Reece Milli Pure User manual

MILLI PURE VERTICAL SINGLE HEATED
TOWEL RAIL 900X38 - CHROME
900
38 ø
60
CLEANING RECOMMENDATIONS
We recommend the use of a soft dry cloth.
This product should not be cleaned with abrasive materials or cleaning agents.
Damage caused by improper treatment is not covered by the product warranty - refer
to warranty conditions.
SPECIFICATIONS
Recommended use Domestic, hotel and commercial
Material Copper Tube with Brass fittings
Electrical Connection Hardwired only
Power Entry Through wall bracket - Bottom Only
Heating Method Water Filled
Wattage 30 watts
IP Rating IPX5
Standard AS/NZS: 3350
Robe Hook Sold seperately
To see the complete MILLI range go to
www.reece.com.au/bathrooms
Dimensions are nominal measurements only.
page 1 of 5
Disclaimer: Products in this specification manual must by regulation be installed by licensed and registered trade people. The manufacturer/
distributor reserves the right to vary specifications or delete models from their range without prior notification. Dimensions are nominal
measurements only. Dimensions and set-outs listed are correct at time of publication however the manufacturer/distributor takes no responsibility
for printing errors.
Tech Page Version 1

MILLI PURE VERTICAL SINGLE HEATED
TOWEL RAIL 900X38 - CHROME
WARNING
This product must be installed by a qualified electrician in accordance with AS/NZS 3000 wiring rules. Switch off the electrical
supply at the mains before installation and maintenance. A means of disconnection must be incorporated in the fixed wiring
in accordance with the wiring rules. Suitable for bathroom and non-bathroom/dry areas. Not suitable for above baths, nor
for installation in saunas, steam rooms or shower cubicles. Please consult with a qualified electrician to confirm appropriate
compliant installation location.
Do not connect to a plug and socket outlet. Rated IPX5 and suitable for indoor use only. Do not fix to damp or conductive
surfaces. Site well away from curtains and fabrics. Switch off after use. Do not leave on for prolonged periods. This appliance is
not to be used by persons (including children) with reduced physical, sensory or mental capabilities.
INSTALLATION INSTRUCTIONS
Please consult with a qualified electrician to confirm appropriate compliant installation location.
Power Entry:
Power cable if hung vertically must always be positioned at the bottom, never at the top.
If hung horizontally it can be installed with the cable on either side.
page 2 of 5

MILLI PURE VERTICAL SINGLE HEATED
TOWEL RAIL 900X38 - CHROME
CLOSE UP
WALL
WALL
Cord
Screw
1
1
Hold Towel Rail in desired position against wall, with a pencil
draw an outline around both bracket arms.
Take brass bracket insert and place against wall in outlined circle.
Feed wall cable through wall mount channel. Using a
pencil mark the screw hole position and cross it for accuracy.
Mark screw hole for second brass bracket insert.
Drill screw holes for both brackets, insert nylon plug into wall (if applicable).
If tiled wall installer MUST use a DIAMOND HEAD drill bit. Position wall
bracket so that GRUB SCREW HOLES face inwards.
Aqualied electrician must then connect towel rail element to
existing wall cable.
Screw
Place Towel Rail in correct position over mounted brackets, secure unit in place by tightening grub screw on inside of
each bracket arm with Alan key provided. Fig 3. and Fig 4.
50mm
WALL
Cord
Screw
70mm
WALL
DO NOT OVERTIGHTEN SCREW - LEAVE SLIGHT
ADJUSTMENT OF THE FLANGE (SLACK) TO ENABLE
MOVEMENT WHEN THE TOWEL RAIL IS POSITIONED.
Fig 1. Fig 2.
Fig 3. Fig 4.
Fig 1.
Fig 2.
Fig 2.
Please ensure that the measurements are taken
accurately and that the screw is in a stud or noggin to
provide support. DO NOT overtighten screws.
Please ensure a DIAMOND HEAD drill bit is used to drill
screw and cord holes into tiled wall.
Hydrotherm take pride in the fact that all rails are
individually hand made. Due to this fact some
measurements may not be exact. PLEASE READ
INSTRUCTIONS CAREFULLY and do not force towel rail
into bracket if position of wall ange is not accurate.
30 mm
Brass Bracket Insert - Close Up
22mm
8mm Wide
Channel
TOWEL RAILS MUST ALWAYS BE INSTALLED WITH THE ELECTRIC ELEMENT
POSITIONED AT THE BOTTOM OF THE UNIT FOR CORRECT HEAT TRANSFER
page 3 of 5

MILLI PURE VERTICAL SINGLE HEATED
TOWEL RAIL 900X38 - CHROME
Step 1.
Step 2. Step 3.
Step 4.
Step 5.
Step 6.
REPLACING ELEMENT
Replacing an old element is a very simple process. All electrical wiring must be carried out by a licensed electrician.
There are Six Basic Steps:
1. You will need to obtain a 22mm tap spanner. Remove towel rail from brackets (if already installed).
2. On the side with the element cable remove push-on cap, and pull element cable through end.
3. Feed cable through spanner until you reach element hex nut.
5. Insert new element and screw in place with spanner until tight.
Please note:
Hydrotherm advise that the unit be removed from the wall and turned upside down to ensure that water does not spill.
Ensure element always remains at bottom of Towel Rail if being installed vertically.
- 22mm Tap Spanner
4. Loosen element with spanner and remove.
6. Feed element cable back through bracket hole, and ret push-on cap. Towel Rail is now ready be re-installed.
page 4 of 5

MILLI PURE VERTICAL SINGLE HEATED
TOWEL RAIL 900X38 - CHROME
HARD WIRING
Hydrotherm recommends that all hard-wired heated towel rails be connected to a light switch
or timer.
Connecting hard-wired heated towel rails to a light switch or timer will prolong the life of the
electric element and reduce energy consumption.
Hydrotherm recommend the brand HPM and the model XLP770TRT, this particular unit is
designed specically for heated towel rails that is incorprated into a light switch panel.
At Hydrotherm we pride ourselves on the highest quality standards of design and
manufacturing.
All Hydrotherm products come with a 10 year manufactures warranty on the construction
and finish of our towel rails.
All electric heating elements are covered by a 3 year manufactures warranty.
100% Australian Made and Owned
Construction & Finish
Manufacturers Warranty
year
Electric Element
Manufacturers Warranty
73
year
CARE DETAILS
This bathroom product should not be cleaned with abrasive
materials eg. steel wool/scourers. Do not use any corrosive or
abrasive cleaning agents containing acids or scouring agents.
Bleaches can also discolour products and therefore should not
be used. Damage caused by any improper treatment is not
covered by the product warranty.
Disclaimer: Products in this specication manual must be installed by licensed and registered
trade people. The manufacturer/distributor reserves the right to vary specications or delete models from
their range without prior notication. Dimensions are nominal measurements only. Dimensions and set-outs
listed are correct at time of publication however the manufacturer/distributor takes no responsibility for
printing errors.
HYDROTHERM WARRANTY
TOWEL RAILS MUST ALWAYS BE INSTALLED WITH THE ELECTRIC ELEMENT
POSITIONED AT THE BOTTOM OF THE UNIT FOR CORRECT HEAT TRANSFER
page 5 of 5
Plumbers, please ensure a copy of the installation
instructions is left with the end user for future reference
