RAMSET D45A TOOL
OPERATOR’S
SAFETY & OPERATING
INSTRUCTION MANUAL
DANGER
THIS TOOL FOR USE BY LICENSED OPERATORS ONLY.
READ AND OBEY ALL SAFETY AND OPERATING
INSTRUCTIONS BEFORE OPERATING TOOL.
SEMI-AUTOMATIC, LOW VELOCITY
PISTON TYPE FASTENING TOOL

Just as no one can merely read a book about driving an automobile and then hope
to drive one safely, no one should attempt to use any Ramset tool without adequate,
one must also be licensed to use apowder actuated tool. No automobile instruction
book or instructor can forewarn a learner against all possibilities and emergencies,
nor can Ramset instructors and printed material detail all possible conditions
surrounding the use of Ramset tools and products.
Responsibility for the safe and proper use of this tool rests with the tool user
and the employer.
SAFETY INTRODUCTION DANGER
SAFETY INTRODUCTION DANGER
2
Operator’s and bystanders
must wear eye and hearing
protection.
Never close tool with hand over fastener loading end of the tool.
A serious hand injury from penetration by the piston or a
discharged fastener could result.
Read manual before
operating tool.
DANGER
THIS TOOL IS TO BE USED ONLY BY PROPERLY TRAINED
AND LICENSED OPERATORS.
YOU MUST SUCCESSFULLY COMPLETE THE
RAMSET’S TRAINING PROGRAM FOR THE
TOOL AND OBTAIN A CERTIFIED OPERATOR’S LICENSE
BEFORE HANDLING, LOADING OR OPERATING THIS TOOL.
ATTEMPTING TO HANDLE OR OPERATE THIS TOOL
WITHOUT PROPER TRAINING AND LICENSING CAN RESULT IN
SERIOUS INJURY TO THE OPERATOR OR BYSTANDERS.
DANGER

Preparation
Acceptable Base Materials
Powder actuated fastening is suitable for
use in the following base materials only:
• Poured Concrete
• Structural Steel
• Masonry Joints (see page 8)
Never attempt to fasten into any other
type of material. Fastening into other
materials can cause blindness or other
serious injury.
Unacceptable Base Materials
Never attempt to fasten into very hard or
brittle materials such as cast iron, tile,
glass, or rock of any type. These materials
can shatter, causing the fastener and/or
base material fragments to fly free and cause
serious injury to the tool operator and others.
Never fasten into soft base materials, such as
drywall or lumber products. These materials
may allow the fastener to travel completely
through and out the other side, endangering
those in the path of the fastener.
Never fasten into any base material that
does not pass the Center Punch test.
Failure to assure the suitability of the base
material can result in serious injury to the
eyes or other body parts.
Center Punch Test
ALWAYS WEAR SAFETY GOGGLES
WHEN PERFORMING THIS TEST.
1. Always check the material being
fastened into for hardness before
attempting any fastening operation.
2. Using a fastener as a center punch,
strike the fastener against the work
surface using an average hammer
blow and check the results.
Center Punch Test Results
1. If the fastener point is flattened,
the material is too hard for a
powder actuated fastening.
2. If the fastener penetrates the
material easily, the material is
too soft.
3. If the material cracks or shatters,
the material is too brittle.
4. If the fastener makes a small
indentation into the material, the
material is suitable for fastening.
DANGER SAFETY INSTRUCTIONS
SAFETY INSTRUCTIONS
DANGER 3
NEVER FASTEN INTO VERY HARD OR
BRITTLE MATERIALS
NEVER FASTEN INTO SOFT MATERIALS
SUCH AS DRYWALL

Loads & Load Selection Safety
1. Always make a test fastening after
being sure that the base material
is suitable for powder actuated
fastening. Failure to determine the
correct power level to be used may
result in the use of excessive power,
allowing the fastener to pass completely
through the work material, causing
serious or fatal injuries to others who
may be in the path of the fastener.
2. Color-blind operators must always
select disc loads by number to
prevent use of an incorrect load for
the same reasons as in #1 above.
Workplace Safety
1. Operators and bystanders must
always wear approved eye protection
and approved hearing protection.
Failure to do so may result in blindness
or serious eye injury from flying debris
and loss of hearing from constant or
repeated unprotected exposure to
fastening noise.
2. Always keep the work area clear of
bystanders and unnecessary materials
that could interfere with safe tool
operation. Operating the tool in a
congested or cluttered area may affect
your ability to operate the tool safely.
3. Never operate tool if flammable
or explosive materials are nearby.
Powder loads burn and create sparks
when fired and could ignite these
materials or fumes.
4. Always post warning signs within
50 ft. of the area where fastening
is to be done. Sign must state:
“WARNING - Powder Actuated
Tool In Use”. Failure to warn others
may result in serious injury to them.
Contact Ramset at 1-800-241-5640
to obtain this sign.
SAFETY INSTRUCTIONS DANGER
SAFETY INSTRUCTIONS DANGER
4
ALWAYS MAKE A TEST FASTENING
COLOR-BLIND OPERATORS MUST
ALWAYS SELECT LOADS BY NUMBER
KEEP WORK AREA CLEAR OF
BYSTANDERS AND CLUTTER
NEVER OPERATE THE TOOL AROUND
FLAMMABLE OR EXPLOSIVE MATERIALS
WARNING
POWDER
ACTUATED
TOOL IN USE
WITHIN 50 FEET
Safety is important – Take proper precautions.
ALWAYS POST WARNING SIGNS

Tool Handling Safety
1. Always be sure tool is operating
properly before attempting to use
it. Follow the “Daily Function Test”
shown to the right and described
on page 9.
2. Always load tool using a disc load
selected directly from a box indicating
the power load type and number.
Never attempt to use loose disc
loads that could be mis-identified.
3. Never carry loose disc loads in pockets
with pins or other hard objects.
4. Never load a tool unless you intend
to immediately make a fastening.
Loading a tool and leaving it unattended in
the work area can result in the tool being
accidentally discharged by others.
5. Never place your hand or any other
body part over the fastener loading
end of the tool. Serious hand injury
could result from being struck by either
a fastener or the tool piston should the
tool be accidentally fired.
6. Always store the tool unloaded and
keep the tool and the loads securely
locked in a tool box. Keep keys away
f rom children and unlicensed persons.
7. Always keep the tool pointed away
from yourself and others.
8. Never carry a loaded tool around
the work area.
9. Never allow anyone not trained
to use the tool.
10. Never engage in horseplay with
the tool.
11. Using the tool in poorly ventilated
areas, cleaning tool or handling
loads may result in exposure to lead
or other substances known to cause
birth defects, and other physical
harm. Have adequate ventilation at
all times and wash thoroughly after
exposure.
DANGER SAFETY INSTRUCTIONS
SAFETY INSTRUCTIONS
DANGER 5
NEVER LOAD THE TOOL UNLESS IT IS
TO BE USED IMMEDIATELY
NEVER PLACE HANDS OR BODY OVER
MUZZLE OPENING
KEEP TOOL LOCKED & OUT OF THE
REACH OF CHILDREN
ALWAYS DO A DAILY FUNCTION TEST
BEFORE LOADING TOOL
B
D

FAILURE TO FOLLOW
INSTRUCTIONS CAN
CAUSE INJURY TO THE
TOOL OPERATOR OR
TO BYSTANDERS.
Fastener Driving Safety
1. Only use the tool for fastening into
a suitable base material.
2. Never fire the tool without a fastener.
Firing a tool without a fastener will
cause the piston to strike the work
surface, and may cause serious injury
to you and others in the work area.
3. Always use the spall guard whenever
possible to minimize flying particles
or debris.
4. Always hold the tool perpendicular
to and firmly against the work surface
when making a fastening. Failure to do
so could allow a fastener to ricochet.
5. Never attempt to drive a fastener
close to an edge or to another
fastener. See page 8 for guidelines.
ALWAYS FOLLOW THE
MISFIRE PROCEDURE.
If the tool does not fire after pulling the
trigger, continue to hold the depressed
tool against the work surface for at least
30 seconds. Then carefully open the tool,
remove the load disc, and put it in a can of
water or other non-flammable liquid. Never
carelessly discard a disc with live loads
into a trash container.
If the tool becomes stuck or jammed with
a live powder load, keep the tool pointed
in a safe direction, and immediately tag it,
“Danger- defective - do not use”. Lock
the tool in a tool box and call your local
Ramset distributor for assistance.
SAFETY INSTRUCTIONS DANGER
SAFETY INSTRUCTIONS DANGER
6
USE THE SPALL GUARD
WHENEVER POSSIBLE
ALWAYS HOLD THE TOOL
PERPENDICULAR TO THE
WORK SURFACE
NEVER DRIVE A FASTENER CLOSE TO
AN EDGE
HOLD THE TOOL FIRMLY AGAINST
THE WORK SURFACE FOR AT
LEAST 30 SECONDS
SPALL GUARD
90°

Your Ramset D45A Tool uses only the Ramset fasteners and loads shown below or
listed for the tool in the Product Catalog.
FASTENERS
FASTENERS / LOADS
FASTENERS / LOADS
7
Never use any other types of fasteners or disc loads in the Ramset D45A Tool. Use of other
types of fasteners or loads may cause unintentional load discharge, damage the tool, cause
poor fastening performance, or create a risk of serious injury to the operator or bystanders.
DANGER
LOADS
Ramset D60/45 disc loads are specially made for use in the Ramset D45A Tool.
The power level of the load is indicated by
the number marked on each box, the color
of the box, and the color on the tip of each
load. As the number increases, the power
level also increases.
Always perform the center punch test
described on page 3 to test the base material.
Always make a test fastening using the
lowest power level first. If more power is
required to set the fastener, use the next
higher power level until the powder level
necessary to drive the fastener is reached.
D60/45
DISC LOAD
POWER CATALOG LOAD CASE
LEVEL NUMBER COLOR COLOR
2 2D60 Brown Brass
3 3D60 Green Brass
4 4D60 Yellow Brass
5 5D45 Red Brass
.300 HEAD PLASTIC FLUTED DRIVE PINS
.145 Shank Diameter in Shank Lengths from
1/2” to 2”
.300 HEAD PLASTIC FLUTED DRIVE PINS
WITH 7/8” WASHER
.145 Shank Diameter in Shank Lengths from
1” to 2-1/2”
.300 HEAD POWER POINT
PLASTIC FLUTED DRIVE PINS
.150 Straight Shank in Shank Lengths
from 1/2” to 7/8”
.150 /.180 Step Shank in Lengths
from 1” to 1-7/8”
CEILING CLIP ASSEMBLIES
Ceiling Clip with 1” or 1-1/4” premounted
.145 Shank Pin and Ceiling Clip with 7/8” or
1-1/4” Premounted .150/.180 Shank Pin
1/4” - 20 THREADED STUDS
.145 Shank Diameter in Shank Lengths of 1/2”
and 1” and Thread Lengths of 1/2”, 3/4” and 1”
8 mm HEAD TOP-HAT DRIVE PINS
.145 Shank Diameter in Shank Lengths from
1/2” to 1”
CONDUIT CLIP ASSEMBLIES
For 1/2” and 3/4” Diameter Conduit with 7/8”
Premounted Power Point Fastener

FASTENING APPLICATIONS
Your Ramset tool can be used for a wide range
of fastening needs in a variety of base materials.
Reading and following these important fastening
guidelines will help you get the best results
from your tool, fasteners, and powder loads,
as well as help you perform these fastening
operations safely and effectively.
Powder actuated fastenings are permanent
fastening so attempting to remove a fastener
from concrete or steel may result in serious
injury.
Fastening to Concrete
When fastening into concrete, always maintain
a minimum spacing of 3” between fastenings
and 3” from any free edge. Concrete thickness
should be at least three times the intended
penetration depth into the concrete. The
primary exception to the 3” edge distance
can occur in a sill plate application where,
by necessity, the edge distance is reduced.
Driving fasteners too close to an edge or too
close to each other can cause the concrete
edge to fail or fasteners to fly free.
Fastening to Concrete Block or
to Masonry Walls
While this application is not recommended,
when used, it is necessary to take care to
observe a 3” edge distance to avoid cracking
the block and over penetration of the
fastener to avoid loss of holding value.
Fastening may be made into the horizontal
joint but not into the vertical joint.
Fastening to Steel
Your Ramset tool can be used for fastening
on the flat surfaces of structural steel. When
fastening into steel, always maintain a mini-
mum spacing of 1-1/2” between fastenings
and 1/2” from any edge.
FASTENING APPLICATIONS
FASTENING APPLICATIONS
8
3"
MIN.
3"
MIN.
3" MIN.
3" MIN.
1/2"
MIN.
1-1/2"
MIN.
SPACING WOOD TO CONCRETE
3"
MIN.
3"
MIN.
3" MIN.
3" MIN.
1/2"
MIN.
1-1/2"
MIN.
PENETRATION — THIN GAUGE
METAL TO CONCRETE
3"
MIN.
3"
MIN.
3" MIN.
3" MIN.
1/2"
MIN.
1-1/2"
MIN.
SPACING — FURRING
STRIP TO CONCRETE
3"
MIN.
3"
MIN.
3" MIN.
3" MIN.
1/2"
MIN.
1-1/2"
MIN.
SPACING — STEEL TO STEEL

TOOL OPERATION
DAILY FUNCTION TEST
Always check the tool first to make sure
that it does not contain a disc load or
fastener. Test the tool several times by
depressing the muzzle bushing fully on a
hard surface and pulling the trigger. You
should hear an audible click as the firing
pin releases. Let up on the tool and check
to be sure the barrel has opened to the
semi-closed position.
OPERATING THE D45A TOOL
1. After checking to be sure that the tool
is not loaded, point it in a safe direction
and be sure that the barrel is fully
extended. This assures that the piston
is in position for the next fastening. Use
the spall guard every time possible to
minimize the risk of being struck by
flying debris.
2. With finger off the trigger, place the
fastener, point out, into the muzzle end
of the tool until the point end is inside
the muzzle. NEVER load a fastener
with your finger on the trigger. DO NOT
use excessive force when inserting a
fastener. STOP immediately if excessive
force is required, inspect the barrel to
find out why the fastener is not entering
the muzzle freely. DO NOT continue
loading unless the problem is corrected.
3. With the tool pointed in a safe direction
and finger away from the trigger, open
the cover by pressing the side button,
and insert a load disc into the slots in
the receiver housing.
TOOL OPERATING INSTRUCTIONS
TOOL OPERATING INSTRUCTIONS
9
PERFORM FUNCTION TEST WITH
EMPTY, UNLOADED TOOL
BE SURE THE BARREL IS
FULLY FORWARD
INSERT FASTENER INTO THE
MUZZLE END OF THE TOOL WITH
THE POINT OUT
INSERT LOAD DISC INTO THE
SLOTS IN THE RECEIVER HOUSING

4. Close the cover and be sure it is locked.
NEVER attempt to make a fastening with
the tool cover in the open or unlocked
position.
5. Hold the tool perpendicular (90°) to
the work surface with both hands and
press firmly to fully depress the tool.
Maintain firm downward pressure on
the tool with both hands and pull the
trigger to drive the fastener. DO NOT
DEPRESS THE TOOL AGAINST
ANYTHING OTHER THAN THE
INTENDED WORK SURFACE. Holding
the tool firmly in place will produce
more consistent fastening quality and
minimize tool wear or damage.
6. After making the fastening, let up on
the tool pressure and note that the
barrel assembly returns to the full open
position. This automatically resets the
piston for the next fastening. Always
keep fingers and other body parts
away from the muzzle end of the
tool.
7. Insert another fastener in the muzzle
end of the tool as before and the tool
is ready for the next fastening. Keep
your finger off of the trigger until the
tool is in position to drive the fastener.
8. To remove a used or partially used
load disc from the tool, open the
cover and lift out the load disc.
NEVER try to remove a jammed or
stuck load disc. Should a “jammed”
load disc occur, call your local
Authorized Ramset Distributor for
technical assistance.
SHOULD YOU DECIDE NOT TO MAKE A
FASTENING AFTER THE TOOL HAS BEEN
LOADED, ALWAYS REMOVE THE POWDER
LOAD FIRST, THEN THE FASTENER. THIS
WILL PREVENT ACCIDENTAL DISCHARGING
OF THE FASTENER OR PISTON INTO THE
OPERATORS HAND.
TOOL OPERATING INSTRUCTIONS
TOOL OPERATING INSTRUCTIONS
10
HOLD THE TOOL FIRMLY AND
PERPENDICULAR TO THE WORK SURFACE
INSERT THE NEXT FASTENER
REMOVE THE LOAD DISC
LET UP ON TOOL PRESSURE.
NOTE THE BARREL HAS RETURNED
TO THE OPEN POSITION
90°

REFER TO PARTS SCHEMATIC FOR PROPER ASSEMBLY OF PARTS
– Overdriving of fasteners – Excessive power – Change to the next lower
power level load disc
color and number.
– Soft base material – Check base material
(see page 3)
– Tool fails to fire – Failure to depress – See “Tool does not
completely completely depress”
– Excessive dirt buildup on – After following misfire
breech face not allowing procedure, check firing
proper penetration of pin indentation on load.
firing pin Clean breech face
– Firing pin and/or breech – Replace damaged parts
damaged
– Tool does not completely – Misassembled or – Check all parts in the
depress damaged parts receiver for damage or
improper assembly.
– Reduction or loss of power – Piston not being returned – Barrel must be pulled
to the full rear position completely opened to
properly reset the piston.
– Worn or damaged – Replace worn or
piston or piston ring damaged parts
– Worn or broken pawls – Replace pawls
– Tool will not spring open – Excessive dirt buildup – Clean tool thoroughly
– Damaged or bent piston – Replace piston
– Broken or damaged parts – Tag tool with warning
“Defective–Do Not Use”
Place in a locked container
and contact your local
Ramset representative
for service.
– Failure to index disc – Disc not inserted in tool – Check load disc. Properly
correctly or is damaged dispose of damaged disc.
(See page 6)
– Damaged indexing – Contact your Ramset
mechanism Distributor for assistance
– Tool fails the – Contact your Ramset
Daily Function Test Distributor for assistance
TROUBLESHOOTING
TROUBLESHOOTING
11

D45A PARTS SCHEMATIC
D45A PARTS SCHEMATIC
12

RAMSET D45A TOOL PARTS LIST
KEY PART NO. DESCRIPTION
1 323300 MUZZLE BUSHING ASSEMBLY
2 316520 BUFFER (PKG OF 3)
3 30645 PISTON
4 323020MA BARREL RETENTION COLLAR ASSEMBLY
5 316540 PAWL (PKG OF 2)
6 323390A BARREL ASSEMBLY
8 308490 LATCH BUTTON ASSEMBLY
9 13510 COVER ASSEMBLY
10 307890 FIRING PIN ASSEMBLY
11 13953 FIRING PIN SPRING
12 335175M RETURN SPRING
13 323050A RETENTION CLIP AND BEARINGS
14 316570 FIRING PIN PAWL AND SPRING
15 13518 INDEXING LEVER AND SPRING
16 13516 TRIGGER LOCK ASSEMBLY
17 316580 SEAR ASSEMBLY AND PIN
18 309280 REAR HANDLE ASSEMBLY
19 308860 READ HANDLE SCREWS AND NUTS
20 13509 TRIGGER AND PIN
21 12266 SPALL GUARD (NOT SHOWN)
22 351000 MUZZLE BUSHING O-RING
23 351001 RETENTION COLLAR O-RING
25 323110 MUZZLE BUSHING SHROUD (NOT SHOWN)
26 32330038M 3/8 MUZZLE BUSHING ASSY. (NOT SHOWN)
PARTS LIST / MAINTENANCE
PARTS LIST / MAINTENANCE
13
Always make sure the tool is not loaded before performing any service or repair and
always wear safety goggles when cleaning or servicing the tool.
DAILY CLEANING
All front end parts shown in the disassembly section are to be cleaned daily with a good
detergent oil and wire brush. Remove all dirt and carbon buildup and wipe parts dry with
a clean rag. Check all parts for wear or damage before reassembly and replace or repair
any worn or damaged parts.
PERIODIC COMPLETE CLEANING / GENERAL MAINTENANCE
Heavy or constant exposure to dirt and debris may require that the tool be cleaned more
extensively. Complete disassembly and cleaning of all parts may be necessary to restore
the tool to normal operation. General maintenance should be performed every six months
or more often if the tool is subjected to heavy use. General maintenance/complete clean-
ing should be done by a qualified repair person.
IMPROPERLY MAINTAINED TOOLS CAN CAUSE SERIOUS INJURIES
TO TOOL OPERATOR AND BYSTANDERS
CLEAN TOOL DAILY
ALWAYS FUNCTION TEST THE TOOL AFTER PERFORMING ANY SERVICE.
SEE PAGE 9 FOR DETAILS ON THE FUNCTION TEST.
MAINTENANCE

DISASSEMBLY
14
DISASSEMBLY
TOOL DISASSEMBLY
1. Uscrew the barrel retention collar and
slide it away from the tool housing.
Handle the tool carefully after the
sleeve is unscrewed to prevent the
two barrel pawls from falling out.
2. Remove the two pawls from the slots
in the sides of the tool housing.
3. Slide the barrel asembly out of the tool
body. Note the position of the slots on
the side of the barrel assembly.
4. Slide the barrel retention collar off of
the barrel assembly.
5. Using an adjustable or 13mm open
end wrench, grip the flats on the end
of the muzzle bushing and unscrew
the muzzle bushing from the barrel
assembly.
UNSCREW THE BARREL
RETENTION COLLAR
REMOVE BOTH PAWLS
SLIDE RETENTION COLLAR AND
RETURN SPRING OFF OF THE BARREL
UNSCREW MUZZLE BUSHING
FROM BARREL ASSEMBLY
SLIDE BARREL ASSEMBLY
OUT OF THE TOOL BODY
Pawl location

DISASSEMBLY
15
DISASSEMBLY
6. Slide the barrel assembly away from
the muzzle bushing.
7. Remove the piston from the muzzle
bushing.
8. Remove the buffer from the muzzle
bushing.
9. Inspect all parts for wear or damage
and clean or replace as required.
Use detergent oil and cleaning brush.
Wipe parts dry before reassembly.
WEAR EYE PROTECTION WHEN
CLEANING TOOL PARTS.
10. Check the piston tip for mushrooming
or other deformities, and grind flat.
The tip of the piston must be 90° to
the shank and grinding must only
be done by qualified personnel. The
overall minimum length of the piston
must not be less than 5-11/16”. When
less than this length, the piston must
be replaced to avoid tool damage.
11. Reassemble the tool in the reverse
order of disassembly.
ALWAYS PERFORM THE DAILY FUNCTION
TEST BEFORE USING THE TOOL AFTER
CLEANING OR SERVICING.
SLIDE 90 ASSEMBLY
FROM MUZZLE BUSHING
PULL PISTON OUT OF THE
MUZZLE BUSHING
PULL BUFFER OUT OF THE
MUZZLE BUSHING
GRIND THE PISTON TIP FLAT AND BEVEL
THE TIP EDGE AT 18°
5/16”
90°
18°

D45A WARRANTY AND LIMITATIONS
POWDER ACTUATED TOOL
MANUFACTURES' INSTITUTE INC.
TM
Concrete Fastening Systems
Glendale Heights, IL 60139
800-RAMSET6 (1-800-726-7386)
www.ramset.com
Buy with Confidence...
Buy From Your Authorized Distributor
AN ILLINOIS TOOL WORKS COMPANY
© ILLINOIS TOOL WORKS 2009
PRINTED IN USA REVISED 04/09 Form No. SMD45A-04/09
THE MODEL D45A TOOL COMPLIES WITH OSHA REQUIREMENTS
AND WITH ANSI A10.3 SPECIFICATIONS
FOR TOOL REPAIR SERVICE CONTACT YOUR LOCAL AUTHORIZED
RAMSET DISTRIBUTOR OR TO FIND YOUR NEAREST RAMSET TOOL
REPAIR CENTER VISIT OUR WEB SITE AT WWW.RAMSET.COM
OR CALL 800-241-5640
Ramset warrants that new D45A power fastening
tools, parts and accessories will be free from
defects in material and workmanship for the
period shown below.
THREE-YEAR WARRANTY
A three-year warranty will apply to all parts,
except those listed below as normal wearing
parts, or parts which are specifically covered
by an extended warranty.
The following parts are considered normal
wearing parts and are excluded from the
warranty:
• Piston • Buffer • Spring Clips
• Pawls • Piston Rings
The warranty period is based off of tool build
date, determined from the tool serial number.
Ramset may extend the warranty time frame
from the date of purchase with a qualifying
document proving date of purchase.
WARRANTY STATEMENT
Ramset’s sole liability hereunder will be to
replace any part or accessory which proves
to be defective within the specific time period.
Any replacement part or accessory provided
in accordance with this warranty will carry a
warranty for the balance of the period of
warranty applicable to the part it replaces.
This warranty does not apply to part
replacement required due to normal wear.
This warranty is void as to any tool which has
been subjected to misuse, abuse, accidental
or intentional damage, use with fasteners, and
loads not meeting Ramset specification, size,
or quality, improperly maintained, repaired
with other than genuine D45A replacement
parts, damaged in transit or handling, or
which, in Ramset’s opinion, has been altered
or repaired in a way that affects or detracts
from the performance of the tool.
Ramset MAKES NO WARRANTY, EXPRESSED OR
IMPLIED, RELATING TO MERCHANTABILITY,
FITNESS, OR OTHERWISE, EXCEPT AS STATED
ABOVE and the liability AS STATED ABOVE
AND AS ASSUMED ABOVE is in lieu of all other
warranties arising out of, or in connection with,
the use and performance of the tool, except to
the extent otherwise provided by applicable law.
Ramset SHALL IN NO EVENT BE LIABLE FOR
ANY DIRECT, INDIRECT, OR CONSEQUENTIAL
DAMAGES, INCLUDING, BUT NOT LIMITED TO
DAMAGES WHICH MAY ARISE FROM LOSS
OF ANTICIPATED PROFITS OR PRODUCTION,
SPOILAGE OF MATERIALS, INCREASED COST
OF OPERATION OR OTHERWISE.
Ramset reserves the right to change specifications,
equipment, or designs at any time without notice
and without incurring obligation.
Copyright 2009 Ramset
