Reflecta DigitDia 6000 User manual

ENGLISH
1
Manual
ENGLISH
CyberView X5

ENGLISH
FEDERAL COMMUNICATIONS COMMISSION
FCC STATEMENT
This Equipment has been tested and found to comply with the limits for a class B
digital device, pursuant to Part 15 of the FCC rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment o and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
C Re-orient or relocate the receiving antenna.
C Increase the separation between the equipment and receiver.
C Connect the equipment into an outlet on a circuit dierent from which
the receiver is connected to.
C Consult the dealer or an experienced radio/TV technician for help.
Warning :
Use only shielded signal cables to connect I/O devices to this equipment.
You are cautioned that changes or modications not expressly approved by the
party responsible for compliance could void your authority to operate the
equipment.
2

ENGLISH
TABLE OF CONTENTS
Getting Started 4
Quick Installation Guide (QIG) 6
Installing Software and Driver 6
Installing Hardware 7
Loading the slides into the Magazine 9
Loading the Magazine into the Scanner 11
Additional Features 14
One Button Scan 15
How to Scan Slides 18
STEP 1 - Acquire Driver 18
STEP 2- Select Film Type 18
STEP 3 - Optional Prescan 18
STEP 4 - Set Scan Settings 19
STEP 5 - Set Scan Preferences 20
STEP 6 - Scan 23
STEP 7 - Exit 23
24User Interface
I Main Window Area 24
II Preview Window Area 28
III Active Frame Setting Area 31
IV Thumbnail Panel Area 32
Technical Support 33
3

ENGLISH
Check the package content before getting started.
For Quick Installation please refer to Quick Installation Guide. (Ref. Pg. 6)
Important! Save the original box, receipt and packing material for future
shipping needs.
Package Contents
t Slide Scanner.
t Magazine.
t Power Adapter
t USB Cable
t Scansoftware CyberView
t Application Software
Warning! Using any other power adapter may severely damage the scan-
ner and will void the product warranty.
NOTE:
t Application software means the imaging software such as Adobe®
Photoshop® Elements, this is subject to change without notice.
t The orange adapter on the transport arm and the arm itself are excluded
from guarantee.
GETTING STARTED
GENERAL GUIDANCE:
t Only use the supplied USB-Cable. Connect the scanner to the computer
directly using the USB 2.0 cable.
t Do not use a hub or extension cable. Only use the USB ports on the rear
of desktop computers.
t
t
If there are any other devices (multifunction device, printers, scanners,
webcam) connected to the computer through USB, disconnect them.
t A minimum of 1GB RAM (Win/Mac) is required.
Magic Touch doesn´t work with B&W and Kodachrome Film. You have
to deactivate it.
4

ENGLISH
Operating Ambient Temperature Range
50º to 104ºF (10º to 40ºC)
Note: Do not turn on the scanner unless it is within this temperature
range. If the scanner has been stored or transported outside of this
temperature range then wait till it has acclimatized before turning
it on.
Operating Ambient Humidity Range 15% to 76% rela-
tive
humidity (non-condensing)
Note: If the scanner is stored or to be transported in cold temperature
and then brought into a warm / humid environment
condensation may occur.
This device is designed for private use only with a guarantee of 2 years or 20,000
scans. It is not intended for commercial use. If used in a commercial way or defects
arise from inappropriate use, or stress then the guarantee is reduced to 1 year.
5

ENGLISH
INSTALLING SOFTWARE AND DRIVER
for PC (Windows) User
Windows Systems installation during driver installation a warning
dialogue box may appear, if this is the case please select “install this
driver anyway.”
Be sure to install the Application Software before installing the scanner CyberView
driver.
You may install the scanner driver directly if you have already installed TWAIN com-
pliant application software in your computer. Mac users can use iPhoto for editing.
Notice:
1. In “Found New Hardware Wizard” window, select “Search automatically or
Browse computer for driver software.”
2. In “Completing the Found New Hardware Wizard” window, click
“Finish”.
Note: Not all PC´s will display the found new hardware window, some will install
in the background.
6

ENGLISH
7
Installing Scanner Driver
a. Insert driver CD into the computer CD/DVD drive and explore the contents.
b. Double click the ”CyberView” icon to begin the installation process. Follow
the onscreen prompts to complete the installation process.
NOTE: Make sure the scanner is NOT connected to the computer during the CyberView
driver installation.
c. Restart computer once the installation process is complete.
Installing Hardware
a. Connect the slide scanner to a power source.
1. Locate the power switch on the lower left side of the scanner. Make sure
the scanner is TURNED OFF.
2. Plug the AC adapter into an AC power source FIRST before plugging it
into the scanner.
3. Attach the USB cable to the computer using the standard USB adapter
end. Attach the USB adapter end of the cable to back panel of the scan-
ner.
b. Ensure the scanner does NOT have a slide magazine loaded, turn the scanner
ON. The calibration cycle on the scanner will start automatically and will take
several minutes to complete. A green light will ash while the calibration is in
progress. The slide transport arm will move in and out of the scanner. MAKE
SURE THERE IS ENOUGH ROOM IN FRONT OF THE SCANNER FOR THE SLIDE
TRANSPORT ARM TO EXTEND FULLY, DO NOT PUSH THE ARM BACK DURING
CALIBRATION.
INSTALLING SOFTWARE AND DRIVER
Before Installing the Scanner Driver...
If you choose to use the provided application for image editing, install the applica-
tion software (ex: Adobe® Photoshop® Elements) by inserting the application CD
into the computer’s CD/DVD drive. Follow the instructions that will be displayed in a
window that opens automatically.
7

8
Compact Magazine
a. As illustrated below, turn the magazine with the embossed lettering“COM-
PACT MAGAZINE 50”and the white strip on the right facing towards the top.
b. Hold the slide right side up, facing forward so the image is NOT reversed.
Rotate the slide as illustrated and Insert each slide, one at a time, into the
magazine.
Warning: Load slides into the magazine properly and make sure the slide mounts are in good
condition. Improperly inserted slides or slides with distorted/damaged slide mounts may cause
the scanner to jam and potentially damage both the slide and the scanner.
Lettering
White Strip
Compact Magazine
General Recommendations:
t y) especially for cardboard frames and framed
Braun Paximat S (grey) for framed slides up to 2 mm
slides up to 2-3.2mm inch thickness.
t Paximat Magazine (Black tray) for framed slides up to 2mm thickness.
t CS Magazine for CS/CS2-framed slides.
t Universal Magazine DIN 108 ( cardboard frames)
t
t Glass slides that are attached to glass frames may cause complications
due to the hard edges.
t LKM Magazine for slides up to 1,8 mm thickness (cardboard frames)
Loading slide(s) into the magazine
ENGLISH

ENGLISH
9
Loading slide(s) into the magazine
Paximat Magazine ( white and grey)
a. Locate the numbering sequence text on the top of the Paximat slide maga-
zine indicating the slide order. The numbers should be facing up and starting
from the left.
b. Hold the slide right side up, facing forward so the image is NOT
reversed. Rotate the slide as illustrated below (180 deg) and Insert each slide,
one at a time, into the magazine.
Paximat Magazine
Numbering
Loading slide(s) into the magazine
CS Magazine
a. Locate the numbering sequence text on the CS slide magazine indicating the
slide order. The numbers should be facing up and starting from the left.
b. Hold the slide right side up, facing forward so the image is NOT reversed.
Rotate the slide as illustrated and Insert each slide, one at a time, into the
magazine.
CS Magazine
Numbering

ENGLISH
,
10
Numbering
Loading slide(s) into the magazine
Universal Magazine
a. Remove the cover from scanner exposing the slide magazine loading area.
b. Load the magazine into the scanner as illustrated below.
Note: Orientation of scanner in the diagrams is from the back of the unit. Take note
of the magazine slide opening also facing towards the back of the scanner for correct
orientation when loading into the scanner.
NOTE: For all magazines (except for the Universal Magazine)
t Return the orange adapter to its original position at the grip of the slide
transport arm after scanning.
t To release the adapter, gently press its outer tip.
Load magazine into the scanner
Loading slide(s) into the magazine
LKM Magazine
a. Locate the numbering sequence text on the top of the Universal
slide magazine indicating the slide order. The numbers should be
facing up and starting from the left.
b. Hold the slide right side up, facing forward so the image is NOT
reversed. Rotate the slide as illustrated below (180 deg) and Insert
each slide, one at a time, into the magazine.
a. Locate the numbering sequence text on the front of the LKM slide
magazine indicating the slide order. The numbers should be facing
forward and starting from the right
b. Hold the slide right side up, facing forward so the image is NOT re-
versed. Rotate the slide as illustrated below (180 deg) and Insert each
slide, one at a time, into the magazine.
Numbering

ENGLISH
11
Fi ng orange Adapter:
1. Push the adapter from the front onto the transport arm.
Paya en on of correct orienta on of the adapter.
2.

ENGLISH
12
1. When using CS, LKM and Paximat Slide Tray you have to move the adapter back.
Therefore gently press down the adapter…
4. … and push it to the end posi on
5. When using UNIVERSAL Slide Magazines you have to move the adapter
to the front of the transport arm.

ENGLISH
13
Slide order numbers printed on magazine facing
towards the back of the scanner.
CS Magazine
Numbering
oad the magazine into the scanner (Continued)
Slide order numbers printed on top of magazine on the
right hand side towards the front of the scanner.
Paximat Magazine ( white and grey)
Numbering
(embossed letters facing up and the white
stripe near the front panel of the scanner).
Compact Magazine

ENGLISH
14
NOTE:
t Use only Universal Magazines with the DIN 108 label. Other magazines may
result in problems and VOIDing the warranty.
t Pull out the slide transport arm fully.
t Gently press the orange adapter on the slide transport arm. Move the
adapter on the slide transport arm to the front until it snaps in.
t Push the slide transport arm back into the scanner.
t Load the magazine from the back in the respective guiding rails of the maga-
zine tunnel until it hits the slide transport arm.
Slide
Transport
Arm
Slide Holder
Slide order numbers printed on top of magazine on the
right hand side of magazine towards the front of the
scanner when loading.
Universal Magazine
Numbering
Universal Magazine
Turn the slide tray around so the numbers face the front of the device, before inserting
LKM Magazine
Numbering
c. Place the slide magazine into the scanner from the left side until it touches
the slide transport arm and the magazine “clicks”into place.

ENGLISH
15
c. Slide Viewer
The scanner has a built in mini light panel which allows the slides to be man-
ually previewed with a backlight before inserting into the tray for scanning.
Insert the slide into the slide viewer for previewing. The scanner has to be
switched on. Gently press down on the top of the slide to engage the back
light for viewing the slide.
MJOJ-JHIUPanel
Additional features
Manual Control Panel
a. You can advance or reverse the slide by pressing the navigation button
or and scan manually with the scan button to enable one button scan
function.
Please Note: When installing your new scanner onto a Windows system that already has an-
other USB Flatbed scanner or All-in-one Scan/Copier/Printer device installed, it may be necessary
for you to disconnect the other scanner from the USB port for the Film scanner to work properly,
.BOVBMCPOUrPMPanel
One Button Scan
1. Open the CyberView (Ref. page 16 to acquire the CyberView driver program)
gure Scan Settings (see Page 17)
gured, Press the
scanner button ( ) to begin scanning.
NOTE: If you do not open CyberView FIRST, the scan button will not function.

ENGLISH
16
d. Single Slide Scanning
t Load the empty magazine into the tunnel FIRST until it touches the slide
transport arm completely. Slide the magazine forward to be sure that the
rst slot of the magazine.
t Press the eject button [I] to make the slide holder open exposing the loaded
slide.
t Place the slide as illustrated [I] into the slide holder and press the slide holder
down [II].
t Open the CyberView X 5.0 driver program to scan the slide.
Attention! When using the single slide scanning function, please check the slide transport arm
.
Eject
Button
Slide
Holder
II.I.

ENGLISH
17
ENGLISH
16
revirDeriuqcA–1PETS
(For PC User)
Open CyberView from Start – All Programs –CyberView
(For MAC User)
Open Macintosh Hard drive – Applications –CyberView
STEP 2 – Select Film Type
lm type to be scanned - Positive, Negative or B&W (Black and White).
HOW TO SCAN SLIDES
STEP 3 – Optional Prescan
Select the “Prescan Current Frame“ to prescan the slide currently loaded into
c positions in the
magazine.
Pre-Scanning should be used to manually adjust color/edit settings for each slide
erent settings for each slide to
be scanned.
Pre-Scanning should be used to
m

18
ENGLISH
STEP 4 – Set Scan Settings
a. Resolution
The default scanning resolution is 1000dpi, additional resolution options
are listed below.
Notice: Higher scanning resolutions result in greater scanning time and hardisk
space requirements.
b. Color Depth
The Film Scanner color depth is 48 bit true color
The scanning software has the capability of selecting 8 bit color mode or 16 bit
color mode when scanning, This will produce 24 or 48 bit color images, 8 bits
or 16 bits per Red, Green and Blue color channels
Example:
8 bit mode = 8 red, 8 green and 8 blue for a total of 24 bit color (JPG or TIF)
16 bit mode = 16 red, 16 green and 16 blue for a total of 48 bit color ( TIF only)
Note: erent resolutions and color depths:
Scan Mode – Normal mode produces a scan in jpeg format while Quality pro-
duces a non-compressed, “loss-less”TIFF image.
Scanning
Resolu-
tion
Color
Depth
(by RGB
channel)
Color
Mode
File Size
TIFF
(no com-
pression)
250dpi 8 bit 24-bit ~350Kb
500dpi 8 bit 24-bit ~1MB
625dpi 8 bit 24-bit
1000dpi 8 bit 24-bit
1250dpi 16 bit 48-bit ~11MB
2500dpi 16 bit 48-bit
5000dpi 16 bit 48-bit ~52MB
Scans include Auto Balance and Digtal Noise
Reduction on:
Processor: AMD 9650 Quad-Core 2.3GHz
Memory: 2GB
System type: Vista 64 bit
ENGLISH

19
ENGLISH
18
“Prescan Resolution“ - Default pre-scan resolution.
“Using default real scan resolution“ - Enables default scan
resolution setting.
“Color Depth“ – Default color depth while scanning.
“Scan Mode“ – Default scan mode while scanning.
Select Scan - Preference - Film Type - Scan Setting
guring Scan settings
1. Select Browse and choose the designated folder to save the scanned
image to
le name.
le
name and numbering sequence up to 6 digits Example image1 or im-
age000001.
STEP 5 – Set Scan Preferences
ENGLISH

20
ENGLISH
19
Advanced Setting
4. Options - Use Film Index: Use the number assigned to the slide based on it’s
position in the cartridge.
c start number
le type , “TIF” or “JPG”. (TIF uncompressed or JPG Compressed-
ers the least amount of compres-
sion
nd the correct exposure to get the widest
range of whites and blacks while putting the middle grays at around the
middle of the data range.
”Auto Balance”- Using the image histogram to balance RGB channels. It
estimates images’color cast and adjust the images accordingly
“Auto Contrast” - The scanner software analyzes the data and automatically
adjusts the Setting for the White and Black Points.
lm grain.
ENGLISH
