R.V.R. Elettronica PJ20KPS-C User manual

PJ20KPS-C/PJ25KPS-C
User & Technical Manual

EC Declaration of conformity
R.V.R. Elettronica S.p.A. declares that this transmitter is in conformity to the essential requi-
rements and to other relevant regulations settled by the 1999/5/CE directive.
Validity of the EC declaration of conformity.
WARNING: the conformity of this product is not valid if the product is used in conditions not
authorized by R.V.R. Elettronica as described in the user manual.
Examples of conditions in which the conformity is not valid (indicative list):
The connection between the exciter and the amplier (i) indicated in the present document is
not done properly;
The components used are different from those used and recommended by R.V.R. Elettronica
S.p.A.;
The additional devices used are not suitable and/or are generating signals which are not
suitable to those supported by the product;
The product is used in operative conditions different from the normal working conditions for
which the product was designed (temperature, humidity, supply voltage, …);
Any modication on parts of the product without any prior authorization from R.V.R.
Elettronica S.p.A..
Limitations for the use of the product in the EEC member countries.
This product is a radio transmitter for FM broadcasting .
It can work on operative frequencies which are not harmonized in the EEC member
countries.
Whoever uses this product, should obtain the authorization from the spectrum local admini-
strative authority before starting using it.
The user is responsible for the conguration of the working frequency, the output power, and
for the other characteristics of the installation to which the transmitter described in the pre-
sent documentation is part of, in order to respect the limitations described in the authoriza-
tion received by the competent local authority.

Waste Electrical or Electronic Equipment
(WEEE)
This symbol indicates that you should not discard waste electrical or electro-
nic equipment (WEEE) in the trash. For proper disposal, contact your local
recycling/reuse or hazardous waste center.
CAUTION
Do discard waste electrical or electronic equipment (WEEE) in the trash.
For proper disposal, contact your local recycling/reuse or hazardous waste
center.

ELETTRONICA
PJ20KPS-C/PJ25KPS-C
User & Technical ManualRev. 1.2 23/07/2012
IV
Index
1.
2.
3.
3.1
3.1.1
3.1.2
3.2
3.2.1
3.2.2
4.
4.1
4.2
5.
5.1
5.1.1
5.1.2
5.1.3
5.1.4
5.1.5
5.1.6
5.1.7
5.1.8
5.1.9
5.1.10
5.1.11
5.1.12
5.1.13
5.2
5.3
5.4
5.4.1
5.5
6.
6.1
6.2
6.2.1
6.2.2
6.3
6.4
6.5
6.6
6.7
6.8
6.9
7.
7.1
7.2
7.3
Introduction.........................................................................................
Warranty..............................................................................................
First Aid...............................................................................................
Treatment of electrical shocks............................................................
If the victim is not responsive..............................................................
If victim is responsive..........................................................................
Treatment of electrical Burns..............................................................
Extensive burned and broken skin.....................................................
Less severe burns..............................................................................
General Description............................................................................
Composition........................................................................................
Technical specications......................................................................
Master control unit (MCU)..................................................................
LCD Display........................................................................................
Overall status menù...........................................................................
Select menù........................................................................................
Master control unit menù....................................................................
R.F. combiners menù..........................................................................
Control units menù.............................................................................
Alarms menù......................................................................................
Service menù......................................................................................
Settings menù.....................................................................................
Exciters menù.....................................................................................
Info menù............................................................................................
Release menù....................................................................................
Modem menù......................................................................................
Password menù..................................................................................
Buttons, selector switches and LEDs.................................................
Phase ADJ..........................................................................................
Alarms.................................................................................................
System derating..................................................................................
Rear panel..........................................................................................
Wiring diagrams MCU........................................................................
CPU board (SLCPUPJ5KM2).............................................................
Main board (SL044IN1002)................................................................
Setting addresses the main board......................................................
Connections main board.....................................................................
Rear panel card (SL044PC2002).......................................................
Motherboard CCU (SLCCU1PJ5KM2)...............................................
Card measures input splitter (SLSPLMEA5KW1)...............................
Synoptic panel board (SL044PC1001)...............................................
CCU board (SLCCUPJ5KM2).............................................................
Splitter board (SLSPLTHC3-01)..........................................................
Phase shifter (SLPHSHHC3-02).........................................................
Electrical and mechanical parts..........................................................
General views.....................................................................................
Low voltage and signals schematic....................................................
Power supply terminal services........................................................
1
2
4
4
4
5
5
5
5
6
6
7
8
10
11
12
12
13
14
15
15
16
17
18
18
19
20
21
24
25
27
28
30
33
40
44
45
46
50
53
55
58
63
66
69
69
74
75

ELETTRONICA
Rev. 1.2 23/07/2012 V User & Technical Manual
PJ20KPS-C/PJ25KPS-C
Parallel interface (MCUPJBUSADP1)................................................
Plate connectors.................................................................................
DB25 pinout (exciter enable)..............................................................
Hybrid coupler (COUP3DB20KF).......................................................
Dummy load (PF1KDI5KWH2O).........................................................
GSM Telemetry (opzional)..................................................................
Installing and conguring the PC software.........................................
Dial-up via PC.....................................................................................
Dial-up via mobile...............................................................................
Alarms................................................................................................
76
79
81
83
84
87
90
102
104
105
7.4
7.5
7.5.1
7.6
7.7
7.8
7.8.1
7.8.2
7.8.3
7.8.4

ELETTRONICA
PJ20KPS-C/PJ25KPS-C
User & Technical ManualRev. 1.2 23/07/2012
VI
[This page has been left blank intentionally]

ELETTRONICA
Rev. 1.2 23/07/2012 1 User & Technical Manual
PJ20KPS-C/PJ25KPS-C
This manual describes the PJ20KPS-C/PJ25KPS-C, a solid-state RF amplier designed
for frequency modulation sound broadcasting, manufactured by R.V.R. Elettronica S.p.A.
Being the PJ20KPS-C/PJ25KPS-C a combination of two PJ10KPS-C or PJ12K5PS-C, in this
manual is described the general operation of the transmitter and of the devices present in
addition, instead of with regard to the single transmitter refer to the manual of PJ10KPS-C.
This manual is written as a general guide for those having previous knowledge and expe-
rience with this kind of equipment, well conscious of the risks connected with the operation
of electrical equipment.
It is not intended to contain a complete statement of all safety rules which should be observed
by personnel in using this or other electronic equipment.
The installation, use and maintenance of this piece of equipment involve risks both for the
personnel performing them and for the device itself, that shall be used only by trained per-
sonnel.
R.V.R. Elettronica S.p.A. doesn’t assume responsibility for injury or damage resulting from
improper procedures or practices by untrained/unqualied personnel in the handling of this
unit.
Please observe all local codes and re protection standards in the operations of this unit.
WARNING: always disconnect power before opening covers or removing any part of this unit.
Use appropriate grounding procedures to short out capacitors and high voltage points before
servicing.
WARNING: this device can irradiate radio frequency waves, and if it’s not installed following
the instructions contained in the manual and local regulations it could generate interferences
in radio communications.
In a residential place this equipment can cause hash. In this case can be requested to user
to take the necessary measures.
R.V.R. Elettronica S.p.A. reserves the right to modify the design and/or the technical
specications of the product and this manual without notice.
1. Introduction
This manual is an integral part of the manual PJ10KPS-C
and not replacement.

ELETTRONICA
PJ20KPS-C/PJ25KPS-C
User & Technical ManualRev. 1.2 23/07/2012
2
Any product of R.V.R. Elettronica is covered by a 24 (twenty four) month warranty.
For components like tubes for power ampliers, the original manufacturer’s warranty applies.
R.V.R. Elettronica S.p.A. extends to the original end-user purchaser all manufacturers
warranties which are transferable and all claims are to be made directly to R.V.R. per
indicated procedures.
Warranty shall not include:
1 You damn that are veried each other during the consignment of the machine to
the R.V.R. for possible reparations;
2 Any unauthorized repair/modication;
3 Incidental/consequential damages as a result of any defect;
4 Nominal non-incidental defects
5 Re-shipment costs or insurance of the unit or replacement units/parts
Any damage to the goods must be reported to the carrier in writing on the shipment receipt.
Any discrepancy or damage discovered subsequent to delivery, shall be reported to R.V.R.
Elettronica within 5 (ve) days from delivery date.
To claim your rights under this warranty, you should follow this procedure:
2. Warranty
Contact the dealer or distributor where you purchased the unit. Describe the problem and,
so that a possible easy solution can be detected.
Dealers and Distributors are supplied with all the information about problems that may oc-
cur and usually they can repair the unit quicker than what the manufacturer could do. Very
often installing errors are discovered by dealers.
If your dealer cannot help you, contact R.V.R. Elettronica and explain the problem. If it is
decided to return the unit to the factory, R.V.R. Elettronica will mail you a regular authori-
zation with all the necessary instructions to send back the goods.
When you receive the authorization, you can return the unit. Pack it carefully for the
shipment, preferably using the original packing and seal the package perfectly. The custo-
mer always assumes the risks of loss (i.e., R.V.R. is never responsible for damage or loss),
until the package reaches R.V.R. premises. For this reason, we suggest you to insure the
goods for the whole value. Shipment must be effected C.I.F. (PREPAID) to the address
specied by R.V.R.’s service manager on the authorization
DO NOT RETURN UNITS WITHOUT OUR AUTHORIZATION AS THEY WILL BE
REFUSED
Be sure to enclose a written technical report where mention all the problems found and a
copy of your original invoice establishing the starting date of the warranty.
1
2
3
4
5
6

ELETTRONICA
Rev. 1.2 23/07/2012 3 User & Technical Manual
PJ20KPS-C/PJ25KPS-C
Replacement and warranty parts may be ordered from the following address. Be sure to inclu-
de the equipment model and serial number as well as part description and part number.
R.V.R. Elettronica SpA
Via del Fonditore, 2/2c
40138 BOLOGNA
ITALY
Tel. [phone]
email: [e-mail]
Web: www.rvr.it

ELETTRONICA
PJ20KPS-C/PJ25KPS-C
User & Technical ManualRev. 1.2 23/07/2012
4
3. First Aid
The personnel employed in the installation, use and maintenance of the device, shall be
familiar with theory and practice of rst aid..
3.1 Treatment of electrical shocks
3.1.1 If the victim is not responsive
Follow the A-B-C’s of basic life support
• Place victim at on his back on a hard surface
• Open airway: lift up neck, push forehead back (Fig. 3-1).
• Clear out mouth if necessary and observe for breathing
• if not breathing, begin articial breathing (Figure 3-2): tilt head, pinch nostrils, make
airtight seal, four quick full breaths. Remember mouth to mouth resuscitation must be
commenced as soon as possible
• Check carotid pulse (Fig 3-3); if pulse is absent, begin articial circulation
(Fig. 3-4) depressing sternum (Fig. 3-5)
• In case of only one rescuer, 15 compressions alternated to two breaths.
• If there are two rescuers, the rhythm shall be of one brath each 5 compressions.
• Do not interrupt the rhythm of compressions when the second person is giving
brath.
• Call for medical assistance as soon as possible.

ELETTRONICA
Rev. 1.2 23/07/2012 5 User & Technical Manual
PJ20KPS-C/PJ25KPS-C
3.1.2 If victim is responsive
• Keep them warm
• Keep them as quiet as possible
• Loosen their clothing (a reclining position is recommended)
• Call for medical help as soon as possible
3.2 Treatment of electrical Burns
3.2.1 Extensive burned and broken skin
• Cover area with clean sheet or cloth
• Do not break blisters, remove tissue, remove adhered particles of clothing, or apply
any salve or ointment.
• Treat victim for shock as required.
• Arrange transportation to a hospital as quickly as possible.
• If arms or legs are affected keep them elevated
If medical help will not be available within an hour and the victim is conscious and not
vomiting, give him a weak solution of salt and soda: 1 level teaspoonful of salt and 1/2
level teaspoonful of baking soda to each quart of water (neither hot or cold). Allow victim
to sip slowly about 4 ounces (half a glass) over a period of 15 minutes. Discontinue uid
if vomiting occurs.
DO NOT give alcohol
3.2.2 Less severe burns
• Apply cool (not ice cold) compresses using the cleansed available cloth article.
• Do not break blisters, remove tissue, remove adhered particles of clothing, or apply
salve or ointment.
• Apply clean dry dressing if necessary.
• Treat victim for shock as required.
• Arrange transportation to a hospital as quickly as possible
• If arms or legs are affected keep them elevated.

ELETTRONICA
PJ20KPS-C/PJ25KPS-C
User & Technical ManualRev. 1.2 23/07/2012
6
4.1 Composition
The PJ20KPS-C/PJ25KPS-C transmitter is made up of modules inserted in a 19” rack. The main
apparatuses are:
• 20 RF amplier modules at 1.2 kW nominal (PJ20KPS-C)
• 20 RF amplier modules at 1.4 kW nominal (High efciency) (PJ25KPS-C)
• 1 Control unit called Master control unit (MCU)
• 1 Hybrid coupler -3dB
• 1 Dummy load
• 4 Power supply
• 1 Service rack (optional)
In standard conguration is supplied with two racks of 40 units as an option you can have a rack
for 40 units of services that can be installed on the right (as shown) or to the left of the transmit-
ter.
4. General Description
The PJ20KPS-C/PJ25KPS-C is a RF amplier for frequency modulation sound broadcasting. It
is a fully solid-state apparatus of modern design that uses MOSFET as active components in the
FM amplifying modules.This chapter briey describes the machine’s main features.

ELETTRONICA
Rev. 1.2 23/07/2012 7 User & Technical Manual
PJ20KPS-C/PJ25KPS-C
4.2 Technical specications
PJ20KPS-C PJ25KPS-C
Frequency range 87.5 - 108.0 MHz
Nominal RF power 20000 - 21000 W 25000 - 26250 W
Power supply voltage 220/380V Threephase, 3F+N
Exciting power Max. 100 W
Consumption 35 Kw 37 Kw
Power factor 0.98

ELETTRONICA
PJ20KPS-C/PJ25KPS-C
User & Technical ManualRev. 1.2 23/07/2012
8
5. Master control unit (MCU)
The operator controls and checks the status of the amplier by means of the common contro
unit (CCU).
NB: the following as an example the PJ20KPS-C, but the meaning applies in similar manners
also for the PJ25KPS-C.
Three control groups are present on this unit:
• LCD and scroll buttons

ELETTRONICA
Rev. 1.2 23/07/2012 9 User & Technical Manual
PJ20KPS-C/PJ25KPS-C
• Buttons, selector switches and LEDs
• Phase ADJ

ELETTRONICA
PJ20KPS-C/PJ25KPS-C
User & Technical ManualRev. 1.2 23/07/2012
10
Figure 5-1
5.1 LCD Display
The operator uses the control software of the transmitter by means of a series of menus
that are displayed on the LCD. Four specic keys are provided for scrolling through the
menus, performing the settings and giving the commands:
Pulsante Descrizione
OK Click this button to access a sub-menu, to enter the editing mode
or to conrm a modied value.
ESC Click this button to exit from a menu or to cancel the modication
of a value.
Click this button to scroll inside a menu (to the right or down) or to
reduce the value of a parameter being modied.
Click this button to scroll inside a menu (to the left or up) or to
increase the value of a parameter being modied.
Trimmer for the regulation of the contrast of display the LCD
When the operator is not using the various buttons to navigate, the LCD displays the
preset screenful that shows the “Output Power” that it indicates the forward and reected
output power (Figure 5-1).
As indicated on the preset screenful, push the ESC button to access at the “Overall Sta-
tus” menù (Figure 5-2).

ELETTRONICA
Rev. 1.2 23/07/2012 11 User & Technical Manual
PJ20KPS-C/PJ25KPS-C
Menù Line Description
Timer (when
enabled)
Indication of the start and stop times of the automatic power
reduction feature - see “Settings” menù
Master Control
unit
Status of the master control unit (Off or On) and indication of the
exciter actually connected to the amplier (Exct.1 or Exct.2)
R.F. Combiner-1 Status of the RF combiner board RF1
R.F. Combiner-2 Status of the RF combiner board RF2
Control unit-1 State of the control unit of the TX1
Control unit-2 State of the control unit of the TX2
Hours Timer counting the hours of operation of the transmitter. For exam-
ple, this indication is useful in order to dene when a maintenance
operation can be made
By pressing the Ok key as indicated on the last line, you can shift to the exchange screen
from which you can have access to the “Select” menù (Figure 5-3).
Note: All control unit (that of TX1 and TX2) must be in REMOTE otherwise will come visuali-
zed “Time-out”. If from LOCAL it is passed REMOTE, will have to pass approximately 30/40
sec. before being able to visualize the relative state.
This menu includes only indications, therefore the user cannot insert any input in its different
lines.(Figure 5-2).
Figure 5-2
5.1.1 Overall Status Menù
5.1.2 Select Menù
This is the exchange menu from which you can select the different sub-menus that
compose the software.(Figure 5-3).
In order to enter a sub-menu, select the correspondent line with the arrow buttons and
press OK key.
Menù Line Description
Master Control
unit
General status of the PJ20KPS-C/PJ25KPS-C
R.F. Combiners Status of RF combiners
Control Units Status of the control units

ELETTRONICA
PJ20KPS-C/PJ25KPS-C
User & Technical ManualRev. 1.2 23/07/2012
12
Menù Line Description
Alarms Summary of the occured alarms
Service Service menu
Settings Setting of the parameters (i.e. Power levels)
Exciters Parameters of the exciters (i.e. output power, on air exciter)
Info Information concerning the conguration of the PJ20KPS-C/
PJ25KPS-C
Release Information concerning the hardware and software versions of the
modules composing the unit
Modem Settings related to the optional telemetry system
Passwords Setting and changing the password to change the parameters of
the menu settings
To return to the predened menu press key ESC many times.
Figure 5-3
5.1.3 Master Control Unit Menù
Informative menu on the inputs and the outputs of the MCU of the machine (Figure
5-4).
Menù Line Description
Ext Intl Input status “external interlock” (JP4/4 parallel interface)
Aux Intl Input status “auxiliary interlock” (JP4/5)
Exc1 A.Audio Input status “audio alarm exciter 1” (JP4/8)
Exc2 A.Audio Input status “audio alarm exciter 2” (JP4/9)
Mains Indicates the status of phase control at the rear of the TX1.
Must be ON in order to ensure that the entire transmitter fun-
ctions, otherwise remain locked and the only visual alarm, will
be the LED WAIT lit on the MCU. There appears no alarm line
in “Alarms Menu”
L.P. Timer Input status of the modality of automatic reduction of the power
Reserve-1 Input status “Reserve 1” (JP8/2)

ELETTRONICA
Rev. 1.2 23/07/2012 13 User & Technical Manual
PJ20KPS-C/PJ25KPS-C
Reserve-2 Input status “Reserve 2” (JP8/3)
Reserve-3 Input status “Reserve 3” (JP8/4)
Relay Exc Exciters exchange relay status (Off = exciter 1 on air)
Exc-1 Mute Exciter 1 interlock status (Off = RF power enabled)
Exc-2 Mute Exciter 2 interlock status (Off = RF power enabled)
Audio Alarm Output Audio Alarm status (JP47/1)
Exc’s Mains Exciters power supply status (On = power supply enabled)
PG1 Status of output PG1
PG2 Status of output PG2
RFL1 Status of output RFL1
RFL2 Status of output RFL2
Stand_by (In) “Stand by” input line status
Stand_by (Out) “Stand by” output line status from the control unit
Total Eff Total efciency of the machine
Figure 5-4
5.1.4 R.F. Combiners Menù
This menu contains the information related to the RF part of the complete transmitter.
(Figure 5-5).
Menu Line Description
Antenna Fwd RF power emitted by the transmitter
Antenna R RF power Reected antenna
Load-1 Fwd RF power on the dummy load
Load-1 R RF power reected on the dummy load
Load-1 Alr. State of the clickson of 120° C on the dummy load: Alr means that if
is protection activated the 120° C and the transmitter is immediately
stopped and goes to FAULT. Only the intervention of a technician or
a reset by telemetry (if the temperature alarm is no longer present)
will restart the transmitter.
Load-1 Wrn. State of the clickson of 50° C on the dummy load: Alr means that if
is protection activated the 50° C, the transmitter continues to run but
care is needed, probably load fans are not working or there is too
much power on the unbalanced load.
Stand-by (In) Not used
Stand-by 1 (Out) Not used
Stand-by 2 (Out) Not used

ELETTRONICA
PJ20KPS-C/PJ25KPS-C
User & Technical ManualRev. 1.2 23/07/2012
14
Figure 5-5
5.1.5 Control Units Menù
This menu contains information regarding the status of all machines that make up the
trasmettiore (Figure 5-6 and 5-7).
Menu Line Description
Control Unit 1 - Overall Status
Control Unit State of the control (Off or On) of TX1
Power Supply State of Power supply board (On or Off) of TX1
R.F. Combiner State of RF combiner board (Off or On) of TX1
R.F. Unit-x State of RF amplier module number N (Off or On) of TX1
In the angle low to right of the display the symbol is present his means that
an ulterior relative page to this menu is available (Figure 5-6 or 5-7), that it is possible
to visualize using the key-arrow.
Menu Line Description
Control Unit 2 - Overall Status
Control Unit State of the control (Off or On) of TX2
Power Supply State of Power supply board (On or Off) of TX2
R.F. Combiner State of RF combiner board (Off or On) of TX2
R.F. Unit-x State of RF amplier module number N (Off or On) of TX2
Figure 5-6 Figure 5-7
