Redmond MultiBaker RMB-M603 User manual

MultiBaker RMB-M603
User manual
Over 40 removable
plates in stock

CONTENTS
IMPORTANT SAFEGUARDS................................................................................................................................................................................................ 8
Technical Specications...........................................................................................................................................................................................................10
Package Includes.......................................................................................................................................................................................................................10
Parts of Appliance......................................................................................................................................................................................................................11
I. PRIOR TO FIRST USE.....................................................................................................................................................................................................11
II. OPERATION.......................................................................................................................................................................................................................11
Replacement of the removable metal plates....................................................................................................................................................................11
Use of the appliance.................................................................................................................................................................................................................12
III. COOKING TIPS...............................................................................................................................................................................................................12
Common Cooking Mistakes and Ways of Solving Them.................................................................................................................................................12
IV. CLEANING AND MAINTENANCE...........................................................................................................................................................................13
Storage and transportation ....................................................................................................................................................................................................14
V. ADDITIONAL ACCESSORIES.....................................................................................................................................................................................14
VI. BEFORE CONTACTING SERVICE CENTER.......................................................................................................................................................14

3
A1
5
4
1
2
8
7
9
9
9
3
6
10
11

4
A2

5
A3
RAMB-01
RAMB-08 RAMB-09 RAMB-10
RAMB-02 RAMB-03 RAMB-04 RAMB-05
RAMB-06 RAMB-07
RAMB-11 RAMB-12 RAMB-13RAMB-14 RAMB-15

6
A3
RAMB-16
RAMB-26 RAMB-27
RAMB-24
RAMB-17 RAMB-19
RAMB-23
RAMB-22
RAMB-18
RAMB-21
RAMB-20
RAMB-28RAMB-25

7
A3
RAMB-40
RAMB-38
RAMB-42
RAMB-36RAMB-35
RAMB-34
RAMB-44
RAMB-30 RAMB-32
RAMB-31 RAMB-33
RAMB-29

8
Read the user manual carefully and keep it as a reference book.
Proper use of the appliance will signicantly prolong its life.
The safetymeasures and instructions contained in this manual do
not cover all possible situations that mayarise during the opera-
tion of the appliance.When operating the device the user should
be guided by common sense, be cautious and attentive.
IMPORTANT SAFEGUARDS
• The manufacturer is not responsible for any failures
arising from the use of this product in a manner
inconsistent with the technical or safety standards.
• This appliance is intended to be used for nonin-
dustrial use in house hold and similar spheres of
application. Industrial application or any other
misuse will be regarded as violation of proper
service conditions. Should this happen, manufac-
turer is not responsible for possible consequences.
• Before installing the appliance, check that the device
voltage corresponds with the supply voltage in your
home (refer to rating plate or technical data).
• While using the extension cord, make sure that its
voltage is the same as specied on the device. Using
different voltage may result in a re or other acci-
dent, causing appliance damage or short circuit.
• Use only earthed electric sockets as this is an ob-
ligatory safety requirement. Use an earthed exten-
sion cord as well.
• Metal parts of the appliance are heated during
operation. Do not touch them with your hands
when the device is connected to a power outlet.
Do not switch on the empty appliance. Never touch
the inner surfaces of the heated appliance.
• Bread can burn that's why the appliance should
not be used close to or under ammable materials,
e.g. curtains.
• Always unplug the device after use, before cleaning
or moving. Never handle the plug with wet hands.
Do not pull the power cord to disconnect from the
outlet; instead, grasp the plug and pull to disconnect
• Keep the power cord away from hot surfaces (gas
or electric ovens) or sharp edges. Do not let the
cord hang over edge of a table or a counter.

RMB-M603
9
RUS
REMEMBER: damaging the cord may lead to
afailure that will not be covered by the war-
ranty. If the power cord is damaged, it must
be replaced by the manufacturer, after-sales
service or similar qualied personnel to avoid
possible danger.
• Do not leave the product unattended while it is in
use. The appliance is not intended to be operated
by means of an external timer or separate remote-
control system.
The appliance can be used only with the
closed lid.
• Do not cover the appliance during operation. It
may lead to overheating and breakage of the ap-
pliance.
• Do not operate the appliance outdoors, to prevent
water or any foreign object or insect from getting
into the device. Doing so may result in serious
damage ofthe appliance.
CAUTION! Do not allow liquid ingredients and
food particles to get between the removable
panels and the base to avoid incorrect operation
of the appliance and foreign odour occurrence
during operation.
• Always unplug the device and let it cool down
before cleaning. Follow cleaning and general main -
tenance guidelines when cleaning the unit.
DO NOT immerse the device in water or wash
itunder running water! If the product falls into
water,immediately unplug it from the electrical
outlet. Do not touch or reach into the water.
• This appliance can be used by children aged from
8years and above and persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given
supervision or instruction concerning use of the
appliance in a safe way and understand the hazards
involved. Children shall not play with the appliance.
Keep the appliance and its cord out of reach of

10
children aged less than 8years. Cleaning and user
maintenance shall not be made by children without
supervision.
• Keep the packaging (lm, foam plastic and other)
out of reach of children as they may choke on them.
• No modications or adjustments to the product are
allowed. All the repairs should be carried out by an
authorized service center. Failure to do so may result
in device and property damage or injury.
CAUTION! Do not use the appliance in case
of any malfunctions.
CAUTION! Hot surface.
Technical Specications
Model....................................................................................... RMB-M603
Rated power....................................................................................700 W
Voltage.................................................................220–240 V, 50/60 Hz
Electrical safety.............................................................................. class I
Number of removable plate sets........................................................ 3
Housing material ........................................................bakelite + metal
Material of removable plate........................................................metal
Operation indicator................................................................. available
Power indicator ........................................................................ available
Overall dimensions ............................................. 240 × 231 × 97 mm
Net weight.....................................................................................1,99 kg
Power cord length ..........................................................................0,8 m
Package Includes
Multibaker...........................................................................................1 pc.
The set of removable plates RAMB-01 ......................................1 pc.
The set of removable plates RAMB-02 ......................................1 pc.
The set of removable plates RAMB-18 ......................................1 pc.
Drip tray to collect oil/grease....................................................... 1 pc.
Cookbook.............................................................................................1 pc.
User manual....................................................................................... 1 pc.
Service booklet...................................................................................1 pc
Manufacturer reserves the right to make any modifications
to design, packaging, or technical specifications of the prod -
uct without prior notice. The specification allows an error
of ±10%.

RMB-M603
11
RUS
Parts of Appliance (gure A1, p. 3)
1. Appliance housing
2. Handles
3. Lid lock
4. Power indicator
5. Operation indicator
6. I/O power switch
7. Buttons for xing removable panels
8. Power cord
9. Removable plate sets
10. Drip tray to collect oil/grease
11. Trench drain with oil/grease
I. PRIOR TO FIRST USE
Carefully remove the unit and its accessories from the packaging.
Dispose of all packaging materials and promotional stickers.
Keep all warning labels, warning stickers (if any), and the serial
number identication label located on the housing.
After transportation or storage at low temperatures allow the
appliance to stay at room temperature for at least 2 hours before
use.
Completely unwind the power cord. Wipe the unit with a moist
cloth. Rinse removable parts with warm soapy water and dry thor-
oughly before connecting the appliance to an electrical outlet. Place
the device on a at, stable, and hard surface away from any objects
or cabinets that could be damaged by steam, humidity, or high
temperatures.
Ensure that outer and visible inner parts of the appliance are not
damaged, do not have chips and other defects.
Before using the appliance as intended, perform the heating cycle
with the empty multibaker (having preliminarily xed the work-
ing plates) to remove technical protective oil. Then unplug the
appliance, let cool down and clean according to section“Cleaning
and maintenance”.
This process should be performed for each set of the removable
plates.
I I. OPERATION
WARNING! Parts of the device may become extremely hot when
operating. Keep out of reach of children.
Replacement of the removable metal plates
1. Open the main lid.
2. Push back the plate lock on the housing of the appliance and
remove the metal plate. Repeat the action with other plate.
3. Push the lock back and install the selected plate into the device
so that the projections on it aligned with the slots on the
housing. Release the lock. Repeat the action with other plate.
NOTE! Be sure to push the lock back before installing the
removable plate, do not press on it! Installing the plate
forcefully can lead to lock breakage!

12
DO NOT replace the metal plates if the appliance is plugged
in.
Use of the appliance
The device must not be used without the plates installed.
1. Plug in the appliance.
2. Turn the O/I switch to the I position. The power indicator light
will turn on.When the device reaches the required tempera-
ture, the operation indicator light will turn on.
To get the best result possible, place food inside when the op-
eration indicator light will switched on!
Food must be frozen.
Do not use products that contain a large amount of water,
remove any excess moisture before cooking. A large amount of
water being released from the product may lead to overheating
and device failure.
3. Open the lid of the appliance. Depending on the type of
adjusted plates put ingredients onto the lower heating sur-
face. Ensure the plates are not overlled.
Non-stick plate coating allows to cook without oil. However, you
may apply a small amount of vegetable oil or butter to plate
working surface if desired.
4. Place the oil & fat collection tray under the multibaker as
shown in diagram A2, page 4.
5. Press products with the upper plate until the lid lock
mechanism clicks.
For your convenience, the appliance is equipped with a
two-level lock that allows you to vary thickness of the
product.
NOTE! Do not apply too much force,it may lead to breakage!
If the size of the product exceeds the capacity of the plates,
reduce the serving.
6. The operation indicator will be occasionally lit up during
cooking. The cooking time isdened by the type of product
and your taste.
When cooking some food, residues of fat / oil or liquid
ingredients may leak underneath the appliance panels. This
is not a malfunction. If this happens, place a paper towel
under the access holes in the lower part of the device.
7. Open the lid of the appliance after a while. Remove the ready
dish using wooden or silicone paddles.
8. When you nish cooking, turn the power switch on the base
to the “O” position and unplug the appliance from the mains.
Clean the appliance according to recommendations of the
section “Cleaning and maintenance”.
III. COOKING TIPS
Common Cooking Mistakes and Ways of Solving Them
This table familiarizes you with the practical tips and solutions
to some common problems you may experience when using the
multibakers.

RMB-M603
13
RUS
THE TOP OF THE PRODUCT IS BAKED THROUGH WORSE THAN
ITS BOTTOM
Possible causes Solutions
The product has been laid for too
long
For uniform baking on both sides add the
products quickly and immediately close the
multibaker
The multibaker was opened during
cooking
Do not open the lid of the appliance while
cooking earlier than recommended
Not enough ingredients Add more
Pastry prepared incorrectly Follow cooking recommendations
THE DISH IS UNDERCOOKED
The dish is cooked with the open lid Cook with the closed lid
The product has been placed onto
the cold plate Put the product onto the preheated plate
The cooking time is not followed Follow the cooking recommendations
THE DISH GETS BURNT
The product doesn't have oil. The
plate was not greased with oil Grease the product or plate with oil
Cooking recommendations haven't
been followed Follow the recommendations on cooking time
THE PRODUCT GETS DRY
The product doesn't have oil.
Cooking with the open lid without
oil
Grease the product or plate with oil.
Cook with the closed lid
Cooking time is too long Follow the recommendations on cooking time
The product has been placed onto
the cold plate Put the product onto the preheated plate
THE PRODUCT STICKS
The vegetables are cut or placed
onto the cold plate.
Long cooking without oil
Follow the cooking recommendations.
Preheat the plate and add the product greased
with oil
The meat has been placed onto the
overheated plate without oil (the
marinade for meat doesn't contain
oil)
The sh has been put onto the
overheated/cold plate without oil
THE PRODUCT LEAKS OUT
Too much liquid product has been
placed onto the plate
Reduce the batch of the product.
Change the consistence (make the product
thicker)
I V. CLEANING AND MAINTENANCE
Wipe the housing of the appliance with a damp soft cloth, ensure
the moist doesn't get inside the appliance
DO NOT use coarse tissues or sponges, abrasive pastes for
cleaning. It is also not recommended to use any chemically
aggressive or other substances, not recommended for use
with items which contact with food.

14
DO NOT immerse the housing and power cord into water or
rinse it under running water.
During the cooking process, fat and oil drain through special
grooves in the panels into the collection tray. Wash the removable
metal plates with warm soapy water after each use. Do not wash
metal plates in a dishwashing machine.
Storage and transportation
Before repeated operation or storage completely dry all parts of
the appliance. Store the assembled appliance in a dry, ventilated
place away from heating appliances and direct sunlight.
During transportation and storage, do not expose the device to
mechanical stress, that may lead to damage of the device and/or
violation of the package integrity.
Keep the device package away from water and other liquids.
V. ADDITIONAL ACCESSORIES
You can purchase additional removable plates for the multibaker
RMB-M603 and nd out about REDMOND products at www.redmond.
company or at the authorized dealers' shops (scheme A3, p. 5–7).
V I. BEFORE CONTACTING SERVICE
CENTER
Problem Possible cause Solution
Indicators are not lit up,
plates are not heated
Electrical outlet is not
working properly
Connect to properly working
electrical outlet
Problem Possible cause Solution
Indicators are not lit up,
plates are not heated
Power cord is not connected
to an electrical outlet
Connect the power cord to an
electrical outlet
Electrical outlet is not
working properly
Connect to properly working
electrical outlet
An off-odour appeared
during operation
The appliance overheats
during operation
Reduce the time of continuous
operation, increase the intervals
between starts
Appliance is new, the
smell is coming from
protective cover
Thoroughly clean the appliance.
The smell will disappear after few
uses
In case you didn’t manage to eliminate the defects, please, refer
to the authorized service centre.
Environmentally friendly disposal (WEEE)
The packaging, user manual and the device itself shall be
taken to the applicable collection point for the recycling
of electrical and electronic equipment. Do not throw away
the electronic waste to help protect the environment.
Old appliances must not be disposed with other household waste
but must be collected separately. Municipal disposal of recyclable
wastes is free of charge. The owners of old appliances are required
to bring it to a waste facility centre. With this little extra effort,
you can help to ensure that valuable raw materials are recycled
and pollutants are treated as appropriate.
This appliance is labelled in accordance with European Directive
2012/19/EU – concerning used electrical and electronic appli-
ances (waste electrical and electronic equipment WEEE).
The guideline determines the framework for the return and recy-
cling of used appliances as applicable throughout the EU.

Manufacturer: “Power Point Inc Limited” №1202 Hai Yun Ge (В1) Lin Hai Shan Zhuang Xiameilin Futian Shenzhen. China. 518049.
Under license of REDMOND®
Изготовитель: «Пауэр Пойнт Инк. Лимитед» №1202 Хай Юн Гэ (B1) Лин Хай Шан Чжуан Сямейлин Футьян, Шеньжень, Китай,
518049. По лицензии REDMOND®
Виробник: «Пауер Поінт Інк. Лімітед» № 1202 Хай Юн Ге (B1) Лін Хай Шан Чжуан Сямейлін Футьян, Шеньжень, Китай, 518049. За
ліцензією REDMOND®
Importer (EU): SIA “SPILVA TRADING” Address: Jelgava, Meiju cels 43 — 62, LV-3007 Reg. Nr. 43603078598. BA Uvoznik i distributer
za Bosnu i Hercegovinu: ASBIS d.o.o., Džemala Bijedića 162, 71 000, Sarajevo, Bosna i Hercegovina. Tel: [phone], e-mail:
[email protected], www.asbis.ba. BG Вносител: АСБИС България ЕООД И.Н.: BG121655056 Адрес: София, бул. Искърско шосе 7,
ТЦ Европа, сгр. 3. Тел.: [phone], www.asbis.bg. CZ Dovozce: ASBIS CZ spol. s r.o Obchodní 103, 251 01 Čestlice, Praha — východ,
Praha, Czech Republic. Tel: [phone], www.asbis.cz. HU Importőr: ASBIS Magyarország Kft., H-1135, Budapest, Reitter
Ferenc utca 46-48. Tel.: [phone], Fax: [phone], www.asbis.hu. PL ASBIS POLAND SP Z O.O., Ul. Krasnowolska 17 A,
02-849, Warszawa. Tel [phone], www.asbis.pl. RO Importator: ASBIS Romania SRL, Splaiul Independentei 319, SEMA PARC,
Obiectiv 5, Etaj 2, Sector 6, Bucuresti, 062650, Romania. Tel. [phone], www.asbis.ro. RU Импортер в России: ООО «ИЛОТ»,
198099, г. Санкт-Петербург, ул. Промышленная., д. 38, к. 2, лит. А, тел.: [phone]. SK Importér/distribútor pre SR: ASBIS
SK spol. s r.o., Tuhovská 33, 831 06, Bratislava. Tel: [phone], www.online.asbis.sk. RS Uvoznik i servis za Republiku Srbiju:
ASBIS d.o.o., Cara Dušana 205A, 11080 Zemun, Beograd. Tel: [phone], www.asbis.rs. LV Izplatītājs: SIA „ASBIS BALTICS”;
Latvia, Riga, Bauskas iela 58A-15, LV-1004; Tel.: [phone], e-mail: [email protected], www.asbis.lv. UA Імпортер в Україні: ТОВ
ПІІ «АСБІС-УКРАЇНА», 03061, м. Київ, вул. Газова, будинок 30. Тел. [phone], www.asbis.ua. SL Distributer, dajalec garan-
cije in servis za Slovenijo, Asbis d.o.o., Brodišče 15, 1236 Trzin; Tel: + 386 (0) 590 79 927; e-mail: [email protected]; www.asbis.si.
HR ASBISc-CR d.o.o.; Slavonska avenija, 24/6 -1 kat; 10000, Zagreb, Croatia; Tel: + 385 1 600 9900, e-mail: [email protected]; www.
asbis.hr. EE Maaletooja: SIA „ASBIS BALTICS”; Türi 10c, 11313, Tallinn, Estonia; Tel.: + 372 66047815, e-mail: [email protected]; www.
asbis.ee. LT Importuotojas: SIA „ASBIS BALTICS”; Ateities g. 25B, 06326, Vilnius, Lietuva; Tel.: [phone], e-mail: sales@asbis.
lt; www.asbis.lt. CY Importer Cyprus: ASBIS Kypros Limited; 26, Spyrou Kyprianou Str, 4040, Germasogeia, Limassol, Cyprus. Tel: +357
25 257 350; Fax: [phone], e-mail: [email protected]; www.asbis.com.cy

www.redmond.company
www.multivarka.pro
www.store.redmond.company
www.smartredmond.com
Made in China
RMB-M603-ENG-UM-1
