Raidon iT4300 Series User manual

前視圖
背視圖
SATA 15Pin 電源輸入埠
V1.2 (Jun 2017)
打開包裝外盒後，包裝內容應包含下列組件 :
請先確認相關配件與產品本身是否有受損或是缺少配件，若有任何疑問，請與您的經銷商或業務人員
聯絡。
請參照下列步驟，完成iT4300系列的硬體安裝 :
硬碟讀寫燈
SAS 連接埠
產品示意圖與配件表
燈號說明
硬體安裝
產品使用注意事項
FAN
Power 1
Power 2
SAS 6G
FAN
Power 1
Power 2
SAS 12G
硬碟托盤手把 硬碟卡榫按鍵
風扇
風扇連接埠 SATA 15Pin 電源輸入埠 風扇連接埠
風扇 SAS 連接埠
iT4300-U6
1. 若想得到較佳的使用效能與選購硬碟的便利性，建議使用規格及廠牌相同的2.5吋硬碟。
2. 請確保使用的硬碟是不含壞軌的，以避免當其中一顆硬碟發生故障時，可能導致系統當機或所有資
料遺失。
3. iT4300 系列允許裝載使用 SAS 或 SATA 硬碟下，還是建議您先確認您所使用的 mini-SAS 擴充卡
是否有向下兼容 SATA 硬碟； 另外，其系統處理效能表現將依 mini-SAS 或 SATA 硬碟而異。
4. 當您需要關閉或移除 iT4300 系列時，務必透過您所操作的作業系統中執行硬碟安全移除後，方可
進行電源關閉的動作。
5. 當系統運作時，請勿任意移除任何一顆硬碟，以免導致資料遺失。
6. 強烈建議除了使用 iT4300 系列的資料儲存功能外，請針對重要資料備份到另一 個儲存裝置上或遠
端備份，雙重備份您重要的資料。若您儲存在 iT4300 系列的資料損毀或遺失，RADION 將不負任
何的責任。
Unlock
Lock
1. 解開硬碟托盤鎖。 2. 按下硬碟卡榫按鍵。
3. 抽出硬碟托盤組。 4. 將 2.5 吋硬碟安裝在硬碟托盤上。
5. 鎖上附件包內的螺絲。 6. 將硬碟托盤安裝回 iT4300 系列產品。
8. 硬體安裝完成。一旦開啟電腦，您的作業系統會自動辨識所裝置好的硬碟。如果您的硬碟是
必須被格式化的，請依照電腦的作業系統進行硬碟格式化步驟。當完成硬碟格式化後，硬碟
便可以進行資料讀寫。
7. 將主體安裝於電腦機殼
上的CD-ROM位置，請
使用配件零件包的螺絲
固定，並連接產品所附
的連接線。
硬碟閒置
資料存取
無硬碟
風扇故障
溫度過高(≧50°C)
恆亮
恆亮
─ ─
─ ─
─ ─
藍色LED
熄滅
閃爍
─ ─
─ ─
─ ─
─ ─
─ ─
─ ─
鳴叫
鳴叫
黃色LED 蜂鳴器
使用SATA硬碟時 (iT4300-U5/U6/S3)
硬碟閒置
資料存取
無硬碟
風扇故障
溫度過高(≧50°C)
恆亮
恆亮
─ ─
─ ─
─ ─
藍色LED
恆亮/熄滅 (註)
閃爍
─ ─
─ ─
─ ─
─ ─
─ ─
─ ─
鳴叫
鳴叫
黃色LED 蜂鳴器
使用SAS硬碟時 (iT4300-U5/U6)
註：依據使用的SAS擴充卡會有不同的燈號狀態。
iT4300-U5/S3
（iT4300-S3不支援SAS硬碟）
iT4300 系列主體 x1 Mini SAS 內接 6G TO
4 Port SATA 連接線
(for iT4300-S3) x1
Mini SAS 6G 內對內連接線
(for iT4300-U5) x1
Mini SAS 12G 內對內連接線
(for iT4300-U6) x1
產品配件表
快速安裝導引 x1 零件包 x3 鑰匙 x2
iT4300
iT4300
Mini SAS
內接 6G TO
4 Port SATA
連接線
SAS
連接線
SATA
連接埠
SAS卡
請確實將電源線
插進正確的位置
注意事項:

FAN
Power 1
Power 2
SAS 6G
FAN
Power 1
Power 2
SAS 12G
Front View
Rear View
15-pin Power Connector
After you open the outer package, make sure that the following items are contained in the package:
Please make sure that you do not have any damaged or in short parts. For any question, please
contact to local distributor or retailer for further assistance.
Please follow the instructions below to complete the iT4300 series installation.
HDD Access Indicator
SAS Connector
LED Instruction
Hardware Installation
Precautions Before Application
HDD Tray Handle HDD Tray Key Lock
And Tray Open Button
Cooling Fan
3-pin Fan
Connector
15-pin Power Connector
3-pin Fan
Connector
Cooling Fan SAS Connector
iT4300-U6
1. The product allows the user to simultaneously utilize two hard drives manufactured by different
companies. However, if the user expects better efficiency, we strongly recommend the users to use
hard drives manufactured by the same manufacturer.
2. Please ensure that the hard drives are free of bad tracks before using, otherwise, it may cause
system crash in turn resulting in data loss.
3. Although iT4300 Series allows you to install either SAS or SATA drives, it is recommended to check
the whether mini-SAS host adapter you´re using is downward compatible with SATA drives. Also
note that the throughput performance may vary if SAS and SATA drive are installed.
4. Whenever turning off or unplugging the iT4300 Series from your computer system becomes
necessary, always remember to safely remove it from your operating system first.
5. When the iT4300 Series is connected to the computer system, it’s prohibited to remove, insert or
swap the harddrive while data transfer is being performed.
6. It is highly recommended for users to back up important data contained within the drives of the iT4300
Series on a regular basis or whenever the user feels necessary to a remote or a separate storage
device. RAIDON will not be responsible for any lost of data caused during the use of the iT4300
Series or the recovery of the data lost.
Unlock
Lock
1. Unlock the hard drive tray lock. 2. Press down the button for hard drive clamp.
3. Pull out the hard drive tray kit. 4. Install a 2.5” hard drive on the hard drive tray.
5. Secure screws from the screw kit in 4 positions. 6. Refit the hard drive tray into the iT4300 series.
7. Install device into one
of the CD-ROM bays
with screws from the
accessory kit. Then
properly connect
SATA/SAS cable and
DC cable from your
system to the device.
Product Diagrams and Contents of Product Package
iT4300 Series Quick Installation Guide
8. Power on your system after hardware installation is completed, and your operating
system will automatically detect the hard drives from booting. Then follow the steps
from your operating system to partition and format the drives when necessary,
device will be ready to use once the format is completed.
HDD Idle
HDD Access
NO HDD
Fan Failure
(Stop Rotating)
Overheat (≥50℃)
Light On
Light On
─ ─
─ ─
─ ─
Blue LED
Light Off
Blinking
─ ─
─ ─
─ ─
─ ─
─ ─
─ ─
On
On
Yellow LED Buzzer
When Using SATA Hard Drives (iT4300-U5/U6/S3)
HDD Idle
HDD Access
NO HDD
Fan Failure
(Stop Rotating)
Overheat (≥50℃)
Light On
Light On
─ ─
─ ─
─ ─
Blue LED
Light On/Light Off (Note)
Blinking
─ ─
─ ─
─ ─
─ ─
─ ─
─ ─
On
On
Yellow LED Buzzer
When Using SAS Hard Drives (iT4300-U5/U6)
Note ：While using a different SAS Interface Adapter, the LED
Indication might be with a different light set.
V1.2 (Jun 2017)
iT4300
iT4300
Mini SAS
Internal 6G
TO 4 Port
SATA Cable
SAS
Cable
SATA
Port
SAS Card
Power
Supply
Motherboard
iT4300 Series Device x1 Mini SAS Internal 6G TO
4 Port SATA Cable
(for iT4300-S3) x1
Mini SAS 6G Internal Cable
(for iT4300-U5) x1
Mini SAS 12G Internal Cable
(for iT4300-U6) x1
Contents of Product Package
Quick Installation
Guide x1
Accessory
Kit x3
Key x2
iT4300-U5/S3
（iT4300-S3 dosen’t support SAS hard drives）
Please make sure
your power cable
is well connected.
Warning:
