RealFlame IGNITE XL Series Installation instructions

08/53411/0 VERSION X.2
The product is compliant with the local electrical standards of all countries where offered for sale by
Glen Dimplex and its subsidiaries.
IGNITE XL
Models: XLF50, XLF74, XLF100
INSTALLATION & OPERATING
MANUAL

2
CAUTION: Read all instructions and warnings carefully before starting installation. Failure to follow these
instructions may result in a possible electric shock, fire hazard and will void the warranty.
Important Safety Advice
When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electrical shock
and injury to persons, including the following:
If the appliance is damaged, check with the supplier before installation and operation.
• Do not use outdoors.
• Do not use in the immediate surroundings of a bath, shower or swimming pool.
• Do not locate the appliance immediately below a fixed socket outlet or connection box.
• Do not use this heater if it has been dropped.
• Do not use if there are visible signs of damage to the heater.
• Use this heater on a horizontal and stable surface.
The appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the
appliance by a person responsible for their safety. Children should be supervised to ensure that they do not play with the
appliance. Children shall not plug in, regulate and clean the appliance or perform user maintenance.
CAUTION: Some parts of this product can become very hot and cause burns. Particular attention has to be given where
children and vulnerable people are present.
Do not use this appliance in series with a thermal control, a program controller, a timer or any other device that switches
on the heat automatically, since a fire risk exists when the heater is accidentally covered or displaced.
Although this appliance complies with safety standards, we do not recommend its use on deep pile carpets or on long
hair type of rugs.
In the event of a fault disconnect the appliance.
Disconnect the appliance when not required for long periods.
The appliance must be positioned so that the plug is accessible. Electrical Requirements section for more details. If the
supply cord is damaged it must be replaced by the manufacturer or service agent or a similarly qualified person in order
to avoid a hazard.
Keep the supply cord away from the front of the appliance.
Warning: This appliance must be earthed.
The use of an extension lead or multi-plug adaptor is not advised when connecting this product to the mains.
Connection through these devices could lead to a risk of overloading, overheating and even fire at the extension lead
or adaptor due to inadequate connection quality.
This heater must be used on an alternating current supply (~) only and the voltage marked on the heater must
correspond to the supply voltage.
WARNING: In order to avoid overheating, do not cover the appliance. Do not place material or garments on the appliance,
or obstruct the air circulation around the appliance.
The appliance carries a DO NOT COVER warning symbol.
This appliance is equipped with a device to control the room temperature. Do not use this appliance in small rooms when
they are occupied by persons not capable of leaving the room on their own, unless constant supervision is provided.
Rating Label
WELCOME
Thank you for purchasing the IGNITE XL electric
fireplace. The edge to edge panoramic display will
ensure you create endless memories in front of this
dazzling electric fire.

3
WARNING - KEEP BATTERIES OUT OF REACH OF CHILDREN
• Swallowing may lead to serious injury in as little as 2 hours or death, due to chemical burns and potential
perforation of the esophagus.
• f you suspect your child has swallowed or inserted a button battery immediately call the 24-hour Poisons
Information Centre on 13 11 26 (in Australia) or 0800 764 766 (in New Zealand) for fast, expert advice.
• Examine devices and make sure the battery compartment is correctly secured, e.g. that the screw or other
mechanical fastener is tightened. Do not use if the compartment is not secure.
• Dispose of used button batteries immediately and safely. Flat batteries can still be dangerous.
The electrical information regarding your electric fireplace can be found on the rating label located on the top of the unit.
If you have any technical questions or concerns regarding the operation of your electric fireplace, or require service
contact the relevant customer service as listed on your warranty card.

4
CAUTION: Ensure installation does not allow fireplace to be in direct contact with building vapor
barrier or insulation and meets all local building code.
!NOTE: A dedicated 10 AMP, 230-240 Volt circuit is required. A dedicated circuit is preferred but not
essential in all cases. A dedicated circuit will be required if, after installation, the circuit breaker trips
or fuse blows on a regular basis when the heater is operating.
WARNING: Construction and wiring must comply with local building codes and other applicable
regulations to reduce the risk of fire, electric shock and injury to persons.
WARNING: To reduce the risk of fire, electric shock or injury to persons, always use a licensed electrician.
WARNING: To reduce the risk of fire, do not store or use gasoline or other flammable vapors or
liquids in the vicinity of the heater.
1. Select a location that is not susceptible to moisture and is away from drapes, furniture and high traffic.
2. Unpack the fireplace and hardware from the box.
!NOTE: Leave the front glass and partially reflective glass, safely, in the box until the time you are
ready to install it.
3. Store the fireplace in a safe, dry and dust free location until you are ready to install the fireplace.
Installation
CAUTION: Two people will be required for various steps of this procedure.
This design of this unit allows three options for installation: partial recess, flush mounted or sub-surface
mounted.
CAUTION: Sub-surface mounting should be limited to ½ in. (12 mm) to ensure adequate air flow of
heated air out of the firebox area.
1. Prepare a wall with a framed opening of 16 in. (406 mm) high,
• XLF50 - 50 ⅝in. (1287 mm)
• XLF74 - 74 ⅝in. (1897 mm)
• XLF100 - 100 ⅝in. (2557 mm) wide, with a bottom sill that is a minimum of 4 in. (102 mm) deep. The
sill can be constructed to support the front of the unit to allow the power supply wires to easily be
run behind or flush with the back of the unit and a pass through hole drilled for electrical wire routing.
WARNING: Do not attempt to wire your own new circuits. To reduce the risk of fire, electric shock or injury
to persons, always use a licensed electrician.
WARNING: Ensure that the circuit on which the fireplace is to be installed has the power cut off at
the service panel until installation is complete.
INSTALLATION

5
2. The unit is provided with an installed ¾ in. (20 mm) trim. Depending on the installation, this trim can
be removed by removing the securing screws and the 4 trim pieces.
3. Lift fireplace, from the bottom and the handles located on the back, and insert into opening to the
desired depth.
4. Using a bubble level (supplied) ensure that the fireplace is level within the framing. Adjust as required.
5. Drive four supplied mounting screws through the four mounting holes located on the inside surface of the
fireplace chassis, into wall studs (Figure 1).
!NOTE: The unit can also be installed without the trim for a seamless installation look.
For Bathroom Use
If this unit is installed in a bathroom it must be protected by a GFI receptacle or circuit. If receptacle is
used it must be readily accessible.
To prevent electrical shock this unit is an electrical appliance that is NOT watertight and must be
installed as to prevent water from entering unit. This must be installed away from showers, tubs, etc.
Never locate fireplace where it may fall into a bathtub or other water container.
Final Assembly
1. Locate and remove the 12 screws securing the partially reflective glass bracket to the unit, along the
top of the opening, and set bracket and screws aside.
2. Remove the provided suction cup from the inside cavity of the unit (only for XLF74 and XLF100 units).
3. Before installation ensure that the front glass and the partially reflective glass are clean. Particles can
be removed by dusting lightly with a clean dry cloth. To remove fingerprints or other marks, the glass
can be cleaned with a damp cloth. Ensure that the glass has completely dried before installation.
4. Carefully secure the suction cup to the partially reflective glass, reflective side out, and place into the
openings on either side of the unit.
Mounting Holes
Flame Panel
FIGURE 1

6
5. Tip the glass into the unit and using the removed screws secure the glass into the unit with the
provided bracket (Figure 2). Remove the suction cup.
6. Evenly space the large media in the media tray along the back of the media tray (for optimum media
effect), then carefully pour and evenly distribute the smaller media into the Media Tray.
7. Carefully place the front glass into the lip located at the bottom of the opening of the firebox.
8. Tip the front glass into the unit and secure using the provided screws and Allen key. (Figure 3).
!NOTE: Ensure that the suction cup and Allen key are kept for any future maintenance or service.
FIGURE 2
Partially Reective Glass
Retaining Bracket
Media Tray
Glass Openings
FIGURE 3

7
UNIT DIMENSIONS
FRAMING DIMENSIONS
D
A
B
C*
XLF50 XLF74 XLF100
A1287 1897 2557
B406 406 406
C* 600 600 600
D160 160 160
Plaster to edge of opening
*C has no minimum, these
measurements are for ideal
viewing only
Opening
Sill

8
General Operation
WARNING: This electric firebox must be properly installed before it is used.
This firebox operates with Comfort$averTM technology, which automatically adjusts the fan speed and
heater wattage to safely and precisely match the requirements of the room based on the thermostat
setting. The heater operates such that once the room reaches the set point, the fan and heater will
continuously run at a low level, to maintain the desired room temperature. If the temperature in the room
rises significantly, i.e. sun coming through a window or a central furnace turns on, the heater will turn off
and periodically turn back on to circulate the air around the unit, until the room temperature drops and
requires the heater to be constantly on again.
!NOTE: The unit is designed so that the fan will run continuously while the heater is on.
!NOTE: The element retains heat after shutdown, there is a built in cool down period of 2 minute
before the fan shuts off completely, when the heat function is turned Off.
Remote Operation
The fireplace is supplied with an IR multi-function remote control.
!NOTE: To operate correctly, the remote control must be pointed towards the front of the unit.
OPERATIONS
A. Power Button
Switches the product on and off. Restores
to previous setting when switched on.
B. Flame Effect
Turns the Flame Effect On and Off
J. Sleep Timer
The timer button increases the timer by
0.5hrs on each press. Up to 8hrs cycle.
I. Brightness
Press to change brightness of the LEDs
from high to low.
G. Heat Boost
Turns the Heater Boost On and Off. Runs
the unit at the full rated wattage.
E. Temp Up
Increases the temperature in
intervals of 1oC.
C. Heat
Switches the heat on and off.
Use Temp buttons to regulate heat.
D. Temp Down
Decreases the temperature in
intervals of 1oC.
F. Eco Operation
Runs the heater in a reduced wattage
range when activated.
H. Colour Theme
Different presets of lighting color
combinations are available in the unit.
A
B C
D
F
H
J
E
G
I

9
AC D E H
Display I
J
Icon Function Description
APower/
Standby
Turns the unit On and Off.
Activated by pressing the Standby button on the remote or the unit.
The unit will turn On with the same functions that it was set to when it was turned Off
and the intake temperature will be indicated on the Display.
!NOTE: When any button is pressed on the unit the intake temperature will be
displayed on the Display for 7 seconds.
BFlame Effect
Turns the Flame Effect On and Off.
Activated by pressing the button on the remote.
CHeat ON/OFF
Turns the heater On and Off.
Activated by pressing the button on the remote or the unit.
Indicated by the icon and the set point temperature will flash on the display, then
the intake temperature will be displayed before turning off.
!NOTE: After the heater is switched off, there is a 2 minute fan delay, where the
fan will continue running before turning off.
!NOTE: The unit can be operated in Heat Only Mode. When the unit is only
running with the heater, the icon will continuously be displayed on the Display.
!NOTE: The heater may emit a slight, harmless odor when first used. This odor is
a normal condition caused by initial heating of internal heater parts and will not occur
again.
DTemp Down
Decreases the temperature setting.
Adjusted by repeatedly pressing the corresponding button on the remote.*
Indicated by set point temperature on the Display decreasing and the speed of the
fan decreasing to reduce the amount of heat being projected into the room.**

10
Icon Function Description
ETemp Up
Increases the temperature setting.
Adjusted by repeatedly pressing the corresponding button on the remote.*
Indicated by the set point on the Display increasing and the speed of the fan increasing
to increase the amount of heat being projected into the room.
* The first time the button is pressed the current temperature set point will be displayed
for 2 seconds.
** The temperature can be adjusted from 5 °C to 37 °C (41 °F to 99 °F).
!NOTE: Holding the and the buttons down for two seconds, on the unit, will
change the temperature scale from °C to °F, or vice versa.
F
Eco
Operations
Runs the heater in a reduced wattage range when activated.
Adjusted by pressing the corresponding button on the remote when the heater is on.
Indicated by the Display and a reduced fan speed.
G Heat Boost
Turns the Heater Boost On and Off. Runs the unit at the full rated wattage.
Activated and adjusted by repeatedly pressing the corresponding button on the remote.
Indicated by the heater running at full heat, for a user set amount of time, to quickly heat
up a cold room/space. The Heat Boost can be set for a maximum of 20 minutes, in 5
minute increments.
Disable Heat
If desired, depending on the season, the heater on the unit can be disabled. The function
of the remaining controls will continue to function as outlined in this manual.
Pressing the and buttons on the unit at the same time and holding for 2 seconds
will disable and enable the heater.
!NOTE: When the heater has been disabled and any of the heat related functions are
used, the Display will indicate “---”.
H
Colour
Themes
Different presets of lighting color combinations are available in the unit.
Changed by repeatedly pressing the corresponding button on the remote or the unit.
Cycles through the different preset light settings of the unit, this includes different
combinations of colors of the flame base and media lighting.
!NOTE: Two of the themes in the cycle are a prism where the unit cycles through a
variety of colors. Pressing the stops the cycling and holds the unit on the preferred
color, indicated by a solid circle. When the unit is on prism, and is cycling through the
colors, a rotating circle will be displayed.
I Brightness
Changes the Brightness of the lights in the unit.
Adjusted by repeatedly pressing the corresponding button on the remote or the unit.
Indicated by the second digit on the Display changing to show: “H” (high), and “L” (low).
