R.V.R. Elettronica RDMODWEB User manual

RDMODWEB
USER MANUAL
Manufactured by R.V.R ELETTRONICA S.p.A. Italy

RDMODWEB - User Manual
Version 1.0
© Copyright 2012
R.V.R. Elettronica SpA
Via del Fonditore 2/2c - 40138 - Bologna (Italia)
Telephone: [phone]
Fax: [phone]
Email: [e-mail]
Web: www.rvr.it
All rights reserved
PrintedandboundinItaly.Nopartofthismanualmaybereproduced,
memorized or transmitted in any form or by any means, electronic
or mechanic, including photocopying, recording or by any informa-
tion storage and retrieval system, without written permission of the
copyright owner.
File Name: RDMODWEB_1.0.indb
Version: 1.0
Date: 20/02/2012
Revision History
Date Version Reason Editor
20/02/2012 1.0 First Version J. H. Berti
Declaration of Conformity
Hereby,R.V.R.ElettronicaSpA,declaresthatthisFMtransmitteris in
compliancewiththeessentialrequirementsandotherrelevantprovisionsof
Directive 1999/5/EC.

RDMODWEB
ELETTRONICA
i
User Manual
Rev. 1.0 - 20/02/12
Table of Contents
1. Preliminary Instructions 1
2. Warranty 1
3. First Aid 2
3.1 Treatment of electrical shocks 2
3.2 Treatment of electrical Burns 2
4. Descrizione Generale 3
4.1 Unpacking 3
 4.2  Specication 3
4.3 Front Panel Description 4
4.4 Rear Panel Description 4
4.5 Connector Description 5
 4.6  TechnicalSpecications 7
 5. Installationandcongurationprocedure 8
5.1 Preparation 8
5.2 First Power-On and Set-Up 9
5.3 Management Software 11
 6. ModuleIdentication 23
6.1 Top View 23

ii User Manual
Rev. 1.0 - 20/02/12
RDMODWEB
ELETTRONICA
This page was intentionally left blank

RDMODWEB
ELETTRONICA
1/ 24
Manuale Utente
Rev. 1.0 - 20/02/12
1. Preliminary Instructions
•GeneralWarnings
This equipment should only be operated, installed and
maintainedby“trained”or“qualied”personnelwhoarefamiliar
withrisksinvolvedinworkingonelectricandelectroniccircuits.
“Trained”meanspersonnelwhohavetechnicalknowledgeof
equipment operation and who are responsible for their own
safetyandthatofotherunqualiedpersonnelplacedunder
their supervision when working on the equipment.
“Qualified” means personnel who are trained in and
experienced with equipment operation and who are
responsiblefortheirownsafetyandthatofotherunqualied
personnel placed under their supervision when working on
the equipment.
WARNING:Residualvoltagemaybepresentinside
theequipmentevenwhentheON/OFFswitchissetto
Off. Before servicing the equipment, disconnect the
power cord or switch off the main power panel and
make sure the safety earth connection is connected.
Some service situations may require inspecting the
equipmentwithlivecircuits.Onlytrainedandqualied
personnelmayworkontheequipmentliveandshallbe
assistedbyatrainedpersonwhoshallkeepreadyto
disconnectpowersupplyatneed.
R.V.R. Elettronica SpA shall not be liable for injury to
persons or damage to property resulting from improper use
oroperationbytrained/untrainedandqualied/unqualied
persons.
WARNING:Theequipmentisnotwaterresistant.
Anywaterenteringtheenclosuremightimpairproper
operation. To prevent the risk of electrical shock or
re,donotexposethisequipmenttorain,drippingor
moisture.
Pleaseobservelocalcodesandrepreventionruleswhen
installing and operating this equipment.
 WARNING: This equipment contains exposed
livepartsinvolvinganelectricalshockhazard.Always
disconnectpowersupplybeforeremovinganycovers
orotherpartsoftheequipment.
Ventilation slits and holes are provided to ensure reliable
operation and prevent overheating; do not obstruct or
cover these slits. Do not obstruct the ventilation slits under
any circumstances. The product must not be incorporated
in a rack unless adequate ventilation is provided or the
manufacturer’s instructions are followed closely.
 WA RNING : T his  eq uipme nt  can  ra diate
radiofrequencyenergyand,ifnotinstalledincompliance
with manual instructions and applicable regulations,
maycauseinterferencewithradiocommunications.
 WARNING: This equipment is tted with earth
connectionsbothinthepowercordandforthechassis.
Makesurebothareproperlyconnected.
Operationof thisequipment ina residentialarea may cause
radio interference, in which case the user may be required
to take adequate measures.
Thespecicationsanddatacontainedhereinareprovided
forinformationonlyandare subjecttochangeswithoutprior
notice. R.V.R. Elettronica SpA disclaims all warranties,
expressorimplied.WhileR.V.R.ElettronicaSpAattemptsto
provideaccurateinformation,it cannotacceptresponsibility
or liability for any errors or inaccuracies in this manual,
including the products and the software described herein.
R.V.R.ElettronicaSpA reservestherighttomakechanges
toequipmentdesignand/orspecicationsandtothismanual
at any time without prior notice.
•Noticeconcerningproductintendedpurposeanduse
limitations.
This product is a radio transmitter suitable for frequency-
modulation audio radio broadcasting. Its operating
frequenciesarenotharmonisedindesignatedusercountries.
Before operating this equipment, user must
obtain a licence to use radio spectrum from the
competent authority in the designated user country.
Operating frequency, transmitter power and other
characteristics of the transmission system are subject to
restrictionsasspeciedinthelicence.
2. Warranty
LaR.V.R. Elettronica S.P.A. warrantsthisproducttobefree
fromdefectsinworkmanshipanditsproperoperationsubject
tothelimitationssetforthinthesuppliedTermsandConditions.
PleasereadtheTermsandConditionscarefully,aspurchase
ofthe productoracceptanceof the orderacknowledgement
imply acceptance of the Terms and Conditions.
Forthelatestupdatedtermsandconditions,pleasevisitourweb
siteatWWW.RVR.IT.Thewebsitemaybemodied,removed
or updated for any reason whatsoever without prior notice.
The warranty will become null and void in the event the
product enclosure is opened, the product is physically
damaged,isrepairedbyunauthorisedpersonsor isusedfor
purposesotherthan itsintendeduse, as well as inthe event
of improper use, unauthorised changes or neglect.
In the event a defect is found, follow this procedure:
1 Contactthesellerordistributorwho soldtheequipment;
provide a description of the problem or malfunction for
theeventaquickxisavailable.
Sellers and Distributors can provide the necessary
informationtotroubleshootthemostfrequentlyencountered
problems. Normally, Sellers and Distributors can offer a
faster repair service than the Manufacturer would. Please
note that Sellers can pinpoint problems due to wrong
installation.
2 If your Seller cannot help you, contact R.V.R.
Elettronica anddescribetheproblem;ifourstaffdeems
itappropriate, youwill receivean authorisationto return
the equipment along with suitable instructions;
3 When you have received the authorisation, you may
return the unit. Pack the unit carefully before shipment;
use the original packaging whenever possible and seal
the package perfectly. The customer bears all risks of
loss (i.e., R.V.R. shall not be liable for loss or damage)
until the package reaches the R.V.R. factory. For this
IMPORTANT
Thelightningashwitharrowhead,withinatriangle,isintendedtoalerttheuserofthepresence
of dangerous voltage that may constitute a risk of electric shock.
The exclamation point within an equilateral triangle is intended to alert the user to the
presence of important operating and maintenance (servicing) instructions in the literature
accompanying the equipment.

2/ 24 Manuale Utente
Rev. 1.0 - 20/02/12
RDMODWEB
ELETTRONICA
reason, we recommend insuring the goods for their full
value.ReturnsmustbesentonaC.I.F.basis(PREPAID)
totheaddressstatedontheauthorisationasspecied
by the R.V.R. Service Manager.
Units returned without a return authorisation may
be rejected and sent back to the sender.
4 Be sure to include a detailed report mentioning all
problems you have found and copy of your original
invoice (to show when the warranty period began) with
the shipment.
Pleasesendspareandwarrantyreplacementpartsordersto
theaddressprovidedbelow.Makesuretospecifyequipment
model and serial number, as well as part description and
quantity.
R.V.R. Elettronica SpA
Via del Fonditore, 2/2c
40138 BOLOGNA ITALY
Tel. [phone]
3. First Aid
All personnel engaged in equipment installation, operation
andmaintenancemustbefamiliarwithrstaidprocedures
and routines.
3.1 Electric shock treatment
3.1.1 If the victim is unconscious
Followtherstaidproceduresoutlinedbelow.
• Laythevictimdownonhis/herbackonarm
surface.
• the neck and tilt the head backwards to free
the airway system (Figure1).
Figure 1
• If needed, open the victim’s mouth and check
for breathing.
• Ifthereisnobreathing,startarticialrespiration
withoutdelay(Figure2)asfollows:tiltthehead
backwards,pinchthe nostrils,seal your mouth
around the victim’s mouth and give four fast
rescue breaths.
Figure 2
• Check for heartbeat (Figure 3); if there is
no heartbeat, begin chest compressions
immediately (Figure4) placing your hands in
the centre of the victim’s chest (Figure5).
Figure 3 Figure 4 Figure 5
• One rescuer:give 2 quick rescuebreaths after
each 15 compressions.
• Two rescuers: one rescue breath after each 5
compressions.
• Do not stop chest compressions while giving
articialbreathing.
• Call for medical help as soon as possible.
3.1.2 If the victim is conscious
• Cover victim with a blanket.
• Try to reassure the victim.
• Loosen the victim’s clothing and have him/her
lie down.
• Call for medical help as soon as possible.
3.2 Treatment of electric burns
3.2.1 Large burns and broken skin
• Cover affected area with a clean cloth or
linen.
• Do not break any blisters that have formed;
remove any clothing or fabric that is stuck to
the skin; apply adequate ointment.
• Administer adequate treatment for the type of
accident.
• Get the victim to a hospital as quickly as
possible.
• Elevate arms and legs if injured.
If medical help is not available within an hour, the victim is
conscious and is not retching, administer a solution of table
salt and baking soda (one teaspoon of table salt to half
teaspoon of baking soda every 250 ml of water).
Have the victim slowly drink half a glass of solution for four
times during a period of 15 minutes.
Stopattherstsignofretching.
Do not administer alcoholic beverages.
3.2.2 Minor burns
• Applycold(noticecold)stripsofgauzeordress
wound with clean cloth.
• Do not break any blisters that have formed;
remove any clothing or fabric that is stuck to
the skin; apply adequate ointment.
• If needed, have the victim change into clean,
dry clothing.
• Administer adequate treatment for the type of
accident.
• Get the victim to a hospital as quickly as
possible.
• Elevate arms and legs if injured.

RDMODWEB
ELETTRONICA
3/ 24
Manuale Utente
Rev. 1.0 - 20/02/12
 4. GeneralDescription
The RDMODWEB is a TCP/IP interface that makes available the telemetry of
exciters by R.V.R.ElettronicaSpA on the internet, by means of connections with
LAN/Ethernet networks 10Base-T.
The RDMODWEB have been designed for installation in a 1HE box for 19” rack.
 4.1 Unpacking
The package contains:
1 RDMODWEB
1 User Manual
1 Mains Power Cable
The following accessories are also available from Your R.V.R. Dealer:
• Accessories,sparepartsandcables
 4.2 Specication
The RDMODWEB uses a 16bit DSP, that is the ideal solution to adjust the device
tothespecicconnectionneeds,italsoimplementstheprotocolstoexchange
data through the Internet, such as ARP & DHCP to assign IP addresses, or like
the conformity to RFC for TCP/IP applications (such as HTTP, FTP server or e-
mail).
An important feature of the RDMODWEB is the extreme user-friendliness of the
control system that allows interaction with user and implements the following
functions, via a web browser:
• Remote setting of the output power, operating frequency and power output by
the transmitter connected to the RDMODWEB interface.
• Displaying of the work parameters of the transmitter connected to the
RDMODWEB interface.
• Alarm display and settings.
• RDMODWEB interface display and settings.
• Communications with external devices, such as ADSL router or PC or LAN
networks, through Ethernet cable.
Status is indicated by eight LEDs available on the front panel: ON, ALARM,
MODEM, SMS,COM, RS232, LOCAL, WAIT.
• Remote setting of the output power, operating frequency and power
output by the transmitter connected to the TCP/IP interface.
• Displaying of the work parameters of the transmitter connected to
the TCP/IP interface.
• Alarm display and settings.
• TCP/IP interface display and settings.
• Communications with external devices, such asADSL router or PC
or LAN networks, through Ethernet cable.

4/ 24 Manuale Utente
Rev. 1.0 - 20/02/12
RDMODWEB
ELETTRONICA
 4.3 FrontPanelDescription
[1] ON Green LED, turns on when the equipment is connected to mains
power supply.
[2] ALARM Red LED, turns on when an alarm detected by the telemetry system
is present.
[3] MODEM Green LED, turns on when modem is connected.
[4] SMS Yellow LED, indicates that SMS messaging is active.
[5] COM Yellow LED, indicates the remote communication, or rather
telephone connection through TELECON software.
[6] RS232 Yellow LED, indicates that communication via RS232 serial port is in
progress.
[7] LOCAL  N.C.(Providedforfutureexpansion).
[8] WAIT Yellow LED, when on, indicates that Start time is active. No alarm
messages will be sent until this LED turns off.
[9] RS232 DB9 female loop connector connected to telemetry unit.
[10] MODEM DB9 female loop connector connected to TCP/IP interface.
 4.4 RearPanelDescription
[1] MAINS IN VDE mains power supply connector.
[2] NETWORK RJ45 connector for LAN communication.
[3] RS485 DB9 female connector for RS485 communication to external
devices.
[4] RS232 Not used.
[5] I2C BUS DB9 male connector for I2C standard communication with exterbal
devices.

RDMODWEB
ELETTRONICA
5/ 24
Manuale Utente
Rev. 1.0 - 20/02/12
 4.5 ConnectorDescription
4.5.1 RS232
Type: DB9 Male
1 NC
2 TXD
3 RXD
4 NC
5 GND
6 NC
7 NC
8 NC
9 NC
4.5.2 I2C BUS
Type: DB9 Male
1 NC
2 SDA
3 SCL
4 NC
5 GND
6 NC
7 NC
8 NC
9 NC
4.5.3 RS485 BUS
Type: DB9 Female
1 NC
2 B
3 A
4 NC
5 GND
6 NC
7 NC
8 NC
9 NC

6/ 24 Manuale Utente
Rev. 1.0 - 20/02/12
RDMODWEB
ELETTRONICA
4.5.4 LANType: RJ45 Female
1 TX+
2 TX-
3 RX+
4 N.C.
5 N.C.
6 RX-
7 N.C.
8 N.C.

RDMODWEB
ELETTRONICA
7/ 24
Manuale Utente
Rev. 1.0 - 20/02/12
 4.6 TechnicalSpecications
Parameters RDMODWEB
Primary Power
115/230 VAC ±15% (internally
selectable)
Phisical Dimensions (W x H x D) 483 x 44 x 238 mm
Weigh 6,5 kg
Environmental working temperature -10 to + 50 °C
Cooling type -
Analog -
Digital/Analog -
Relay -
RS232 -
RS485 Yes
IIC BUS Yes
RJ 45 (LAN) Yes
Safety EN60215:1997
EMC EN 301 489-11 V1.4.1
Spectrum Optimization -
STANDARD COMPLIANCE
GENERALS
INPUT
OUTPUTS
INTERFACE

8/ 24 Manuale Utente
Rev. 1.0 - 20/02/12
RDMODWEB
ELETTRONICA
 5. Installationandcongurationprocedure
This section provides a step-by-step description of device installation and
conguration procedure. Follow these procedures closely upon rst power-on
andeachtimeanychangeismadetogeneralconguration,suchaswhenanew
transmission station is added or the equipment is replaced.
Oncethedesiredcongurationhasbeensetup,nomoresettingsarerequired
for normal operation; at each power-up (even after an accidental shutdown), the
devicedefaultstotheparameterssetduringtheinitialcongurationprocedure.
The topics covered in this section are discussed at greater length in the next
sections, with detailed descriptions of all hardware and rmware features and
capabilities. Please see the relevant sections for additional details.
 5.1 Preparation
5.1.1 Preliminary checks
UnpacktheRDMODWEB interfaceandimmediatelyinspectitfortransportdamage.
Ensure that all connectors are in perfect condition.
Provide for the following (applicable to operating tests and putting into service):
√ Connection cable kit including:
• Mains supply, 230 VAC (-15% / +10%), with adequate ground connection;
• Cable for connection of the exciter telemetry signal;
• Ethernet cable (not included) for connection to an ADSL router or LAN
network;
or
• Crossover Ethernet cable (not included) for connection to an ADSL router or
LAN network.
5.1.2 Connections
1) Connect transmitter I2Coutput to RDMODWEB interface I2C input.
2) Connect the RDMODWEB interface NETWORK output to the relevant input
of its ADSL router or LAN network. If your connection equipment is different,
identify an equivalent output.

RDMODWEB
ELETTRONICA
9/ 24
Manuale Utente
Rev. 1.0 - 20/02/12
Note : If you intend to connect it directly to a PC, it is necessary to use a
crossover ethernet cable. This is a basic prerequisite to ensure equipment correct
operation.
3) ConnectthenetworkcabletotherelevantMAINS IN connectoronRDMODWEB
interface.
 5.2 FirstPower-OnandSet-Up
Performthisprocedureuponrstpower-upandeachtimeyoumakechangesto
thecongurationthiscomponentisintegratedinto.
5.2.1 Web User Interface (WUI)
Once all connections previously described are performed, the equipment is ready
for commissioning.
The WUI (Web User Interface) allows you to adjust, modify or display the
congurationvariablesandoperationdata.Followtheprocedurebelowtoopen
the WUI:
1) Open your web browser on your PC, and connect to http://192.168.0.244 to
connect to the WUI(ifLANIPaddresswaspreviouslymodied,itisnecessary
to use the new one). The following page opens:
User Name
Password
Login
Menù 1
Note : If address http://192.168.0.244 does not work, check and set IP address
as 192.168.0.XXX (where XXX is a gure between 0 and 255, excluding 244 that
is RDMODWEB interface default address). To change the IP address, follow the
instructions in the manual or in the online guide and technical help, specic for
the Operating System you use.

10 / 24 Manuale Utente
Rev. 1.0 - 20/02/12
RDMODWEB
ELETTRONICA
2) If the User Name and the Password have not been entered and saved yet,
and if no changes were made to access modes, enter RVR and RVR to enter
asadministrator(ifaccessdataweremodied,enterthenewUser Name and
Password). Then click on Login.
Note : Toenterasuser,typeuser anduser intoUser Name andPassword elds.
This enables WUI read-only mode.
3) Now interface is ready to remotely read data and modify the various settings
of the equipment.
 5.3 ManagementSoftware
1a) After access is made, the Main menu (main page) opens and shows
possible viewing options. This picture shows the Main menu after access as
administrator:
Main menu
Device Show all the device information
Device status Read all the device data and navigate to the showing page
Device settings
A
llow the user to change the device settings
A
larms Show the last ten active alarms
Network settings
A
llow you to set up the network parameters
General settings
A
llow you to set up all the parameters for the application behaviour
Commands
A
llow you to perform command on the TCP/IP interface
Menu 2
1b) If you enter as user, with no administrator privileges, only reading functions
will be available within the WUI, and the Main menu will be like this:
Main menu
Device Show all the device information
Device status Read all the device data and navigate to the showing page
Device settingsDevice settings
A
llow the user to change the device settings
A
larms Show the last ten active alarms
Network settingsNetwork settings
A
llow you to set up the network parameters
General settings
A
llow you to set up all the parameters for the application behaviour
Commands
A
llow you to perform command on the TCP/IP interface
Menu 3

RDMODWEB
ELETTRONICA
11 / 24
Manuale Utente
Rev. 1.0 - 20/02/12
To enter in one of the sub-menus, select the name and then click on item to
enter.
To go back to MAIN menu, just click on RVR logo at top left of all sub-menus.
If user tries to enter a sub-menu with no prior login, or after a certain period of
inactivity that can be set and causes automatic logout, upon attempt to enter any
of the sub-menus, the following page is displayed:
A
ttention
User not logged in
State 1
RepeatWUI accessproceduretorestoreoperatingconditionswiththesamemode
valid before logout.
If user enters information sub-menu about a device that is not yet acknowledged,
the following page is displayed:
A
ttention
Device not ready
State 2
In this case, allow a few seconds for RDMODWEB interface acknowledgement.
While to go back to MAIN menu, just click on RVR logo at top left of the sub-
menu.

12 / 24 Manuale Utente
Rev. 1.0 - 20/02/12
RDMODWEB
ELETTRONICA
5.3.1 Device Menu
Valuesfoundhereare“livereadings”,andassuchtheycannotbemodied.
This page shows the user the data of the exciter connected to the RDMODWEB
interface:
Device
Status Present
Model 10
Hardware 300
Software 306
Module connected 1
A
nalog inputs 8
A
nalog outputs 1
Digital inputs 16
Digital outputs 16
Generic I/O 13
Menu 4
Status Shows exciter connection state.
Model Shows exciter decimal ID number (10 is for TEX-LCD series).
Hardware
Shows exciter hardware release.
Software
Showsexciterrmwarerelease.
Module connected
Shows devices connected to exciter.
Analog inputs
Shows the analogue inputs managed by exciter.
Analog outputs
Shows the analogue outputs managed by exciter.
Generic I/O
Shows the general inputs and outputs managed by RDMODWEB
interface.

RDMODWEB
ELETTRONICA
13 / 24
Manuale Utente
Rev. 1.0 - 20/02/12
5.3.2 Status Menu
Values found here are “live readings”, and as such they can not be modied.
To change power setting use the Set Device (chapt. 5.3.3) after logging in as
administrator.
This page shows the user the data of the exciter connected to the RDMODWEB
interface:
Status
Ready...
PowerON On State
Frequency 98 MHz
Modulation 0.2 KHz
Forward Power 300.6 W
Reflected Power 6.9 W
Pa Voltage 50.5 V
PA Current 9 A
Temperature 3.6 C
% Power Out 100 %
Foldback Off State
Ext R.F. Mute No Mute State
Unlock
A
bsent State
Menu 5
Power ON
Shows exciter operating status.
Frequency
Shows exciter operating frequency.
Modulation
Shows exciter modulation.
Forward Power
Shows exciter forward power.
Reected Power
Showsexciterreectedpower.
Pa Voltage
Showsexciterampliermodulevoltage.
Pa Current
Showsexciterampliermodulecurrent.
Temperature
Shows equipment internal temperature reading.

14 / 24 Manuale Utente
Rev. 1.0 - 20/02/12
RDMODWEB
ELETTRONICA
% Power Out
Showspowersettingefciency.
Foldback
Showsthetriggeredstatusofthefoldbackfunction(automaticreduction
of output power).
Ext R.F. Mute
Shows the status of power inhibition by an interlock signal.
Unlock Shows the status of lock at frequency set by PLL.
5.3.3 Device Setting Menu
Nota : L’accesso a questo menù, ed eventuale modica dei parametri, è possibile
solo se si è effettuato il login come amministratore.
This page not only shows the user the information about the exciter connected to
the RDMODWEB interface, but also allows setting various parameters.
Followingisadescriptionoftheitemsthatallowmodicationoftheparameter,
withrespectto theStatus menu(chapt.5.3.2).PresstheUpdatebuttontoconrm
selection; if you let timer to time out or press the RVR logo, the parameter setting
will remain as previously set.
Set Device
Ready...
PowerON On State On Update
Frequency 98 MHz Update
Modulation 0.4 KHz
Forward Power 300.6 W
Reflected Power 6.8 W
Pa Voltage 50.5 V
PA Current 9 A
Temperature 3.6 C
% Power Out 100 % Update
Foldback Off State
Ext R.F. Mute No Mute State
Unlock
A
bsent State
Menu 6
Power ON
Enables (ON) or disables (OFF) exciter power output.

RDMODWEB
ELETTRONICA
15 / 24
Manuale Utente
Rev. 1.0 - 20/02/12
Frequency
Remote adjustment of exciter frequency. This value, in MHz, can be
modiedaccordingtoone’sownbandin0.1MHzsteps.
% Power Out
Remoteadjustmentofexciterpower.Thisvalue,in%,canbemodied
in the range 0 to 100, in steps of 1%.
5.3.4 Active alarms
Values found here are “live readings”, and as such they can not be modied.
To change alarms settings, use the GeneralSettings menu (chapt. 5.3.6) after
logging in as administrator.
Within this menu you can display all alarms saved by the system: any new event
will automatically delete the older ones. Using Reset item at bottom right of the
menu, you can delete all pending alarms.
This page showsthe userthe alarmsof theexciter connected tothe RDMODWEB
interface:
A
ctive alarms
TYPE NAME TIME DATE VALUE
3
A
udio alarm 9:32 6/9/2007 2
3
A
udio alarm 9:56 30/8/2007 1
Reset
Ready...
Menu 7
Type Shows the alarm code.
Name Shows the description for the error that led to event recording.
Time Shows event recording time (hh:mm).
Date Shows the day event was recorded (dd/MM/yyyy).
Value Shows progressive number for event recording.

16 / 24 Manuale Utente
Rev. 1.0 - 20/02/12
RDMODWEB
ELETTRONICA
5.3.5 Network settings
Note : Access to this menu and modication of these parameters are only possible
after login with administrator rights.
ThispagenotonlyshowstheusertheinformationabouttheRDMODWEB interface
network connection, but also allows setting various parameters.
Press the Updatebuttontoconrmselection;ifyoulettimertotimeoutorpress
the RVR logo, the parameter setting will remain as previously set.
Note : to make changes within these sub-menus you need to have thorough
technicalknowledgeof networkmanagement.Itis recommendedto havechanges
performed by trained or qualied personnel.
5.3.5.1 Ethernet menu
Network settings
Ethernet
DHCP Mode 0
IP address 192.168.0.244
Subnet Mask 255.255.255.0
DNS server 192.168.0.250
Gateway 192.168.0.1
SMTP
POP3
Update
Menu 8
Thispageallows congurationof theparametersneeded forconnecting toan
ethernet network.
DHCP Mode
Enables (0) or disables (1) dynamic address conguration mode
(DynamicHostCongurationProtocol).
IP address
Shows and sets the number that unequivocally identies, within a
single network, the devices connected to an IT network that uses the
IP standard (Internet Protocol).
