Recyko D451 User manual
Charging instructions
Speed Charger Dock (USB) 4-Slot / 8-Slot NiMH with LCD
Fig. 1
Fig. 3a
Fig.3b
Fig. 2b D851
Display indication
Condition Battery icon
Charging in progress
Charging completed
Bad or single-use batteries
Aging batteries, replacement recommended
Standby
Charging time^
Size Capacity Charging time**
AA 1300 - 2600 mAh 1.3 - 5.2 hrs
AAA 650 - 950 mAh 2 - 3 hrs
^ Charging time varies with different power input and battery capacity in different charger ranges.
Please refer to corresponding charger instruction manual for details.
** Charging time refers to M451 only.
* For exact product contents,please refer to “In the box”section of the packaging.
USB charging cable (input/output)
Features
•Charging of 1–8 pcs of AA / AAA batteries via battery charger(s) simultaneously
•LCD display to show the charging status
•Approx. charging time for AA 2100 mAh / AAA 850 mAh batteries: 2–4 hours
•Battery health check for individual battery
•Compatible charging for any Recyko chargers#
# Exact Models: B421, M451 & P461
Charging instructions
Read the instruction manual thoroughly before use. Keep the manual for future reference.
1. Insert 1–8 pcs NiMH batteries into 1 or 2 battery charger(s) according to the battery polarity (Fig. 1).
2. Place the battery charger(s) onto the charger dock (Fig. 2a & 2b).
3. Connect the micro USB end of the cable to the micro USB port of the charger dock (Fig. 3a).
4. Connect the other end of the USB cable to a smartphone wall charger (Fig. 3b) or similar USB port on a
power bank or USB car charger.
Charging will commence and the battery icons on the display will show the status of the batteries.
The battery icons will flash green when the batteries are charging ( ).
For bad or single-use batteries, battery icons will flash rapidly ( ).
5. Once the batteries are fully charged (Battery icons constant green ), remove the charger(s) from the charger
dock. Remove the batteries from the charger(s) and disconnect the charger dock from the power supply.
When using 8-slot charger dock & 2 chargers for charging batteries, the required power source for normal
operation is 5V/2A. Once the 8-slot charger dock & 2 chargers are connected to a power source lower than
5V/2A, there will be insufficient power for charging. One of the chargers will probably be shut-down and stop
charging.
The 4 LEDs on the first detected (shut-down) charger will flash red & green alternatively and stop charging,
and the charger dock will change to stand-by mode (symbol ( ) will be shown on LCD display). The charger
must be removed and re-inserted to the charger dock with 5V/2A power source to reset for normal operation.
Remark: Most computer USB ports may not reach to 5V/2A, which may cause the insufficient power condition
for charging batteries.
6. Replace the batteries if the aging icons ( ) is shown on the display for that particular channel.
7. For charger usage instructions, please refer to the instruction manual of Recyko chargers.
For best performance and safety, always use NiMH Recyko batteries
Usage tips
•It is normal for batteries to become hot during charging and they will gradually cool down to room
temperature after fully charged.
•Remove batteries from the electrical device if the device is not going to be used for a long time.
•Battery storage temperature: -20 ~ +35°C
•Charger dock operation temperature: 0 ~ +33°C
Safety information
•This charger dock is designed to charge only NiMH batteries. Charging other batteries may lead to explosion,
battery rupture or leakage, personal injury or property damage.
•This charger dock is designed for indoor use only. Do not expose the charger dock to rain, snow or direct
sunlight.
•Do not use the charger dock in humid conditions.
•Make sure the charger dock is used between 0 ~ +33°C.
•Do not use non-rechargeable, LiFePO4, NiCD or Li-ion batteries.
•Do not use the charger dock if it has a damaged plug.
•
Do not use the charger dock after it has been dropped or damaged. Do not open/disassemble the charger dock.
•This charger dock is maintenance-free but should be wiped clean regularly with a dry and soft cloth. Do not
use abrasives or solvents. Unplug the charger dock before cleaning.
•This appliance can be used by children aged from 8 years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall
not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
AA 31300mAh / 2600mAh 1.3 – 5.2
650mAh / 950mAh 2 – 3
1-8AAA 4
^
^
#
Do not dispose of electrical appliances as unsorted municipal waste, use separate collection facilities.
Contact your local government for information regarding the collection systems available. If electrical
appliances are disposed of in landfills or dumps, hazardous substances can leak into the groundwater
and get into the food chain, damaging your health and well-being.
GB (mAh) / Recyko Speed Charger Dock (USB)
4-Slot / 8-Slot NiMH with LCD
Instruction Manual
Unpacking and checking
You should find the following items in the packaging*. Please make sure they are undamaged and in
good working order.
Go to gpbatteries.com
for product information
D451 / D851
D451
D851
USB power input: 5V/2A
Fig. 2a D451
USB power input: 5V/1A
D451 / D851
D451
D851
ZH-TC
Recyko
batteries
(1 - 8 pcs) 請瀏覽gpbatteries.com
1300 - 2600 1.3 - 5.2
650 - 950 2 - 3
^
^
D451
ZH-SC ZH-S C
D451
