Quectel BG96-NA Supplement

B
G
Ha
LTE
M
Rev.
Date:
G
9
6
rd
w
M
odule
S
BG96-N
A
2017-0
4
6
-N
A
w
a
r
S
eries
A
_Hardw
4
-28
A
r
e
D
are_Des
i
D
e
s
i
gn
_
V1.0
s
ig
n
n
w
w
ww.quectel.com

LTE Module Series
BG96-NA Hardware Design
BG96-NA_Hardware_Design Confidential / Released 1 / 64
Our aim is to provide customers with timely and comprehensive service. For any
assistance, please contact our company headquarters:
Quectel Wireless Solutions Co., Ltd.
Office 501, Building 13, No.99, Tianzhou Road, Shanghai, China, 200233
Tel: [phone]
Email: [email protected]
Or our local office. For more information, please visit:
http://www.quectel.com/support/salesupport.aspx
For technical support, or to report documentation errors, please visit:
http://www.quectel.com/support/techsupport.aspx
Or Email to: [email protected]
GENERAL NOTES
QUECTEL OFFERS THE INFORMATION AS A SERVICE TO ITS CUSTOMERS. THE INFORMATION
PROVIDED IS BASED UPON CUSTOMERS’ REQUIREMENTS. QUECTEL MAKES EVERY EFFORT
TO ENSURE THE QUALITY OF THE INFORMATION IT MAKES AVAILABLE. QUECTEL DOES NOT
MAKE ANY WARRANTY AS TO THE INFORMATION CONTAINED HEREIN, AND DOES NOT ACCEPT
ANY LIABILITY FOR ANY INJURY, LOSS OR DAMAGE OF ANY KIND INCURRED BY USE OF OR
RELIANCE UPON THE INFORMATION. ALL INFORMATION SUPPLIED HEREIN IS SUBJECT TO
CHANGE WITHOUT PRIOR NOTICE.
COPYRIGHT
THE INFORMATIONCONTAINED HERE IS PROPRIETARY TECHNICAL INFORMATIONOF QUECTEL
CO., LTD. TRANSMITTING, REPRODUCTION, DISSEMINATION AND EDITING OF THIS DOCUMENT
AS WELL AS UTILIZATION OF THE CONTENT ARE FORBIDDEN WITHOUT PERMISSION.
OFFENDERS WILL BE HELD LIABLE FOR PAYMENT OF DAMAGES. ALL RIGHTS ARE RESERVED
IN THE EVENT OF A PATENT GRANT OR REGISTRATION OF A UTILITY MODEL OR DESIGN.
Copyright © Quectel Wireless Solutions Co., Ltd. 2017. All rights reserved.

LTE Module Series
BG96-NA Hardware Design
BG96-NA_Hardware_Design Confidential / Released 2 / 64
About the Document
History
Revision Date Author Description
1.0 2017-04-28
Allen WANG/
Daryl DU Initial

LTE Module Series
BG96-NA Hardware Design
BG96-NA_Hardware_Design Confidential / Released 3 / 64
Contents
About the Document................................................................................................................................ 2
Contents.................................................................................................................................................... 3
Table Index ............................................................................................................................................... 5
Figure Index.............................................................................................................................................. 6
1Introduction....................................................................................................................................... 7
1.1. Safety Information................................................................................................................... 8
2Product Concept ............................................................................................................................. 12
2.1. General Description .............................................................................................................. 12
2.2. Key Features......................................................................................................................... 13
2.3. Functional Diagram ............................................................................................................... 14
2.4. Evaluation Board................................................................................................................... 15
3Application Interfaces..................................................................................................................... 16
3.1. General Description .............................................................................................................. 16
3.2. Pin Assignment ..................................................................................................................... 17
3.3. Pin Description...................................................................................................................... 18
3.4. Operating Modes .................................................................................................................. 23
3.5. Power Saving........................................................................................................................ 23
3.5.1. Sleep Mode.................................................................................................................. 23
3.5.1.1. UART Application............................................................................................... 24
3.5.1.2. USB Application with USB Remote Wakeup Function ....................................... 24
3.5.1.3. USB Application with USB Suspend/Resume and RI Function.......................... 25
3.5.1.4. USB Application without USB Suspend Function............................................... 26
3.5.2. Airplane Mode.............................................................................................................. 27
3.6. Power Supply........................................................................................................................ 27
3.6.1. Power Supply Pins....................................................................................................... 27
3.6.2. Decrease Voltage Drop................................................................................................ 28
3.6.3. Monitor the Power Supply............................................................................................ 29
3.7. Turn on and off Scenarios ..................................................................................................... 29
3.7.1. Turn on Module Using the PWRKEY ........................................................................... 29
3.7.2. Turn off Module............................................................................................................ 31
3.7.2.1. Turn off Module Using the PWRKEY Pin ........................................................... 31
3.7.2.2. Turn off Module Using AT Command ................................................................. 31
3.8. Reset the Module.................................................................................................................. 31
3.9. (U)SIM Card Interfaces ......................................................................................................... 33
3.10. USB Interface........................................................................................................................ 35
3.11. UART Interfaces.................................................................................................................... 37
3.12. I2C Interfaces........................................................................................................................ 39
3.13. Network Status Indication ..................................................................................................... 40
3.14. STATUS ................................................................................................................................ 41
3.15. Behavior of the RI ................................................................................................................. 41

LTE Module Series
BG96-NA Hardware Design
BG96-NA_Hardware_Design Confidential / Released 4 / 64
3.16. USB_BOOT Interface............................................................................................................ 42
4GNSS Receiver................................................................................................................................ 43
4.1. General Description .............................................................................................................. 43
4.2. GNSS Performance .............................................................................................................. 43
4.3. Layout Guidelines ................................................................................................................. 44
5Antenna Interfaces.......................................................................................................................... 45
5.1. MainAntenna Interface.......................................................................................................... 45
5.1.1. Pin Definition................................................................................................................ 45
5.1.2. Operating Frequency ................................................................................................... 45
5.1.3. Reference Design of RF Antenna Interface ................................................................. 45
5.1.4. Reference Design of RF Layout................................................................................... 46
5.2. GNSS Antenna Interface....................................................................................................... 48
5.3. Antenna Installation .............................................................................................................. 49
5.3.1. Antenna Requirements ................................................................................................ 49
5.3.2. Recommended RF Connector for Antenna Installation................................................ 50
6Electrical, Reliability and Radio Characteristics.......................................................................... 52
6.1. Absolute Maximum Ratings .................................................................................................. 52
6.2. Power Supply Ratings........................................................................................................... 52
6.3. Operating Temperature ......................................................................................................... 53
6.4. Current Consumption............................................................................................................ 53
6.5. RF Output Power .................................................................................................................. 54
6.6. RF Receiving Sensitivity ....................................................................................................... 54
6.7. Electrostatic Discharge ......................................................................................................... 54
7Mechanical Dimensions.................................................................................................................. 55
7.1. Mechanical Dimensions of the Module.................................................................................. 55
7.2. Recommended Footprint....................................................................................................... 57
7.3. Design Effect Drawings of the Module .................................................................................. 58
8Storage, Manufacturing and Packaging........................................................................................ 59
8.1. Storage ................................................................................................................................. 59
8.2. Manufacturing and Welding .................................................................................................. 60
8.3. Packaging ............................................................................................................................. 60
9Appendix A References.................................................................................................................. 61
10 Appendix B GPRS Coding Schemes............................................................................................. 65
11 Appendix C GPRS Multi-slot Classes............................................................................................ 66
12 Appendix D EDGE Modulation and Coding Schemes.................................................................. 67

LTE Module Series
BG96-NA Hardware Design
BG96-NA_Hardware_Design Confidential / Released 5 / 64
Table Index
TABLE 1: FREQUENCY BANDS OF BG96-NA MODULE................................................................................ 12
TABLE 2: KEY FEATURES OF BG96-NA......................................................................................................... 13
TABLE 3: I/O PARAMETERS DEFINITION....................................................................................................... 18
TABLE 4: PIN DESCRIPTION........................................................................................................................... 18
TABLE 5: OVERVIEW OF OPERATING MODES............................................................................................. 23
TABLE 6: VBAT AND GND PINS....................................................................................................................... 28
TABLE 7: PWRKEY PIN DESCRIPTION .......................................................................................................... 29
TABLE 8: RESET_N PIN DESCRIPTION ......................................................................................................... 32
TABLE 9: PIN DEFINITION OF THE (U)SIM CARD INTERFACES ................................................................. 33
TABLE 10: PIN DESCRIPTION OF USB INTERFACE ..................................................................................... 35
TABLE 11: PIN DEFINITION OF UART1 INTERFACE ..................................................................................... 37
TABLE 12: PIN DEFINITION OF UART2 INTERFACE..................................................................................... 37
TABLE 13:LOGIC LEVELS OF DIGITAL I/O ..................................................................................................... 38
TABLE 14: PIN DEFINITION OF I2C INTERFACES......................................................................................... 39
TABLE 15: PIN DEFINITION OF NETWORK STATUS INDICATOR ................................................................ 40
TABLE 16: WORKING STATE OF THE NETWORK STATUS INDICATOR...................................................... 40
TABLE 17: PIN DEFINITION OF STATUS ........................................................................................................ 41
TABLE 18: DEFAULT BEHAVIOR OF RI........................................................................................................... 42
TABLE 19: PIN DEFINITION OF USB_BOOT INTERFACE ............................................................................. 42
TABLE 20: GNSS PERFORMANCE ................................................................................................................. 43
TABLE 21: PIN DEFINITION OF THE RF ANTENNA INTERFACE.................................................................. 45
TABLE 22: MODULE OPERATING FREQUENCIES ........................................................................................ 45
TABLE 23: PIN DEFINITION OF GNSS ANTENNA INTERFACE..................................................................... 48
TABLE 24: GNSS FREQUENCY....................................................................................................................... 48
TABLE 25: MAIN ANTENNA REQUIREMENTS................................................................................................ 49
TABLE 26: ABSOLUTE MAXIMUM RATINGS .................................................................................................. 52
TABLE 27: POWER SUPPLY RATINGS ........................................................................................................... 52
TABLE 28: OPERATING TEMPERATURE........................................................................................................ 53
TABLE 29: CONDUCTED RF OUTPUT POWER ............................................................................................. 54
TABLE 30: BG96-NA CONDUCTED RF RECEIVING SENSITIVITY ............................................................... 54
TABLE 31: RELATED DOCUMENTS ............................................................................................................... 61
TABLE 32: TERMS AND ABBREVIATIONS...................................................................................................... 61
TABLE 33: DESCRIPTION OF DIFFERENT CODING SCHEMES .................................................................. 65
TABLE 34: GPRS MULTI-SLOT CLASSES ...................................................................................................... 66
TABLE 35: EDGE MODULATION AND CODING SCHEMES........................................................................... 67

LTE Module Series
BG96-NA Hardware Design
BG96-NA_Hardware_Design Confidential / Released 6 / 64
Figure Index
FIGURE 1: FUNCTIONAL DIAGRAM ............................................................................................................... 15
FIGURE 2: PIN ASSIGNMENT (TOP VIEW) .................................................................................................... 17
FIGURE 3: SLEEP MODE APPLICATION VIA UART....................................................................................... 24
FIGURE 4: SLEEP MODE APPLICATION WITH USB REMOTE WAKEUP .................................................... 25
FIGURE 5: SLEEP MODE APPLICATION WITH RI ......................................................................................... 26
FIGURE 6: SLEEP MODE APPLICATION WITHOUT SUSPEND FUNCTION ................................................ 26
FIGURE 7: STAR STRUCTURE OF THE POWER SUPPLY............................................................................ 28
FIGURE 8: TURN ON THE MODULE USING DRIVING CIRCUIT................................................................... 29
FIGURE 9: TURN ON THE MODULE USING KEYSTROKE ........................................................................... 30
FIGURE 10: TIMING OF TURNING ON MODULE ........................................................................................... 30
FIGURE 11: TIMING OF TURNING OFF MODULE.......................................................................................... 31
FIGURE 12: REFERENCE CIRCUIT OF RESET_N BY USING DRIVING CIRCUIT ...................................... 32
FIGURE 13: REFERENCE CIRCUIT OF RESET_N BY USING BUTTON ...................................................... 32
FIGURE 14: TIMING OF RESETTING MODULE ............................................................................................. 33
FIGURE 15: REFERENCE CIRCUIT OF (U)SIM CARD INTERFACE WITH AN 8-PIN (U)SIM CARD
CONNECTOR ............................................................................................................................................ 34
FIGURE 16: REFERENCE CIRCUIT OF (U)SIM CARD INTERFACE WITH A 6-PIN (U)SIM CARD
CONNECTOR ............................................................................................................................................ 34
FIGURE 17: REFERENCE CIRCUIT OF USB APPLICATION ......................................................................... 36
FIGURE 18: REFERENCE CIRCUIT WITH TRANSLATOR CHIP ................................................................... 38
FIGURE 19: REFERENCE CIRCUIT WITH TRANSISTOR CIRCUIT .............................................................. 39
FIGURE 20: REFERENCE CIRCUIT OF THE NETWORK INDICATOR.......................................................... 40
FIGURE 21: REFERENCE CIRCUIT OF THE STATUS ................................................................................... 41
FIGURE 22: REFERENCE CIRCUIT OF USB_BOOT INTERFACE ................................................................ 42
FIGURE 23: REFERENCE CIRCUIT OF RF ANTENNA INTERFACE ............................................................. 46
FIGURE 24: MICROSTRIP LINE DESIGN ON A 2-LAYER PCB...................................................................... 46
FIGURE 25: COPLANAR WAVEGUIDE LINE DESIGN ON A 2-LAYER PCB.................................................. 47
FIGURE 26: COPLANAR WAVEGUIDE LINE DESIGN ON A 4-LAYER PCB (LAYER 3 AS REFERENCE
GROUND) .................................................................................................................................................. 47
FIGURE 27: COPLANAR WAVEGUIDE LINE DESIGN ON A 4-LAYER PCB (LAYER 4 AS REFERENCE
GROUND) .................................................................................................................................................. 47
FIGURE 28: REFERENCE CIRCUIT OF GNSS ANTENNA INTERFACE........................................................ 49
FIGURE 29: DIMENSIONS OF THE UF.L-R-SMT CONNECTOR (UNIT: MM) ................................................ 50
FIGURE 30: MECHANICALS OF UF.L-LP CONNECTORS ............................................................................. 50
FIGURE 31: SPACE FACTOR OF MATED CONNECTOR (UNIT: MM) ........................................................... 51
FIGURE 32: MODULE TOP AND SIDE DIMENSIONS..................................................................................... 55
FIGURE 33: MODULE BOTTOM DIMENSIONS (BOTTOM VIEW) ................................................................. 56
FIGURE 34: RECOMMENDED FOOTPRINT (TOP VIEW) .............................................................................. 57
FIGURE 35: TOP VIEW OF THE MODULE ...................................................................................................... 58
FIGURE 36: BOTTOM VIEW OF THE MODULE.............................................................................................. 58
FIGURE 37: REFLOW SOLDERING THERMAL PROFILE.............................................................................. 60

LTE Module Series
BG96-NA Hardware Design
BG96-NA_Hardware_Design Confidential / Released 7 / 64
1Introduction
This document defines the BG96-NAmodule and describes its air interface and hardware interface which
are connected with your application.
This document can help you quickly understand module interface specifications, electrical andmechanical
details, etc. Associated with application note and user guide, you can use BG96-NA module to design and
set up mobile applications easily.

LTE Module Series
BG96-NA Hardware Design
BG96-NA_Hardware_Design Confidential / Released 8 / 64
1.1. Safety Information
The following safety precautions must be observed during all phases of the operation, such as usage,
service or repair of any cellular terminal or mobile incorporating BG96-NA module. Manufacturers of the
cellular terminal should send the following safety information to users and operating personnel, and
incorporate these guidelines into all manuals supplied with the product. If not so, Quectel assumes no
liability for the customer’s failure to comply with these precautions.
Full attention must be given to driving at all times in order to reduce the risk of an
accident.Using a mobile while driving (even with a handsfree kit) causes distraction
and can lead to an accident. You must comply with laws and regulations restricting
the use of wireless devices while driving.
Switch off the cellular terminal or mobile before boarding an aircraft. Make sure it is
switched off. The operation of wireless appliances in an aircraft is forbidden, so as
to prevent interference with communication systems. Consult the airline staff about
the use of wireless devices on boarding the aircraft, if your device offers an
Airplane Mode which must be enabled prior to boarding an aircraft.
Switch off your wireless device when in hospitals,clinics or other health care
facilities. These requests are desinged to prevent possible interference with
sensitive medical equipment.
Cellular terminals or mobiles operatingover radio frequency signal and cellular
network cannot be guaranteed to connect in all conditions, for example no mobile
fee or with an invalid (U)SIM card. While you are in this condition and need
emergent help, please remember using emergency call. In order to make or
receive a call, the cellular terminal or mobile must be switched on and in a service
area with adequate cellular signal strength.
Your cellular terminal or mobile contains a transmitter and receiver. When it is ON,
it receives and transmits radio frequency energy. RF interference can occur if it is
used close to TV set, radio, computer or other electric equipment.
In locations with potentially explosive atmospheres, obey all posted signs to turn
off wireless devices such as your phone or other cellular terminals. Areas with
potentially explosive atmospheres includefuelling areas, below decks on boats,
fuel or chemical transfer or storage facilities, areas where the air contains
chemicals or particles such as grain, dust or metal powders, etc.

LTE Module Series
BG96-NA Hardware Design
BG96-NA_Hardware_Design Confidential / Released 9 / 64
1.2 FCC Certification Requirements.
According to the definition of mobile and fixed device is described in Part 2.1091(b), this device is a
mobile device.
And the following conditions must be met:
1. This Modular Approval is limited to OEM installation for mobile and fixed applications only. The antenna
installation and operating configurations of this transmitter, including any applicable source-based time-
averaging duty factor, antenna gain and cable loss must satisfy MPE categorical Exclusion Requirements
of 2.1091.
2. The EUT is a mobile device; maintain at least a 20 cm separation between the EUT and the user’s
body and must not transmit simultaneously with any other antenna or transmitter.
3.A label with the following statements must be attached to the host end product: This device contains
FCC ID: XMR201705BG96NA
4.To comply with FCC regulations limiting both maximum RF output power and human exposure to RF
radiation, maximum antenna gain (including cable loss) must not exceed:
❒LTE Band2:≤8.00dBi
❒LTE Band4:≤5.00dBi
❒LTE Band12:≤8.734dBi
❒LTE Band13:≤9.173dBi
5. This module must not transmit simultaneously with any other antenna or transmitter
6. The host end product must include a user manual that clearly defines operating requirements and
conditions that must be observed to ensure compliance with current FCC RF exposure guidelines.
For portable devices, in addition to the conditions 3 through 6 described above, a separate approval is
required to satisfy the SAR requirements of FCC Part 2.1093

LTE Module Series
BG96-NA Hardware Design
BG96-NA_Hardware_Design Confidential / Released 10 / 64
If the device is used for other equipment that separate approval is required for all other operating
configurations, including portable configurations with respect to 2.1093 and different antenna
configurations.
For this device, OEM integrators must be provided with labeling instructions of finished products.
Please refer to KDB784748 D01 v07, section 8. Page 6/7 last two paragraphs:
A certified modular has the option to use a permanently affixed label, or an electronic label. For a
permanently affixed label, the module must be labeled with an FCC ID - Section 2.926 (see 2.2
Certification (labeling requirements) above). The OEM manual must provide clear instructions
explaining to the OEM the labeling requirements, options and OEM user manual instructions that are
required (see next paragraph).
For a host using a certified modular with a standard fixed label, if (1) the module’s FCC ID is not visible
when installed in the host, or (2) if the host is marketed so that end users do not have straightforward
commonly used methods for access to remove the module so that the FCC ID of the module is visible;
then an additional permanent label referring to the enclosed module:“Contains Transmitter Module FCC
ID: XMR201705BG96NA” or “Contains FCC ID: XMR201705BG96NA” must be used. The host OEM
user manual must also contain clear instructions on how end users can find and/or access the module
and the FCC ID.
The final host / module combination may also need to be evaluated against the FCC Part 15B criteria
for unintentional radiators in order to be properly authorized for operation as a Part 15 digital device.
The user’s manual or instruction manual for an intentional or unintentional radiator shall caution the
user that changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment. In cases where the manual is provided only in
a form other than paper, such as on a computer disk or over the Internet, the information required by
this section may be included in the manual in that alternative form, provided the user can reasonably be
expected to have the capability to access information in that form.

LTE Module Series
BG96-NA Hardware Design
BG96-NA_Hardware_Design Confidential / Released 11 / 64
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Changes or modifications not expressly approved by the manufacturer could void the user’s authority to
operate the equipment.
To ensure compliance with all non-transmitter functions the host manufacturer is responsible for ensuring
compliance with the module(s) installed and fully operational. For example, if a host was previously
authorized as an unintentional radiator under the Declaration of Conformity procedure without a
transmitter certified module and a module is added, the host manufacturer is responsible for ensuring that
the after the module is installed and operational the host continues to be compliant with the Part 15B
unintentional radiator requirements

LTE Module Series
BG96-NA Hardware Design
BG96-NA_Hardware_Design Confidential / Released 12 / 64
2Product Concept
2.1. General Description
BG96-NAmodule is anembeddedIoT(LTE CatM1) wireless communication modulewithout receive
diversity. It supportsHalf-duplex LTE-FDD wireless communication, whichprovides data connectivity on
LTE-FDDnetworks. The following table shows the frequency bands of BG96-NA module.
Table 1: Frequency Bands of BG96-NA Module
With a compact profile of 22.5mm ×26.5mm ×2.3mm, BG96-NA can meet almost all requirements for
M2M applications such as automotive, metering, tracking system, security, router, wireless POS, mobile
computing device, PDA phone, tablet PC, etc.
BG96-NA is an SMD type module which can be embedded into application through its 102 LGA pads.
BG96-NAsupports internet service protocols like TCP, UDP and PPP. Extended AT commands have
been developed for customers to use these internet service protocols easily.
Module LTE Bands GSM Rx-diversity GNSS (Optional)
BG96-NA FDD: B2/B4/B12/B13 Not
Supported Not Supported
GPS,
GLONASS,BeiDou/Compass,
Galileo, QZSS

LTE Module Series
BG96-NA Hardware Design
BG96-NA_Hardware_Design Confidential / Released 13 / 64
2.2. Key Features
The following table describes the detailed features of BG96-NA module.
Table 2: Key Features of BG96-NA
Features Details
Power Supply Supply voltage: 3.3V~4.3V
Typical supply voltage: 3.8V
Transmitting Power Class 3 (23dBm±2.7dB) for LTE-FDD bands
LTE Features
Support up to LTE Cat M1
Support 1.08MHz RF bandwidth
Support SISO in DL direction
Cat M1: Max. 375kbps (DL)/375kbps (UL)
Internet Protocol
Features*
Support TCP/UDP/PPP protocols
Support PAP (Password Authentication Protocol) and CHAP (Challenge
Handshake Authentication Protocol) protocols which are usually used for
PPP connections
SMS*
Text and PDU mode
Point to point MO and MT
SMS cell broadcast
SMS storage: ME by default
(U)SIM Interface Support (U)SIM card: 1.8V, 3.0V
USB Interface
Compliant with USB 2.0 specification (slave only); the data transfer rate
can reach up to 480Mbps
Used for AT command communication, data transmission, GNSS NMEA
output, software debugging and firmware upgrade
SupportUSB drivers forWindows XP, Windows Vista, Windows 7, Windows
8/8.1, Windows 10, Windows CE 5.0/6.0/7.0*,Linux 2.6/3.x/4.1,Android
4.x/5.x/6.0
UART Interface
UART1:
Used for AT command communication and data transmission
Baud rate reach up to 3000000bps; 115200bps by default
Support RTS and CTS hardware flow control
UART2:
Used for module debugging and log output
115200bps baud rate
AT Commands 3GPP TS 27.007 and 3GPP TS 27.005 AT commands, as well as
Quectel enhanced AT commands
Network Indication OneNETLIGHT pin for network connectivity status indication

LTE Module Series
BG96-NA Hardware Design
BG96-NA_Hardware_Design Confidential / Released 14 / 64
Antenna Interfaces Including main antenna (ANT_MAIN) and GNSS antenna (ANT_GNSS)
interfaces
Physical Characteristics Size: 22.5mm ×26.5mm×2.3mm
Weight: 3.1g
Temperature Range Operation temperature range: -35°C ~ +75°C1)
Extended temperature range: -40°C ~ +85°C2)
Firmware Upgrade USB interface and DFOTA*
RoHS All hardware components are fully compliant with EU RoHS directive
1. 1) Within operation temperature range, the module is 3GPP compliant.
2. 2) Within extended temperature range, the module remains the ability to establish and maintain SMS,
data transmission, etc. There is no unrecoverable malfunction. Only one or more parameters like Pout
might reduce in their value and exceed the specified tolerances. When the temperature returns to the
normal operating temperature levels, the module will meet 3GPP compliant again.
3. “*” means under development.
2.3. Functional Diagram
The following figure shows a block diagram of BG96-NA and illustrates the major functional parts.
Power management
Baseband
DDR+NAND flash
Radio frequency
Peripheral interfaces
NOTES

LTE Module Series
BG96-NA Hardware Design
BG96-NA_Hardware_Design Confidential / Released 15 / 64
Figure 1: Functional Diagram
“*” means under development.
2.4. Evaluation Board
In order to help customers develop applications conveniently with BG96-NA, Quectel supplies
theevaluation board (EVB), USB data cable, earphone, antenna and other peripherals to control or test
the module.
NOTE

LTE Module Series
BG96-NA Hardware Design
BG96-NA_Hardware_Design Confidential / Released 16 / 64
3Application Interfaces
3.1. General Description
BG96-NAis equipped with 62-pin 1.1mm pitch SMT pads plus 40-pin ground pads and reserved pads that
can be connected to customers’ cellular application platform. The subsequent chapters will provide
detailed description of interfaces listed below:
Power supply
(U)SIM card interfaces
USB interface
UART interfaces
Network status indication
USB_BOOT interface

LTE Module Series
BG96-NA Hardware Design
BG96-NA_Hardware_Design Confidential / Released 17 / 64
3.2. Pin Assignment
The following figure shows the pin assignment of the BG96-NA module.
Figure 2: Pin Assignment (Top View)
1. Keep all RESERVEDpins and unused pins unconnected.
2. GND pads should be connected to ground in the design.
3. 1)PWRKEY output voltage is 0.8V because of the diode drop in the Qualcomm chipset.
4. “*” means under development.
NOTES

LTE Module Series
BG96-NA Hardware Design
BG96-NA_Hardware_Design Confidential / Released 18 / 64
3.3. Pin Description
The following tables show the pin definition and description of BG96-NA.
Table 3: I/O Parameters Definition
Type Description
IO Bidirectional
DI Digital input
DO Digital output
PI Power input
PO Power output
AI Analog input
AO Analog output
OD Open drain
Table 4: Pin Description
Power Supply
Pin Name Pin No. I/O Description DC
Characteristics Comment
VBAT_BB 32, 33 PI
Power supply
for module
baseband part.
Vmax=4.3V
Vmin=3.3V
Vnorm=3.8V
VBAT_RF 52,53 PI
Power supply
for module RF
part.
Vmax=4.3V
Vmin=3.3V
Vnorm=3.8V
VDD_EXT 29 PO
Provide 1.8V for
external circuit.
Vnorm=1.8V
IOmax=50mA
Power supply for external
GPIO’s pull up circuits.
GND
3, 31, 48,
50, 54, 55,
58, 59, 61,
62, 67~74,
79~82,
89~91,
100~102
Ground

LTE Module Series
BG96-NA Hardware Design
BG96-NA_Hardware_Design Confidential / Released 19 / 64
Turn on/off
Pin Name Pin No. I/O Description DC
Characteristics Comment
PWRKEY 15 DI
Turnon/off the
module
VIHmax=2.1V
VIHmin=1.3V
VILmax=0.5V
The output voltage is0.8V
because of thediode drop
in theQualcomm chipset.
RESET_N 17 DI
Reset the
module
VIHmax=2.1V
VIHmin=1.3V
VILmax=0.5V
If unused, keep this pin
open.
Status Indication
Pin Name Pin No. I/O Description DC
Characteristics Comment
STATUS 20 OD
Indicate the
module’s
operating
status.
VOHmin=1.35V
VOLmax=0.45V
1.8V power domain.
If unused, keep this pin
open.
NETLIGHT 21 DO
Indicate the
module’snetwor
k activity status.
VOHmin=1.35V
VOLmax=0.45V
1.8V power domain.
If unused, keep it open.
USB Interface
Pin Name Pin No. I/O Description DC
Characteristics Comment
USB_VBUS 8 PI USB detection
Vmax=5.25V
Vmin=3.0V
Vnorm=5.0V
USB_DP 9 IO
USB differential
data bus (+)
Compliant with
USB 2.0 standard
specification.
Require differential
impedance of 90ohm.
USB_DM 10 IO
USB differential
data bus (-)
Compliant with
USB 2.0 standard
specification.
Require differential
impedance of 90ohm.
(U)SIM Interface
Pin Name Pin No. I/O Description DC
Characteristics Comment
USIM_GND 47
Specified
ground for
(U)SIM card
USIM_VDD 43 PO
Power supply
for (U)SIM card
For 1.8V(U)SIM:
Vmax=1.9V
Vmin=1.7V
Either 1.8V or 3.0V is
supported by the module
automatically.
