Quantum CHECK POINT SPARK 1500 Series Instruction Manual

Models: V-80, V-80W, V-81, V-81W, V-81WL, V-81WD, V-81R, V-81WLR, V-82, V-83 [Classification: Protected]
12 April2022
QUANTUM SPARK 1500,
1600 AND 1800
APPLIANCE SERIES
R80.20.40
Locally Managed
Administration Guide

Check Point Copyright Notice
Quantum Spark 1500, 1600 and 1800 Appliance Series R80.20.40 Locally Managed Administration Guide | 2
Check Point Copyright Notice
© 2022 Check Point Software Technologies Ltd.
All rights reserved. This product and related documentation are protected by copyright and distributed under
licensing restricting their use, copying, distribution, and decompilation. No part of this product or related
documentation may be reproduced in any form or by any means without prior written authorization of Check
Point. While every precaution has been taken in the preparation of this book, Check Point assumes no
responsibility for errors or omissions. This publication and features described herein are subject to change
without notice.
RESTRICTED RIGHTS LEGEND:
Use, duplication, or disclosure by the government is subject to restrictions as set forth in subparagraph (c)
(1)(ii) of the Rights in Technical Data and Computer Software clause at DFARS 252.227-7013 and FAR
52.227-19.
TRADEMARKS:
Refer to the Copyright page for a list of our trademarks.
Refer to the Third Party copyright notices for a list of relevant copyrights and third-party licenses.

Quantum Spark 1500, 1600 and 1800 Appliance Series R80.20.40 Locally Managed Administration Guide
Quantum Spark 1500, 1600 and 1800 Appliance Series R80.20.40 Locally Managed Administration Guide | 3
Important Information
Latest Software
We recommend that you install the most recent software release to stay up-to-date with the
latest functional improvements, stability fixes, security enhancements and protection against
new and evolving attacks.
Certifications
For third party independent certification of Check Point products, see the Check Point
Certifications page.
Check Point R80.20.40
For more about this release, see the R80.20.40 home page.
Latest Version of this Document in English
Open the latest version of this document in a Web browser.
Download the latest version of this document in PDF format.
Feedback
Check Point is engaged in a continuous effort to improve its documentation.
Please help us by sending your comments.
Revision History
Date Description
12 April2022 First release of this document

Table of Contents
Quantum Spark 1500, 1600 and 1800 Appliance Series R80.20.40 Locally Managed Administration Guide | 4
Table of Contents
Quantum Spark 1500, 1600 and 1800 Appliance Series Overview 11
1500 Appliances 11
1600 and 1800 Appliances 11
Getting Started 13
Setting up the Quantum Spark Appliance 15
First Time Deployment Options 16
Zero Touch Cloud Service 17
Deploying from a USB Drive or SD Card 18
Sample Configuration File 18
Preparing the Configuration Files 18
Deploying the Configuration File - Initial Configuration 19
Deploying the Configuration File - Existing Configuration 20
Viewing Configuration Logs 20
Troubleshooting Configuration Files 21
Configuration File Error 21
Suggested Workflow - Configuration File Error 21
Sample Configuration Log with Error 22
Using the set property Command 22
Configuration and Upgrade Scenarios 23
Configuring Cloud Services 23
Configuring a Guest Network 24
Configuring VPN 25
Configuring Remote Access VPN 25
Introduction 25
Prerequisites 25
Remote Access Configuration 25
L2TP VPN Client configuration 26
Configuring Site to Site VPN with a Preshared Secret 27
Introduction 27
Prerequisites 27
Configuration 27
Monitoring 27
Configuring Site to Site VPN with a Certificate 27

Table of Contents
Quantum Spark 1500, 1600 and 1800 Appliance Series R80.20.40 Locally Managed Administration Guide | 5
Introduction 27
Prerequisites 27
Configuration 28
Trust Procedures 28
Monitoring 29
Managing Clusters 30
Configuring a Cluster 30
Upgrading a Cluster 31
Configuring QoS 33
Appliance Configuration 34
The Home Tab 35
Viewing System Information 35
Controlling and Monitoring Software Blades 36
Setting the Management Mode 38
Configuring Cloud Services 40
Managing Licenses 43
Viewing the Site Map 45
Notifications 45
Managing Active Devices 46
Viewing Monitoring Data 48
Network 48
Troubleshooting 49
Viewing Reports 50
Using System Tools 52
Managing the Device 54
Configuring Internet Connectivity 54
The 'Configuration' tab 55
Prefix Delegation (IPv6 only) 58
Neighbor Discover Protocol (ND Proxy) - IPv6 only 59
DS-Lite (Dual Stack Lite, IPoE) 60
IPIP 60
Creating a New Bond (WAN) 62
Configuring a USB Cellular Connection 63
Configuring an LTE Internet Connection (WiFi-LTE models only) 63
The 'Connection Monitoring' tab 65

Table of Contents
Quantum Spark 1500, 1600 and 1800 Appliance Series R80.20.40 Locally Managed Administration Guide | 6
The 'Advanced' tab 66
Monitoring 68
Configuring Wireless Network 70
Wireless Scheduler 70
Wi-Fi Quality Analyzer 74
Configuring the Local Network 76
Reserved IP Address for Specific MAC 77
Switch 77
WAN as LAN 78
Monitor Mode 79
Physical Interfaces 80
Bridge 81
VLANs 84
Alias IP 84
VPN Tunnel (VTI) 85
Virtual Access Point (VAP) 86
BOND 87
Configuring a Hotspot 89
Configuring the Routing Table 92
Configuring MAC Filtering 95
802.1x Authentication Protocol 96
Configuring the DNS Server 98
Configuring the Proxy Server 99
Backup, Restore, Upgrade, and Other System Operations 100
Using the Software Upgrade Wizard 102
Welcome 102
Upload Software 103
Upgrade Settings 103
Upgrading 103
Backing up the System 103
Configuring Local and Remote System Administrators 105
Configuring Administrator Access 111
Managing Device Details 113
Managing Date and Time 114
Configuring DDNS and Access Service 115

Table of Contents
Quantum Spark 1500, 1600 and 1800 Appliance Series R80.20.40 Locally Managed Administration Guide | 7
DDNS 115
Reach My Device 115
Remote Access to the WebUI 116
Remote Access to the CLI 116
Using System Tools 116
Managing Installed Certificates 116
Managing Internal Certificates 119
Configuring High Availability 121
Advanced Settings 125
Managing the Access Policy 158
Configuring the Firewall Access Policy and Blade 158
Firewall Policy 159
Application & URL Filtering 160
Updates 161
User Awareness 162
Tracking 163
More Information 163
Working with the Firewall Access Policy 164
Firewall Policy 164
Configuring Access Rules 167
Updatable Objects 169
Customizing Messages 169
Defining Firewall Servers 171
Defining NAT Control 174
Advanced - Creating and Editing NAT Rules 179
Inspecting VoIP Traffic 181
Introduction 182
Configuration 184
Working with User Awareness 185
Configuring the QoS Blade 188
Working with QoS Policy 190
SSL Inspection Policy 193
SSL Inspection 193
Deploying SSL Inspection 193
SSL Inspection Bypass Policy 194

Table of Contents
Quantum Spark 1500, 1600 and 1800 Appliance Series R80.20.40 Locally Managed Administration Guide | 8
HTTPS Categorization 195
SSL Inspection Exceptions 196
SSL Inspection Advanced 197
Managing Threat Prevention 198
Configuring Threat Prevention Blade Control 198
Configuring Threat Prevention Policy Exceptions 201
Threat Prevention Exceptions 201
allowlists 201
Threat Prevention - Infinity SOC 202
Viewing Infected Devices 204
Viewing the IPS Protections List 207
Advanced Threat Prevention Engine Settings 208
IPS 208
Anti-Virus 208
Anti-Bot 210
Threat Emulation 211
User Messages 212
Configuring the Anti-Spam Blade Control 214
Configuring Anti-Spam Exceptions 216
Managing VPN 217
Configuring the Remote Access Blade 217
Configuring Remote Access Users 220
Two-Factor Authentication 222
Remote Access - Connected Remote Users 225
Configuring Remote Access Authentication Servers 226
Configuring Advanced Remote Access Options 229
Office Mode 229
DNS Servers for Remote Access users 230
DNS Domain Name 230
SSL VPN bookmarks 231
Configuring the Site to Site VPN Blade 232
Configuring VPN Sites 233
Configuring Advanced Site to Site Community Settings 239
Viewing VPN Tunnels 240
Configuring Advanced Site to Site Settings 241

Table of Contents
Quantum Spark 1500, 1600 and 1800 Appliance Series R80.20.40 Locally Managed Administration Guide | 9
Configuring a Local Encryption Domain 241
Configuring the Appliance Interfaces 242
Tunnel Health Monitoring 243
Managing Trusted CAs 244
Managing Installed Certificates 246
Managing Internal Certificates 248
Managing Users and Objects 250
Working with User Awareness 250
Configuring Local Users and User Groups 253
Configuring Local and Remote System Administrators 255
Managing Authentication Servers 261
Managing Applications & URLs 265
Managing System Services 267
Managing Service Groups 270
Managing Network Objects 272
Managing Network Object Groups 275
Logs and Monitoring 276
Viewing Security Logs 276
Viewing System Logs 278
Configuring External Log Servers 279
External Check Point Log Server 279
Syslog Server Configuration 280
Secured Syslog 281
Notifications 282
Managing Active Devices 282
Wireless Active Devices 282
Paired Mobile Devices 282
Viewing Infected Devices 282
Viewing VPN Tunnels 283
Viewing Active Connections 284
Access Points 285
Viewing Monitoring Data 285
Viewing Reports 285
Using System Tools 285
SNMP 286

Table of Contents
Quantum Spark 1500, 1600 and 1800 Appliance Series R80.20.40 Locally Managed Administration Guide | 10
SNMP Traps Receivers 287
SNMP Traps 287
SNMPTraps for VPNTunnels 287
SNMP Traps for Hardware Sensors 287
Advanced Configuration 289
Upgrade Using a USB Drive 289
Upgrade Using an SD Card 290
Boot Loader 291
Upgrade Using Boot Loader 292
Restoring Factory Defaults 293
RESTful API 295
Enabling and disabling the REST API 295
Request Structure 295
Response Structure 296
Versioning 296
REST API Commands 297
(1) Login 297
(2) Logout 298
(3) Generate-Report 298
(4) Run-Clish-Command 299

Quantum Spark 1500, 1600 and 1800 Appliance Series Overview
Quantum Spark 1500, 1600 and 1800 Appliance Series R80.20.40 Locally Managed Administration Guide | 11
Quantum Spark 1500, 1600 and
1800 Appliance Series Overview
1500 Appliances
Quantum Spark1500 appliance series includes the 1530, 1550, 1570, 1590, and 1570R appliances. These
appliances support the Check Point Software Blade architecture and provide independent modular security
building blocks. You can quickly enable and configure the Software Blades to meet your specific security
needs.
Quantum Spark 1530, 1550, 1570, 1590, and 1570R appliances deliver integrated unified threat
management to protect your organization from today's emerging threats. Based on proven Check Point
security technologies such as Stateful Inspection, Application Intelligence, and SMART (Security
Management Architecture), the appliances provides simplified deployment while delivering uncompromising
levels of security.
These appliances run an embedded version of the Gaia operating system. The appliances include core
configuration elements such as clish interface, SNMPv2/3 and routing stack implementations. In addition to
the Gaia features, Embedded Gaia contains support for built-in network switches, wireless networks, 4G
LTE Internet connectivity, multiple Internet connections (more than 2) in High Availability or Load Sharing
mode, Policy Based Routing, and DDNS support. Quick deployment with USB is supported for all
appliances, and with SD card and Dual SIM card for the 1570 / 1590 appliances. For more information, see
the 1500 appliance series product page.
This guide describes all aspects that apply to the Quantum Spark 1530 / 1550, 1570R, and 1570 / 1590
Appliances.
1600 and 1800 Appliances
The Quantum Spark 1600 / 1800 Security Appliances, part of the new 1600 / 1800 Appliance family, deliver
enterprise-grade security, run the R80 code base in an all-in-one security solution to protect Medium
Business employees, network and data from cyber-theft.
The 1600 / 1800 Security Gateways offer integrated, multi-layered security in a 1U form factor, a high
performance platform which is easy and simple to configure and manage. The Security Gateway offers
firewall, VPN, Anti-Virus, Application Visibility and Control, URL Filtering, Email Security, and SandBlast
Zero-Day Protection.
Quantum Spark 1600 / 1800 Security Appliances can be managed either locally in a Web interface, or
centrally by means of a cloud-based Quantum Spark Security Management Portal (Quantum Spark Portal).
Note - Some topics only apply to specific appliances or models.
Appliance Model Appliance
Homepage
1530 / 1550 V-80 Wired, V-80W WiFi sk157412
1570 / 1590 V-81 Wired, V-81W WiFi, V-81WL WiFi-LTE, V-81WD WiFi-
DSL
sk157412

Quantum Spark 1500, 1600 and 1800 Appliance Series Overview
Quantum Spark 1500, 1600 and 1800 Appliance Series R80.20.40 Locally Managed Administration Guide | 12
Appliance Model Appliance
Homepage
1570R V-81R, V-81WLR sk166654
1600 V-82 (wired only) sk168880
1800 V-83 (wired only) sk168880
For front, side, and back panel details for each appliance, see the relevant Getting Started Guide .
Review these materials before doing the procedures in this guide:
nR80.20.40 SMB Release Notes
nKnown Limitations
nResolved Issues
nGetting Started Guide
nSmall Business Security video channel
See the SMB R80.20.40 home page.

Getting Started
Quantum Spark 1500, 1600 and 1800 Appliance Series R80.20.40 Locally Managed Administration Guide | 13
Getting Started
This Administration Guide describes:
nInstalling the appliance and connecting the cables.
nConfiguring Security Policies.
nConfiguring local users and administrators.
nConfiguring VPN.
nConfiguring a cluster.
nConfiguring advanced settings.
nLogging and monitoring
Workflow:
1. Install the Quantum Spark appliance and connect all cables.
See the:
n
Getting Started Guide for 1530 / 1550 Appliances .
n
Getting Started Guide for 1570 / 1590 Appliances .
n
Getting Started Guide for 1570R Appliances .
n
Getting Started Guide for 1600 / 1800 Appliances .
n
"Setting up the Quantum Spark Appliance" on page15 .
2. Follow the applicable First Time Deployment option.
See "First Time Deployment Options" on page16 .
3. Install the required licenses.
See "Managing Licenses" on page43
4. Configure the required users and objects.
See "Managing Users and Objects" on page250 .
5. Configure required appliance settings.
See "Managing the Device" on page54 .
6. Configure and install the required Security Policies.
See:
n
"Managing the Access Policy" on page158
n
"Managing Threat Prevention" on page198
7. Make sure the appliance works as required.
See "Logs and Monitoring" on page276 .
8. Configure other required settings, such as:

Getting Started
Quantum Spark 1500, 1600 and 1800 Appliance Series R80.20.40 Locally Managed Administration Guide | 14
nVPN (see
"Configuring VPN" on page25 and "Managing VPN" on page217 )
nClusters (see
"Managing Clusters" on page30 )
nQoS (see
"Configuring QoS" on page33 )

Setting up the Quantum Spark Appliance
Quantum Spark 1500, 1600 and 1800 Appliance Series R80.20.40 Locally Managed Administration Guide | 15
Setting up the Quantum Spark
Appliance
To set up the Quantum Spark 1530 / 1550, 1570 / 1590, 1570R, 1600, and 1800 Appliance:
1. Remove the Quantum Spark Appliance from the shipping carton and place it on a tabletop.
2. Identity the network interface marked as LAN1.
This interface is preconfigured with the IP address 192.168.1.1 and Subnet Mask 255.255.255.0.
Connecting the Cables:
1. Connect the power cable to the appliance. The appliance is connected directly to the power source.
1530 / 1550 appliances only: Turn on the power switch located on the back panel.
2. When the appliance is turned on, the Power LED on the front panel lights up in red for a short period.
The LED then turns blue and starts to blink. This shows a boot is in progress and firmware is being
installed.
When the LED turns a solid blue, the appliance is ready for login.
Note – The LED is red if there is an alert or error.
nIf you use an external modem:
Connect the Ethernet cable to the WAN port on the appliance back panel and plug it into your
external modem or router's PC/LAN network port. The Internet LED on the appliance front
panel lights up when the Ethernet is connected.
nIf you do not use an external modem:
Connect the telephone cable to the DSL port on the appliance back panel and plug it into the
DSL line socket. The DSL LED as well as the Internet Link LED remains off until you configure
the appliance, including setting up the DSL as an internet connection.
3. Connect the standard network cable to the LAN1 port on the appliance and to the network adapter on
your PC.
Note - Wait 10 seconds between power cycles (off and on).

First Time Deployment Options
Quantum Spark 1500, 1600 and 1800 Appliance Series R80.20.40 Locally Managed Administration Guide | 16
First Time Deployment Options
There are different options for first time deployment of your Small and Medium Business (SMB) gateways:
nFirst Time Configuration Wizard - For more information, see the
Getting Started Guide for your
appliance model.
n
"Zero Touch Cloud Service" on page17
n
"Deploying from a USB Drive or SD Card" on page18
Note - SD card deployment is supported only in 1570 / 1590 appliances.

Zero Touch Cloud Service
Quantum Spark 1500, 1600 and 1800 Appliance Series R80.20.40 Locally Managed Administration Guide | 17
Zero Touch Cloud Service
The Zero Touch Cloud Service lets you easily manage the initial deployment of your gateways in the Check
Point Zero Touch Portal .
Note - You cannot use Zero Touch if you connect to the internet through a proxy server.
Zero Touch enables a gateway to automatically fetch settings from the cloud when it is connected to the
internet for the first time.
Note - The appliance is fully configured after you complete the First Time Configuration Wizard (click Finish
on the final screen or click Quit on an earlier screen after you enter a username and password). To use the
Zero Touch Cloud Service after this point, you must first restore the factory defaults.
If the gateway connects to the internet using DHCP, the gateway fetches the Zero Touch settings without
any additional action. If no DHCP service is available, you must run the First Time Configuration Wizard,
configure the Internet Connection settings, and then fetch the settings from the Zero Touch server.
To connect to the Zero Touch server from the First Time Configuration Wizard:
1. In the Welcome page of the First Time Configuration Wizard, click Fetch Settings from the Cloud.
2. In the window that opens, click Yes to confirm that you want to proceed.
3. The Internet connection page of the First Time Configuration Wizard opens. Configure your Internet
connection and click Connect.
4. The settings are automatically downloaded and installed.
5. A new window opens and shows the installation status. It may take several minutes until the
installation is complete.
Note - If a collision is detected between an internal network (LAN) and an IP returned via DHCP (WAN), the
conflicting LAN address is changed automatically. If a colliding LAN IP address is changed, a message
appears in the system logs.
When you reconnect to the WebUI or click Refresh, the browser opens to show the status of the installation
process.
After the gateway downloads and successfully applies the settings, it does not connect to the Zero Touch
server again.
For more information on how to use Zero Touch, see sk116375 and the R80.20 ZeroTouch Web Portal
Administration Guide

Deploying from a USB Drive or SD Card
Quantum Spark 1500, 1600 and 1800 Appliance Series R80.20.40 Locally Managed Administration Guide | 18
Deploying from a USB Drive or SD Card
You can deploy the Quantum Spark Appliance configuration files from a USB drive or SD card (1570 / 1590,
1600 / 1800 appliances only) and quickly configure many appliances without using the First Time
Configuration Wizard. The configuration file lets you configure more settings and parameters than are
available in the First Time Configuration Wizard.
Note - SD card deployment is not supported for 1530 / 1550 appliances.
You can deploy configuration files in these conditions:
nAn appliance with default settings is not configured at all.
nAn appliance that already has an existing configuration.
The Quantum Spark Appliance starts, automatically mounts the USB drive, and searches the root directory
for a configuration file.
Note - The USB drive must be formatted in FAT32. SD cards are formatted with ext4.
Sample Configuration File
This is a sample Quantum Spark 1530 / 1550 Appliance configuration file for USB deployment.
set time-zone GMT+01:00(Amsterdam/Berlin/Bern/Rome/Stockholm/Vienna)
set ntp server primary 10.1.1.10
set ntp server secondary
set user admin type admin password aaaa
set interface WAN ipv4-address 10.1.1.134 subnet-mask 255.255.255.192 default-gw 10.1.1.129
delete interface LAN1_Switch
set dhcp server interface LAN1 disable
set interface LAN1 ipv4-address 10.4.6.3 subnet-mask 255.255.255.0
add interface LAN1 vlan 2
set dhcp server interface LAN1:2 disable
set interface LAN1:2 ipv4-address 10.4.3.3 subnet-mask 255.255.255.0
set dhcp server interface LAN2 disable
set interface LAN2 ipv4-address 192.168.254.254 subnet-mask 255.255.255.248
set interface LAN2 state on
set admin-access interfaces WAN access allow
set hostname DEMOgw01
Preparing the Configuration Files
The Quantum Spark Appliance Massive Deployment configuration files are composed of Gaia Clish
commands.
These are the file names that you can use:
nautoconf.clish
nautoconf.<MAC Address>.clish
<MAC Address> is the specified MAC address in this format: XX-XX-XX-XX-XX
You can create multiple configuration files for Quantum Spark Appliance gateways. The gateways run both
files or only one of them. First the autoconf.clish configuration file is loaded. If there is a configuration
file with the same MAC address as the gateway, that file is loaded second.
Use the #symbol to add comments to the configuration file.

Deploying from a USB Drive or SD Card
Quantum Spark 1500, 1600 and 1800 Appliance Series R80.20.40 Locally Managed Administration Guide | 19
Deploying the Configuration File - Initial Configuration
This section describes how to deploy a configuration file on a USB drive to Quantum Spark Appliance. You
must configure and format the file correctly before you deploy it. You can insert the USB drive in the front or
rear USB port. Make sure the USB drive is formatted in FAT32.
You can deploy the configuration file to the Quantum Spark Appliance when the appliance is off or when it is
powered on.
Important - Do not remove the USB drive or insert a second USB drive while the
configuration script runs. This may cause a configuration error.
To deploy the configuration file from a USB drive for the initial configuration:
1. Insert the USB drive into a Quantum Spark Appliance.
nQuantum Spark Appliance is OFF - Turn on the appliance. The Power LED is red when the
appliance is first turned on.It blinks blue while the boot is in progress and then turns solid blue
when the process is complete..
nQuantum Spark Appliance is ON - The appliance automatically detects the USB drive.
2. The Quantum Spark Appliance locates the USB configuration file and begins to run the script. The
USB LED blinks blue while the script runs.
3. The configuration script finishes and the Quantum Spark Appliance Power LED is a constant blue.
4. Remove the USB drive from the Quantum Spark Appliance.
Note - The USB LED is red when there is a problem running the configuration script. Turn off the Quantum
Spark Appliance and confirm that the configuration files are formatted correctly.

Deploying from a USB Drive or SD Card
Quantum Spark 1500, 1600 and 1800 Appliance Series R80.20.40 Locally Managed Administration Guide | 20
Deploying the Configuration File - Existing Configuration
To edit or upgrade the existing configuration of a Quantum Spark Appliance, deploy a configuration file. Use
the set property command to set the appliance to use a configuration file on a USB drive. The USB drive
can be inserted in the front or the rear USB port.
You can deploy the configuration file to the Quantum Spark Appliance either when the appliance is off or
when it is powered on.
Important - Do not remove the USB drive or insert a second USB drive while the
Quantum Spark Appliance configuration script runs. This may cause a configuration
error.
To deploy the configuration file from a USB drive to a configured appliance:
1. From the CLI, enter the command:
set property USB_auto_configuration once
The appliance is set to use a configuration script from a USB drive.
2. Insert the USB drive in the appliance (the appliance automatically detects the USB drive).
The USB LED comes on and is a constant orange.
3. The appliance locates the USB configuration file and begins to run the script. The USB LED blinks
blue while the script runs.
4. The configuration script finishes.
The USB LED is a constant blue and the screen displays: System Started.
5. Remove the USB drive from the appliance.
Note - The USB LED is red when there is a problem running the configuration script. Turn off the appliance
and confirm that the configuration files are formatted correctly.
Viewing Configuration Logs
After the Quantum Spark Appliance is successfully configured from a USB drive, a log is created.
nThe log file is called: autonconf.<MAC Address>.<timestamp>.<log>
nThe log file is created in the USB root directory and in /tmp on the appliance.
