Raritan Marine Elegance Toilet User manual

1
Installation and Maintenance Instructions
Description:
Our Marine Elegance toilet is available in 12V or 24V DC. Bowls
are available in four models: standard with angled back, standard
with straight back, tall with angled back and tall with straight
back. Fresh water model utilizes onboard freshwater, the Sea
water model utilizes a remote pump installed between raw water
source and bowl. Sea/Fresh model can switch between fresh and
raw water source.
Flush control options available:
1. Smart Toilet Control: provides timed operation and inde-
pendant control of water and discharge.
2. Multifunction Flush Panel: provides momentary operation
and independant momentary control of water and discharge.
3. Momentary Flush Switch: providing only the ability to
ush with no independant control of water or discharge.
4. Touchless Flush Sense Control: designed to activate a ush
cycle without touching the control. Simply wave your hand
within 2” of the sensor.
5. Wireless Remote Bluetooth Control: program your STC
wirelessly up to 50 ft away from the toilet. Eliminates the need
to route wires through bulkheads and cabinetry.
Marine
Elegance
THE FOLLOWING ARE CAUTIONARY STATEMENTS THAT MUST BE READ AND
FOLLOWED DURING BOTH INSTALLATION AND OPERATION.
WARNING: Raritan Engineering Company, Inc. recommends that a qualied person or electrician install this product.
Equipment damage, injury to personnel or death could result from improper installation. Raritan Engineering
Company, Inc. accepts no responsibility or liability for damage to equipment, injury or death to personnel that
may result from improper installation or operation of this product.
WARNING: HAZARD OF SHOCK OR FIRE
Always use recommended fuse, circuit breaker and wire size.
Motors used with this product are “Ignition Protected”. They are not however, explosion-proof as dened in 46CFR
110.15-65(e), Subchapter J-Electrical Engineering.
DO NOT run continuously for more than 30 seconds.
Pressurized
Freshwater Model
Sea Water Model
(Remote Pump)
Manufactured after August 2016
Model and Serial Number:
1-800-352-5630
www.raritaneng. com
L490 0720jlc
Toilet

2
L490 0720jlc
SAFETY
IMPORTANT SAFETY INSTRUCTIONS:
WARNING:
Young children should NOT be left unsupervised
around toilet. Serious injury or death could
occur. Children can drown in water retained in
the bowl. Seat and/or lid could close and strike
child. Always replace circuit breaker and fuses
with same rating . Use Raritan parts to maintain
ignition protection requirements.
Toilets mounted at or below the waterline must have
a vented loop installed in the discharge line. The top
of the vented loop must be a minimum of 4” (10cm)
above the waterline at the boats greatest angle of
heel (see vented loop manufacturer’s instructions).
Sea Water Models must also have a vented loop
installed between the intake pump and the toilet bowl.
Double clamp all below waterline connections.
Recommended Visual Inspection
For leaks at toilet and hose connections
Hose clamps
Condition of hoses
Seacocks
Condition of wires and connections
In-Line Strainer (if you have one)
• No special toilet paper is required.
• Water should appear in the bowl within ten
seconds. If not, see troubleshooting section.
• Hard objects or stringy substances (paper
towels, feminine hygiene products, filter
cigarettes, etc.) must not be thrown into the
toilet as they will cause damage.
• Always shut o seacock(s) before leaving the
boat unattended.
WARNING: HAZARD OF FLOODING - Always
shut o seacock(s) before leaving the
boat unattended.
Double clamp all below waterline
hose ttings and check frequently for
integrity.
Cleaning Instructions
IMPORTANT: Do not use cleaners that contain
ammonia, ethyl acetate, phosphoric acid or
concentrated chlorine bleach. Do not allow acids,
such as vinegar, and other cleaners to sit for
extended periods of time in the toilet. These may
cause damage to the toilet. Do not use abrasive
cleaners or cleaning pads. Flushing fresh water
through toilet when leaving for extended periods
is recommended.
Using C.P. a bio-enzymatic toilet bowl cleaner
(available from Raritan Engineering Part#
1PCP32) will keep the bowl clean and fresh
smelling.

3
WINTERIZING
Winterizing:
• Improper winter lay up is a major cause of marine
toilet failure.
• Use only nontoxic antifreeze.
• Flush toilet several times to clear waste from
system.
• Dispose of all antifreeze in accordance with local
and federal regulations.
• Winterize holding tanks, plumbing, treatment
systems (MSD’s), etc. independently following
manufacturer’s instructions.
Pressurized Freshwater Models
Parts Required
• 1” (25 mm.) or 1 1/2” (38 mm.) I.D.
discharge hose, approximately 3 feet (1 m.) long
• Two buckets
• Nontoxic antifreeze approximately 1 quart
(1 liter)
Steps
1. Close discharge seacock (if one exists).
2. Shut o intake water at source.
3. Turn o power to unit.
4. Disconnect and drain discharge hose.
5. Disconnect intake hoses from water solenoid
and place in one of the buckets.
6. Connect short hose to toilet’s discharge and
place in other bucket.
7. Pour antifreeze in bowl.
8. Turn on power to unit and ush until antifreeze
is removed from the bowl and water is drained
from the solenoid and hose.
9. Disconnect power to toilet.
10. Reconnect intake hoses to water solenoid.
Integral and Remote Intake Pump Models
Parts Required
3/4” (19 mm.) I.D. intake hose approximately 3 feet
(1 m.) long.
1” (25 mm.) or 1 1/2” (38 mm.) I.D. discharge hose
approximately 3 feet (1 m.) long.
Two buckets
Nontoxic antifreeze approximately 1 quart (1 liter)
Steps
1. Close the intake and discharge seacocks.
2. Turn o power to unit.
3. Disconnect and drain intake hose and discharge
hose .
4. Connect short hoses to toilet’s intake and
discharge.
5. Place one bucket under hose connected to
toilet’s discharge.
6. Pour nontoxic antifreeze in other bucket.
7. Place hose connected to intake pump into
bucket with antifreeze.
8. Turn on power to unit and ush toilet until
antifreeze begins to be discharged from toilet.
9. Disconnect power from toilet.
RECOMMISSIONING
1. Using the buckets, hoses and approximately
one gallon (3.8 liters) of clean fresh water, ush
antifreeze out of the toilet (see Winterizing).
Dispose of antifreeze in accordance with local
and federal regulations.
2. Reconnect the intake and discharge hoses and
open both seacocks and water source valve.
3. Check all connections for leaks with several
test ushes.
SYSTEM START-UP
1. Open seacock(s).
NOTE: Pressurized freshwater models; open water
source valve.
2. Turn on power to toilet.
3. Flush toilet per Operation Instructions.
4. Check for leaks.
IMPORTANT: If toilet does not ush properly
or if water does not enter the bowl within 10
seconds, refer to Troubleshooting.
L490 0720jlc
Operation: Please see instructions included
with control to see how to operate your unit.

4
SPECIFICATIONS
Pressurized Freshwater Model - Recommended Wire and Fuse/Circuit Breaker Size
Sea Water Model - Recommended Wire and Fuse/Circuit Breaker Size
Plumbing
NOTES: for Wiring
Hose Sizes
INLET
1/2”(12.7 mm.) for freshwater model
3/4” (19 mm.) for sea water model
Discharge
1”(25.4 mm.) or 1 1/2”(38 mm.)
CONVERSIONS
Wire - AWG to mm2
Feet to Meters
Bowl type A B C D E F G
ME-
angledback
18 3/8
(467)
12 1/4
(311)
14
(355)
12
(305)
14
(355)
8 1/2
(216)
2 1/8
(54)
ME-
straightback
18 3/8
(467)
12 1/4
(311)
14
(355)
12
(305)
14
(355)
8 1/2
(216) NA
ME-TALL
angled back
18 3/8
(467)
12 1/4
(311)
17
(432)
15
(380)
14
(355)
8 1/2
(216)
2 1/8
(54)
ME-TALL
Straight back
18 3/8
(467)
12 1/4
(311)
17
(432)
15
(380)
14
(355)
8 1/2
(216) NA
SIZE inch (mm.)
E
B
C
G
F
A
D
AWG 16 14 12 10 8 6 4 2
mm
2
1.5 2.5 4.0 6.0 10.0 16.0 25.0 35.0
Feet 10 15 20 25 30 40 50
Meter 3.1 4.6 6.1 7.6 9.2 12.2 15.2
1. Distances are from source to unit and back to source.
2.
Distance from power source to remote intake pump MUST be included when
determining total distance.Same wire size MUST be used for lower base and
remote intake pump.
3. Recommended conductor wire minimum AWG (mm2) for 3% voltage drop.
4. Recommended conductor sizes are based on 105oC rated insulation.
Refer to ABYC Standards for other insulation ratings.
5. For 120/240 VAC units use 12VDC specifications from transformer to unit.
Units
Voltage
Circuit
Breaker/fuse
size (amps)
Elegance
toilet
Amp. draw
@ nominal
Voltage/
Remote
Pump
Only
Amp. draw
@ nominal
voltage
15
feet 20 feet 30 feet 40 feet 50 feet
12 VDC 30 18 10 10 AWG 8 AWG 6 AWG 6 AWG 4 AWG
24 VDC 20 10 514 AWG 14 AWG 12 AWG 10 AWG 10 AWG
Units
Voltage
Circuit
Breaker/fuse
size (amps)
Amp. draw
@ nominal
voltage
10
feet 15 feet 20 feet 30 feet 40 feet 50 feet
12 VDC 25 18 12 AWG 10 AWG 10 AWG 8 AWG 6 AWG 6 AWG
24 VDC 15 10 14 AWG 12 AWG 10 AWG 10 AWG 8 AWG 6 AWG
L490 0720jlc
Maximum suction of Intake Pump
(Maximum height above waterline)
4  (1.2m) from Intake Pump
Maximum height of discharge vented
loop
10  (3 m) from base of toilet
Pressurized water source minimum
requirements
Minimum ow rate 3 gallons
(113 liters) per minute. Mini-
mum pressure 5 PSI (34.5 KPA)
Angled Back
Straight Back
Tall
Straight Back
Tall
Angled Back

5
Additional Parts Required:
• 1” (25 mm.) or 1 1/2” (38 mm.) I.D. discharge hose
• 3/4” (19 mm.) I.D. reinforced intake hose
• 3/4” (19 mm.) and 1” (25 mm.) or 1 1/2” (38 mm.) hose
clamps (two for each connection below waterline)
• Wire
• Terminals
• Fuse/circuit breaker
Parts included with all models:
1. Toilet bowl assembly
2. Mounting bracket kit
3. Seat
4. Flush control - includes User and Installation
guides. (In some cases distribution points
may package and sell controls seperatly.)
5. User guide and Installation guide with labels
Additional Parts included with sea water model:
1. Remote pump assy.
2. Relay for remote pump (Momentary Flush
Switch and SeaFresh models only)
SIZE inch (mm.)
MOUNTING
Mounting Toilet
Mounting surface must be at and solid.
Seat must open more than 90 degrees.
1. Place the toilet and mark mounting holes’ center
line, and outside of the bowl (FIG 1). Draw a
center line between two holes. Mark front hole
outside and center and draw a line perpendicular
to rst center line.
2. Mark three lines A, B, and C, 3/8” from outside
lines.
3. Line up outside edges of the brackets with
marked lines A, B, and C.
4. Secure bracket assembly to deck. Using three #14
self threading bolts and at washers. Other types
of fasteners may be used if so desired.
Note: place bolts as close to mark lines A, B,and
C as possible
5. Drill holes for discharge hose (2”(51 mm.) for 1
1/2” hose; 1 1/2”(38 mm) for 1” hose), inlet hose
(7/8” (22 mm.) and wires (3/4”(19 mm.) using
dimensions shown in FIG 2.
Note: check outside diameter of the hoses and
adjust hole sizes accordingly.
6. Complete plumbing and wiring before installing
toilet.
FIG 1
L490 0720jlc
13
8[35] 1
4[6]
2 [51]
WIRES
INLET HOSE DISCHARGE HOSE
Bolt and
Washers
Line A
Line C
Line B
See #5 under Mounting
See #5 under Mounting
See #5 under Mounting
25
8[67]
3 [76]
inch [mm]
FIG 2

6
PLUMBING
PLUMBING
WARNING: HAZARD OF FLOODING
Toilets mounted at or below the waterline, at
greatest angle of heel, and connected to a Seacock/
Thru Hull Fitting(s) MUST have VENTED LOOPS
installed in toilet discharge plumbing and between
raw water intake pump and toilet bowl.
Install vented loops per manufacturer’s instructions.
Sea Water Models installed below the waterline
MUST have a vented loop installed between the
intake pump and the toilet bowl.
Double clamp all below-waterline connections.
IMPORTANT
• Fittings and 90° bends should be kept to a
minimum.
• In-Line Strainer may be installed on Sea
Water Models per Installation Instructions.
This will prevent clogs.
• Discharging untreated sewage is forbidden in
all U. S. waters within the three-mile limit.
• Thru-hull fittings and seacocks must be
installed where they are easily accessible.
• Use only quality reinforced hoses such as
Raritan Saniex (SFH)
• Secure all hoses properly.
Waterline
Pressurized Freshwater Model Installed
Above/below Waterline
Discharge
Pressurized Fresh-
water
Source
Shut o Valve
Waterline
remote pump
Electroscan
Waterline
Discharge Seacock
Waterline
Discharge Vented
Loop
Intake Vented Loop
Discharge
Seacock Intake Seacock
Electroscan
Pressurized Freshwater Model Installed
below Waterline
Holding Tank
Residual Water in the Bowl
The Marine Elegance is equipped with an
integral vent to maintain water in the bowl when
the plumbing lines are routed downward
(See FIG 4a and FIG 4b).
The Smart Toilet Control (STC) is designed to
add water at the end of the ush cycle. The toilet
will not hold more than about 4” in the bowl.
If any of the discharge hose runs higher than
the internal integral vent, DO NOT REMOVE
THE VENT CAP. For vent to work properly
in downward installation, the vent cap must be
removed (see FIG 5).
Remote Intake Pump Model Mounted
below Waterline
To enable vent, remove Vent Cap (FIG 5).
Toilet Installed above waterline
or above Treatment Device and
or Holding Tank = Downward
discharge ow
Remove vent cap
Toilet installed below waterline
or below Treatment Device
and or holding Tank = Upward
discharge ow
Do not remove vent cap
FIG 3a
FIG 4a
FIG 5
L490 0720jlc
Vent Cap
FIG 3b
FIG 3c
FIG 4b

7
Remote Sea Water Models
Intake pump ttings are interchangeable to allow more
exibility during installation. Inlet ports are located on
either side of intake pump. Outlet port (to toilet bowl) is
at top of intake pump (FIG 8).
NOTE: To avoid poor pump performance installation
of strainer (163000) is recommended
1. Slide tting clips to open position (FIG 7).
2. Select inlet port to be used.
3. Install appropriate ttings into inlet and
outlet ports.
NOTE: The 90° tting can be rotated 360°.
4. Install the plug tting into unused inlet port.
IMPORTANT: Be sure not to install plug tting into
outlet port! Damage to pump will occur!
PLUMBING
Discharge
port
Inlet
port
Discharge Lines
Raritan Sanitation Hose is recommended
Part numbers:
SFH 1 1/2 inch
SFH1 1 inch
1. Connect quality sanitation hose 1” (25 mm.) or 1
1/2”(38 mm.) discharge tting on toilet.
2. Run hose to appropriate device (i.e.: treatment
system, holding tank, etc.).
Inlet Lines
1. Connect 1/2”(13 mm.) hose to pressurized
supply or 3/4”(19 mm.) hose to remote pump
Intake Lines
Pressurized Freshwater Models
1. Install a shut o valve in intake line before
water solenoid valve.
2. Connect hose from shut o valve to inlet port of
water solenoid valve at the toilet.
NOTE: To avoid malfunction of water solenoid due to
debris in water, installation of Freshwater Strainer
(190601) is recommended.
FIG 6
FIG 7
FIG 9
L490 0720jlc
Open
Arrow
Plug
Inlet Ports
Outlet Port
To Bowl
FIG 8
5. Slide tting clips back to closed position (FIG
7)
6. Connect hose from seacock to inlet port of intake
pump. If used, strainer is in-line. Use hose clamp
provided.
IMPORTANT: Double clamp all below waterline
hose connections!
7. Connect hose from outlet port of intake pump to
bowl elbow located on back of toilet bowl.
Mounting Remote Pump
1. Locate remote pump between thru hull tting
and toilet bowl.
2. Locate in an area away from berth to keep noise
level down.
3. Use Inline Strainer (optional) to avoid clogs.
4. Secure remote pump to the oor using four bolts
through the pump base (FIG 9).
Closed

8
WIRING
WIRING
WARNING: Hazard of Shock and Fire
• Always use proper wire, wire connectors
and fuse/circuit breaker. See Specication
Chart.
• Secure wire properly.
• Do not connect appliances to toilet circuit.
• Make sure power is o before proceeding.
• Use proper wire terminals for all wire
connections.
1. Determine proper wire size by measuring
distance from:
• Power Source to push button to toilet motor
and back to power source.
• Remote pump units - also include distance
from power source for remote pump to
remote pump and back. Same wire gauge
must be used for both lower base and
remote pump.
2. Select proper wire and fuse/circuit breaker
size from Specications on Installation page.
3. Install fuse/circuit breaker in positive line at
source.
4. Wire control to the toilet and battery using
one of the wiring diagram supplied with the
control.
Mounting controls:
Refer to instruction enclosed with control.
Install the Warning Label (L322) where it can
be easily seen.
5. Route wire from control per wiring
diagrams.
6. Install seat. Install discharge support strap
between seat nut and the bowl (FIG 10).
Caution: To avoid kinking, do not pull on the
discharge hose. Be certain there is no pressure on
the discharge line.
7. Install mounting bushings, bolts. (FIG 11)
8. Tighten bolts being careful to not overtighten
(Do not exceed 30 inch lb. when tightening)
9. Install caps over mounting bolts.
Connect Hoses and wiring to toilet
Mount toilet
FIG 10
FIG 11
L490 0720jlc

9
TROUBLESHOOTING
WARNING: HAZARD OF ELECTRIC SHOCK - Before beginning any work on the toilet, be sure that all
power to the unit has been turned o.
WARNING: HAZARD OF FLOODING - Make sure seacocks are in the CLOSED or OFF position before
working on toilet.
NOTE: The following information reects the most probable causes and solutions to problems although not
every possible cause and solution is provided.
Any questions regarding servicing or operation of the Marine Elegance should be directed to our Technical Support
Department in Millville, NJ. Please have model and serial number available before calling.
PROBLEM
1. Poor pumpout, especially
solids.
2. Poor water ow, especially
at front of bowl (or no
water ow).
3. Foul odors from toilet area.
4. Bowl lls while underway.
5. Water leaking from under
unit.
POSSIBLE CAUSE
1A. Clogged discharge line.
1B. Plumbing restrictions, bends and ells.
1C. Clogged vents.
1D. Mineral buildup in hoses and ttings.
1E. Low voltage.
2A. Toilet not level.
2B. Restriction in intake line.
2C. Intake Pump sucking air.
2D. Low voltage.
2E. Clogged strainer.
3A. “Marine life” lodged in rim of bowl.
3B. Permeated discharge hose.
3C. Sewage remaining in discharge line.
4A. Pressure buildup at seacocks.
5A. Leaking Bowl Throat adapter.
5B. Leak at shaft seal.
5C. Leak from bowl spud.
TROUBLESHOOTING
SOLUTION
1A. Be sure discharge seacock is open. Clear line, remove
clog.
1B. Replumb to eliminate bends and ells.
1C. Clean holding tank vent and vented loop vents
1D. Clean or replace aected parts. Replace hose if needed.
1E. Check voltage at toilet while toilet is running. If
less than nominal voltage of toilet (12 or 24), check
condition of batteries and wire sizes. Check terminals
and wire connections for corrosion (heat at terminals
and junctions indicates a bad or corroded connection).
2A. Raise rear of toilet; check with level.
2B. Be sure seacock is open. Clear line-remove clog.
2C. Check all connections from intake thru-hull to intake
pump to be sure no air leaks are present.
2D. See 1E, above.
2E. Remove or Clear debris from strainer.
3A. Remove and ush bowl with pressure hose to remove
all material. Install strainer in intake line to avoid
recurrence.
3B. Replace hose with Raritan Saniex Hose (#SFH).
3C. Flush toilet longer; replace hose if permeated; reroute
hose making a shorter run if possible.
4A. Close intake, then discharge seacock to determine
which is causing problem. If discharge, be sure the
vent or vented loop is clean. If intake, there is too
much pressure on seacock; contact Raritan Technical
Support.
5A. Tighten adapter clamps.
5B. Check seal and motor shaft.
5C. Check and reseat bowl grommet
Tip for Removing Intake Pump
Plug
Set screw must be loosened
with 1/8” hex key before
removing the intake pump
from motor
L490 0720jlc

10
Marine Elegance PARTS LIST
EXPLODED PARTS
ItemNo. Part No. Description
1 1245SC Seat & Cover (Slow Close)
1 1245A Seat & Cover (Almond)
2 221100W ME Bowl, Std Hgt, Angled Back, White
2 221100AW ME Bowl, Std Hgt, Angled Back, Almond
2 221101W ME Bowl, Std Hgt, Straight Back, White
2 221101AW ME Bowl, Std Hgt, Straight Back, Almond
2 231100W ME Bowl, Tall, Angled Back, White
2 231100AW ME Bowl, Tall, Angled Back, Almond
2 231101W ME Bowl, Tall, Straight Back, White
2 231101AW ME Bowl, Tall, Straight Back, Almond
3 M23A #10 Lockwasher SS (5)
4 1108A 10-32 SS Nut
5 161123 Macerator Blade
6 31-102 Motor Shaft Seal
7 221110 Discharge Pump Seal Plate
8 221105 O-Ring
9 161115 Impeller
10 221115 Discharge Pump Macerator Housing
11 31-114 Lock Nut 10-32 W/Nylon(3)
12 221012 Discharge Motor 12 V
12 221024 Discharge Motor 24V
13 221125 Bowl Throat Adapter Clamp - Pump
14 221120 Bowl Throat Adapter
15 221130 Bowl Throat Adapter Clamp - Bowl
16 221155 Pump Mtg. Bracket, Angled Back Bowl
16 221156 Pump Mtg Bracket, Striaght Back Bowl
17 F193VT Screw 10-32 X 3/8 W/VT
21 221141W Discharge Hose
22 221135W Joker Valve (2) (Also includes #24)
23 221145 Discharge Adapter Fitting
24 221146 Joker Valve Insert
25 221160 Discharge Hose Clamp (small)
26 221165 Discharge Hose Clamp (large)
27 VLVE Vent Valve Assembly
28 FC001 Vent Valve Hose Clamp
29 221150 Spud Seal
31 221210 ME Bowl Mtg Bushing (2)
31 221210A ME Bowl Mtg Bushing Almond (2)
32 F186 Screw Bowl Mtg (2)
33 221215 ME Bowl Mtg Cap (2)
33 221215A ME Bowl Mtg Cap Almond
34 F196 ME Front Mounting Cap
34 F196A ME Front Mounting Cap Almond
35 F187 Screw ME Bowl Mtg
36 F195 Washer Cup
37 F199 Bushing Bowl Mtg
38 221240A Cam Nut (2)
39 F197 Cage Nut
REMOTE INTAKE PUMP UNITS
40 166012A Pump Motor 12VDC
40 166024A Pump Motor 24VDC
41 162000W Remote Intake Pump w/o Motor
42 162405 3/4” Hose Barb 90° Fitting
43 162410 3/4” Hose Barb Straight
44 162415 Plug Fitting
45 162420 Fitting Retaining Clip (3)
46 162425 O-ring (3)
47 F162VT Inlet Pump Mounting Bolt (4)
48 F144 #10 Washer SS Flat (4)
50 PLA26 Elbow Adapter 3/4 X 1/2
PRESSURIZED FRESH WATER UNITS
71 221300 Vacuum Breaker Assembly
72 221351 Solenoid Valve 12VDC
72 221352 Solenoid Valve 24VDC
73 221335 Hose 1/2”
74 221340 Hose Clamps 1/2” (2)
75 221356 ME Nut 3/4 BSP
75 221357 ME Hose Adadpter Straight
PARTS NOT SHOWN
221175 L Bolt (2)
F321P Washer Fender Style (3)
F188 Well Nut 10-32 (3)
F144 Washer #10L 18-8 SS (2)
FLUSH CONTROL OPTIONS
SMART TOILET CONTROL
80 STC548W Smart Toilet Control (12 & 24 VDC)
81 STC545 Control Cable 7 ft
82 221524 Wall Switch Cover Plate White
82 221524A Wall Switch Cover Plate Almond
83 STC543 Touch Panel w/Back Plate
84 221525 Touch Panel Gasket
MULTIFUNCTION FLUSH PANEL (NOT SHOWN)
221600 Multifunction Flush Panel
221524 Wall switch plate
221601 Fill/Empty Switch
221602 Flush Switch
221603 Switch Actuator-Flush, Horizontal Panel
221604 Switch Actuator-Fill/Empty, Horizontal Panel
221605 Switch Actuator-Flush, Vertical Panel
221606 Switch Actuator-Fill/Empty, Vertical Panel
MOMENTARY FLUSH SWITCH (NOT SHOWN)
PRS Momentary Flush Switch
MOUNTING BRACKET ASSEMBLY
90 221230W Mounting Bracket w/Hardware
(includes items 31-39, 91 & 92)
91 221205 Bowl Mtg Bracket (3)
92 221230 Mounting Bracket Base
REPAIR KITS
MERK Discharge Pump Repair Kit (includes #6, 8, 22 and 24)
22100** Discharge Pump Assembly (includes #3 thru 12 and 21
thru 28)
ADDITIONAL ACCESSORIES AVAILABLE FROM RARITAN
221147 1 1/2 inch Thru Wall Discharge Kit
221148 1 inch Thru Wall Discharge Kit
1PCP32 C.P. Cleans Potties, 32 OZ
1PCHGAL Cleans Hoses, Tanks and MSD (gal)
SFH Sanitation Hose 1 1/2” (sold by foot)
SFH1 Sanitation Hose 1” (sold by foot)
163000 Seawater Inline Strainer
RTME12D Power Converter for 120/240 VAC
KO2 Deodorant System (Seawater Models)
1PKO32 Kills Odors, 32oz
STCTSA: Holding Tank Full Sensor (Sensa Level TM)
For use with STC Flush Control.
STCFL: Holding Tank Full Sensor (Float Switch) For use with
STC Flush Control.
L490 0720jlc
** Specify Voltage

11
EXPLODED PARTS
L490 0720jlc

12
L490 0720 jlc Specications Subject to Change Without Notice Printed in U.S.A.
Raritan Engineering Company warrants to the original purchaser that this product is free of defects
in materials or workmanship for a period of one year from the product’s date of purchase. Should
this product prove defective by reason of improper workmanship and/or materials within the war-
ranty period, Raritan shall, at its sole option, repair or replace the product.
1. TO OBTAIN WARRANTY SERVICE, Consumer must deliver the product prepaid, together with
a detailed description of the problem, to Raritan at 530 Orange St., Millville, N.J. 08332. When
requesting warranty service, purchaser must present a sales slip or other document which establishes
proof of purchase. THE RETURN OF THE OWNER REGISTRATION CARD IS NOT A CONDI-
TION PRECEDENT OF WARRANTY COVERAGE. However, please complete and return the
owner Registration Card so that Raritan can contact you should a question of safety arise which
could aect you.
2. THIS WARRANTY DOES NOT COVER defects caused by modications, alterations, repairs or
service of this product by anyone other than Raritan; defects in materials or workmanship supplied
by others in the process of installation of this product; defects caused by installation of this product
other than in accordance with the manufacturer’s recommended installation instructions or standard
industry procedures; physical abuse to, or misuse of, this product. This warranty also does not cover
damages to equipment caused by re, ood, external water, excessive corrosion or Act of God.
3. ANY EXPRESS WARRANTY NOT PROVIDED HEREIN, AND ANY REMEDY FOR BREACH
OF CONTRACT WHICH BUT FOR THIS PROVISION MIGHT ARISE BY IMPLICATION OR
OPERATION OF LAW, IS HEREBY EXCLUDED AND DISCLAIMED. ALL IMPLIED WAR-
RANTIES SUCH AS THOSE OF MERCHANTABILITY AND OF FITNESS FOR A PARTICULAR
PURPOSE, IF APPLICABLE, AS WELL AS ANY IMPLIED WARRANTIES WHICH MIGHT
ARISE BY IMPLICATION OF LAW, ARE EXPRESSLY LIMITED TO A TERM OF ONE YEAR.
SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG A LIMITED WARRANTY
LASTS, SO THE ABOVE LIMITATION MAY NOT APPLY TO YOU.
4. UNDER NO CIRCUMSTANCES SHALL RARITAN BE LIABLE TO PURCHASER OR ANY
OTHER PERSONS FOR ANY SPECIAL OR CONSEQUENTIAL DAMAGES, WHETHER
ARISING OUT OF BREACH OF WARRANTY, BREACH OF CONTRACT, OR OTHERWISE.
SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR
CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT
APPLY TO YOU.
5. No other person or entity is authorized to make any express warranty, promise or armation of
fact or to assume any other liability on behalf of Raritan in connection with its products except as
specically set forth in this warranty.
6. This warranty gives you specic legal rights, and you may also have other rights which vary from
state to state.
LIMITED WARRANTY
530 Orange Street
Millville, NJ 08332 USA
Telephone: [phone]
FAX: [phone]
www.raritaneng.com
