RASOR ZERO702 Mounting instructions

USE MANUAL
ED.1-01/14
English
BATTERYSCISSORS
MOD.ZERO702
SERIALNUMBER

2
EN
COMPANY
ACKNOWLEDGMENT
DearCustomer,
thankyouforchoosingaRasor®ElettromeccanicaS.r.l.product.
Rasor®hasbeenareferencepointinthefieldofcuttingsystemsinthetextile,clothing,
furniture,tailoring,sport,chemical,automotive,nauticalandinsulatingmaterialsectorsfor
years.Itsproductionhasbeenalwayssynonymouswithreliabilityattestedbymanyof
satisfiedcustomers.
Rasor®qualitysystem supervisesall thecompanyactivities in orderto providetheCustomer
withaservicethatmeets its needsandexpectations intermsof productquality,delivery
reliabilityandstock of finishedproducts.
Allthepartsofthedeviceshavebeenplannedandproducedto guaranteeanoptimum
performance.InordertokeepthehighqualitylevelandthelongreliabiltyoftheRasor®
products,itisrecommendedusingonlyoriginalsparepartsandtocontacttheheadoffice
foranymaintenancework.
Rasor®ElettromeccanicaS.r.l.wasestablishedinMilanin1946 byLuigiSpinelli.Formore
thansixtyyearsithasbeenproducingautomaticcuttingsystems,cuttingunits fortextile
applications andelectricandpneumaticcutters.
Initiallyconsideredasapointof referenceforcuttingsystemsinthe
textileapplications,theRasor®products arenowadayswidelyusedin
otherfields:chemical,automotive,nauticalandsportsectorsandin
furnituremanufacturing.
Rasor®canrelyontheprofessionalcontinuityof three generations,
thanksto theprecious supportof thepromotingpartner,to hispassion,dedicationandgreat
experienceof seventyyears.
Themaincharacteristicof Rasor®isthateachworkingphase,startingfromthemanufacturing
of theproductupto its packinganddelivery,iscarriedoutinRasor®premisesbyqualified
operatorswhohaveprofessionalygrownupfollowingthespiritof thecompanyandof its
founders.ThisensuresthehighqualitywhichRasor® hasalwaysconsideredasessentialsince
thebeginningof its activity.
Followingtheinnovativespiritmentionedabove,ourcompanyisconstantlyfocusedonthe
improvementof theproductquality,onthestudyanddevelopmentof newmaterialsand
technologies.

EN
3
1.GENERALSAFETY RULES
Thismanualisanintegralpartof batteryscissorsZERO702 andmust becarefully
readbeforeusingit,sinceitgivesimportantindicationswithregardstoitssafe
installation,useandmaintenance.Keepitwith care.
BeforeusingbatteryscissorsZERO702,readcarefullythefollowinggeneral
safetyrules.
•PACKAGING.
Aftertakingoffthepackagingmakesurethatthebatteryscissorsareintact.In
caseofdoubtdonotusethemandcontactanauthorizedservicecentre.Do
notleavepiecesofpackaging(plasticbags,foampolystyrene,boxes,etc.)
withinthereachofchildrenordisabledpersons,sincetheyarepotentialsources
ofdanger.
•AVOIDDANGEROUSENVIRONMENTS.
PreventthebatteryscissorsZERO702componentsfromcomingincontact
withdamporwetsurfaces.
•KEEPCHILDRENAWAY.
Unauthorizedpersons,inparticularchildren,mustbekeptawayfromtheworking
area.
•KEEPTHE WORKINGAREAALWAYSINORDER.
Theworkplacemustalwaysbekeptinorderandwell lightened;liquidsoroil
tracesmustnotbepresent.
•ALWAYSUSEBATTERYSCISSORSZERO702PROPERLY.
Usethebatteryscissorsonlytocarryouttheworkstheyhavebeen designed
for;donotusethemimproperly.
•OBSERVETHEUSEOFTHE TOOLS.
Donotcutexcessivelythickmaterialsandalwayscheckbladeconditions.
•AVOIDACCIDENTALSTARTINGS.
BeforeconnectingbatteryscissorsZERO702,makesurethateverythingis
installedproperly.
•CLOTHING.
Donotuselargeclothesoraccessoriesthatmightgetstuck inthemoving
parts.
•GOGGLESANDPROTECTIVEMETALMESHGLOVES.
Always usegoggles,protectivemetalmesh glovesapprovedbyRasor®during
useandmaintenanceoperations(accordingtoUNIEN388:2004standard).
•SPAREPARTS.
Duringmaintenanceandreplacementoperations useonlyoriginalspareparts.
Blademaintenancemust beonlyperformedbyRasor®technicians.
•INSTALLATION.
Anyinstallationthatisnot inconformitywiththesespecifications couldjeopardize
yoursafetyandcancelsthewarranty.

4
EN
ALLRIGHTSARERESERVEDACCORDINGTOTHE
INTERNATIONALCOPYRIGHTCONVENTIONS,
Thereproductionof anypartof thismanual, inanyform,isforbiddenwithoutthe
priorwrittenauthorizationof Rasor®ElettromeccanicaS.r.l.
Thecontentof thisguidecanbemodifiedwithoutpriornotice.Greatcarehas
beentakenincollectingandcheckingthedocumentationcontainedinthis
manualto makeitas completeandcomprehensibleaspossible.
Nothingcontainedinthismanualcanbeconsideredasawarranty,either
expressedorimplied-including,not inarestrictiveway,thesuitabilitywarranty
foranyspecialpurpose.Nothingcontainedinthismanualcanbeinterpretedasa
modificationorconfirmationof thetermsof anypurchasecontract.
Rasor®ElettromeccanicaS.r.l.products havenot beenconceivedtoworkinareasatriskof
explosions andathigh riskof fireandtheycannotcutwetordampmaterials.Moreover,they
cannotworkincaseofrain.
Incaseof damageormalfunction,batteryscissorsZERO702mustnotbeuseduntilthe
CustomerCareTechnicalServicehasrepairedthem.
Theoriginalconfigurationof thebatteryscissorsmustnot bechangedatall.
Onreceivingthem,makesurethesupplycorrespondstowhathasbeenordered.
Incaseofnon-complianceimmediatelyinformRasor®.
Alsomakesurethescissorshavenotbeen damagedduringtransport.
CustomerCareTechnicalService
WARNING
Theinstallerandthemaintenancemanmustknowthecontentof thismanual.Although
themain featuresoftheequipmentdescribedin thismanualarenot subjecttochange,
Rasor®ElettromeccanicaS.r.l.reservestherightto modifythecomponents,details
andaccessories itdeemsnecessaryto improvetheproductorto meetmanufacturingor
commercialrequirements atanytimeandwithoutbeingobligedto updatethismanual
immediately.
Informativeletter
WARNING
RASOR
Foranyinformation,pleasecontact
RASOR®ELETTROMECCANICA S.r.l.
ViaV.Caldesi,6;20161,MILANO(MI)-ITALY
Phone:[phone];Fax:[phone]
e-mail: [e-mail]
web: www.rasor-cutters.com

EN
5
4
2.TRANSPORTAND PACKING
Thescissorsaredeliveredinacarryingcasewiththebatteryandthecharger.Thecodeof the
orderedproductandits serialnumberareindicatedoutsidethepackage(see picture1).The
followingaccessoriesarecontainedinabaginsidethecarryingcase:
1)Quadrangularblade(4sides);
2)Greasetube;
3)Driftforbladeassembly/disassembly;
4)Butterflywrenchforbladenutdisassembly.
2
2
3.PLATE DATA
Themanufacturer'sidentificationandECSTANDARD2006/42/ECconformityplate(see picture
below) islocatedonthefrontpartof thebatteryscissors.
The plate mustnotbe removedatall, evenifthe equipment isresold.Alwaysrefer
totheserialnumber(writtenontheplateitself)whencontactingthemanufacturer.
Severalsafetywarningsareprintedonacardwhichisappliedto thebatteryscissors;such
warningsmust bestrictlyfollowedbyeveryonedealingwiththeequipment. Thecompanyis
nottobe heldresponsiblefordamagetopropertyoraccidentstopeoplewhich
might occur iftheabove-mentionedwarnings arenotobserved.Insuch acase,
theoperatoristheonlypersonresponsible.
1
Serialnumber
Yearofproduction
Model
Motor
data
3
ZERO702 ZE_____ 18
600-1000 400
Batteryvoltage
READ
THE
INSTRUCTION
MANUAL
DONOT
REMOVE
THE
SAFETY
DEVICES
SHEARING
RISK
USE
METAL
GLOVES
USE
GOGGLES
1

6
EN
4. PRODUCTDESCRIPTION
ThismanualdescribesbatteryscissorsmodelZERO702 whichareusedinorderto quicklycut
fabricsinthetextileindustry,technicalandcompositefabrics.Theyareextremelyversatile,
lightandpreciseinthecuttingoperation.Thanksto theuseof asupportingfrontfootandof
aneffectivecuttingsystemwith quadrangularblade,itispossibleto usethebatteryscissors
to cutdifferentmaterials.Inparticularthescissorshavebeendesignedto cutdifficultmaterials
such asmoquettes,polymericmaterials,fiberglass,insulations andleather(even hide).
Onespecialfeatureof batteryscissorsZERO702 is theirabilityto sharpenthebladeineach
moment,withoutdisassemblingit,bymeans of agrindingwheelmountedonthescissors
head.Aftercarryingoutthisoperation,itispossibleto immediatelystartcuttingagain.A
highpowermotor,perfectlybalanced,withahighnumberof revolutions andtotallyfree of
maintenance,reducesthevibrations to theminimum.Forthisreasonthebatteryscissors
complywithLegislativeDecree no 187 dated19/8/2005, whichadopts EuropeanDirectiveno
2002/44/ECconcerningtherisksderivingfrommechanicalvibrations.
Themechanicalparts aremadeof high-qualitysteel,bronzeandaluminium andrequire
lubricationafterseveralworkinghours.
1
413
7
9
10
3
12 11
5
8
6
14
2
15
16
1Slidingswitch 9 Frontprotectionguard
2BatteryLi-Ion18VwithLED 10 Motorsupport
3Plasticmotorcasing 11 Backprotectionguard
4Steelfoot 12 Referencepoint
5Steelpolygonalblade 13 Carbidecounterblade
6Greaser 14 Platelockingthethreads
7Emerygrindingwheel 15 Bladespeedregulator
8Sharpeningbutton 16 Buttonforbattery
disconnection
Device components

EN
7
7.FIELDOFAPPLICATIONS
6.NOISE LEVEL
NOTE
It isadvisableforbatteryscissorsZERO702 ownersto verifythecompliancewiththestandard
concerningsafetyof workers:Italianlegislativedecree 81/08.Theuseof earprotecting
devicesiscompulsory.
Themaximum acousticpressurelevelemittedbybatteryscissorsZERO702 isabout60 dB(A).
Noisetests havebeen carriedoutin compliancewith StandardUNIENISO11202:2010. The
devicenoiselevels,measuredatdifferentdistances(withoutanysoundwavefilteringsystem),
varyintheextentof fewdb (A).
BatteryscissorsZERO702 havebeendesigned,manufacturedandassembledto cuteverykind
of fabricsormaterials,withtheexceptionofmetal,plasticorwood,bymeans of rotary
blades.
Thisequipmentmust not work:
-in areas proneto explosions;
-in presenceof finedustorcorrosivegases;
-to cutplastic,metalandwoodenmaterials.
ItisforbiddentousebatteryscissorsZERO702 for purposesdifferentfromthe
above-mentionedones.
5.TECHNICALFEATURES
The technical data isonlyindicative andit canbe changedwithout notice
HSSsteelquadrangularblade Ø70mm
HSS steel hexagonalbladeØ70mm
ExtrasteelcircularbladeØ70mm
HSS steel decagonalbladeØ70mm
Teflon® coatedHSS steel quadrangular
bladeØ70mm
Teflon®coatedHSSsteelhexagonal
blade Ø70mm
Integralcarbidehexagonalblade
Ø70 mm
70EHSS
Featuresoftheavailableblades
70SHSS
70CEXT
70EMD
70DHSS
70SHSSTF
70EHSSTF
70mm withcarbide counterblade
70SHSS,HSS steelquadrangular
blade 70 mm
600-1000 revolutions/min,
adjustable
about20 mm
DC18 V-400 W
Li-Ion18 V,3.0AhwithLED
indicator
1900 g
4400 g
LUX200
<2.5m/s
2
0~55°C
10 ~95%withoutcondensate
BatteryscissorsZERO702features
Blade diameter
Blade supplied
Blade speed
Cuttingworkingdepth
Motorpower
Humidity
Battery
Weight(withbattery)
Weightwithpackage
Minimumluminosityforworking
operations
Vibrationsatthe startup
Temperature

8
EN
9. RESIDUALRISKS
Eventhoughthebatteryscissorsaresafe,operatorsmust payattentionto preservetheirand
otherpeople’ssafety.
LAttheendof theworkingoperations,themetalliccomponents couldbeveryhot.
LThecuttingbladecanworkevenwhentheprotectivedeviceisdisassembled.
8.USE WARNINGS
We recommendfollowingtheindications belowinorderto alwaysworkinsafetyconditions.
·All theoperations must becarriedoutcomplyingstrictlywiththesafetyrulesof the
countrywherethedeviceissold.
·It is STRICTLY FORBIDDENto smokeduringtheinstallation oradjustmentoperations of
thebatteryscissors.
·TheCustomerundertakesto complywithandmakehisstaff observeall therulesand
regulations inforceconcerningsafety,preventionof accidents andhealthinthework
place.Therefore,theCustomerassumestheresponsibilityto strictlyfollowall therules
andregulations inforce,aswell asthespecialprovisions inforceinsportandpublic
installationstheCustomerdeclarestoknowafterreceivingalltherelativenecessarypieces
of information.
·Thebatteryscissorswork alsowithouttheir safetyprotectivedevice.This
protectivedevicemustNEVERbe removed.
·Alwayscheck theresistanceof thematerialto becutandthekindof bladewhichisbeing
used.
·TheCustomershall equiphis own personnelwith all theindividualsafetyprotections for
theexecutionof theworks,aswell aswiththeoneswhichmightbeprescribedbythe
Manufacturerdueto specificdangerconditions of theplantorof thearea wherethe
personnelmust work.
·Onlyoneoperatormust usethebatteryscissorsalwaysstandingbehindtheguidehandle.
Donot makeanyadjustmentwhilethebladeisworking.
·It isallowedto assemblebatteryscissorsZERO702 onmachinesO.E.M.onconditionthat
theiroriginalstructureisnot modified.Otherwise,theinterventionmust becertifiedby
Rasor®.

EN
9
10.RULES FOR THECAREOFTHELITHIUM-ION BATTERIES
Thefollowingrulesshouldbenotedwhencaringforyourlithium-ionbatteriesifyouwant
tomaintaintheperformanceoftheenergystoreforaslongaspossible:
·Thefirstchargeiscrucial.Fullychargethebatterybeforeusingitforthefirsttime.
·Eachbatteryonlyhasalimitednumberofchargecycles.Don'tthereforerechargethe
batteryateveryopportunity.Insteaduseituntilitisalmostflat(10...20%ofcharge).
Dependingonloading,thehigh-quality,3Ah capacitybatterycells canbecharged
upto2,000times.Assuming250daysareworkedayearandthatthebatteriesare
chargeddaily,this corresponds toabatterylifeof8years.
·IIfthebatteryisdischargedbelowitsnominalvoltage,thiscantriggerprocesses
whichdamageordestroythebattery.Thebatteriesarethereforefittedwithelectronics
which warn theuserandshutdown thedevicebeforetotaldischargecan takeplace.
·Frequentoverchargingcanalsopermanentlydamagethebattery.Thechargertherefore
automaticallyfinishes thechargingprocess as soonasthebatteryis fullycharged.Do
notattempttoforcemorechargeintothebatteriesbyunpluggingandreconnecting
thecharger.Suchactionwill notproduceahighercharge-itwillonlydamagethe
batteries.
·Chargingshouldgenerallyonlybeundertakenatroomtemperature(around18-21
degrees).Avoidchargingacoldbatteryasitdamagesthecells.Alwayswarmthe
batteryuptoroom temperaturebeforecharging,especiallywhen itiscoldoutdoors
inwinter.
·Hightemperaturesalsodamagethebattery.Neverleavethebattery,andpreferably
nottheentiretoolbox,inthecarordirectsunlightonhot sunnydays.Attemperatures
above60 degreesCelsius,theLi-ionbatterypermanentlylosescapacity.
·Lithium-ionbatteriesshouldn'tbestoredflatorfullychargedforlongperiods.Extensive
testinghasfoundacapacityof40...50 %andlowtemperatures (butnotbelow0°C)
tobeoptimum forstorage.Ideallytheyshouldbekeptat5°Cto10°C.Rechargingis
neededatleast every12monthsas thebatteries willself-discharge.
·Abatterywhichisnot beingusedshouldbestoredinacoolbutnotcoldplace.Even
whennot beingused,batteriesloseenergy.TheLi-ionbatteryloses3...5%ofits
chargeamonth.
·Ifalithium-ion batteryisnotusedforalongperiod,itshouldberechargedafter12
months atthelatestotherwiseitwillbeirreparablydamaged.
·Old,usedbatteriesmustofcoursebedisposedofinanenvironmentallyfriendly
manner.

10
EN
A
11. USE
3
Tousethebatteryscissorsmanually,proceedasfollows:
1) Releasethebattery(ifitischarged)fromthe
chargerasdescribedatparagraph 13;
2) Connectthebatteryto themotorandfixit
followingtheslotsonthebattery;
3) Laythematerialto becuton atable;
4) Putthematerialonthecuttingfoot(see picture
3);
5) Lettheswitchslideforwardinorderto startthe
scissors;
6) Push thebatteryscissorsinthedesireddirection,
beingcarefulto keepthematerialinfrontofthem
asstretchedaspossibleandpreventingitfrom
curlinginthefrontpartof thescissors.
NOTE
Thethrustonthebatteryscissorsmust beasuniformas
possible.Tocarryoutlinearcuts withprecision(andto
followpredeterminedpaths),wealsorecommendusing
thearrowpoint(see point“A”inpicture4).
4
12.SPEEDREGULATION
5
ThescissorsZERO702 havearegulatorfor6speedlevels
(see picture5).It ispossibleto changethespeedalso
whenthescissorsareworking.Thebladespeedcango
from600 rpm(Pos.“1”) to 1000 rpm.
The“standard” positionisposition“2”formostmaterials.
It is advisableto uselowspeedlevels forhard,gummy,
plasticoradhesivematerials.Highspeedlevelsareinstead
suggestedfornaturalfibersandsimplefabricsorwhen
araisedspeedisneeded.
WARNING
Usingthebattery scissorsZERO702 with highbladespeedacceleratesthewearof
themovingpartssuch asblade,counterbladeandgearpair.
Thehighbladespeeddeterminesalsoafasterloss ofbatterycharge.

EN
11
13. BATTERYCHARGING
Whenthebatteryisdischarged,itisnecessaryto chargeitusingexclusivelythecharger
providedwiththetool.
WARNING
Alwayscheck ifthechargervoltagecorrespondsto thenetworkvoltageof thecountrywhere
thescissorsareused.
DoNOTusechargersthataredifferentfromtheoneprovided(FEINALG 50 -50Hz/230V-
10,8-18V)-(FEINALG 30 -50Hz/230V-10,8-18Voptional).
Releasethebatteryfromthemotorbypushingtheorangebutton,theninsertitinthecharger
followingtheinstructions writtenonthemanualprovidedwiththecharger.
Neverusebatteriesthataredifferentfromtheoneprovided(FEIN18V-3.0Ah-54Wh).
It ispossibleto check thechargingstatus bymeans of theLEDlights placedonthecharger
(see picture6).
WARNING
UsingthestandardchargerCH01 (providedwiththescissors),thetimeneededforacomplete
chargeisabout50 minutes;usingthefast chargerCH02 (optional),thetimeneededfora
completechargeisabout30 minutes.
6
12345
Meaning
1continuousyellow
light
Thebatterychargerisreadyforoperation;mainsvoltageis
given
2greenflashinglight Therapidchargingisactive
3continuousgreen
light
Therapidchargingiscompleted.Tricklechargingisactive
(onlyNiCd/NiMHbatteries)
4redflashinglight
Chargingnotpossibleduetothefollowingpossiblereasons:
-Contactscontaminated.Improvementmeasure:Cleanthe
contactsbyinsertingandremovingthebatteryseveraltimes.
-Thebatteryisdefective.Improvementmeasure:Replacethe
battery!
5
greenflashinglight
andredflashing
light
Thebatterytemperatureisnotwithinthecharge-temperature
rangeof0°Cto+45°C.Therapidchargingprocedurestarts
assoonasthebatteryreachestheallowablecharge-
temperaturerange.
LEDindicator

12
EN
14. BLADESHARPENING
Aftermanyhoursof acontinuativeuseof thebatteryscissors
oriftheyarenot ableto cutanymore,itisnecessaryto sharp
theblade.Tocarryoutthisoperation,startthebladeand
press sharpeningbutton“1”for3-4seconds(asshownin
picture7).Repeatthisoperation2-3times.
Ifthesharpeningprocessshouldbeineffective,checkthe
wearof theemerygrindingwheel“2”(see picture7).Ifwheel
“2”istoo worn ordirty,replaceitbyremovingthebladewith
thepropertool.
1
7
WARNING
Thesharpeningbuttoncanbeonlypressedifthefrontmobileprotectioniscompletely
lowered.
15. LUBRICATION
Every3-4daysof use,itisnecessaryto lubricatethepair
of gears.Tocarryoutthisoperation,removeprotective
plug“A”locatedontheheadof thebatteryscissorsand
fill itwiththesuppliedlubricatinggrease.
Screwplug“A”againfewturns.Screwplug“A”some
turns every2-3workinghours(see picture8).
Fill theplugagain,onceithasbeentightened.
Theblademust neverbedirtywith greaseoroil.
8
WARNING
A
2

EN
13
Ifthebladeisnomoreableto cut(evenafterrepeating
thesharpeningoperationseveraltimes),itisnecessary
to replaceit.Inorderto carryoutthisoperation,use
butterflywrench“1”anddrift“3”lockingtheblade
(showninpicture9).
Inorderto replacetheblade,proceedasfollows:
1) Usesomeprotectiveglovesincompliancewith
ItalianLegislativeDecree81/08;
2) Removethesafetybackfixed protection“A”(see
picture10),byunscrewingthetwoslotted
screws“C”bymeansofascrewdriver(not
suppliedbythemanufacturer)asshownin
picture11.
Removethesafetyfrontmobileprotection“B”
(see picture10)byunscrewingpin“D”andby
extracting thetwowashers“E”asshownin
picture11.
3) Insertdrift“3”(see picture12)intohole“F”in
ordertolocktheblade(theholeintheblade
must correspondtotheholeinthestructure).
4) Usebutterflywrench“1”inordertounscrew
nut“G”(see picture12)andremoveblade“H”
(see picture13).
5) Replacethewornbladewiththenewone“2”,
beingcarefultocenterthebladeontheshaft,
inthecorrectposition,and rememberto
assembleitwiththesidewiththewritingRasor
positionedtowardstheexternalsideofthe
batteryscissors.
6) Assembleall thecomponentsagainandcarry
out somecuttingandsharpeningtests. 11
3
16.BLADEREPLACEMENT
1
2
3
9
C
D
12
B
A
10
E
F
1
G
H
13

14
EN
18.SPAREPARTS /EXPLODEDVIEW
17.TROUBLESHOOTING
OPTIONAL ACCESSORIES
CODE DESCRIPTION
BAT18 BATTERY Li-Ionâ 18V,3.0Ah WITH
LED
CH01 STANDARDCHARGER(220 Vor 100
V)
CH02 FASTCHARGER(220Vor110V)
à
SOLUTION
Checkthatbladeandcounterblade contact witheachother
Checkthe kindoffabric
Sharpentheblade
Checkthe fabricthickness
Checkthe compatibilitybetweenblade andfabric
Makesure thatthe motorturns correctly
Reducethe feedingspeed
Checkthecounterbladeintegrity
Carryoutthelubrication
Disassemblethe bladeandremovethe materialresidues
Checkthewearofthe pairofgears
Checkthebatterycharge levelbymeans ofthe LEDindicator
Checkifthebatteryhasbeencorrectlyinserted
Checkthe plasticjointbetweenmotorandcuttingpart
The scissorsstartslowly,work
intermittentlyordo notstart
6
PROBLEM
The batteryscissorsarenoisy
Thefabricisnotcutoritgetsstuck
betweentheblade andthecounterblade
CODE DESCRIPTION CODE DESCRIPTION CODE DESCRIPTION CODE DESCRIPTION
70SHSS QUADRANGULARBLADEØ70mm,
H.S.S.STEEL F7027 JOINT F7044 BACKPROTECTIONGUARD FASTENING SCREW SW108700 EMERY GRINDING WHEELPIN
BA001 MOTOR CASING OFPLASTIC F7028 CLOSING RING F7045 BACKPROTECTIONGUARD SW108800
EMERY GRINDING WHEELSPRING Ø11
mm
BA002 SLIDING SWITCH F7029 WORMSCREWBEARING mm10x22x6 F7045CPL BACKPROTECTIONSET SW108900 SCREWEDBUSH
BA003 MAGNETMOTOR WITHCOUPLING
POINTS F7030 WORMSCREW-MOD.1 F7049 PLATELOCKING THETHREADS SW109000 EMERY GRINDING WHEELSPRING Ø6 mm
BA004 MOTOR FLANGEFASTENING SCREW F7030CPL COMPLETEWORMSCREW-MOD.1 F7050 PLATELOCKING THETHREADS
FASTENING SCREW SW109200 EMERY GRINDING WHEELCAP FASTENING SCREW
BA005 MOTOR CASING FASTENING SCREW F7031 ANTIFRICTIONBUSHING F7053 WELDFOOT SW109300 STEELWASHER
BA006 ELECTRONICCONTROLCIRCUIT F7032 SNAPRING F7053CPL COMPLETESTEELFOOT T104500 FRONTPROTECTIONGUARD
FASTENING SCREW
BA008 LOCKINGSPRING F7033 CORRUGATEDTHRUSTWASHER F7054 FOOTFASTENING SCREW T104501 CONVEXEDWASHER
BA010 Zero702 COMPLETEMOTOR F7036 THRUSTWASHER F7054/1 TOOTHEDWASHER T104700 GREASERCAP
BAT18
BATTERY Li-Ion18V,3.0AhWITHLED
F7037 RINGGEAR F7055 WIDIACOUNTERBLADEWITHSPRING T104800 GREASER
CH01 STANDARDCHARGER F7038 RINGGEARBEARING F7056 COUNTERBLADEFASTENING SCREW T105200 MOTOR SUPPORTFASTENING BOLT
F5057 DRIFTLOCKING THEBLADE F7039CPL COMPLETERING GEAR F7061 SUB-BLADERING T105300 SPLITWASHER
F5059 BLADEASSEMBLY/DISASSEMBLY
WRENCH F7042 BLADEFIXING RING NUT FRN70B Zero702COMPLETEACCESSORIES SET T106000 RING GEARLEFTFASTENING SCREW
F7006 EMERYGRINDING WHEELCAP F7043 FRONTPROTECTIONGUARD SW108600 EMERY GRINDING WHEEL:MEDIUM
GRAIN T107900 LUBRICATING GREASE
F7026B Zero702 COMPLETEMOTOR SUPPORT F7043CPL FRONTPROTECTIONSET SW1086CPL COMPLETEEMERYGRINDINGWHEEL
UNIT

BA001
T105300
T105200
T104700
T104800
F7026B
FRN70B
CH01
BAT18
F7027
F7028
F7032
F7029
F7029
F7030
BA005
BA 002
BA006
BA008
BA 003
BA004
BA010
F7042
F7038
F7038
F7037
F7045
F7044
F7033
F7061
F7036
F7031
F7043
F7043CPL
F5057
F5059
T107900
F7044
F7045CPL
F7056
F7056
F7053
F7054/1 F7053CPL
F7054/1
F7054
F7054
F7055
F7049
F7050
F7050
F7006
T106000
70SHSS
SW108700
SW108900
SW108600
SW109300
SW109200
T104500
SW1086CPL
F7039CPL
SW109000
SW108800
T104501
70SHSS
F7030CPL
®
dal1946

WARRANTY
Rasor®ElettromeccanicaS.r.l. batteryscissorshavea12monthwarrantyfromthedateindicated
on thelast pageof this manual,exceptin caseof differentwritten agreements.
Thewarrantycoversallmanufacturingandmaterialdefects.Replacementandrepairoperations
arecoveredonlyifcarriedoutbyourcompanyandatourworkshop.Ifin-warrantygoods
needto berepaired, thecustomermustalwayssendthecompletemachinetoRasor®.
Singleunitswill notbe repairedunderwarranty.
Thematerialto berepairedmust besentCARRIAGEFREE.
Oncetheequipmenthas been repaired,itwill besentCARRIAGEFORWARDto thecustomer.
Thewarrantycoversneithertechnicians'interventiononthesitewherethebatteryscissorsare
usednortheirdisassembly.
Ifforpracticalreasons,oneof ourtechnicians issentto thepremises,thecustomerwill be
chargedthecosts plus thetravellingexpenses.
Thewarrantydoesnot include:
+failurecausedbywronguseorassembly,
+failurecausedbyexternalagents,
+failurecausedbylack of maintenanceorneglicence;
+blades andparts subjectto wear.
WARRANTYFORFEITURE:
+Incaseof arrearageorotherbreaches of contract,
+Wheneverchangesorrepairsarecarriedoutonourbatteryscissorswithoutourprior
authorization,
+Whenevertheserialnumberistamperedwithorcancelled,
+Wheneverthedamageiscausedbyimproperuse,badtreatment,bumps,fallsand
othercausesnot dueto normalworkingconditions,
+Whenevertheunitseemstamperedwith,dismantledorpreviouslyrepairedby
unauthorizedstaff,
+Incasethebatteryscissorsareusedforpurposesthataredifferentfromtheones
describedinthismanual.
+Incasenon-originalRasor®spareparts areinstalled.
All repair operations carriedoutunderwarrantydonotinterruptits duration.
All disputeswill be settledin thecourt ofjusticeofMilan(Italy).
We thankyouinadvancefortheattentionyouwill payto thismanualandweinviteyouto
informus of anychangeyoudeem necessaryto improveitandmakeitmorecomplete.

TRANSPORTATIONCERTIFICATE
Concerningthetransportaccordingtothedangerousgoods regulationsofthedifferenttransportmodes
asinforce since January,1st2003 andchangeseffectivefrom2013
WEHEREWITHCERTIFYTHATEACHBATTERYPACKISOFTHETYPEPROVEDTOMEETTHEREQUIREMENTS
OFEACHAPPLICABLE TESTINTHEUNMANUALOFTESTSANDCRITERIA, PARTIII,SUB-SECTION 38.3,
Rev.5,Amend.1
Watt-hourratingofthebatterypack:72,00Wh
ThislithiumionbatterypackisNOTRESTRICTEDanditisadmittedtotheEASEDTRANSPORTATION(as
withoutcomplyingwiththerulesoftheDangerousGoodsRegulationinfullscale).
AccordingtoPackingInstruction965 (UN3480)or966/967(UN3481),SectionII–ExceptedLithiumIon
CellsandBatteries-oftheIATA-DGRandSpecialInstruction188 oftheADR/RID,ADN,IMDG-Code.
FORCARRIAGEBYAIRPLANETHE"LITHIUMBATTERYHANDLINGLABEL"ISREQUIRED.
Incaseofdamagedbatteriesduringtransport/unpacking,pleasecallthefollowing24/
24hnumber:[phone].
CERTIFICATO
PERBATTERIEAL LITIO
Signature:SvenBauer,CEO
No.UN/Shippingname:
UN3480LITHIUMBATTERY
UN3481LITHIUMBATTERY
(packedwithequipment/containedinequipment)
Certifiedproduct: Accumulator-RechargeableLI-ION
Modeldesignation: 5S2PICR18650 HD2(18V/4Ah)
Articlenumber: B18A.165.01 /16226-12GP
Certificationholder:
C.&E.FeinGmbH
Hans-Fein-Str.81 D-73519Schwäbisch-Gmünd -Germany
CERTIFICATE/REPORTNO.:BU-2013-000402-UN
PERFORMED TESTS RESULTS
38.3.4.1 Test1:Altitudesimulation passed
38.3.4.2 Test2:Thermaltest passed
38.3.4.3 Test3:Vibration passed
38.3.4.4 Test4:Shock passed
38.3.4.5 Test5:Externalshortcircuit passed
38.3.4.6 Test6:Impact/Crush not requiredforbatterypacks
38.3.4.7 Test7:Overcharge passed
38.3.4.8 Test8:Forceddischarge not requiredforbatterypacks

RASORELETTROMECCANICAS.R.L.
CUTTING EQUIPMENTS
DECLARATIONOFCONFORMITY
Weherebycertifythatthedevice*specifiedhereundercompliestotherequirements of
MachineryDirective2006/42/CEandtotechnicalrulingsUNIEN414:2002,UNIENISO
12100:2010.
Noisetests havebeencarriedoutaccordingto UNIENISO11202:2010 Standards.
BatteryscissorsZERO702havebeenproducedaccordingto workmanlikestandards.
We declarethattheabove-mentionedgoodscomplywiththestandardsinforceconcerning
safetyandhygieneatworkthatcanbeappliedto thematerialitselfaccordingto theItalian
legislativedecree No.81/08 (locallaw);theabove-mentionedgoodsarenot includedinthe
goodsindicatedinannexIVof MachineryDirective2006/42/EC.
1.Category: BATTERYSCISSORS
2.Manufacturer: RASOR®ELETTROMECCANICA S.R.L.
3.Type: ZERO702
4.Serialnumber:..........................................................................................
5.Chargervoltage:220 V110 V
6.Yearof manufacture:.................................................................................
7.Countryof manufacture: ITALY
8.Additionalinformation:..............................................................................
(Signature)
Warrantyexpiry:
12 months frominvoicedataorreceipt
*Batteryandchargerareproduced,warrantedandcertifiedbyFEINGmbH.

Authorizeddealer
(Stamp)
