debris
Block may cause combustion air starvation
Smoke spillage may set off alarms or irritate
sensitive individuals.
WARNING
Asphyxiation Risk.
Length of outside air supply duct shall NOT
exceed the length of the vertical height of the
exhaust ue.
• Fire will not burn properly
• Smoke spillage occurs when door is opened
due to air starvation.
WARNING

1917 August, 2018 7075-177A
VOYAGEUR GRAND AU
Flue Collar Stove Pipe/Liner
Gasket
Figure 19.2
Figure 19.3
Remove 2 screws from both sides.
Adjust the legs up or down to level
appliance.
C. Securing Stove Pipe/Liner to Flue Collar
1. There are 4 already drilled holes in the ue collar 90
degrees apart. Attach the ue collar to the stove pipe/
liner. If the seal is questionable use high temperature
sealant such as stove mastic (Figure 19.2).
2. Attach gasket to bottom side of ue collar with a thin
coat of silicone.
B. Optional Offset Adapter Installation
Optional use of a Simpson Duravent 15° Universal Elbow
Part Number 4615 may be purchased directly through your
local Simpson Duravent Pipe Distributor or from your local
Quadra-Fire dealer, Part Number DV-6DLR-E15ADSS.
Figure 19.1 shows a vertical installation and also how to
create an optional 30° elbow installation.
The 15° elbow may be secured directly to the ue collar.
Follow the pipe manufacturer’s instructions for using
screws or rivets for attachment. Most pipe manufacturer’s
152mm diameter ue liners may be attached directly to the
top of the 15° elbow.
D. Leveling Legs
1. Remove the 2 screws already installed on each leg.
2. Move legs to the desired height.
3. Re-install the screws to secure in place.
A
B
30 degree
30o
A
B
Vertical
Figure 19.1
Flue Adapter A B
Vertical 344mm 532mm
30 Degree 371mm 525mm

17 August, 201820 7075-177A
VOYAGEUR GRAND AU
5/16 Nuts
Attachment
Bar
5/16 Bolts
Figure 20.1
Corner Brackets
Figure 20.3
Figure 20.2
Strain Relief for
Blower Cord and
Cover Plug for hole
in each side
Secure 2 Sides to Top
Mounting Tabs
Slide into Slots
on Firebox Face
Secure to
Firebox Face
E. Securing Appliance to Stove Pipe/Liner
1. Once you have the appliance in place and secured,
reach up through the ue opening and grab the
attachment bar and pull down inside ue opening
(Figure 20.1).
2. Insert the 5/16 bolts inside the cast ue and through
the chimney mounting bar. Securely tighten the nuts.
Fasteners are provided.
3. Re-install the tube channel assembly, bafe board,
ceramic blanket and bafe protection channel.
F. Surround & Trim Kit Installation
Standard Size: 109.22cm W x 78.74cm H
Large Size: 129.54cm W x 86.36cm H
1. Lay surround face down on a protected surface to
prevent scratching.
2. Using a 4 to 6 inches long Phillips head screw driver
attach the side surrounds to the top surround using (2)
#8 sheet metal screws on each side provided with the
kit (Figure 20.3).
3. Lay the trim face down and place the corner brackets
into position.
4. Using a standard at screw driver tighten the corner
brackets (Figure 20.3).
5. Slide the assembled trim set over the surround set. and
then over the appliance matching the mounting tabs on
the side pieces with the slots on the appliance (Figure
20.3).
6. Align the 2 screws in the top surround piece to the 2
alignment holes on the appliance top. Secure in place
(Figure 20.2).
7. Use the strain relief in the surround side for blower cord
installation and use the cover plug to insert into the
hole where the blower cord is not installed.
