Regal Rexnord UVANTAGE PLUS User manual

installation manual
READ THE LABEL AND OPERATING MANUAL BEFORE USING THIS PRODUCT
8-inch
UVantage_InsallationManual_Canadian-8inch_12-5-22.indd 1UVantage_InsallationManual_Canadian-8inch_12-5-22.indd 1 12/5/22 9:52 AM12/5/22 9:52 AM

2
|UVantage PLUS™ Installation Guide
intended use
of the device
first aid instructions
UV AIR TREATMENT TECHNOLOGY HELPS REDUCE AIRBORNE
BACTERIA AND VIRUSES*
*The UVantage PLUS™ device is intended to be installed in existing residential and commercial HVAC systems.
This UV device helps to reduce airborne bacteria and viruses. The use of this device is a supplement to and not
a substitute for standard infection control practices; users must continue to follow all current infection control
practices, including those practices related to cleaning and disinfection of environmental surfaces.
Skin Injury
UV radiation can initiate a photochemical
reaction called erythema within exposed
skin. This “sunburn” can be quite severe
and can occur as a result of only a
few seconds exposure. Chronic skin
exposure to UV radiation has been linked
to premature skin aging, wrinkles and
skin cancer.
Eye Injury
UV radiation exposure can injure the
cornea, the outer protective coating
of the eye. Photokeratitis is a painful
inflammation of the eye caused by UV
radiation-induced lesions on the cornea.
Symptoms include a sensation of sand
in the eye that may last up to two days.
Chronic exposures to acute high-energy
UV radiation can lead to the formation of
cataracts.
There are no immediate warning symptoms to indicate overexposure. If you suspect a UV
exposure, seek medical attention by contacting a medical physician; note that symptoms
may not appear until 12 – 48 hours after exposure.
Symptoms of overexposure including varying degrees of erythema (sunburn) or
photokeratitis (welder’s flash) typically appear hours after exposure has occurred.
UVantage_InsallationManual_Canadian-8inch_12-5-22.indd 2UVantage_InsallationManual_Canadian-8inch_12-5-22.indd 2 12/5/22 9:52 AM12/5/22 9:52 AM

Visit regalrexnord.com/uvantage-plus-canada for additional information |
3
Input Voltage: 81104299: 100 - 240VAC
81104300: 120 - 277VAC
Rated Input Frequency: 50/60Hz
Rated Current: 0.9A Max
Output Voltage: 24 VDC
Power Consumption: AC input power up to 32W
Lamp Type: UVC LEDs
UVC Wavelength: 275 ± 5 nm
Reliability (hrs.): 33,000 hrs @ 25°C ambient, 100 mA
Operating Conditions: Temp Range: 10-60C (50-140F)
Relative Humidity (non-condensing): 10% to 95% RH
Regulatory Standards: UVC LEDs: UL – CCN ABQK, UL 2998,
Safety: UL/ cUL, FCC Part 15 Class B
Dimensions: 3.31” x 3.31” x 9.37”
specifications
UVantage_InsallationManual_Canadian-8inch_12-5-22.indd 3UVantage_InsallationManual_Canadian-8inch_12-5-22.indd 3 12/5/22 9:52 AM12/5/22 9:52 AM

4
|UVantage PLUS™ Installation Guide
preferred
mounting locations
6”
Suggested
Location
Optional
Location
RETURN
AIR DUCT
SUPPLY
AIR DUCT
Above image is for all metal duct wall. For Flex duct, duct board, or drywall applications,
proposed option of mounting the device at the apex of the evaporator coil.
UVantage_InsallationManual_Canadian-8inch_12-5-22.indd 4UVantage_InsallationManual_Canadian-8inch_12-5-22.indd 4 12/5/22 9:52 AM12/5/22 9:52 AM

Visit regalrexnord.com/uvantage-plus-canada for additional information |
5
safety guidelines
AUV radiation emitted from this device
AUnintended use of the device, or
damage to the housing, may result in
exposure to ultraviolet radiation.
AUltraviolet radiation may cause eye and
skin irritation.
AAvoid exposing eyes and skin to
ultraviolet radiation.
AKeep out of reach of CHILDREN.
ADO NOT touch UVC LEDs with bare
hands.
ADisconnect all power before servicing
the UVantage PLUS™device.
AOnly use supplied power adapter.
AWARNING indicates a hazard which,
if not avoided, could result in serious injury
or death.
PRECAUTIONS
DISPOSAL
AWARNING
ACAUTION indicates a hazard which,
if not avoided, could result in minor or
moderate personal injury.
ACAUTION
Products are made from high grade recyclable materials. Recycle where possible.
Dispose of, or recycle, the device in accordance with local ordinances or regulations.
UVantage_InsallationManual_Canadian-8inch_12-5-22.indd 5UVantage_InsallationManual_Canadian-8inch_12-5-22.indd 5 12/5/22 9:52 AM12/5/22 9:52 AM

6
|UVantage PLUS™ Installation Guide
items included for
installation
Control Cover Qty 1
Duct Plate Qty 1
LED Module Qty 1
Lead Assembly Qty 1
Screw Qty 4
Power Supply Qty 1
Template Qty 1
Gasket Qty 1
UVantage_InsallationManual_Canadian-8inch_12-5-22.indd 6UVantage_InsallationManual_Canadian-8inch_12-5-22.indd 6 12/5/22 9:52 AM12/5/22 9:52 AM

Visit regalrexnord.com/uvantage-plus-canada for additional information |
7
DO’s
✓Disconnect all power supplies to the
HVAC unit and UVantage PLUS™ module
(hereafter referred to as “LED module”)
before beginning any servicing.
✓Install the LED module at one of the
preferred locations listed by the
manufacturer in this manual.
✓Use the power supply which was provided
with the LED module for safe operation.
✓Use gloves and safety goggles while
installing the LED module.
✓Replace unit when light emitting diodes
(LEDs) reach end of life - RED LED will be lit.
✓Understand all the safety guidelines of
UVC radiation before handling the LED
module. Refer to the Safety Guidelines in
this manual.
✓While installing the UVC product, maintain
a minimum distance of 6 feet clearance
from filter or plastic materials which are
in direct line of sight. If not in direct line
of sight, a minimum distance of 3 feet is
recommended.
DON’Ts
✗Don’t attempt to look at the UVC
LED module while in operation.
✗Don’t allow any UV light to
escape from ductwork in any
way. Make sure ducts are
sealed.
✗Don’t touch the UVC LEDs
directly with bare hands, oil from
hands may damage the bulb.
✗Don’t assemble the unit by
rotating the LED bar clockwise.
Parts are designed for a snug fit.
✗Don’t connect power to the
module before completing the
entire installation.
installation
UVantage_InsallationManual_Canadian-8inch_12-5-22.indd 7UVantage_InsallationManual_Canadian-8inch_12-5-22.indd 7 12/5/22 9:52 AM12/5/22 9:52 AM

8
|UVantage PLUS™ Installation Guide
installation
1. Use template to mark the cut-pattern on
the duct surface. It is suggested to align
the template centered in the ductwork.
2. Use a hole saw to make a
1 1/4” to 1 3/8” hole on the
duct surface.
Ensure there is enough duct
depth (minimum 10 inches) before
proceeding with installation.
A
UVantage_InsallationManual_Canadian-8inch_12-5-22.indd 8UVantage_InsallationManual_Canadian-8inch_12-5-22.indd 8 12/5/22 9:52 AM12/5/22 9:52 AM

Visit regalrexnord.com/uvantage-plus-canada for additional information |
9
installation
4. Install the wall plate to the duct
surface along with the gasket using
the 4 self-threaded screws where
actual template mark was drawn.
Recommended mounting torque for
the screws is 0.4 ~ 0.5 N-m
The direction of the mounting should
match the airflow direction in the
ductwork as per the marking given on
the wall plate.
3. Mount the gasket on the
duct wall.
UVantage_InsallationManual_Canadian-8inch_12-5-22.indd 9UVantage_InsallationManual_Canadian-8inch_12-5-22.indd 9 12/5/22 9:52 AM12/5/22 9:52 AM

10
|UVantage PLUS™ Installation Guide
installation
6. Insert the LED module through
the hole of the wall plate and
rotate it counter-clockwise to
lock the LED module.
5. Connect the wire harness to the
LED module.
Don’t touch UVC LEDs
with bare hand.
Don’t rotate the module
clockwise; it could
result in causing
damage to the LED
module.
A
APress this latch if
you need to remove
the LED bar
UVantage_InsallationManual_Canadian-8inch_12-5-22.indd 10UVantage_InsallationManual_Canadian-8inch_12-5-22.indd 10 12/5/22 9:52 AM12/5/22 9:52 AM

Visit regalrexnord.com/uvantage-plus-canada for additional information |
11
installation
7. Connect the LED module harness
to the control cover as shown in
the image.
8. Snap the control cover firmly to the
wall plate.
SAFETY
SWITCH
UVantage_InsallationManual_Canadian-8inch_12-5-22.indd 11UVantage_InsallationManual_Canadian-8inch_12-5-22.indd 11 12/5/22 9:52 AM12/5/22 9:52 AM

12
|UVantage PLUS™ Installation Guide
installation
INDICATOR CAUSE*
GREEN LED Unit ON
PURPLE LED UVC LEDs ON
GREEN LED
(flash once)
Voltage fluctuations
(Refer to the troubleshooting section)
GREEN LED
(flash twice)
Current fluctuations
(Refer to the troubleshooting section)
PURPLE LED
(flashing) SAFETY SWITCH malfunction
RED LED
(flash once)
UVC LEDs life span reached 80%
(Plan for part replacement)
RED LED UVC LEDs reached end of life span
(Replacement is needed)
*Refer to the troubleshooting
section for more detail.
9. Connect the 24V adapter plug
to the DC jack on the control
cover and plug the power
supply into an outlet or control
wiring depending on the
application requirements. Hardwired Power
Supply (UVLED-C)
Wall Plugin Power
Supply (UVLED-R)
Green LED
Red/Purple LED
UVantage_InsallationManual_Canadian-8inch_12-5-22.indd 12UVantage_InsallationManual_Canadian-8inch_12-5-22.indd 12 12/5/22 9:52 AM12/5/22 9:52 AM

Visit regalrexnord.com/uvantage-plus-canada for additional information |
13
troubleshooting
LED
Indicator Status Condition Troubleshooting
Green
LED
ON Unit ON No action required.
OFF Unit OFF / Power
Failure
1. Verify the system is receiving proper line
voltage.
2. If the line voltage reading is good, check
for any loose connections of the power
supply adapter.
3. If the above steps do not work, contact the
service provider for unit replacement.
SINGLE
FLASH
Over / Under Voltage
Error
1. Verify the system is receiving proper line
voltage, If the line voltage reading is good
proceed with the next step.
2. Use only adapter provided with UVantage
PLUS
™
unit.
3. If the above steps do not work, contact the
service provider for unit replacement.
DOUBLE
FLASH
Over / Under Current
Error
1. Check for any loose connections of the UVC
LED module.
2. If the above steps do not work, contact the
service provider for unit replacement.
Purple
LED
ON UVC ON No action required.
OFF UVC OFF / Halted
1. Check if there is airflow in the duct. UVC LED
turns ON only in the presence of airflow
inside the duct.
2. If the UVC LED doesn’t turn on in the
presence of airflow, the UVC LED module
needs to be replaced.
UVantage_InsallationManual_Canadian-8inch_12-5-22.indd 13UVantage_InsallationManual_Canadian-8inch_12-5-22.indd 13 12/5/22 9:52 AM12/5/22 9:52 AM

14
|UVantage PLUS™ Installation Guide
troubleshooting
Red
LED
OFF No UVC Replacement
Notification No action required.
ON
100% UVC LED
Life consumed.
(The UVC LED life
has reached its end
and replacement is
mandatory)
Turn off the UVantage PLUS™unit and consult
supplier for the unit replacement.
SINGLE
FLASH
80% UVC LED
Life consumed.
(UVC LEDs life reached
80% of its lifetime.)
Plan for the UVantage PLUS™replacement.
LED
Indicator Status Condition Troubleshooting
Purple
LED FLASH Safety Switch Error
1. Verify the Control unit is mounted properly
without any loose fittings on the duct wall, so
that safety switch holds with wall plate firmly.
2. If the above steps do not work, contact the
service provider for unit replacement.
UVantage_InsallationManual_Canadian-8inch_12-5-22.indd 14UVantage_InsallationManual_Canadian-8inch_12-5-22.indd 14 12/5/22 9:52 AM12/5/22 9:52 AM

Visit regalrexnord.com/uvantage-plus-canada for additional information |
15
Red
LED
OFF No UVC Replacement
Notification No action required.
ON
100% UVC LED
Life consumed.
(The UVC LED life
has reached its end
and replacement is
mandatory)
Turn off the UVantage PLUS™unit and consult
supplier for the unit replacement.
SINGLE
FLASH
80% UVC LED
Life consumed.
(UVC LEDs life reached
80% of its lifetime.)
Plan for the UVantage PLUS™replacement.
faq’s
1. What is UVC?
UVC refers to an ultraviolet light with a wavelength between 200-280 nm. The light in this
wavelength can be used for germicidal irradiation in a HVAC system.
2. Where should the UVantage PLUS™ product be installed in the HVAC system?
The UVantage PLUS
™
device can be installed safely in all the duct works as highlighted in
preferred location for both residential and commercial HVAC systems.
3. Is the UVantage PLUS™ product effective in deactivating bacteria/viruses?
This UV device helps to reduce airborne bacteria and viruses. The use of this device is a
supplement to and not a substitute for standard infection control practices; users must
continue to follow all current infection control practices, including those practices related to
cleaning and disinfection of environmental surfaces.
4. How often do we need to clean the UVantage PLUS™ device?
Avoid direct cleaning of the UVC LEDs. UVC LED membranes are sensitive towards human
touch or brushes which might damage them and impact their operation. Should you need to
clean the device, it is advised to simply blow over the LED module.
5. Do UVC LEDs replace filters which are already being used in the duct?
No. The UVantage PLUS
™
device is not intended to replace filters. This product, when used
in conjunction with duct filters, provides an additional layer of protection to reduce airborne
contaminants.
6. Is UVC harmful?
UVC is harmful to all organic matter including human beings. Direct exposure may cause eye
or skin injuries and prolonged exposure may also lead to serious skin concerns. To operate
the UVantage PLUS
™
device safely, it is highly recommended to follow the safety guidelines
provided in this manual. Read the label and operating manual before using.
7. Does the UVantage PLUS™ device generate ozone?
No, the UVantage PLUS
™
device is completely ozone free and is compliant to UL 2998 standard.
UVantage_InsallationManual_Canadian-8inch_12-5-22.indd 15UVantage_InsallationManual_Canadian-8inch_12-5-22.indd 15 12/5/22 9:52 AM12/5/22 9:52 AM

Regal Rexnord Corporation, Climate Solutions
320 Superior Blvd. Mississauga, Ontario, Canada L5T 2N7
Contact: 905-670-4770
5yr
LIMITED
WARRANTY
Scan QR Code
Learn more or watch the
installation video
PRECAUTIONS:
Warning - UV radiation emitted from this device. Unintended use of the device, or damage
to the housing, may result in exposure to ultraviolet radiation. Ultraviolet radiation may
cause eye and skin irritation. Avoid exposing eyes and skin to ultraviolet radiation.
Regal Rexnord and UVantage PLUS are trademarks of Regal Rexnord Corporation or one of
its affiliated companies. Regal Rexnord Corporation, Climate Solutions 1946 W. Cook Road,
Fort Wayne, IN 46818, United States
Designed by Regal Rexnord Corporation.
Patent Pending
* RegalRexnord does not own or manage the following marks: UL & RoHS, which
are owned or managed by other third parties.
UVantage_InsallationManual_Canadian-8inch_12-5-22.indd 16UVantage_InsallationManual_Canadian-8inch_12-5-22.indd 16 12/5/22 9:52 AM12/5/22 9:52 AM
