Reflecta X6 TouchScan User manual

-0-

-1-
Table of Contents
1. Precaution................................................................2
2. Preparation...............................................................5
zStandard Accessories....................................5
zPart Names....................................................6
zInstalling the Battery Pack .............................8
zCharging the Battery Pack………………........9
3. Place Film / Slide Into The Holder..........................11
4. Using the x6-TouchScan ........................................12
5. Playback Mode.......................................................22
6. Delete Mode...........................................................24
7. Calibrate the Touch Screen..................................26
8. To Link the Card to Computer..................................27
9. Viewing Images from TV….……………………….....30
10. Edit the Pictures.......................................................34
11. Appendix………………………………………………..42
zSpecifications...............................................42
zIcon & Indicators..........................................43
zSystem Requirements...................................44
EN

-2-
Welcome
Thank you for purchasing a x6-TouchScan.
Please take a moment to read through this manual. Its
contents will send you on an educational journey into your
recorder multiple capabilities.
1. Precaution
Before using x6-TouchScan, please ensure that you read
and understand the safety precautions described below.
Always ensure that the x6-TouchScan is operated
correctly.
•Never operate x6-TouchScan inside of an aircraft or
anywhere else where operation of such devices is
restricted. Improper use creates the risk of serious
accident.
•Do not try to open the case of x6-TouchScan or
attempt to modify x6-TouchScan in any way.
High-voltage internal components create the risk of
electric shock when exposed. Maintenance and
repairs should be performed only by authorized
service providers.
•Keep Digital x6-TouchScan away from water and
other liquids. Do not use x6-TouchScan with wet
hands. Never use x6-TouchScan in the rain or snow.
Moisture creates the danger of fire and electric
shock.
•Keep x6-TouchScan and its accessories out of the
reach of children and animals to prevent accidents
or damage to the x6-TouchScan

-3-
If you notice smoke or a strange odor coming from
x6-TouchScan, turn the power off immediately. Take
x6-TouchScan to the nearest authorized service center
for repairing. Never attempt to repair x6-TouchScan on
your own.
•Use only the recommended power accessories. Use
of power sources not expressly recommended for
x6-TouchScan may lead to overheating, distortion of
the equipment, fire, electrical shock or other
hazards.
•x6-TouchScan may become slightly warm during
use. This does not indicate malfunction.
•If the exterior of x6-TouchScan needs cleaning, wipe
it with a soft, dry cloth.
EN

-4-
FCC Notice
This equipment has been tested and found to comply with
the limits for a Class B Digitize device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses
and can radiate radio frequency energy. If not installed
and used in accordance with the instruction, it may cause
harmful interference to radio communication. However,
there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception, which
can be determined by turning the equipment on to off, the
user is encouraged to try to correct the interference by
one or more the following suggestion.
zReorient or relocate the receiving antenna.
zIncrease the distance between the equipment and
the receiver.
zConnect the equipment to a different power outlet
other than the one where the receiver is connected.
zConsult an experienced television or radio
technician for help.
CAUTION
To comply with the limits for a Class B Digitize device,
pursuant to Part 15 of the FCC Rules, this device must
only be installed on computer equipment certified to
comply with the Class B limits.

-5-
2. Preparation
Standard Accessories
x6-TouchScan QuickGuide CD
135 Slide Holder 135 Negative Holder
110 Negative Holder Clean brush
(Optional)
Adaptor USB cable TV cable Lithium Battery
(Optional)
EN

-6-
Part Names

-7-
Note: We suggest using bundled brush to insert into the
x6-TouchScan Film Holder Slot and clean the glass surface
periodically to produce a clear image. Please make sure your
film negatives / mounted slides and cover trays are clean before
inserting into the x6-TouchScan as well. Dust or dirt from the
negatives and cover trays will affect the quality of your scanned
images.
EN

-8-
Installing the Battery Pack
1. Open the Battery Cover by lightly pressing and sliding
it back as shown. You may open it with coin too.
2. Insert the supplied battery. Make sure the battery
polarities match the (+ and -) sign indicated in the
battery compartment.
3. Push the battery cover latch to snap the cover back
into place.
Battery power status
Full Empty

-9-
Charging the Battery Pack
The battery pack is not fully charged at the time of
purchase and therefore needs to be charged before use.
If the battery charge becomes low while you are using the
x6-TouchScan, it is recommended to recharge it as soon
as possible.
1. Insert the battery pack into the battery compartment
(see page 8)
2. You may charge the battery in 2 ways:
(a) Plug the USB mini B of the supplied USB cable to
the USB port of the x6-TouchScan, and plug the
other USB end into the USB port of your
computer/notebook.
Please charge the battery at least 5.5~6 hours prior
to your first use.
EN

-10-
(b) Plug the USB mini B of the supplied AC adaptor to
the USB port of the x6-TouchScan, and plug the
adaptor to the power outlet.
Please charge the battery at least 2.5~3 hours
3. Red LED will light on during charging. When the
battery pack is fully charged, the red LED light will be
off and you may disconnect the charging connections.
Status LED:
Red: The x6-TouchScan is OFF, the battery is charging.
Purple: The Ix6-TouchScan is ON, the battery is charged
simultaneously.
Blue: The x6-TouchScan is ON, the battery is not charging
or no battery is loaded.

-11-
3. PlaceFilm/SlideIntoTheHolder
1. Keep the glossy surface of the film in the upward
direction.
Open the negative/ positive slide holder as Illustrated.
2. Put a 135 positive slide/ negative film/ 110 negative
film into holder as shown.
3. Close the holder and please make sure the holder
close properly.
EN

-12-
4. Usingthex6-TouchScan
1. Insert SD card into the SD Card Slot first.
2. Press Power on / off button to power on.
Press Power on / off button to power off if you do not
want to use the x6-TouchScan.

-13-
3. Insert the loaded film/ slide holder properly into the
Film/Slide Holder Slot according to the ▲or ●sign
shown on the x6-TouchScan and film holder.
(Insert from the right)
(Insert from the left)
EN

-14-
You can adjust the location of the film by moving the
Film Holder; the Film Holder can be moved in both
directions.
Keep your picture in the rectangular white frame,
improper adjustment of picture may copy the black
edges of the Film Holder.
If the black edge of a slide film is on top or bottom of
the LCD display, you may crop away the black edges
later by the software. (please refer to page 23 edit the
pictures section 1.4 crop)

-15-
4. To select film type on the screen.
Touch the preview area anywhere to enter the Main
Function Mode.
Touch the Film Type Icon for selection.
The type of film selected is shown at the bottom of
the LCD.
EN

-16-
Note: Improper selection of Film type may not get good
result.
5. Touch the Copy Icon to convert picture to Digital image.
135 positive
(
slide
)
135
ne
g
ative
135 black &
white 110
ne
g
ative

-17-
To get the best Digitize image wait for the image
display on the LCD screen to adjust the brightness until
it becomes stable. It normally takes 3~4 seconds,
depending on the brightness of your film.
Wait for the “Wait” cursor to disappear, then you may
take your next picture.
Note: For power saving the x6-TouchScan will
automatically turns to sleep condition if you are not
using it for more than 3 minutes. You may wake up
the x6-TouchScan by pressing the screen.
If the x6-TouchScan is not using for more than 6
minutes it will turn off automatically.
6. Touch the Star Icon to adjust the image quality.
Low
Standard
Best
EN

-18-
7. Moving the Film Holder for next.
8. The exposure of the x6-TouchScan is set automatically,
in some occasion you need to adjust the brightness
(exposure) at your subject.
Touch the EV Icon to adjust expose value.

-19-
Touch the and Icon to adjust the exposure
compensation from +2EV to -2EV in 0.5 increments.
The amount of compensation is shown at the bottom
of the LCD.
