RADVision SCOPIA 100 User manual

SCOPIA100 Gateway Quick Start
Version 5.6

NOTICE
© 2000-2008 RADVISION Ltd. All intellectual property rights in this publication are owned
by RADVISION Ltd and are protected by United States copyright laws, other applicable
copyright laws and international treaty provisions. RADVISION Ltd retains all rights not
expressly granted.
This publication is RADVISION confidential. No part of this publication may be reproduced
in any form whatsoever or used to make any derivative work without prior written approval
by RADVISION Ltd.
No representation of warranties for fitness for any purpose other than what is specifically
mentioned in this guide is made either by RADVISION Ltd or its agents.
RADVISION Ltd reserves the right to revise this publication and make changes without
obligation to notify any person of such revisions or changes. RADVISION Ltd may make
improvements or changes in the product(s) and/or the program(s) described in this
documentation at any time.
If there is any software on removable media described in this publication, it is furnished
under a license agreement included with the product as a separate document. If you are
unable to locate a copy, please contact RADVISION Ltd and a copy will be provided to
you.
Unless otherwise indicated, RADVISION registered trademarks are registered in the
United States and other territories. All registered trademarks recognized.
For further information contact RADVISION or your local distributor or reseller.
SCOPIA Gateway version 5.6, June 2008
Publication 9
http://www.radvision.com
62782-00001 Rev A03

What’s in this Guide 1
Quick Start
WHAT’SIN THIS
GUIDE ThisQuickStart provides thebasic steps required for getting your
SCOPIA100 Gateway up and running:
The suggested order of operation is as follows:
1. Unpack and Verify the Equipment
2. Prepare a Checklist
3. Prepare the Site
4. Mount the SCOPIA100 Gateway Unit in a 19" Rack
(Optional)
5. Assign an IP Address to the Gateway
6. Connect to the IP Network
7. Connect to the ISDN Network (PRI and BRI
Gateways only)
8. Connect to the Serial Interface (Serial Gateways
only)
9. Configure the Gateway
10. Make Trial Calls
Note For more detailed information, see the SCOPIA100
Gateway User Guide.
UNPACK AND
VERIFY THE
EQUIPMENT
The shipping box for a single SCOPIA100 Gateway unit includes
the following items:
SCOPIA100 Gateway unit
Power cable (depending on customer location)
Terminal cable
LAN cable
Rack mounting kit (two brackets and six screws)
Four rubber feet
SCOPIA100 Gateway User Guide (in PDF format only)

2 SCOPIA 100 Gateway Quick Start
SCOPIA100 Gateway Quick Start
SCOPIA Gateway Release Notes
Utilities and Documentation CD-ROM containing
product documentation, utilities and online help files.
PREPARE A
CHECKLIST Before you start configuration, fill in the checklist below.
ISDN NETWORK
DIRECTORY
NUMBERS (PRI AND
BRI GATEWAYS
ONLY)
PRI/BRI Service Provider
Service Provider: ______________________
Type of service: ______________________
PRI/BRI Directory Numbers
How many Directory Numbers are there? ________
Directory number range: _______-_______. For consecutive
directory numbers, fill in the digits that indicate the range.

Prepare a Checklist 3
ISDN NETWORK
PHYSICAL
INTERFACE (PRI
GATEWAYS ONLY)
Channel Rate
Carrier/Switch Signaling Protocol
Network Access
PRI E1 56 Kbps 64 Kbps
Port 1 T1 56 Kbps 64 Kbps
PRI E1 56 Kbps 64 Kbps
Port 2 T1 56 Kbps 64 Kbps
PRI E1 Euro ISDN VN6 5ESS
Port 1 T1 DMS100 Nat ISDN 5ESS
4ESS NTT Euro ISDN
Hong Kong
PRI E1 Euro ISDN VN6 5ESS
Port 2 T1 DMS100 Nat ISDN 5ESS
4ESS NTT Euro ISDN
Hong Kong
PRI Port 1 TE NT
PRI Port 2 TE NT

4 SCOPIA 100 Gateway Quick Start
Line Coding
Line Framing
PRI E1 AMI CMI HDB3
Port 1 NRZ
T1 B8ZS AMI-B7 NRZ
PRI E1 AMI CMI HDB3
Port 2 NRZ
T1 B8ZS AMI-B7 NRZ
PRI E1 CRC4 Double framing
Port 1 Extended CRC4
T1 ESF no CRC ESF F4
ESF CRC6 JT F12 F72
PRI E1 CRC4 Double framing
Port 2 Extended CRC4
T1 ESF no CRC ESF F4
ESF CRC6 JT F12 F72

Prepare a Checklist 5
ISDN NETWORK
PHYSICAL
INTERFACE (BRI
GATEWAYS ONLY)
Carrier/Switch Signaling Protocol
BRI DMS100 Nat ISDN 5ESS
Port 1 5ESS PTP ETSI ETSI PTP
VN6 Austel 1 KDD
NTT Hong Kong
BRI DMS100 Nat ISDN 5ESS
Port 2 5ESS PTP ETSI ETSI PTP
VN6 Austel 1 KDD
NTT Hong Kong
BRI DMS100 Nat ISDN 5ESS
Port 3 5ESS PTP ETSI ETSI PTP
VN6 Austel 1 KDD
NTT Hong Kong
BRI DMS100 Nat ISDN 5ESS
Port 4 5ESS PTP ETSI ETSI PTP
VN6 Austel 1 KDD
NTT Hong Kong

6 SCOPIA 100 Gateway Quick Start
SERIAL PORT
PHYSICAL
INTERFACE (SERIAL
GATEWAYS ONLY)
DTE/DCE Interface Configuration Options
IP NETWORK
CHECKLIST Network Addressing
Gateway IP address _ _ _ . _ _ _ . _ _ _ . _ _ _
IP Mask (subnet mask) _ _ _ . _ _ _ . _ _ _ . _ _ _
Gatekeeper IP address _ _ _ . _ _ _ . _ _ _ . _ _ _
Default router IP address _ _ _ . _ _ _ . _ _ _ . _ _ _
AUDIO PROTOCOLS Preferred Audio Transcoding Priority
Disable
G.711 (ISDN/serial) < > G.723.1 (IP)
G.728 (ISDN/serial) < > G.711 (IP)
G.728 (ISDN/serial) < > G.711 (IP) for up to 256 Kbps
PREPARE THE
SITE When installing the Gateway, ensure that:
An IP network port is available on the hub for the
Gateway.
There is a gatekeeper available to register the Gateway
IP address and services.
Interface Terminal Adaptor Options Signaling Protocol Options
DTE Common RS-366
Manual Control
Data Triggered
KG-Device RS-366
Manual Control
Data Triggered
DCE Common RS-366

Mount the SCOPIA100 Gateway Unit in a 19" Rack (Optional) 7
MOUNT THE
SCOPIA100
GATEWAY UNIT IN
A19" RACK
(OPTIONAL)
You can optionally mount the SCOPIA100 Gateway unit in a
standard 19-inch rack. Two mounting brackets and a set of
screws are included in the SCOPIA100 Gateway unit shipping
box.
 Procedure
1. Disconnect all cables including the power cables.
2. Place the SCOPIA100 Gateway unit right-side up
on a hard flat surface, with the front panel facing
you.
3. Position a mounting bracket over the mounting
holes on each side of the SCOPIA100 Gateway
unit.
Figure 1 Fitting a Bracket for Rack
Mounting
4. Pass the screws through the brackets and tighten
them into the screw holes on each side of the
SCOPIA100 Gateway unit using a suitable
screwdriver.

8 SCOPIA 100 Gateway Quick Start
5. Insert the SCOPIA100 Gateway unit into the 19-
inch rack.
6. Fasten the brackets to the side rails of the rack.
7. Make sure that the air vents at the sides of the
SCOPIA100 Gateway unit are not blocked.
ASSIGN AN IP
ADDRESS TO THE
GATEWAY
The first time you install the Gateway, you assign an IP address
using a terminal cable connection. This allows you to access the
boot configuration menu of the Gateway. At power-up, the
Gateway goes through the following boot phases:
Auto-boot—The embedded operating system initializes
and displays basic information.
Configuration menu—A six-second countdown allows
you to enter the configuration menu.
Initialization—The Gateway completes its boot
sequence and is ready for operation.
Note You can only perform serial port configuration of the
Gateway at startup, during a short period indicated by a
six-second countdown. Once the initialization phase is
complete, the only way you can enter the configuration menu is
by restarting the Gateway.

Assign an IP Address to the Gateway 9
CONNECT TO APC You make the serial connection by connecting a PC terminal
equipped with a terminal emulation application to the front panel
serial port of the Gateway.
 Procedure
1. Run a terminal emulation application (such as
HyperTerminal) on the PC.
2. Configure the communication settings for the PC
serial port as follows:
9600 Baud rate
8 data bits
1 stop bit
No parity
No flow control
3. Connect a terminal cable to the PC terminal.
Usethesuppliedterminal cabletoconnecttheother end
to the Gateway serial port on the front panel.
4. Start the terminal emulation application on the PC.
5. Turn on or reset the Gateway.
6. The following command prompt displays:
Press any Key To start configuration...

10 SCOPIA 100 Gateway Quick Start
7. Press any key during the six-second countdown to
enter the configuration menu.
The network configuration Main menu displays as
shown at Figure 2. If you do not press a key before the
countdownends, the Gatewaycontinuesits initialization
andyou can only configure the Gateway by pressing the
Reset button on the front panel.
Figure 2 Network Configuration Main
Menu
Warning Configuration of any of the parameters other than
<N> should not be performed by an unauthorized person.
Press any Key To start
configuration...
Main menu
Enter <N> to configure default
network port values
Enter <P> to change the
configuration software password
Enter <A> to display advanced
configuration menu
Enter <Q> to quit configuration
menu and start GW

Assign an IP Address to the Gateway 11
CONFIGURING AN IP
ADDRESS
 Procedure
1. At the colon type N.
The Default Network Port Values screen (Figure 3)
displays.
Figure 3 Default Network Port Values
Screen
2. Type the IP address, default router IP address and
IP subnet mask as shown in Figure 3. Press Enter
to proceed from one parameter to the next.
3. Press Enter to finalize the new settings. The
Gateway returns to the network configuration Main
menu displayed at Figure 2.
4. At the colon type Q to quit the network
configuration Main menu and start the Gateway. If
you have changed any of the settings in the
network configuration Main menu (IP address,
default router IP address or IP subnet mask) typing
Q resets the Gateway with the new settings.
Enter IP Address for Interface No. 1
Without leading zeros <
172.27.20.194>:
Enter Default Router IP Address
Without leading zeros < 172.27.37.254>:
Enter IP Mask
Without leading zeros < 172.27.37.254>:
Updating NVRAM
Updating BOOT LINE PARAMS with new IP

12 SCOPIA 100 Gateway Quick Start
CONNECT TO THE
IP NETWORK Use the supplied LAN cable to connect the Ethernet IP network port on the front panel of the Gateway to a 10/100Base-T IP
network connection on your network hub.
CONNECT TO THE
ISDN NETWORK
(PRI AND BRI
GATEWAYS ONLY)
Use the appropriate cables to connect the PRI/BRI ISDN ports to
your PBX or direct PRI/BRI line connection.
CONNECT TO THE
SERIAL
INTERFACE
(SERIAL
GATEWAYS ONLY)
Line cables are attached to the Gateway via a DB-60 connector
that provides the serial line connection for the Gateway serial
ports.ThecablesareY-type withsplit leadsat theremote end.On
one side is either a V.35, RS-449 or EIA-530 connector. On the
other side is an RS-366 connector.
Gateway terminal adapter cables have either a DTE or a DCE
interface.
The Gateway can identify which type of cable has been
connected to its DB-60 serial ports. Cable configuration settings
are automatically displayed in the Physical Interface section of
the Port tabs. The automatically configured settings are shown in
DTE/DCE Interface Configuration Options on page 6.
Note If the Physical Interface section of the Port tabs is
displayed while you are connecting a cable to the Gateway, exit
the screen and then return to see the displayed cable
configuration settings.
CONFIGURE THE
GATEWAY Once you have assigned an IP address to the Gateway, you can use the web interface to configure and monitor the Gateway.
 Procedure
1. In your web browser, enter the IP address or
device name of the Gateway.
For example: http://125.221.23.44
Press Enter to display the Login screen.

Configure the Gateway 13
2. Enter your user name and password and click OK
to proceed to the configuration page. The default
user name is admin and the default password is
null.
The configuration interface displays.
CHECK THE
NETWORKADDRESS
SETTINGS
Use the web interface to check that the network addresses you
set in the previous step were properly recorded by the Gateway.
 Procedure
1. In the sidebar, click the Device button to display
the Device configuration tabs.
2. Check the settings in the Addressing tab to
ensure that the network addressing parameters
you entered earlier (see Procedure on page 11)
were properly recorded in the Gateway.
SET THE
GATEKEEPER
ADDRESS
Before you can work with the Gateway, you must set a
gatekeeper IP address with which the Gateway registers.
1. In the Gatekeeper section of the Gateway
interface Settings tab, enter the gatekeeper IP
address in the Gatekeeper Address field.
2. Click Upload in the toolbar and wait for the
Gateway to reset itself.
3. Log out by clicking the Logout button in the
sidebar.
Note To review the settings, log in to the Gateway web
interface again.

14 SCOPIA 100 Gateway Quick Start
SET GATEWAY
SERVICES The Gateway is pre-programmed with a number of default
service prefixes used in outgoing calls. You can modify the
existing prefixes to suit your network environment or define new
services and add them to the list.
Before setting a Gateway service, consider the following:
Ensure that the service prefix numbers are not identical
to the first digits of any of your IP network endpoint
phone numbers or aliases.
Note that changing a service prefix or adding a new
service may require resetting the Gateway.
 Procedure
1. In the Gateway interface Services tab, click Add
to add a new service, or select a service and click
Edit to modify that service.
2. Type in the prefix number for this service, select
the call type, bit rate, and ISDN ports for this
service. Click Upload to send the new parameters
to the Gateway.
SET GATEWAY
PORT PARAMETERS PRI Ports
Configure your Gateway PRI port. If your Gateway supports two
PRI ports, configure a single port first. When the first port is
configured, you can use the Same as Port checkbox to duplicate
settings from one PRI port to the other.
 Procedure
1. In the Gateway interface PRI Port tabs Basics
section, enable the port and define the phone
numbers for this port.
2. In the Physical Interface, Advanced ISDN, Call
Policies and Supported Services sections,
define the settings you want for this port. Follow
your checklist to help organize the settings.

Configure the Gateway 15
3. If your Gateway supports two PRI ports, enable the
second PRI port and define the phone numbers
used for that port.
4. Check the Same as Port checkbox to duplicate
the settings from the first PRI port in each of the
remaining sections: Physical Interface,
Advanced ISDN, Call Policies and Supported
Services.
BRI Ports
Configure your Gateway BRI port. When the first port is
configured, you can use the Same as Port checkbox to
duplicate settings from one BRI port to the other.
 Procedure
1. In the Gateway interface BRI Port tabs Basics
section, enable the port and define the phone
numbers for this port.
2. In the Physical Interface, Call Policies and
Supported Services sections, define the settings
you want for this port. Follow your checklist to help
organize the settings.
3. Check the Same as Port checkbox to duplicate
the settings from the first BRI port in each of the
remaining sections: Physical Interface, Call
Policies and Supported Services.
Serial Ports
Configure your Gateway serial ports. When the first port is
configured, you can use the Same as Port checkbox to duplicate
settings from one serial port to the other.

16 SCOPIA 100 Gateway Quick Start
 Procedure
1. In the Gateway interface Port tabs Basics
section, enable the required port.
2. In the Physical Interface, Call Policies and
Supported Services sections, define the settings
you want for this port. Follow your checklist to help
organize the settings.
3. Enable additional ports as required.
4. Check the Same as Port checkbox in the
Physical Interface section to duplicate the
settings from the first serial port in each of the
remaining sections: Physical Interface, Call
Policies and Supported Services.
SAVE THE
CONFIGURATION The Export button on the toolbar allows you to save the Gateway
configuration parameters as an *.ini file to your local hard disk or
to any network directory that you choose.
 Procedure
1. In the toolbar, click Export to display the Windows
File Download dialog box.
2. Check the Save this file to disk option. Click OK
to display the Windows Save As dialog box.
3. In the File name text box, type a file name for this
configuration setup.
For example, GW1_NEW
4. Select a location to save the file to and click Save.
MAKE TRIAL
CALLS As a final step, make a few trial calls following the dialing sequences described in this section.
Calls are made between the IP network and the ISDN network.
The ISDN network is connected directly to the PRI Gateway or to
an Imux that gives the Serial Gateway access to the ISDN
network.

Make Trial Calls 17
When acallisconnected, the front panel ACT LEDlightsup.If you
are not able to complete the trial calls, refer to the
Troubleshooting chapter in the SCOPIA100 Gateway User Guide.
Dialing Example 1 Voice calls (PRI and BRI Gateways only)
From an IP phone on the IP network, dial the Gateway service
prefix for voice calls and the destination phone number.
912015294300
9is the Gateway service prefix for voice calls.
12015294300 isthedestinationphonenumberincluding
the area code.
Dialing Example 2 2B video calls (PRI and BRI Gateways only)
A 2B video call from an IP network terminal to an H.323 endpoint
on another IP network or to a terminal on the ISDN network. Both
B channels have the same number.
821816455318*
82 is the service prefix for a 2B video call.
1816455318 is the destination phone number including
the area code.
*is the second number delimiter. The second number
delimiter tells the Gateway to dial the destination phone
number a second time.
Dialing Example 3 2B video calls (PRI and BRI Gateways only)
A 2B video call from an IP network terminal to an H.323 endpoint
on another IP network or to a terminal on the ISDN network. The
B channels have different numbers (or your endpoint does not
have two phone number fields).
821816455318*1816455319
82 is the service prefix for a 2B video call.
1816455318 is the destination phone number including
the area code.

18 SCOPIA 100 Gateway Quick Start
*is the second number delimiter.
1816455319 is the second B channel number including
the area code.
Dialing Example 4 384 Kbps bonded call
From a videoconferencing endpoint on the IP network, dial the
Gateway prefix for 384 Kbps bonded calls and the phone number
of the destination Gateway or H.320 room system.
86745501
86 is the Gateway service prefix for 384 Kbps bonded
calls
86745501 is the phone number of the destination
terminal.
