RCA RC5215P User manual

DVD
RC5215P
Digital Video Disc
Player
• Plays Movies from CD-Size Discs
• Unsurpassed Picture Quality1
• Distortion-Free Special Effects
• 4:3, 4:3-Letterbox2and 16:93Capability
(with compatible discs)
Sound
• SRS TruSurround4
• CD-Quality Sound1
• Plays Music CDs
• Dolby5Digital and DTS6Bit Stream Output7
Convenience
• DVD Remote
• Multiple Repeat and Programming
Functions
• Parental Rating Control Capability†
• Multi-Language/Subtitle Capability8
• Multiple Viewing Angle Capability
• Audio/Video Outputs
• S-Video Output
• Optical Digital Output
• Intelliseek®Scan Modes
• Scene Again®Instant Replay
• Component Video Outputs
Plays
Audio
CDS

Specifications
• Dimensions: 24⁄5" H, 15" W, 131⁄2" D
• Approx. Shipping Weight: 11.6 Lbs.
General
• Full Complement of Operational
Controls on Front Panel Including
Surround Sound and Random
Functionality
• Enhanced Fluorescent Alpha
Numeric Display
• On-Screen Displays Available in
English, French, or Spanish
• Compatible with Music CDs
The RCA DVD Player is totally compatible with
your current CD collection and offers similar
playback features.
Remote
• DVD Remote
(CRK16F1)
DVD remote provides control of all DVD
functions.
• Requires Two “AA” Batteries (Included)
• High-Resolution Video Performance
720 pixels per horizontal line9for crystal-clear
detail and picture clarity. More than twice the
definition of standard VHS.
• 10-Bit D/A Conversion
• Multiple Aspect Ratios
With the press of a button, the DVD player
can switch between 4:3, 4:3-letterbox2and
16:93formats.
• Still Picture Switchable to Field/Frame
Minimizes screen jump and flicker depending
on how the original content was recorded on
the disc.
Sound
• 96 kHz, 24-Bit Audio D/A
• Signal-to-Noise Ratio
More than 95dB.
• Frequency Response
20 Hz - 20,000 Hz.
• Dynamic Range Compression
Compresses the dynamic range of a disc’s
soundtrack—quiets loud explosions,
increases dialogue.
• 5and 6Compatible
With Dolby5Digital or DTS6ready audio
equipment, will play full six-channel 5.1 audio
via the optical (tosslink) digital output. Full two-
channel Dolby5Pro Logic down mix for full
compatibility with Pro Logic audio equipment.
• SRS TruSurround4
Offers a six-speaker surround sound listening
experience through the use of two stereo
speakers.
Convenience
• Parental Rating Control
The RCA DVD Player gives studios the
capability to put the control of movie viewing
where it belongs—in parents’ hands. It allows
you to choose what is suitable for your child to
see.†And without a password, the rating
control cannot be altered—great when adult
supervision is not always possible.
• Multi-Language/Subtitle Capability8
DVD discs can support up to eight different
audio languages, 32 different subtitle tracks
and closed captioning.
• Programmable Playback
Memorizes playback sequence of video
chapters or audio tracks for automatic
playback.
• Chapter/Track/Search
Scan through each DVD chapter or CD audio
track in sequence or access the desired
chapter/track by direct input, via remote.
• Chapter/Track/Side Repeat
Permits automatic repeat of favorite DVD
chapter or audio track.
• Repeat A-B
Repeat specified segment of program material.
• Random Playback CD
Randomly plays back tracks on CDs.
• Six Marker Functions
Player remembers up to six different locations
on disc for fast indexing to specific location.
• Intelliseek®Scan Modes
Exceptionally clear pictures in fast, slow,
forward and reverse motion playback. 3, 6, 15,
30, 60X speeds allow for immediate scanning
to any point in the disc. 1/3, 1/6, 1/13X slow
motion forward and reverse speeds allow for
fine-tune scanning.
• Scene Again®Instant Replay
Press the AGAIN button on the remote control
to automatically jump backward in the video to
catch missed dialogue. Need more time? Press
AGAIN. Subtitles are automatically turned on
(in pre-determined language if available on the
disc) with each button press.
• Display Auto Dimming
Select between Auto, Bright, and Dim to
adjust the brightness of the player's front
panel display.
Connections
• Component Video Outputs
YPrPb component video outputs provide
optimal video connection between the DVD
player and advanced TV systems. Minimizes
line scan and digital artifacts providing the best
video image possible.
• Audio/Video Outputs
Direct audio and video connections for
optimum performance.
• S-Video Output
Provides optimum video performance with
increased brightness/color signal separation for
monitors equipped with S-Video input.
• 5and 6Bit-Stream Output7
Provides an encoded six-channel digital output
via an optical jack.
• Included Accessories
– Stereo Audio/Video Cables
– AC Power Cord
• Back Panel
Plus
• Limited Warranty
–90 days—unit exchange, which includes parts
and labor.
–91 days to one year—unit exchange, which
includes parts only; you pay the labor.
–See RCA dealer for complete details.
1 Quality of picture and sound are dependent upon the audio system, cables,
and/or television used by the consumer. Television also requires S-Video input
to realize full capability of the RCA DVD Player.
2 On properly encoded widescreen discs.
3 On properly encoded widescreen discs. Requires 16:9 television.
4 SRS, the SRS symbol , and TruSurround are trademarks of SRS Labs, Inc.
5 Dolby and the double-D symbol are trademarks of Dolby Laboratories
Licensing Corporation. Requires optional speakers and Dolby Digital Receiver.
6 DTS and DTS Digital Surround are trademarks of Digital Theater Systems, Inc.
7 Dolby Ready audio receiver and DTS receiver are required to obtain the full
benefit of Dolby Digital and DTS Surround Sound.
8 With compatible disc.
9 Based on EIA measurement criteria.
† When discs are encoded with special rating codes by movie studios.
©2000 Thomson Consumer Electronics, Inc.
Form S-RC5215P
Trademark(s) ® Registered
Marca(s) Registrada(s)
Photos and features subject to change without
notice. Illustration of product finish may vary
from actual color.
PC13803
RC5215P
RIGHT
AUDIO OUT
DIGITAL
AUDIO
OUT
LEFT
S-VIDEO
AC IN
Pr
Pb
Y
VIDEO OUT
