RASOR NERA Mounting instructions

BATTERY SCISSORS
USE MANUAL
NERA NERA

2
EN
COMPANY
ACKNOWLEDGMENT
Dear Customer,
thank you for choosing a Rasor®Elettromeccanica S.r.l. product.
Rasor®has been a reference point in the field of cutting systems in the textile, clothing,
furniture, tailoring, sport, chemical, automotive, nautical and insulating material sectors for
years. Its production has been always synonymous with reliability attested by many of
satisfied customers.
Rasor®quality system supervises all the company activities in order to provide the Customer
with a service that meets its needs and expectations in terms of product quality, delivery
reliability and stock of finished products.
All the parts of the devices have been planned and produced to guarantee an optimum
performance. In order to keep the high quality level and the long reliabilty of the Rasor®
products, it is recommended using only original spare parts and to contact the head office
for any maintenance work.
Rasor®Elettromeccanica S.r.l. was established in Milan in 1946 by Luigi Spinelli. For more
than sixty years it has been producing automatic cutting systems, cutting units for textile
applications and electric and pneumatic cutters.
Initially considered as a point of reference for cutting systems in the
textile applications, the Rasor®products are nowadays widely used in
other fields: chemical, automotive, nautical and sport sectors and in
furniture manufacturing.
Nowadays Rasor®can rely on the professional continuity of two
generations, with the experience inherited from the promoting partner, with his passion
and dedication.
The main characteristic of Rasor®is that each working phase, starting from the manufacturing
of the product up to its packing and delivery is carried out in Rasor®premises by qualified
operators who have professionaly grown up following the spirit of the company and of its
founders. This ensures the high quality which Rasor®has always considered as essential
since the beginning of its activity.
Following the innovative spirit mentioned above, our company is constantly focused on the
improvement of the product quality, on the study and development of new materials and
technologies.

EN
3
1. GENERAL SAFETY RULES
This manual is an integral part of battery scissors NERA and must be carefully
read before using it, since it gives important indications with regards to its
safe installation, use and maintenance. Keep it with care.
Before using battery scissors NERA, read carefully the following general safety
rules.
• PACKAGING.
After taking off the packaging make sure that the battery scissors are intact.
In case of doubt do not use them and contact an authorized service centre.
Do not leave pieces of packaging (plastic bags, foam polystyrene, boxes, etc.)
within the reach of children or disabled persons, since they are potential sources
of danger.
• AVOID DANGEROUS ENVIRONMENTS.
Prevent the battery scissors NERA components from coming in contact with
damp or wet surfaces.
•KEEPCHILDRENAWAY.
Unauthorized persons, in particular children, must be kept away from the
working area.
• KEEP THE WORKING AREA ALWAYS IN ORDER.
The workplace must always be kept in order and well lightened; liquids or oil
traces must not be present.
• ALWAYS USE BATTERY SCISSORS NERA PROPERLY.
Usethebatteryscissorsonlytocarryouttheworkstheyhavebeendesigned
for; do not use them improperly.
• OBSERVE THE USE OF THE TOOLS.
Do not cut excessively thick materials and always check blade conditions.
• AVOID ACCIDENTAL STARTINGS.
Before connecting battery scissorsNERA, make sure that everything is installed
properly.
• CLOTHING.
Do not use large clothes or accessories that might get stuck in the moving
parts.
• GOGGLES AND PROTECTIVE METAL MESH GLOVES.
Always use goggles, protective metal mesh gloves approved by Rasor®during
use and maintenance operations (according to UNI EN 388:2017 standard).
•SPAREPARTS.
During maintenance and replacement operations use only original spare parts.
Blade maintenance must be only performed by Rasor®technicians.
• INSTALLATION.
Any installation that is not in conformity with these specifications could jeopardize
your safety and cancels the warranty.

4
EN
ALL RIGHTS ARE RESERVED ACCORDING TO THE
INTERNATIONALCOPYRIGHT CONVENTIONS,
The reproduction of any part of this manual, in any form, is forbidden without
the prior written authorization of Rasor®Elettromeccanica S.r.l.
The content of this guide can be modified without prior notice. Great care has
been taken in collecting and checking the documentation contained in this
manual to make it as complete and comprehensible as possible.
Nothing contained in this manual can be considered as a warranty, either
expressed or implied - including, not in a restrictive way, the suitability warranty
for any special purpose. Nothing contained in this manual can be interpreted as a
modification or confirmation of the terms of any purchase contract.
Rasor®Elettromeccanica S.r.l. products have not been conceived to work in areas at risk of
explosions and at high risk of fire and they cannot cut wet or damp materials. Moreover, they
cannot work in case of rain.
In case of damage or malfunction, battery scissors NERA must not be used until the Customer
Care Technical Service has repaired them.
The original configuration of the battery scissors must not be changed at all.
On receiving them, make sure the supply corresponds to what has been ordered.
In case of non-compliance immediately inform Rasor®.
Also make sure the scissors have not been damaged during transport.
Customer Care Technical Service
WARNING
The installer and the maintenance man must know the content of this manual. Although
the main features of the equipment described in this manual are not subject to change,
Rasor®Elettromeccanica S.r.l. reserves the right to modify the components, details
and accessories it deems necessary to improve the product or to meet manufacturing
or commercial requirements at any time and without being obliged to update this
manual immediately.
Informative letter
Forany information, please contact
RASOR®ELETTROMECCANICAS.r.l.
Via V. Caldesi, 6; 20161, MILANO (MI) - ITALY
Phone: [phone]; Fax: [phone]
e-mail: [e-mail]
web: www.rasor-cutters.com
WARNING

EN
5
3
2. TRANSPORT AND PACKING
The scissors are delivered in a cardboard with the batteries and the charger. The code of the
ordered product and its serial number are indicated outside the package (see picture 1). The
following accessories are also contained inside the cardboard (see picture 2):
1) Hexagonal blade (6 sides);
2)
3)
Drift for blade assembly/disassembly;
4)
Butterfly wrench for blade nut disassembly.
5)
Rechargeable 3.7V battery with Lithium®Ion technology (x 2);
6)
Standard charger with European or American plug;
Charging docking station for 3.7 V batteries with Lithium®Ion technology.
3. PLATE DATA
The manufacturer's identification and Machinery Directive 2006/42/EC conformity plate (see
picture below) is located on the front part of the battery scissors.
The plate must not be removed at all, even if the equipment is resold. Always refer
to the serial number (written on the plate itself) when contacting the manufacturer.
Several safety warnings are printed on a card which is applied to the battery scissors; such
warnings must be strictly followed by everyone dealing with the equipment. The company
is not to be held responsible for damage to property or accidents to people which
might occur if the above-mentioned warnings are not observed. In such a case,
the operator is the only person responsible.
1
Model
Motor data
S e r i a l
numbe r
2
Battery voltage
2
1
READ THE INSTRUCTION MANUAL
USE METAL GLOVES
USE GOGGLES
SHEARING RISK
DO NOT REMOVE THE SAFETY DEVICES
4
5
6
x 2
Year of
production

6
EN
4. PRODUCT DESCRIPTION
This manual describes battery scissors model NERA which are used in order to cut fabrics in
the textile industry, technical fabrics and light leathers. They are extremely versatile, light
and precise in the cutting operation. The 3.7 V Lithium®-Ion battery-powered miniature
motor, extremely compact and reliable, combined with a special series of blades with a
diameter of 50 mm, ensures cuts of thickness up to 9 mm. The Lithium®Ion battery
develops 2400 mAh and is easily rechargeable with the appropriate docking station complete
with LED indicator. The second battery, included in the package, allows you to cut continuously
without interrupting the work. The strong cutting foot with a thin shape allows the cutting
of curved profiles with great ease. One of the peculiarities of the battery scissors NERA is
the possibility, thanks to the presence of a grinding wheel mounted on the scissors, to be
able to sharpen the blade at any time, without disassembling it. After carrying out this
operation, it is possible to immediately resume cutting operations. A perfectly balanced
motor, with a high number of revolutions and maintenance-free, reduces vibrations to a
minimum, making the battery scissors compliant with the European Directive 2002/44/EC on
the risks deriving from mechanical vibrations. The mechanical parts are made of high quality
steel, bronze and aluminum and require lubrication after several working hours.
1
4
32
7
6
5
8
10
9
12 13
14
15
11
1 Start button 9 Blade protection guard
2 Battery Li-Ion 3,7V 10 Motor support
3 Plastic motor casing 11 Adjusting perpetual screw
4 Steel foot 12 Reference point
5 Steel polygonal blade 13 Carbide counterblade
6 Grease cup 14 Plate locking the threads
7 Emery grinding wheel 15 Upper and lower buttons for
battery disconnection
8 Sharpening button
Device components

EN
7
7. FIELD OF APPLICATIONS
6. NOISE LEVEL
NOTE
It is advisable for battery scissors NERA owners to verify the compliance with the standard
concerning safety of workers: Italian legislative decree 81/08.
The maximum acoustic pressure level emitted by battery scissors NERA is about 60 dB (A).
Noise tests have been carried out in compliance with Standard UNI EN ISO 11202:2010. The
device noise levels, measured at different distances (without any sound wave filtering system),
vary in the extent of few db (A).
Battery scissors NERA have been designed, manufactured and assembled to cut every kind
of fabrics or materials, with the exception of metal, plastic or wood, by means of rotary
blades.
This equipment must not work:
- in areas prone to explosions;
- in presence of fine dust or corrosive gases;
- to cut plastic, metal and wooden materials.
It is forbidden to use battery scissors NERA for purposes different from the above-
mentioned ones.
5. TECHNICAL FEATURES
The technical data is only indicative and it can be changed without notice
50 mm with carbide counterblade
50EEXT, EXTRA steel hexagonal
blade
900 revolutions/min
about 9 mm
DC 3,7 V - 35 W
Li-Ion 3,7 V, 2,4 Ah rechargeable
580 g
950 g
LUX 200
<2.5m/s
2
0~55°C
10 ~ 95% without condensate
Humidity
Battery
Weight (with battery)
Weight with package
Minimum luminosity for working
o
p
erations
Vibrations at the start up
Temperature
Battery scissors NERA features
Blade diameter
Blade supplied
Blade speed
Cutting working depth
Motor power
EXTRA steel hexagonal blade
HSS steel hexagonal blade
HSS steel circular blade
HSS steel decagonal blade
HSS steel decagonal blade covered
with Teflon®
HSS steel hexagonal blade covered
with Teflon®
503DHSSTF
503EHSS
Features of the available blades
503EEXT
503CHSS
503EHSSTF
503DHSS

8
EN
9. RESIDUAL RISKS
Even though the battery scissors are safe, operators must pay attention to preserve their
and other people’s safety.
At the end of the working operations, the metallic components could be very hot.
The cutting blade can work even when the protective device is disassembled.
8. USE WARNINGS
We recommend following the indications below in order to always work in safety conditions.
All the operations must be carried out complying strictly with the safety rules of the
country where the device is sold.
It is STRICTLY FORBIDDEN to smoke during the installation or adjustment operations of
the battery scissors.
The Customer undertakes to comply with and make his staff observe all the rules and
regulations in force concerning safety, prevention of accidents and health in the work
place. Therefore, the Customer assumes the responsibility to strictly follow all the rules
and regulations in force, as well as the special provisions in force in sport and public
installations the Customer declares to know after receiving all the relative necessary
pieces of information.
The battery scissors work also without their safety protective device. This
protective device must NEVER be removed.
Always check the resistance of the material to be cut and the kind of blade which is
being used.
The Customer shall equip his own personnel with all the individual safety protections for
the execution of the works, as well as with the ones which might be prescribed by the
Manufacturer due to specific danger conditions of the plant or of the area where the
personnel must work.
Only one operator must use the battery scissors always standing behind the guide
handle. Do not make any adjustment while the blade is working.
It is allowed to assemble battery scissors NERA on machines O.E.M. on condition that
their original structure is not modified. Otherwise, the intervention must be certified by
Rasor®.

EN
9
10. RULES FOR THE CARE OF THE LITHIUM-ION BATTERIES
The following rules should be noted when caring for your lithium-ion batteries if you want
to maintain the performance of the energy store for as long as possible:
Thefirstchargeiscrucial.Fullychargethebatterybeforeusingitforthefirsttime.
Each battery only has a limited number of charge cycles. Don't therefore recharge
the battery at every opportunity. Instead use it until it is almost flat (10-20% of
charge). Depending on loading, the high-quality, 2,4 Ah capacity battery cells can be
chargedupto500times.Assuming150daysareworkedayearandthatthebatteries
are charged daily, this corresponds to a battery life of 2 years.
If the battery is discharged below its nominal voltage, this can trigger processes
which damage or destroy the battery. The batteries are therefore fitted with
electronics which warn the user and shut down the device before total discharge
can take place.
Frequent overcharging can also permanently damage the battery. The charger
therefore automatically finishes the charging process as soon as the battery is fully
charged.Do not attempt to force more charge into the batteries by unplugging and
reconnecting the charger. Such action will not produce a higher charge - it will only
damage the batteries.
Charging should generally only be undertaken at room temperature (around 18 - 21
degrees). Avoid charging a cold battery as it damages the cells. Always warm the
battery up to room temperature before charging, especially when it is cold outdoors
in winter.
High temperatures also damage the battery. Never leave the battery, and preferably
not the entire tool box, in the car or direct sunlight on hot sunny days. At
temperatures above 60 degrees Celsius, the Li-ion battery permanently loses capacity.
Lithium-ion batteries shouldn't be stored flat or fully charged for long periods. Extensive
testinghasfoundacapacityof40-50%andlowtemperatures(butnotbelow0°C)
to be optimum for storage. Ideally they should be kept at 5°C to 10°C. Recharging
is needed at least every 12 months as the batteries will self-discharge.
A battery which is not being used should be stored in a cool but not cold place. Even
when not being used, batteries lose energy. The Li-ion battery loses 3-5% of its
charge a month.
If a lithium-ion battery is not used for a long period, it should be recharged after 12
months at the latest otherwise it will be irreparably damaged.
Old, used batteries must of course be disposed of in an environmentally friendly
manner.

10
EN

A
11. USE
3
To use the batteryscissors manually, proceed as follows:
1) Release the battery (if it is charged) from the
charger as described at paragraph 12;
2) Connect the battery to the motor and fix it
following the slots on the battery;
3) Lay the material to be cut on a table;
4) Put the material on the cutting foot (see picture
3);
5) Press the button under the handle to start the
scissors;
6) Push the battery scissors in the desired direction, being careful to keep the material in
front of them as stretched as possible and preventing it from curling in the front part
of the scissors.
NOTE
The thrust on the battery scissors must be as uniform
as possible. To carry out linear cuts with precision (and
to follow predetermined paths), we also recommend
using the arrow point (see point “A”inpicture4).
4

EN
11
12. BATTERY CHARGING
When the battery is empty, it is necessary to recharge it using only the special docking
station supplied with the device.
The docking station must be connected to the standard charger with European or American
plug, also supplied with the scissors.
WARNING
Always check if the charger voltage corresponds to the network voltage of the country
where the scissors are used.
Never use chargers other than those supplied (100-
240VAC, 50/60 Hz, 0.4A max - Output: 4,2V, 2A).
Remove the battery "A"fromthemotorbypressing
the appropriate orange "B" buttons on the top and
bottom of the battery (see picture 5), then insert it
into the "C" docking station as shown in picture 6.
Never use batteries other than the one supplied (3,7V
rechargeable with Lithium®Ion technology).
It is possible to control the recharging operation through
the LED light located on both the docking station and
the charger. These LEDs indicate:
- battery charging (red colour)
- fully charged battery (green colour)
Using the standard charger CH36 (with European plug)
or CH3601 (with American plug), the time required for
a full charge is approx. 4 hours.
WARNING
5
AB
6
A
C

12
EN
13. BLADE SHARPENING
After many hours of a continuative use of the battery
scissors or if they are not able to cut anymore, it is
necessary to sharp the blade. To carry out this operation,
start the blade and press sharpening button “1”for3-4
seconds (as shown in picture 7). Repeat this operation
2-3 times.
If the sharpening process should be ineffective, check
the wear of the emery grinding wheel “2”(seepicture
7). If wheel “2” is too worn or dirty, replace it by removing
the blade by means of the proper tool.
1
7
14. LUBRICATION
Every 3-4 working days, it is necessary to lubricate the
gear pair. In order to carry out this operation, remove
protective plug “A” located on the head of the battery
scissors and fill it with the grease supplied. Screw plug
“A” again a few turns. Screw plug “A” a few turns every
day (see picture 8).
The blade must never be dirty with grease or oil.
8
WARNING
A
2

EN
13
If the blade is no more able to cut (even after repeating
the sharpening operation several times) it is necessary
to replace it. In order to carry out this operation, use
butterfly wrench “1”anddrift“3”lockingtheblade
(shown in picture 9). In order to replace the blade,
proceed as follows:
1) Disconnect the battery from the machine;
2) Use someprotective gloves in compliancewith Italian
Legislative Decree 81/08.
3) Remove safety protection “B”, by unscrewing the
two slotted screws “A”bymeansofascrewdriver
(not supplied by the manufacturer), as shown in
picture 10.
4) Insert drift “3”(seepicture11)intohole“C”in
ordertolocktheblade(theholeintheblademust
correspond to the hole in the structure).
5) Use butterfly wrench “1” in order to unscrew nut
“D”andremoveblade“E”(seepicture12).
6) Replace the worn blade with the new one “2”,
being careful to center the blade on the gear, in
the correct position, and remember to assemble it
with its sharp side (the one with the writing Rasor)
positioned towards the external side of the battery
scissors.
7) Assemble all the components again and carry out
some cutting and sharpening tests.
15. BLADE REPLACEMENT
1
2
3
9
10
311
C1
12
A
A
B
1
D
E

F 5027 JOINT
14
EN
17. SPARE PARTS / EXPLODED VIEW
16. TROUBLESHOOTING
OPTIONAL ACCESSORIES
SOLUTION
V
erif
y
that the blade and the counterblade
are in contact with each other and that the
counterblade has no material residues
Check the counterblade integrity
Check the kind of fabric
Sharpen the blade
Check the fabric thickness
Check the compatibility between blade and fabric
Make sure that the motor turns correctly
Check the battery charge
Reduce the feeding speed
Carry out the lubrication
Disassemble the blade and remove the material
residues
Check the correct insertion of the battery
Check the integrity of the plastic joint
Check the battery charge
PROBLEM
The electric scissors are noisy
The scissors start slowly, work intermittently
or do not start
The fabric is not cut or it gets stuck between
the blade and the counterblade
CODE DESCRIPTION CODE DESCRIPTION CODE DESCRIPTION CODE DESCRIPTION
503EEXT EXTRA STEEL HEXAGONAL BLADE, 50
mm F 5029 5x11x4 GEAR SCREW BEARING F 5042 RING NUT FIXING THE BLADE F 5074 PLATE WITH EMERY
BA 011 MOTOR FLANGE F 5029/1 CRINKLE WASHER F 5057 DRIFT LOCKING THE BLADE F 5074CPL COMPLETE EMERY GRINDING WHEEL
UNIT
BA 012 ELECTRIC MOTOR WITH SPEED
REDUCTION GEAR F 5029/2 SEGER RING F 5059 WRENCH FOR BLADE DISASSEMBLY F 5075 EMERY GRINDING WHEEL BUSH
BA 012CPL COMPLETE MOTOR NERA504 F 502901 5x13x4 GEAR SCREW BEARING F 5065 SCREW FIXING THE FOOT F 5076 WASHER
BA 013 PLASTIC MOTOR CAP RIGHTS F 503101 ADJUSTING RING NUT F 5066 PLATELOCKINGTHETHREADS
FASTENING SCREW F5077 SPRING INSIDE THE SHARPENING
BUTTON, Ø 6 mm
BA 014 PLASTIC MOTOR CAP LEFT F 5032 GEAR RING CENTRAL PIN F 5067 PLATE LOCKING THE THREADS F 5078 SPRINGINSIDE THE SHARPENING
BUTTON, Ø 9 mm
BA 015 MOTOR CAP FASTENING SCREW F 5033 GREASER CAP F 5068 WIDIA COUNTERBLADE WITH SPRING F 5079 SHARPENING BUTTON
BA 016 PLASTIC BUTTON F 5034 GREASING CUP F 5069 SCREW FIXING THE COUNTERBLADE F 5080 SCREW FIXING THE SHARPENING
BUTTON
BA 017 BUTTON SPRING F 5036 SHIM ADJUSTMENT WASHER F 5070 STEEL FOOT F 5082 GEAR ENDLESS SCREW
BA 018 STARTING BUTTON F 5037 RING NUT FIXING THE BEARING F 5070CPL COMPLETE FOOT F 5082CPL COMPLETE ENDLESS SCREW
BA 019 CONTACT TERMINALS F 5038 GEAR RING BEARING F 5071 BLADE PROTECTION GUARD F 5083CPL COMPLETE GEAR CROWN
BA 020 REDUCER FLANGE FIXING SCREW F 5040 SCREW FIXING THE GEAR RING F 5071/1 SCREW FIXING THE BLADE
PROTECTION GUARD F 5084CPL COMPLETE MOTOR SUPPORT
F 5084SET COMPLETE CUTTING PART
FRNN504 NERA COMPLETE ACCESSORY SET
CODE DESCRIPTION
BAT36 3.7 V, 2400 mA Li-Ion

BATTERY
DK36 DOCKING STATION
CH36 100-240 V CHARGER EU PLUG
CH3601 100-240 V CHARGER US PLUG
BA 021 ENGINE SUPPORT FASTENING SCREW

FRNN504
503EEXT
F5059
F5057
F5079
F5080
F5029/2
F5027
BA020
BA020
F5029/1
F5029
F502901
F5033
F5034 F5032
F503101
F5082CPL
F5082
F5076
F5077
F5075
F5074
F5078
F5036
F5037
F5038
F5038
F5040
503EEXT
F5042
F5071
F5071/1
F5074
F5084SET
BA012CPL
BAT36
BA014
BA013
BA015
BA012
BA011
BA019
BA019
BA017
BA017
BA018
BA016
BAT36 CH36
(EU PLUG)
CH3601
(US PLUG)
DK36
CPL
F5084CPL
F5083CPL
F5067
F5066
F5065
F5070
F5069
F5068
F5070CPL
BA021
BA021

WARRANTY
Rasor®Elettromeccanica S.r.l. battery scissors have a 12 month warranty from the date
indicated on the last page of this manual, except in case of different written agreements.
The warranty covers all manufacturing and material defects. Replacement and repair operations
are covered only if carried out by our company and at our workshop. If in-warranty goods
need to be repaired, the customer must always send the complete machine to Rasor®.
Single units will not be repaired under warranty.
The material to be repaired must be sent CARRIAGE FREE.
Once the equipment has been repaired, it will be sent CARRIAGE FORWARD to the customer.
The warranty covers neither technicians' intervention on the site where the battery scissors
are used nor their disassembly.
If for practical reasons, one of our technicians is sent to the premises, the customer will be
charged the costs plus the travelling expenses.
The warranty does not include:
failure caused by wrong use or assembly,
failure caused by external agents,
failure caused by lack of maintenance or neglicence;
blades and parts subject to wear.
WARRANTY FORFEITURE:
In case of arrearage or other breaches of contract,
Whenever changes or repairs are carried out on our battery scissors without our
prior authorization,
Whenever the serial number is tampered with or cancelled,
Whenever the damage is caused by improper use, bad treatment, bumps, falls and
other causes not due to normal working conditions,
Whenever the unit seems tampered with, dismantled or previously repaired by
unauthorized staff,
In case the battery scissors are used for purposes that are different from the ones
described in this manual.
In case non-original Rasor®spare parts are installed.
All repair operations carried out under warranty do not interrupt its duration.
All disputes will be settled in the court of justice of Milan (Italy).
We thank you in advance for the attention you will pay to this manual and we invite you to
inform us of any change you deem necessary to improve it and make it more complete.

RASOR ELETTROMECCANICA SRL
Via Vincenzo Caldesi 6
20161 Milan ∙ Italy
ph. [phone]
fax [phone]
[email protected]
www.rasor-cutters.com
FOLLOW US:
