Raven Case SPX 3150 User manual

Case SPX 3150/3185/3200
Sprayer with Raven SCS 460
Console
AccuBoom™
Installation Manual
P/N 016-0171-081 Rev B 01-16
Copyright 2009, 2016

Manual #016-0171-081 Rev. B 07/08
CHAPTER
1
INTRODUCTION
____________________________________________________________
Congratulations on your purchase of the Raven AccuBoom system! This
system is designed to provide worry free turn on and turn off of your
booms with respect to the as-applied coverage map. The following
instructions are designed to assist you in the proper installation of the
AccuBoom system. See your Console Operation Manual for instructions
on setting up the software and using the AccuBoom system.
Important! All boom switches must remain
in the OFF position while AccuBoom control
is in operation.
COMPONENTS
NEEDED
•CAN AccuBoom Control Node: P/N 063-0172-316
•CASE3150/3185/3200 CAN AccuBoom Cable: P/N 115-1001-011
•6’ CAN Tee Cable: 115-0171-326
•AccuBoom installation Manual, CASE SPX3150/3185/3200:
P/N 016-0171-081
Important: If no CAN system currently exists
on the machine you are installing AccuBoom
on, you will need these additional
components:
Kit, CANBus, Terminators & Power Adapter
“T” – P/N 117-0159-923
1

Manual #016-0171-081 Rev. B 07/08
Notes:
2

Manual #016-0171-081 Rev. B 07/08
CHAPTER
2
INSTALLATION
___________________________________________________________
Use the following procedure to properly install the AccuBoom system on
a CASE SPX3150/3185/3200 sprayer.
1. Open the access door located on the left side of the cab.
2. Locate the boom control cable located toward the rear of the cable
compartment.
3

Manual #016-0171-081 Rev. B 07/08
3. Disconnect the 6 pin boom connections.
Important! There may be two sets of 6 pin
connectors. Be sure you have located the
connectors coming from the boom switches.
4. Plug the mating connectors from the CAN AccuBoom cable P/N 115-
1001-011 to the corresponding connectors previously disconnected.
4

5. Mount the CAN AccuBoom node in a suitable located in the cable
compartment.
6. Connect the AccuBoom cable to the AccuBoom node.
a. Connect the rectangular connectors from the AccuBoom Cable P/N
115-1001-011 to the CAN Accuboom Node P/N 063-0172-316.
7. Connect supplied CAN Tee cable (115-0171-326) to the CAN
connection on the CAN AccuBoom cable P/N 115-1001-011.
8. If using a Viper or Viper Pro console connected serially to the
SCS 460, connect the orange wire from the AccuBoom harness
(115-1001-011) to the Master Apply Switch so that the orange
wire is supplied power when the Master Apply switch is in the
“ON” position. If you are not using a Viper or Viper Pro connected
serially to the SCS 460, orange wire is not needed for installation.
Node Connection
Manual #016-0171-081 Rev. B 07-08
5

Manual #016-0171-081 Rev. B 07/08
6

Manual #016-0171-081 Rev. B 07/08
9. Connect a CAN terminator P/N 063-0172-369 to the end of the CAN
cable P/N 115-0171-362.
Note: If the machine already has a CAN
system installed, remove the terminator from
the existing CAN system and move it to the
CAN cable previously installed. If no CAN
system exists on the machine, refer to Chapter
3 and use on of the terminators contained in
the CAN Tee With Power kit P/N 117-0159-
923.
10. Connect the CAN system.
a. Connect the single end of the CAN cable P/N 115-0171-326 to
the CAN bus or to the CAN PWR Tee system installed in
Chapter 3.
11. Connect power and ground.
a. Wire the red power wire to a clean source of switched 12 volt
power.
b. Connect the white ground wire directly to the battery ground.
12. The CAN AccuBoom installation is now complete.
7

Manual #016-0171-081 Rev. B 07/08
Notes:
8

Manual #016-0171-081 Rev. B 07/08
CHAPTER
3
CAN INSTALLATION
________________________________________________________________________
If the machine you are working on does not currently have a Raven CAN
system, you will need a Kit, CANbus, Terminators & Power Adapter “T”
P/N 117-0159-923. This kit contains the CAN Cable Adapter Tee With
Power P/N 115-0171-368 and two(2) CANBus Terminators P/N 063-
0172-369. To install a Raven CAN system:
1. Connect CAN Tee to power and ground.
a. Locate a convenient source of power and ground near the control
system.
b. Connect the red wire of the CAN Cable Adapter Tee With Power
P/N 115-0171-368 to a source of clean 12 volt power.
c. Connect the white wire from the CAN Cable Adapter Tee With
Power P/N 115-0171-368 to a clean battery ground.
9

Manual #016-0171-081 Rev. B 07/08
2. Connect the CAN bus to the Controller.
a. Connect CAN Terminator P/N 063-0172-369 to one connector on
the Can Cable Adapter Tee With Power P/N 115-0171-368.
CAN Terminator
b. Connect the second connector on the CAN Cable Adapter Tee
With Power P/N 115-0171-368 to the CAN connector on the
Envizio or Viper interface cable.
The CAN bus system is now installed and CAN nodes may be connected
to it.
10

CHAPTER
4
SYSTEM TROUBLESHOOTING
________________________________________________________________________
The CAN AccuBoom Node P/N 063-0172-316 has additional features to
allow the user to diagnose the AccuBoom system. The CAN AccuBoom
node has a plastic window in the case that allows the user to view green
diagnostic lights. The picture below shows the positioning and function of
each of the LED lights.
Logic Power
High Current
Power
(
HC
)
Micro 1 Hz
CAN Rx
CAN Tx
Manual #016-0171-081 Rev. B 07/08
•Logic Power: Lit when 12VDC logic power is available at the node.
•Micro 1 Hz: Flashes at 1 Hz interval when processor is active.
•CAN Rx: Flashes when CAN messages are being received.
•CAN Tx: Flashes when CAN messages are being transmitted.
•High Current Power: Lit when High Current Power is applied to the
node.
11

Manual #016-0171-081 Rev. B 07/08
Notes:
12

Raven Industries will not assume any expense or liability for repairs
made outside our facilities without written consent. Raven Industries
is not responsible for damage to any associated equipment or
products and will not be liable for loss of profit or other special
damages. The obligation of this warranty is in lieu of all other
warranties, expressed or implied, and no person or organization is
authorized to assume any liability for Raven Industries.
Damages caused by normal wear and tear, misuse, abuse, neglect,
accident, or improper installation and maintenance are not covered
by this warranty.
What Does this Warranty Cover?
How Long is the Coverage Period?
How Can I Get Service?
What Will Raven Industries Do?
What is not Covered by this Warranty?
Bring the defective part and proof of purchase to your Raven Dealer.
If your Dealer agrees with the warranty claim, the Dealer will send the
part and proof of purchase to their distributor or to Raven Industries
for final approval.
Upon confirmation of the warranty claim, Raven Industries will, at our
discretion, repair or replace the defective part and pay for return
freight.
RAVENINDUSTRIES
Limited Warranty
This warranty covers all defects in workmanship or materials in your
Raven Applied Technology Product under normal use, maintenance,
and service.
Raven Applied Technology Products are covered by this warranty for
12 months after the date of purchase. This warranty coverage applies
only to the original owner and is nontransferable.
