Raritan SeaEra QC Series User manual

Sea Water Model
(Remote Pump)
SeaEra QC Toilet
Series QC, Model 162 (manufactured after June 2014)
OPERATION, MAINTENANCE AND INSTALLATION INSTRUCTIONS
THE FOLLOWING ARE CAUTIONARY STATEMENTS THAT MUST BE READ AND
FOLLOWED DURING BOTH INSTALLATION AND OPERATION.
WARNING: Raritan Engineering Company, Inc. recommends that a qualied person or electrician install this
product. Equipment damage, injury to personnel or death could result from improper installation.
Raritan Engineering Company, Inc. accepts no responsibility or liability for damage to equipment,
injury or death to personnel that may result from improper installation or operation of this product.
WARNING: HAZARD OF SHOCK OR FIRE
Always use recommended fuse, circuit breaker and wire size.
Motors used with this product are “Ignition Protected”. ey are not however,
explosion-proof as dened in 46CFR 110.15-65(e), Subchapter J-Electrical Engineering.
DO NOT run continuously for more than 30 seconds.
WARNING: HAZARD OF FLOODING - Always shut o seacock(s) before leaving the boat unattended.
Double clamp all below waterline hose ttings and check frequently for integrity.
Pressurized
Freshwater Model
SeaEra toilet is available in 12V or 24V DC. Bowls
are available in two models: standard and house-
hold. Fresh water model utilizes onboard freshwa-
ter, the Sea water model utilizes a remote pump
installed between raw water source and bowl. Sea/
Fresh models can switch between fresh and raw
water source.
ree dierent control options are available:
1. Smart toilet control (STC): provides timed
operation and independent control of water
and discharge
2. Multifunction control: provides momen-
tary operation and independent momentary
control of water and discharge
3. Push button switch: providing only the abil-
ity to ush with no independent control of
water or discharge.
1-800-352-5630
www.raritaneng.com
Model and Serial #
L365v0320jlc 1

SAFETY
2
IMPORTANT SAFETY INSTRUCTIONS:
Toilets mounted at or below the waterline must have
a vented loop installed in the discharge line. e top
of the vented loop must be a minimum of 4" (10cm)
above the waterline at the boats greatest angle of heel
(see vented loop manufacturer’s instructions).
Sea Water Models must also have a vented loop in-
stalled between the intake pump and the toilet bowl.
Double clamp all below waterline connections.
WARNING: HAZARD OF FLOODING - Always shut o seacock(s) before leaving the boat unattended.
Double clamp all below waterline hose ttings and check frequently for integrity.
WARNING:
Young children should NOT be le unsupervised
around toilet. Serious injury or death could occur.
Children can drown in water retained in the bowl.
Seat and/or lid could close and strike child.
Always replace circuit breaker and fuses with same
rating . Use Raritan parts to maintain ignition pro-
tection requirements.
• Nospecialtoiletpaperisrequired.
• Watershouldappearinthebowlwithin
ten seconds. If not, see troubleshooting
section.
• Hardobjectsorstringysubstances(paper
towels, feminine hygiene products, lter
cigarettes, etc.) must not be thrown into
the toilet as they will cause damage.
• Alwaysshutoseacock(s)beforeleaving
the boat unattended.
Cleaning Instructions
IMPORTANT: Do not use cleaners that contain
ammonia, ethyl acetate, phosphoric acid or
concentrated chlorine bleach. These may cause
damage to the toilet.
Using Raritan C.P. (part# 1PCP22) a bio-enzymatic
toilet bowl cleaner will keep the bowl clean and fresh
smelling.
Recommend Visual Inspection
 PFor leaks at toilet and hose connections
 PHose clamps
 PCondition of hoses
 PSeacocks
 PCondition of wires and connections
 PIn-Line Strainer (if you have one)
Cleaning In-Line Strainer
(Optional part# 163000)
(Sea Water Models only)
Shut o intake seacock. Unscrew bowl. Remove
lter. Clean bowl and lter with a clean cloth.
Clean gasket and gasket contact surfaces
thoroughly. Replace gasket, lter and bowl. Open
seacock. Check for leaks.
MAINTENANCE
L365v0320jlc

3
CONTROL SWITCH OPERATION:
Refer to manual enclosed in control switch.
Winterizing:
• Improperwinterlayupisamajorcauseof
marine toilet failure.
• Useonlynontoxicantifreeze.
• Flushtoiletseveraltimestoclearwastefrom
system.
• Disposeofallantifreezeinaccordancewith
local and federal regulations.
• Winterizeholdingtanks,plumbing,treat-
ment systems (MSD’s), etc. Independently
following manufacturer’s instructions.
Pressurized Freshwater Models
Parts Required:
• 1"(25mm.)Or11/2"(38mm.)I.D.
discharge hose, approximately 3 feet (1 m.)
long
• Twobuckets
• Nontoxicantifreezeapproximately1quart
(1 liter)
Steps:
1. Close discharge seacock (if one exists).
2. Shut o intake water at source.
3. Turn o power to unit.
4. Disconnect and drain discharge hose.
5. Disconnect intake hoses from water sole-
noid and place in one of the buckets.
6. Connect short hose to toilet’s discharge and
place in other bucket.
7. Pour antifreeze in bowl.
8. Turnonpowertounitandushuntilanti-
freeze is removed from the bowl and water is
drained from the solenoid and hose.
9. Disconnect power to toilet.
10. Reconnect intake hoses to water solenoid.
Remote Intake Pump Model
Parts Required:
• 3/4" (19 mm.) I.D. intake hose approximately 3
feet (1 m.) long.
• 1"(25mm.)or11/2"(38mm.)I.D.discharge
hose approximately 3 feet (1 m.) long.
• Two buckets
• Nontoxic antifreeze approximately 1 quart (1
liter)
Steps:
1. Close the intake and discharge seacocks.
2. Turn o power to unit.
3. Disconnect and drain intake hose and dis-
charge hose .
4. Connect short hoses to toilet’s intake and dis-
charge.
5. Place one bucket under hose connected to
toilet’s discharge.
6. Pour nontoxic antifreeze in other bucket.
7. Place hose connected to intake pump into
bucket with antifreeze.
8. Turnonpowertounitandushtoiletuntil
antifreeze begins to be discharged from toilet.
9. Disconnect power from toilet.
RECOMMISSIONING
1. Using the buckets, hoses and approximately
onegallon(3.8liters)ofcleanfreshwater,ush
antifreeze out of the toilet (see Winterizing).
Dispose of antifreeze in accordance with local
and federal regulations.
2. Reconnect the intake and discharge hoses and
open both seacocks and water source valve.
3. Check all connections for leaks with several
test ushes.
SYSTEM START-UP
1. Open seacock(s).
NOTE: Pressurized freshwater models; open wa-
ter source valve.
2. Turn on power to toilet.
3. Flush toilet per operation instructions.
4. Check for leaks.
IMPORTANT: If toilet does not ush properly
or if water does not enter the bowl within 10
seconds, refer to troubleshooting.
WINTERIZING
L365v0320jlc

SPECIFICATIONS
Pressurized Freshwater or Remote Sea Water Model
4L365v0320jlc
BOWL TYPE A B C D E
MARINE 14 1/2
(368)
26 1/2
(673)
103/8
(264)
17 1/4
(438)
13
(330)
HOUSEHOLD 147/8
(378)
295/8
(752)
11 1/2
(292)
20
(508)
143/8
(365)
INCHES
(MM)
NOTE:
1. THE SEAT WILL OPEN WITHIN THE DEPTH OF THE BOWL (D). HOWEVER, IT MAY BE
DESIRABLE TO INCREASE THIS ANGLE BY ALLOWING MORE ROOM AT THE BACK OF
THE BOWL FOR THE SEAT TO OPEN.
2. DIMENSIONS ARE FOR REFERENCE AS VITREOUS CHINA DIMENTIONS
MAY VARY +/- 5%
SEE NOTE 1
A
B
C
D
3 5/16
(84)
10 3/16
(258)
65/8
(168)
6 3/16
(157)
15/8
(42)
6
(152)
41/8
(105)
4 1/16
(104)

Pressurized Freshwater Model - Recommended Wire and Fuse/Circuit Breaker Size
4
Sea Water Model - Recommended Wire and Fuse/Circuit Breaker Size
Plumbing
CONVERSIONS
Wire - AWG to mm2
Feet to Meters
NOTES: for Wiring
Feet 10 15 20 25 30 40 50
Meter 3.1 4.6 6.1 7.6 9.2 12.2 15.2
AWG 16 14 12 10 86 4 2
mm21.5 2.5 4.0 6.0 10.0 16.0 25.0 35.0
Maximum suction of Intake pump
(Maximum height above waterline)
4 Ft. (1.2m) from Intake Pump.
Maximum height of discharge vented loop 6Ft.(1.8m)frombaseoftoilet.
Pressurized water source requirements
Minimum ow rate of 3.5 gpm (13.25 liters)
at 10psi (70 K pa)
shuto pressure of 5 psi (34.5 kPa).
1. Distances are from source to unit and back to source.
2.
Distance from power source to remote intake pump MUST be included when
determining total distance.Same wire size MUST be used for lower base and
remote intake pump.
3. Recommended conductor wire minimum AWG (mm2) for 3% voltage drop.
4. Recommended conductor sizes are based on 105oC rated insulation.
Refer to ABYC Standards for other insulation ratings.
5. For 120/240 VAC units use 12VDC specications from transformer to unit.
Units
Voltage
Circuit Breaker/
fuse size (amps)
Amp. draw
@ nominal voltage
10 feet 15 feet 20 feet 30 feet 40 feet 50 feet
12 VDC
Lower Base 25 13 12 AWG 10 AWG 10 AWG 8AWG 6 AWG 6 AWG
24 VDC
Lower Base
15 7.5
14 AWG 12 AWG 10 AWG 10 AWG 8AWG 6 AWG
12, 24, and Water Solenoid
Valve
3 2 16 AWG 16 AWG 16 AWG 16 AWG 16 AWG 16 AWG
SPECIFICATIONS
5
L365v0320jlc
Units
Voltage
Circuit
Breaker/fuse
size (amps)
Remote Pump
and lower base
Amp. draw
@ nominal
voltage
Remote Pump
only
Amp. draw
@ nominal
voltage
15
feet
20
feet
30
feet
40
feet
50
feet
12 VDC 25 23 10 10 AWG 8AWG 6 AWG 6 AWG 4 AWG
24 VDC 15 12.5 514 AWG 14 AWG 12 AWG 10 AWG 10 AWG

6
Mounting Toilet
Mounting surface must be at and solid.
1. Install seat on toilet (FIG 1).
2. Remove motor cover.
3. Place toilet where it will be located.
Make sure there is room to route hoses.
Make sure seat will open properly (FIG 2).
4. Mark location of toilet base mounting holes on
mounting surface (FIG 1).
5. Drill holes for toilet mounting bolts/screws.
NOTE: Hole size will depend on type of bolt/screws
used(5/16”[8mm]sizebolts/screwsarerecommended).
6. Secure toilet to surface
Additional Parts Required
• Four stainless steel mounting bolts or lag screws
(minimum1/4”[6mm])andwashers.
• 1”(25mm)or11/2”(38mm)I.D.dischargehose.
• 3/4” (19mm) for seawater models or 1/2” (13mm)
for freshwater models, reinforced intake hose.
• Hose clamps (two for each connection below
waterline).
• Wire.
• Terminals.
• Fuse/circuit breaker.
Parts Included
All Complete Toilets
Toilet Bowl
Seat and Cover
Lower Base Assembly
Motor Cover
11/2(38mm)90°Dischargetting   
Adapter, 1” FPT x Barb
Control
Sea Water Model
Intake Pump
3/4” Hose Barb - straight tting (2)
3/4”HoseBarb-90°tting  
Plug Fitting
90° Rotation of Toilet Bowl
Toiletbowlcanberotated90°onthebase,forinstallingin
conned locations (FIG 3).
1. Determine which direction bowl is to be mounted.
2. Remove four vinyl caps at the base of toilet bowl.
3. Remove four nuts and shoulder washers.
4. Carefully remove toilet bowl from base.
5. Rotate toilet bowl to desired position.
6. Replace four shoulder washers, nuts and vinyl caps.
NOTE: Tighten nuts carefully and evenly. Do
Not over tighten.
Install the Warning Label (L322) where it can be easily
seen.
Mounting In-Line Strainer
(Seawater Models Only)
Make sure strainer bowl is tight.
1. Locate strainer where it will be accessible.
2. Mark and drill mounting holes.
NOTE: Hole size will depend on type of bolts/screws used
(1/4” [6mm] size bolts/screws are recommended).
3. Install ttings provided (PLA14) on strainer’s inlet and
outlet ports.
NOTE: Use thread sealant.
4. Mount strainer. Hoses must be installed according to ow
marking on strainer top.
Mounting Remote Intake Pump
(Remote Pump Models Only)
1. Remote intake pump must be mounted on a at solid surface
in an area that is dry and well ventilated.
2. Mark and drill mounting holes.
NOTE: Hole size will depend on type of bolts/screws used
1 /4” [6mm] size bolts/screws are recommended).
3. Mount pump. Do not over tighten bolts.
INSTALLATION
Tools Required
• 5/16” nut driver, wrench or screw driver.
• 5/8”(16mm)drillbit,bitfordrillingmountingsurface,
wire cutters, wire terminal crimpers, hose cutters, tape
measure.
L365v0320jlc
FIG 1
FIG 2
FIG 3

INSTALLATION
7
Discharge Lines
1. Connect quality sanitation hose 1” (25mm),
Raritanpart#SFH1,or1 1/2” (38mm) I.D.,
Raritan part# SFH to discharge tting on toilet
(FIG 7).
2. Run hose to appropriate device (i.e.: treatment
system, holding tank, etc.).
PLUMBING
WARNING: HAZARD OF FLOODING
Toilets mounted at or below the waterline,
at greatest angle of heel, and connected to
a Seacock/Thru Hull Fitting(s) MUST have
VENTED LOOPS installed in toilet discharge
plumbing and between raw water intake pump
and toilet bowl.
Install vented loops per manufacturer’s
instructions. Double clamp all below-waterline
connections.
IMPORTANT:
• Fittingsand90°bendsshouldbekepttoa
minimum.
• Discharginguntreatedsewageisforbiddeninall
U. S. waters within the three-mile limit.
• ru-hullttingsandseacocksmustbeinstalled
where they are easily accessible.
• Useonlyqualityreinforcedhoses.
• Secureallhosesproperly.
Pressurized Freshwater Model Installed
Above Waterline
SeaEra Toilet
Discharge
Holding Tank
Pressurized Freshwater
Source
Waterline
Shut o
Valve
11/2”(38mm)
Discharge Fitting
1” (25mm) Discharge
Fitting
Hose
Discharge Fittings
The SeaEra QC has a straight discharge fitting
installed.A11/2”(38mm)90° tting is also provided.
Also provided is a 1” hose adapter for the 90°tting.
To change the discharge tting (FIG 6):
1. Remove four screws securing tting to base.
2. Remove ange adapter from the straight tting
andinstallitonthe90°tting.
3. Install90°ttingtobase.Becertainthejoker
valve is properly in place.
4. If 1” (25mm) discharge hose will be used, install
the1”hoseadapterintothe90°tting.Usenon
hardening thread sealant.
IMPORTANT: Do not overtighten!
L365v0320jlc
FIG 4
FIG 6
FIG 7
Intake
Seacock
Remote
Intake
Pump
Holding Tank
SeaEra Toilet
Y Valve
In-Line
Strainer
Marine Sanitation
Device
Remote Intake Pump Model Mounted
Above Waterline
Discharge
Seacock
Discharge
Vented
Loop
FIG 5

8
INSTALLATION
Remote Sea Water Models (FIG 9)
Intake pump ttings are interchangeable to allow
more exibility during installation. Inlet ports are
located on either side of intake pump. Outlet port
(to toilet bowl) is at top of intake pump (FIG 10).
NOTE: To avoid poor pump performance installa-
tion of strainer (163000) is recommended
1. Slide tting clips to open position.
2. Select inlet port to be used.
3. Install appropriate ttings into inlet and outlet
ports.
NOTE: e90°ttingcanberotated360°.
4. Install the plug tting into unused inlet port.
IMPORTANT: Be sure not to install plug tting into
outlet port! Damage to pump will occur!
5. Slide tting clips back to closed position.
6. Connect hose from seacock to inlet port of
optional In-Line Strainer if installed. Use hose
clamp provided.
7. Connect hose from outlet port of In-Line
Strainer to inlet port of intake pump. Use hose
clamp provided.
IMPORTANT: Double clamp all below waterline
hose connections!
8. Connecthosefromoutletportofintakepump
to bowl elbow located on back of toilet bowl.
Mounting Remote Pump (FIG 11):
1. Locate remote pump between thru hull tting
and toilet bowl.
2. Locate in an area away from berth to keep noise
level down.
3. Use Inline Strainer (optional) to avoid clogs.
4. Secure remote pump to the oor using four
bolts through the pump base.
Intake Lines
Pressurized Freshwater Models
1. Install a shut o valve in intake line before
water solenoid valve.
2. Connect hose from shut o valve to inlet port of
watersolenoidvalve(FIG8).
NOTE: To avoid malfunction of water solenoid due to
debris in water, installation of Freshwater Strainer
(190601) is recommended.
L365v0320jlc
FIG 8
FIG 11
Inlet Ports
Outlet Port
Arrow
FIG 10
Open
Closed
FIG 9

TROUBLESHOOTING
WARNING: HAZARD OF ELECTRIC SHOCK - Before beginning any work on the SeaEra, be sure that all
power to the unit has been turned o.
WARNING: HAZARD OF FLOODING - Make sure seacocks are in the CLOSED or OFF position before
working on toilet.
NOTE: e following information reects the most probable causes and solutions to problems although not
every possible cause and solution is provided.
Any questions regarding servicing or operation of the SeaEra should be directed to our Technical Support Department
in Millville, NJ or Ft. Lauderdale, FL. Please have model and serial number available before calling.
TROUBLESHOOTING
9
PROBLEM
1. Poor pumpout, especially
solids.
2. Poor water flow, especially
at front of bowl (or no water
ow).
3. Foul odors from toilet area.
4. Bowl lls while underway.
5. Water leaking from under
unit.
6. Erratic operation/sluggish
running.
POSSIBLE CAUSE
1A. Clogged discharge line.
1B. Plumbing restrictions, bends and ells.
1C. Clogged vents.
1D. Mineral buildup in hoses and ttings.
1E. Low voltage.
2A. Toilet not level.
2B. Restriction in intake line.
2C. Pump sucking air.
2D. Low voltage.
2E. Clogged strainer.
3A. “Marine life” lodged in rim of bowl.
3B. Permeated discharge hose.
3C. Sewage remaining in discharge line.
4A. Pressure buildup at seacocks.
5A. Leaking bowl gasket.
5B. Leak at sha seal.
5C. Leak from seal plate area.
6A. Worn motor brushes.
6B. Motor bearings damaged by seal leak.
6C. Low or inconsistent voltage.
1A. Be sure discharge seacock is open. Clear line, remove
clog.
1B. Replumb to eliminate bends and ells.
1C. Clean holding tank vent and vented loop vents
1D. Clean or replace aected parts. Replace hose if needed.
1E. Check voltage at toilet while toilet is running. If less
than nominal voltage of toilet (12, 24), check condi-
tion of batteries and wire sizes. Check terminals and
wire connections for corrosion (heat at terminals and
junctions indicates a bad or corroded connection).
2A. Raise rear of toilet; check with level.
2B. Be sure seacock is open. Clear line-remove clog.
2C. Check all connections from intake thru-hull to intake
pump to be sure no air leaks are present.
2D. See 1E, above.
2E. Remove or clear debris from strainer.
3A. Remove and ush bowl with pressure hose to remove
all material. Install strainer or KO2 kit in intake line
to avoid recurrence.
3B. Replace hose with Raritan sanitation hose (#SFH).
3C. Flush longer; replace hose if permeated; reroute hose
making a shorter run or downward slope if possible.
4A. Close intake, then discharge seacock to determine
which is causing problem. If discharge, be sure the
vent or vented loop is clean. If intake, there is too
much pressure on seacock; contact Raritan Technical
Support.
5A. Tighten (4) bowl mounting nuts (#1226B).
5B. Check seal and motor sha.
5C. Check seal plate o-ring.
6A. Return motor to factory for servicing or replacement.
6B. Return motor to factory for servicing or replacement.
6C. See 1E above.
Set screw must be loosened with
1/8”hexkeybeforeremovingthe
intake pump from motor
Tip for Removing Intake Pump
Plug
L365v0320jlc
SOLUTION

EXPLODED PARTS
Item Part# Description
1 1237W Marine-size Bowl
1 1244W Household-style Bowl
2 1236AW Bowl Spud Assembly
3 1236E Bowl Elbow (sea water only)
4 221361 Sealing Washer
5 1234 Bowl Gasket
6 VCAP White Vinyl Cap
7 1226B 1/4-20 Hex Nut (4)
8 RNI ShoulderWasher
9 CH38 1/4-20X2readedstud
10 161105 Base
11 C254 Joker Valve
12 161130 Discharge Fitting
13 1222D 90°DischargeFitting
14 161125 Discharge Mounting Flange
15 F164 Discharge Mounting Flange Fastener(4)
16 161107 Seal Plate O-Ring
17 1108A MaceratorNut
18 M23A MaceratorLockwasher(5)
19 161123 Macerator Blade
20 161120 Impeller/Macerator Housing
21 161115 Impeller
21A F237 Washer- D Shape
22 31-102 Sha Seal
23 161110 Seal Plate
24 1610* Discharge Motor
25 HW1 Mounting Screw Lockwasher (4)
26 F098 1/4-20x1”hex(4)
29 PLA34 Adapter: 1” MPT xHS
41 162420 Fitting Clip (3)
43 162425 Fitting O-Ring (4)
45 162405 3/4”HoseBarb-90°Fitting
47 162415 Plug Fitting
50 162410 3/4” Hose Barb - Straight Fitting
51 190601 Inline Fresh Water Strainer (Optional)
61 163000 Inline Strainer (Optional)
SeaEra QC model 162 PARTS LIST
Additional Parts Included with
REMOTE MODELS
Item Part# Description
27 161135 Motor Cover
62 1660*A Intake Motor
166000 Remote Intake Pump, 12V DC
166100 Remote Intake Pump, 24V DC
64 162000W Diaphragm Pump Assy.
(Includes 162420, 162425)
Additional Parts Included with Freshwater models
Item Part# Description
70 161145 Motor cover
71 221351 Water Solenoid 12 Volts
71 221352 Water Solenoid 24 Volts
72 PLH-50P Hose, white 1/2”, 1 FT.
73 PLE90-50N 1/2” 90 deg Hose Barb Elbow
74 221366 Clips
75 161146 Grommet plate
76 F201 Screw M4 x 10mm
77 221357 Hose adapter straight
80 168006  Vacuumbreakcover
81 221360  O-ring
82 25309  Nut3/4FNPT
83 221300  Vacuumbreakerassy.
DISCHARGE ASSEMBLY
Item Part# Description
16-24 162012W Discharge Assembly w/o intake pump 12V
16-24 162024W Discharge Assembly w/o intake pump 24V
Repair Kits
DIAPUMPRK Diaphragm Pump Repair Kit
SEADISRK SeaEra Discharge Repair Kit
* Specify DC Voltage (12, 24)
10
L365v0320jlc
841238SCSlowCloseMarine-sizeSeatandCover 
841245SCSlowCloseHousehold-styleSeatandCover

11
EXPLODED PARTS
SeaEra QC Series Exploded Parts View
Optional
Sea Water
Strainer
Optional
Fresh Water
Strainer
L365v0320jlc
84

L365v0320jlc Specications Subject to Change Without Notice Printed in U.S.A.
530 Orange Street, Millville, NJ 08332 USA
Telephone: [phone] FAX: [phone]
www.raritaneng.com
Fort Lauderdale, FL 33315 USA
Telephone: [phone]
LIMITED WARRANTY
Raritan Engineering Company warrants to the original purchaser that this product is free of defects
in materials or workmanship for a period of two years from the product’s date of purchase. Should
this product prove defective by reason of improper workmanship and/or materials within the war-
ranty period, Raritan shall, at its sole option, repair or replace the product.
1. TO OBTAIN WARRANTY SERVICE, Consumer must deliver the product prepaid, together with
adetaileddescriptionoftheproblem,toRaritanat530OrangeSt.,Millville,N.J.08332.When
requesting warranty service, purchaser must present a sales slip or other document which estab-
lishes proof of purchase. THE RETURN OF THE OWNER REGISTRATION CARD IS NOT A
CONDITION PRECEDENT OF WARRANTY COVERAGE. However, please complete and return
the owner Registration Card so that Raritan can contact you should a question of safety arise which
could aect you.
2. THIS WARRANTY DOES NOT COVER defects caused by modications, alterations, repairs or
service of this product by anyone other than Raritan; defects in materials or workmanship supplied
by others in the process of installation of this product; defects caused by installation of this product
otherthanin accordancewith themanufacturer’srecommendedinstallationinstructionsorstandard
industry procedures; physical abuse to, or misuse of, this product. is warranty also does not cover
damages to equipment caused by re, ood, external water, excessive corrosion or Act of God.
 3.ANYEXPRESSWARRANTYNOTPROVIDEDHEREIN,ANDANYREMEDYFORBREACH
OF CONTRACT WHICH BUT FOR THIS PROVISION MIGHT ARISE BY IMPLICATION OR
OPERATIONOFLAW, ISHEREBYEXCLUDED AND DISCLAIMED. ALLIMPLIEDWAR-
RANTIES SUCH AS THOSE OF MERCHANTABILITY AND OF FITNESS FOR A PARTICULAR
PURPOSE,IFAPPLICABLE,ASWELLASANYIMPLIEDWARRANTIES WHICHMIGHTARISE
BYIMPLICATIONOFLAW,AREEXPRESSLYLIMITEDTOATERMOFONEYEAR.SOME
STATES DO NOT ALLOW LIMITATIONS ON HOW LONG A LIMITED WARRANTY LASTS,
SO THE ABOVE LIMITATION MAY NOT APPLY TO YOU.
4. UNDERNOCIRCUMSTANCESSHALLRARITAN BELIABLETOPURCHASERORANYOTHER
PERSONS FOR ANY SPECIAL OR CONSEQUENTIAL DAMAGES, WHETHER ARISING OUT
OF BREACH OF WARRANTY, BREACH OF CONTRACT, OR OTHERWISE. SOME STATES DO
NOTALLOWTHEEXCLUSIONORLIMITATIONOFINCIDENTALORCONSEQUENTIAL
DAMAGES,SOTHEABOVELIMITATIONOREXCLUSIONMAYNOTAPPLYTOYOU.
5. No other person or entity is authorized to make any express warranty, promise or armation of
fact or to assume any other liability on behalf of Raritan in connection with its products except as
specically set forth in this warranty.
6. is warranty gives you specic legal rights, and you may also have other rights which vary from
state to state.
12
