RADLEY 1281-112 User manual

OWNER’S MANUAL
3 Year Limited Warranty
READ ALL INSTRUCTIONS BEFORE FIRST USE. KEEP THIS
MANUAL FOR FUTURE REFERENCE. KEEP AWAY FROM
CHILDREN.
WEAR CSA APPROVED
EYE PROTECTION
WEAR EAR
PROTECTION
WEAR FACE
PROTECTION

Product Specifications ......................................................................................... 1
Table of Contents................................................................................................... 2
Safety Guidelines................................................................................................3-6
Symbols................................................................................................................... 9
Tool specific warnings .......................................................................................... 10
Know your Sharpener ........................................................................................... 10
Assembly and Operating................................................................................ 11-14
Maintenance................................................................................................... 15-18
Exploded View ..................................................................................................... 15
Parts List ...........................................................................................................16-17
Warranty ................................................................................................................ 18

Rating:
120 V, 60 Hz AC
Amperes:
1 A
Grinding speed:
5,500 RPM (no load)
Sharpens Bit sizes
1/8-1/2” (3-13mm)
Tool Weight
4.6 lbs.(2.1kg)
Call us on our toll-free customer support line:
1-866-349-8665 (Monday through Friday 9am –5pm Eastern Standard Time)
1. Technical questions
2. Replacement parts
3. Parts missing from package

EYE, EAR & LUNG PROTECTION
SAVE THESE INSTRUCTIONS FOR REFERENCE
! WARNING: Before using this tool or any of its accessories, read this
manual and follow all Safety Rules and Operating Instructions. The important
precautions, safeguards and instructions appearing in this manual are not
meant to cover all possible situations. It must be understood that common
sense and caution are factors which cannot be built into the product.
ALWAYS WEAR EYE PROTECTION THAT CONFORMS WITH CSA
REQUIREMENTS or ANSI SAFETY STANDARD Z87.1
FLYING DEBRIS can cause permanent eye damage. Prescription
eyeglasses ARE NOT a replacement for proper eye protection.
WARNING: Non-compliant eyewear can cause serious injury if
broken during the operation of a power tool.
WARNING: Use hearing protection, particularly during extended
periods of operation of the tool, or if the operation is noisy.

WEAR A DUST MASK THAT IS DESIGNED TO BE USED WHEN
OPERATING A POWER TOOL IN A DUSTY ENVIRONMENT.
!
WARNING: Dust that is created by power sanding, sawing, grinding,
drilling, and other construction activities may contain chemicals that are
known to cause cancer, birth defects, or other genetic abnormalities. These
chemicals include:
Lead from lead-based paints
Crystalline silica from bricks, cement, and other masonry products
Arsenic and chromium from chemically treated lumber
The level of risk from exposure to these chemicals varies, according to how
often this type of work is performed. In order to reduce exposure to these
chemicals, work in a well-ventilated area, and use approved safety
equipment, such as a dust mask that is specifically designed to filter out
microscopic particles.
ELECTRICAL SAFETY
WARNING: To avoid electrical hazards, fire hazards or damage to the
tool, use proper circuit protection.
This tool is wired at the factory for 120 V AC operation. It must be
connected to a 120 V AC, 15 A circuit that is protected by a time-delayed
fuse or circuit breaker. To avoid shock or fire, replace power cord
immediately if it is worn, cut or damaged in any way.

!
WARNING: Read all safety warnings
and instructions. Failure to follow the warnings
and instructions may result in electric shock, fire
and/or serious injury.
Save all warnings and instructions for future
reference.
Work area safety
Keep work area clean and well lit. Cluttered or
dark areas invite accidents.
Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases, or dust. Power
tools create sparks which may ignite the dust or
fumes.
Keep children and bystanders away while
operating a power tool. Distractions can cause
you to lose control.
Electrical safety
Power tool plugs must match the outlet.
Never modify the plug in any way. Do not
u s e any adapter plugs with earthed
(grounded) power tools. Unmodified plugs and
matching outlets will reduce risk of electric
shock.
Avoid body contact with earthed or
grounded surfaces such as pipes, radiators,
ranges, and refrigerators. There is an
increased risk of electric shock if your body is
earthed or grounded.
Do not expose power tools to rain or wet
conditions. Water entering a power tool will
increase the risk of electric shock.
Do not abuse the cord. Never use the cord for
carrying, pulling, or unplugging the power
tool. Keep cord away from heat, oil, sharp
edges or moving parts. Damaged or
entangled cords increase the risk of electric
shock.
When operating a power tool outdoors, use
an extension cord suitable for outdoor use.
Use of a cord suitable for outdoor use reduces
the risk of electric shock.
If operating a power tool in a damp location
is unavoidable, use a residual current device
(RCD) protected supply. Use of a ground fault
circuit interrupter (GFCI) reduces the risk of
electric shock.
Personalsafety
Stay alert, watch what you are doing and use
common sense when operating a power tool.
Do not use a power tool while you are tired
or under the influence of drugs, alcohol, or
medication. A moment of inattention while
operating power tools may result in serious
personal injury.
Use personal protectiveequipment. Always
wear eye protection. Protective equipment
such as dust mask, non-skid safety shoes, hard
hat, or hearing protection used for appropriate
conditions will reduce personal injuries.
Prevent unintentional starting. Ensure the
switch is in the off position before
connecting to power source and/or battery
pack, picking up or carrying the tool.
Carrying power tools with your finger on the
switch or energizing power tools that have the
switch on invites accidents.
Remove any adjusting keyor wrench before
turning the power tool on. A wrench or a key
left attached to a rotating part of the power tool
may result in personal injury.
Do not overreach. Keep proper footing and
balance at all times. This enables better
control of the power tool in unexpected
situations.
Dress properly. Do not wear loose clothing
or jewellery. Keep your hair, clothing, and
gloves away from moving parts. Loose
clothes, jewellery or long hair can be caught in
movingparts.

Personal safety –cont’d
If devices are provided for the connection of
dust extraction and collection facilities,
ensure these are connected and properly
used. Use of dust collection can reduce dust-
relatedhazards.
Power tool use and care
Do not force the power tool. Use the correct
power tool for your application. The correct
power tool will do the job better and safer at the
rate for which it was designed.
Do not use the power tool if the switch does
not turn it on and off. Any power tool that
cannot be controlled with the switch is
dangerous and must be repaired.
Disconnect the plug from the power source
and/or the battery pack from the power tool
before making any adjustments, changing
accessories, or storing power tools. Such
preventive safety measures reduce the risk of
starting the power tool accidentally.
Store idle power tools out of the reach of
children and do not allow persons unfamiliar
with the power tool or these instructions to
operate the power tool. Power tools are
dangerous in the hands of untrained users.
Maintain power tools. Check for
misalignment or binding of moving parts,
breakage of parts and any other condition
that may affect the power tool’s operation. If
damaged, have the power tool repaired
before use. Many accidents arecaused by
poorly maintained power tools.
Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting
edges are less likely to bind and are easier to
control.
Use the power tool, accessories, and tool
bits etc. in accordance with these
instructions, taking into account the working
conditions and the work to be performed.
Use of the power tool for operations different
from those intended could result in a hazardous
situation.
Service
Have your power tool serviced by a qualified
repairperson using only identical
replacement parts. This will ensure that the
safety of the power tool is maintained.

! WARNING: Know your multi-purpose
sharpener. Do not plug in the tool until you
have read and understand this Instruction
Manual.
Learn the tool’s applications and limitations,
as well as the specific potential hazards
related to this tool. Following this rule will
reducethe risk of electric shock, fire, or serious
injury.
Always wear eye protection. Any
power tool can throw foreign
objects into your eyes and cause
permanent eye damage.
ALWAYS wear safety goggles (not glasses) that
comply with ANSI safety standard Z87.1.
Everyday glasses have only impact resistant
lenses. They ARE NOT safety glasses.
.
1. Always remove the power cord from the power
source before making 1. Always remove the
power cord from the power source before making
any adjustments or maintenance, including
changing the wheel.
2. Always turn the sharpener off when it is not in
use and never leave it unattended without first
switching off and unplugging power cord. Never
leave the sharpener until the wheel has come to a
complete stop.
3. Do not use a wheel that has received a blow,
especially to the side of the wheel. Replace a
cracked or suspect wheel.
4. Always allow a new wheel to run for a few
minutes at full speed before using it.
5. Check that the wheel rotates freely before each
start up.
6. Do not use the sharpener unless all the
attachments are properly fitted and secure.
7. Do not overload the sharpener. Allow the
sharpener to run at full speed before use.
8. Never apply excessive pressure to the wheel. It
might shatter causing personal injury.
9. Make sure the wheel is not in contact with the
work when you start the sharpener.
10. When using the sharpener, use safety
equipment including safety goggles or shield, ear
protection, dust mask and protective clothing
including safety gloves.
11. Abrasive grinding wheels should be stored
and handled with care in compliance with the
manufacturer’s instructions.
12. Examine the grinding wheel before use; do
not use chipped, cracked or otherwise deficient
products.
13. Use only grinding wheels reinforced with
organic bond (80m/s)
14. Make sure that the abrasive product is
correctly mounted and clamped before use.
15.Avoid use in the presence of flammable
materials or substances. Sparks created by
the tool may ignite them.
16. Make sure air vents are unobstructed and
cleaned of dust.
17. Grinding wheels continue to rotate after the
motor stops.
18. If the supply cord is damaged, it must be
replaced by the manufacturer, its service
agent, or similarly qualified persons.
19. When servicing use only identical
replacement parts
20.To reduce the risk of electric shock, this
equipment has a polarized plug (one blade is
wider than the other). This plug will fit in a
polarized outlet only one way. If the plug does
not fit fully in the outlet, reverse the plug. If it
still does not fit, contact a qualified electrician
to install the proper outlet. Do not change the
plug in any way
21. Do not operate this tool in a damp location.
Do not apply water to tool.

!
Make sure your extension cord is the proper
size. When using an extension cord, be sure to
use one heavy enough to carry the current the
tool will draw. An undersized cord will cause a
drop in line voltage resulting in loss of power
and overheating. The table on at right shows the
correct size to use according to cord length and
nameplate ampere rating. If in doubt, use the
next heavier gauge. The smaller the gauge
number the heavier the cord.
Be sure your extension cord is properly
wired and in good condition. Always replace a
damaged extension cord or have it repaired by a
qualified electrician before using it. Protect your
extension cord from sharp objects, excessive
heat and damp or wet areas.
When operating a power tool outdoors, use
an outdoor extension cord marked “W -A” or
“W”. Thesecords are rated for outdoor use and
reducethe risk of electric shock.
WARNING: Keep the extension cord
clear of the working area. Position the cord
so it will not get caught on the workpiece,
tools, or any other obstructions while you are
working with the power tool.
! WARNING: Repair or replace
damaged or worn extension cords
immediately.
Select the appropriate extension cord gauge
and length using the chart to the right.
MINIMUM GAUGE(AWG) EXTENSION
CORDS (120 V use only)
Ampererating
Total length in feet
More
than
Not
more
than
7.5 m
(25')
15 m
(50')
30 m
(100')
45 m
(150')
0
6
18
16
16
14
6
10
18
16
14
12
10
12
16
16
14
12
12
16
14
12
NotApplicable

9
!
Direct current
No load speed
Alternating or direct
current
Class II construction
Splash-proof
construction
Watertight construction
Protective grounding at
grounding terminal,
Class I tools
Revolutions or
reciprocations per
minute
Diameter
Off position
Directional arrow
Warning symbol
Wear your safety
glasses
WARNING: Some of the following symbols may appear on the tool. Study these
symbols and learn their meaning. Proper interpretation of these symbols will allow for
more efficient and safer operation of this tool.
This symbol designates that this tool is listed
with U.S. and Canadian requirements by
ETL Testing Laboratories, Inc.
Conforms to UL Std.987
Certified to CAN/CSA-C22.2 No.71.2-08
V
Volts
A
Amperes
Hz
Hertz
W
Watts
kW
Kilowatts
Microfarads
L
Liters
kg
Kilograms
H
Hours
N/cm2
Newtons per square
centimeter
Pa
Pascals
OPM
Oscillations per minute
Min
Minutes
S
Seconds
or a.c.
Alternating current
Three-phase alternating
current
Three-phase alternating
current with neutral
ETL3115903
JS-950M

1. Hatchet andknife sharpener 2. Depth adjustment dial
3. Plunger 4. Positioning claws
5. InternalPositioningPad 6. Drill bit sharpener
7. Guide 8. ON/OFF switch
9. Drill bit sharpener 10. Dust Box
11.Dust Box 12. Scissor Sharpener
13.Drill bit holder
1
2 3
6
7
45
30 70
20 75
DC Inverter Arc Welder
4
5

SHARPENING TOOLS
1. Place the sharpener on a stable table or
bench.
2. Plug the sharpener into a 120v~ 60Hz
outlet.
3. Turn the tool ON by setting the switch to
the “I” position.
4. Allow the sharpener to run for a few
minutes.
5. Choose the desired sharpening slot.
according to the tool to be sharpened.
a. To sharpen hatchets and similar tools, insert the
blade of the tool into the sharpening slot and
pull the tool toward you, never push it! (Fig.
1)
b. To sharpen knives and kitchen utensils, place
the blade in the guide and pull the item to be
sharpened toward you, never push it! (Fig. 2)
c. To sharpen scissors, place the blade in the
guard on the oblique cut side and pull toward
you, never push blade. (Fig.3)
SHARPENING DRILL BITS
1. Insert the Drill Bit Holder into the Guide and ensure the “rib” on the Holder matches with the
rib on the Guide. (Fig. 4). Open the Drill Bit holder (turn counterclockwise) and adjust the
depth dial to the desired setting. Adjust this setting with the plunger up and the positioning
claws closed: O is the least material removed, 3 is the most (used for damaged drill bits)
(Fig. 5).
IMPORTANT: Ensure you adjust the depth within the number range on the scale.
(Fig. 4)
(Fig. 5)
Fig. 2
Fig. 3
Fig. 1

2. Open the positioning claws by pushing down on the plunger (Fig.6)
(Fig.6)
3. Insert the drill bit into the Drill Bit Holder. Ensure the drill bit tip is in contact with the
Internal Positioning Pad. Pull up on the Plunger to close the Positioning Claws. Tighten
the Drill Bit Holder enough to hold the bit in place but still allow the bit inserted inside to
rotate. Rotate the drill bit inside the holder and ensure the claws meet the surface of the
drill bit when the bit is rotated. Turn the Drill Bit Holder clockwise to lock the drill bit into
place. (Fig.7).
Plunger
Positioning Claws
Internal
positioning pad
Plunger
(Fig. 7)

4. Push down on the Plunger to open the Positioning Claws and remove the Drill Bit Holder from the
Guide. Ensure the drill bit is secured tightly in the Drill Bit Holder.
(Fig. 8)
5.Turn the sharpener on and let it run for several seconds. Choose the appropriate Drill Bit
Sharpener –Top Sharpener is (designed) intended for drill bits 10mm (3/8”) or larger. The drill
bit sharpener on the side of the tool is for bits smaller than 10mm (3/8”). Push the safety cover
off to one side.
6.To use the drill bit sharpener for bits smaller than 3/8” (10mm). Push the safety cover to the
side and then insert the drill bit (held securely in the Drill Bit Holder) into the sharpener opening.
Ensure the “rib” on the Holder matches with the rib on the Guide. Oscillate the Drill Bit Holder in
the sharpener, then remove the Drill Bit Holder (with bit inserted) and turn it 180°, then reinsert
and oscillate to ensure symmetry while sharpening the bit.
7.To use the drill bit sharpener for bits larger than 3/8” (10mm) Insert the drill bit into the Drill Bit
Holder, while ensuring the cutting face of the drill bit aligns with the positioning rib on the Drill
Bit Holder. Ensure the drill bit is held securely in the Drill Bit Holder. Push the safety cover
aside and insert the Drill Bit Holder (with drill bit inserted) into the sharpener opening. Ensure
the “rib” on the Holder matches with the rib on the Guide. then remove the Drill Bit
Holder (with bit inserted) and turn it 180°, reinsert (this is to ensure symmetry while sharpening
the bit).
IMPORTANT: If you are sharpening a bit 10mm (3/8”) or larger, you must ensure the
cutting face of the drill bit aligns with the positioning rib on the Drill Bit Holder (Fig. 8)
13

GENERAL
WARNING: When servicing, use only identical replacement parts. Use of any other
replacement parts may create a hazard or cause product damage.
DO NOT use solvents when cleaning plastic parts. Most plastics are susceptible to damage from
various types of commercial solvents and may be damaged by their use. Use a clean cloth to
remove dirt, dust, oil, grease etc.
WARNING: Do not at any time allow brakefluids,gasoline, petroleum-based
products, penetrating oils, etc. to come in contact with plastic parts. They contain
chemicals that can damage, weaken, or destroy plastic.
DO NOT abuse power tools. Abusive practices can damage the tool as well as the
workpiece.
WARNING: DO NOT attempt to modify tools or create accessories not recommended.
Any such alteration or modification is misuse and could result in a hazardous condition
leading to possible serious injury. It will also void the warranty.
WARNING: Remove the plug from the socket before carrying out any adjustment,
service, or maintenance
Cleaning
1. Ensure dust collection boxes are emptied after each use.
Service
To change grind wheels, remove the screws from the tool as illustrated below.
IMPORTANT- GRINDING WHEELS MUST BE REPLACED WITH IDENTICAL GRINDING
WHEELS
Dust collection
boxes

15

When servicing, use only original equipment replacement parts
1
1281-112-001
Self-locking nut
1
2
1281-112-002
Washer
1
3
1281-112-003
Knife grinder A
2
4
1281-112-004
Knife grinder B
2
5
1281-112-005
Rubber/metal washer
1
6
1281-112-006
Graduated knob
1
7
1281-112-007
Screw
6
8
1281-112-008
Screw
1
9
1281-112-009
Screw
2
10
1281-112-010
Block
1
11
1281-112-011
Drill seat
1
12
1281-112-012
Drill button
1
13
1281-112-013
Holding clamp
2
14
1281-112-014
Shell-A
1
15
1281-112-015
Cover /screw plate
1
16
1281-112-016
Nameplate
1
17
1281-112-017
Shell-B
1
18
1281-112-018
Grinding drilling seat
1
19
1281-112-019
Motor assembly
1
20
1281-112-020
Toothed driven wheel
1
21
1281-112-021
Double ended shaft
1
22
1281-112-022
Toothed belt
1
23
1281-112-023
Circlip
1
24
1281-112-024
Bering clamps
2
25
1281-112-025
Motor pinion/cooling fan
1
26
1281-112-026
Axletree
2
27
1281-112-027
Motor fan hex nut
1
28
1281-112-028
Knife grinder-A
1
29
1281-112-029
Bit holder body
1
30
1281-112-001
Bit holding blades
6
The use of any other parts may create a safety hazard or cause damage to the
tool. Any attempt to repair or replace electrical parts on this tool may create a
safety hazard unless repairs are performed by a qualified technician.
For more information, call the Toll-free Helpline, at 1-866-349-8665.

31
1281-112 -031
Blades formed wire carrier
6
32
1281-112 -032
Blades seat
1
33
1281-112 -033
Bit holder cap
1
34
1281-112 -034
Cord
1
35
1281-112 -035
Washer
2
36
1281-112 -036
Hex nut
1
37
1281-112 -037
Switch
1
38
1281-112 -038
Base
1
39
1281-112 -039
Dampening pad
4
40
1281-112 -040
Dust boxes
2
41
1281-112 -041
Screw
4
42
1281-112 -042
Screw
1
43
1281-112 -043
Knob with spring
1
44
1281-112 -044
Grinding s e a t cover
1
45
1281-112 -045
Drill grinding assembly
1
46
1281-112 -046
Cord fixing
1
47
1281-112 -047
Sleeve
1
48
1281-112 -048
Screw
3
17

If this Radley Tool fails due to a defect in material or workmanship within three
years from the date of purchase, return it to any Home Hardware store with the
original bill of sale for exchange. Two years for battery and charger. This
warranty does not include expendable parts including but not limited to
blades, brushes, belts, and light bulbs.This warranty coves defects in material
or workmanship only. It does not cover normal wear and tear, failure due to
abuse/misuse, or defects caused by careless or accidental mishandling. If this
Radley product is used for commercial or rental purposes, this warranty does
not apply. For use at the consumer level. The warranty is not for industrial or
commercial applications.
15
18

OWNER’S MANUAL
3 Year Limited Warranty on tool
RADLEY TOOLS
1-866-349-8665
1282-201
READ ALL INSTRUCTIONS BEFORE FIRST USE.
KEEP THIS MANUAL FOR FUTURE REFERENCE.
KEEP AWAY FROM CHILDREN.
WEAR CSA APPROVED
EYE PROTECTION
WEAR EAR
PROTECTION
WEAR FACE
WEAR FACE
PROTECTION
WEAR FACE
