Regency Fireplace Products Bellavista B41XTCE Quick start guide
Tested by:
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
Bellavista B41XTCE Video
appliance.
- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch: do not use any phone in your building.
Leave the building immediately.
• Immediately call your gas supplier from a neighbour's phone. Follow the gas supplier's
instructions.
WARNING
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could result in serious
injury, death, or property damage.
Bellavista® B41XTCE
Gas Fireplace
Owners &
Installation Manual
MODELS: B41XTCE-NG10
B41XTCE-LP10
919-375c FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4 12.13.16
2| Regency Bellavista® B41XTCE-10 Gas Fireplace
|
2
To the New Owner:
Congratulations!
You are the owner of a state-of-the-art Gas Fireplace by REGENCY®. The Bellavista™ B41XTCE has been designed
moment now to acquaint yourself with these instructions and the many features of your Regency® Fireplace.
Regency Bellavista® B41XTCE-10 Gas Fireplace | 3
| 3
MANUFACTURED MOBILE HOME REQUIREMENTS
INFORMATION FOR MOBILE/MANUFACTURED HOMES AFTER FIRST SALE
This Regency®
to local codes.
prohibited by local codes.
This appliance can only be used with the type of gas indicated on the rating plate. This appliance is not convertible for use with other
gases.
Bellavista
B41XTCE Video
Bellavista B36XT
4| Regency Bellavista® B41XTCE-10 Gas Fireplace
|
4table of contents
.................................................6
............................................................7
Installation
......................................................
Before You Start ............................................................
............................................
.....................................................9
Locating Your Gas Fireplace .........................................9
Clearances ..................................................................10
Mantel Clearances....................................................... 11
Mantel Leg Clearances................................................12
Non-Combustible Requirements .................................12
Framing ......................................................................13
Framing & Finishing.....................................................14
Tile Finish ............................................................14
Clean Finish .........................................................14
...............................16
........................................16
Nailing strips .......................................................16
.....................................................19
.............................19
.....................20
.......................................................21
Cross Reference Chart only ........................................21
..
23
..........................23
......................23
...............23
...............................................24
.................................................24
.................................................25
........................26
for corner installations .................................................26
..............................................26
........................................27
.............27
venting arrangements ..........................................
.................................
................................................29
o ...............29
................................................29
o ............29
venting arrangements ..........................................30
.....................................30
...................................................31
o .............31
..........................................32
..........................................33
....................34
..............................................................34
....................................................34
...........................................................35
.............................................................35
.........................................35
Gas Pipe Pressure Testing ..........................................35
.................................................36
.....................37
Log set installation .......................................................39
....................................43
Wiring Diagram ............................................................44
Optional Fan installation ..............................................45
Wiring Diagram With Optional Fan ..............................47
..........................
................................49
...................51
.......................................52
Safety Screen ..............................................................52
Operating Instructions
.................................................53
First Fire ......................................................................53
.............53
....................................................53
Lighting Procedure ......................................................54
Shutdown Procedure ...................................................54
..............................55
Maintenance
.............................................56
Log Replacement ........................................................56
...............................................................56
Door Glass...................................................................56
..................................57
......................................................
.............................................................
Parts
............................................................59
.........................................................60
Warranty
Warranty ......................................................................62
Regency Bellavista® B41XTCE-10 Gas Fireplace | 5
| 5
safety decal
review.
NOTE: Regency®
and repair must be done by a plumber or
Massachusetts.
connectors shall not exceed 36 inches in
length.
-
t-handle type valve.
The State of Massachusetts requires the
installation of a carbon monoxide alarm in
the gas appliance is installed.
DO NOT REMOVE THIS LABEL / NE PAS ENLEVER CETTE ÉTIQUETTE
411
411
DOOR SEAL: Please
check that the door is
properly sealed
Minimum Clearances to Combustibles /
D gagement ini at riaux ombustiblesésm maux aux mé c
Serial No./ No de serie
MAY BE INSTALLED IN MANUFACTURED (MOBILE) HOMES AFTER FIRST SALE.
Duplicate S/N
(See Instruction Manual for
detailed instructions)
APPAREIL FONCTIONNANT AU GAZ PROPANE
Modle B41XT E-LPèC10
PROPANE GAS: Model B41XT E-LPC10
NATURAL GAS: Model B41XT E-NGC10
Minimum supply pressure
Manifold pressure high
Manifold pressure low
Orifice size
Minimum input
Maximum input
Altitude
APPAREIL FONCTIONNANT AU NATURGAZEL
Modle B41XT E-NGèC10
Pression d'alimentation minimum
Pression emanifold - él vée
Pression bassemanifold -
Taille de lorifice
Dbit alorifique minimumcé
Dbit alorifique maximum seloncé
l'altitude
5.0" WC/C.E. (1.25 kPa)
3.5" WC/C.E. (0.87 kPa)
1.6" WC/C.E. (0.40 kPa)
#30DMS
30,000 Btu/h(8.79 kW) 42,500
Btu/h(12.45 kW)
0-4500 ft/pi(0-1372 m)
Pression d'alimentation minimum
Pression manifold - élevée
Pression bassemanifold -
Taille de lorifice
Dbit alorifique minimumcé
Dbit alorifique maximum seloncé
l'altitude
11" WC/C.E. (2.74 kPa)
10" WC/C.E. (2..49 kPa)
6.4" WC/C.E. (1.60 kPa)
#49DMS
29,500 Btu/h(8.65 kW) 37,500
Btu/h(10.99 kW)
0-4500 ft/pi(0-1372 m)
Minimum supply pressure
Manifold pressure high
Manifold pressure low
Orifice size
Minimum input
Maximum input
Altitude
FPI Fireplace Products International Ltd.
Delta, BC, Canada
919-374
This appliance must be installed in accordance with local codes, if any; if none, follow the National Fuel Gas Code, ANSI Z223.1, or Natural Gas and Propane Installation Code, CSA B149.1.
This appliance must be installed in accordance with the Standard CAN/CSA Z240 MH, Mobile Housing, in Canada, or with the Manufactured Home Construction and Safety Standard, Title 24 CFR, Part 3280, in the
United States, or when such a standard is not applicable,ANSI/NCSBCSA225.1/NFPA 501A, Manufactured Home Installations Standard.
This appliance is only for use with the type of gas indicated on the rating plate and may be installed in an aftermarket, permanently located, manufactured (mobile) home where not prohibited by local codes. See
owner's manual for details.
Installer l'appareil selon les codes ou règlements locaux, ou, en l'absence de tels règlements, selon les codes d'installationANSI Z223.1, National Fuel Gas Code ou CSA-B149.1 en vigueur.
Installer l'appareil selon la norme CAN/CSA-Z240, Série MM, Maison mobiles ou CAN/CSA-Z240 VC, Véhicules de camping, ou la norme 24 CFR Part 3280, Manufactured Home Construction and Safety Standard.
Si ces normes ne sont pas pertinentes, utilisez la normeANSI/NCSBCSA225.1/NFPA 501A, Manufactured Home Installations Standard, ouANSIA119.2 ou NFPA501C Standard for Recreational Vehicles.
Cet appareil doit être utili uniquement avec le type de gaz indiqué sur la plaque signalétique. Cet appareil peut être installé dans une maison préfabriquée ou mobile (É.-U. seulement) installée à demeure si lessé
règlements locaux le permettent. Voir la notice de l'utilisateur pour plus de renseignements. Cet appareil ne peut pas être utilisé avec d'autres gaz sauf si une trousse de conversion certifiée est fournie.
This vented gas fireplace heater is not for use with air filters. Ne pas utiliser de filtre à air avec ce foyer au gaz à évacuation.
For use with glass doors certified with the appliance only uniquement avec les portes en verre certifiées avec l'appareilÀ utiliser
Electrical supply / Électrique 115VAC, 1.13 A, 60Hz. Made in Canada/ Fabriqu au Canadaé
For Use Only with Barrier 508-100 Follow installation instructions. Utiliser uniquement avec lécran (n°508-100) Suivre les s d'installation.(Part #) consigne
VENTED GAS FIREPLACE HEATER - NOT FOR USE WITH SOLID FUELS.
NE PAS UTILISER AVEC DU COMBUSTIBLE SOLIDE.FOYER AU GAZ À ÉVACUATION -
Mantel Clearances from
Fireplace Opening:
(A) Min. 1"( mm)7-9/16 446
Side Wall Clearance
from Fireplace Opening
B) Min. 9 (229mm)
Ceiling from Top of
Fireplace Opening:
C) 3-/( mm)658 930
Mantel Depth:
D) Max. 12 (304mm)
Alcove Clearances:
E) Min. Width 60" (1524mm),
F) Max. Depth 36" (914mm)
Minimum Vent Clearances:
Horizontal Top 3" (76mm)
Horizontal Side 2" (51mm)
Horizontal Bottom 2" (51mm)
Vertical Vent 2" (51mm)
4001172
C
Floor
Wall
Ceiling
A
F
E
D
Listed: VENTED GAS FIREPLACE HEATER / FOYER AU GAZ À ÉVACUATION
CANADA and U.S.A.Certified for/Certifi e pour:é
Tested to: CAN/CGA-2.17-M91(R2009)
ANSI Z21.88-2014Conforms to:
14CSA 2.33-20Certified to:
Part #: 919-374
Colour: Everything black on grey except indicated items to be printed red.
Size: File at 100%
Material: 2 ml silver matt polyester (DPM SMS)
May 28/14: Created draft
*:Continue number sequence from 919-163 - do not restart at 0Printer
COPY OF THE SAFETY DECAL
6| Regency Bellavista® B41XTCE-10 Gas Fireplace
|
6requirements
5.08: Modifications to NFPA-54, Chapter 10
(2) Revise 10.8.3 by adding the following additional requirements:
(a) For all side wall horizontally vented gas fueled equipment installed in every dwelling, building or structure used in whole or in part for
residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent termination is less than
seven (7) feet above finished grade in the area of the venting, including but not limited to decks and porches, the following requirements shall
be satisfied:
1. INSTALLATION OF CARBON MONOXIDE DETECTORS. At the time of installation of the side wall horizontal vented gas fueled
equipment, the installing plumber or gasfitter shall observe that a hard wired carbon monoxide detector with an alarm and battery back-up is
installed on the floor level where the gas equipment is to be installed. In addition, the installing plumber or gasfitter shallobserve that a battery
operated or hard wired carbon monoxide detector with an alarm is installed on each additional level of the dwelling, building or structure
served by the side wall horizontal vented gas fueled equipment. It shall be the responsibility of the property owner to secure the services of
qualified licensed professionals for the installation of hard wired carbon monoxide detectors
a. In the event that the side wall horizontally vented gas fueled equipment is installed in a crawl space or an attic, the hard wired carbon
monoxide detector with alarm and battery back-up may be installed on the next adjacent floor level.
b. In the event that the requirements of this subdivision can not be met at the time of completion of installation, the owner shall have a period of
thirty (30) days to comply with the above requirements; provided, however, that during said thirty (30) day period, a battery operated carbon
monoxide detector with an alarm shall be installed.
2. APPROVED CARBON MONOXIDE DETECTORS. Each carbon monoxide detector as required in accordance with the above provisions
shall comply with NFPA 720 and be ANSI/UL 2034 listed and IAS certified.
3. SIGNAGE. A metal or plastic identification plate shall be permanently mounted to the exterior of the building at a minimum height of eight
(8) feet above grade directly in line with the exhaust vent terminal for the horizontally vented gas fueled heating appliance or equipment. The
sign shall read, in print size no less than one-half (1/2) inch in size, "GAS VENT DIRECTLY BELOW. KEEP CLEAR OF ALL
OBSTRUCTIONS".
4. INSPECTION. The state or local gas inspector of the side wall horizontally vented gas fueled equipment shall not approve the installation
unless, upon inspection, the inspector observes carbon monoxide detectors and signage installed in accordance with the provisions of 248 CMR
5.08(2)(a)1 through 4.
(b) EXEMPTIONS: The following equipment is exempt from 248 CMR 5.08(2)(a)1 through 4:
1. The equipment listed in Chapter 10 entitled "Equipment Not Required To Be Vented" in the most current edition of NFPA 54 as adopted by
the Board; and
2. Product Approved side wall horizontally vented gas fueled equipment installed in a room or structure separate from the dwelling, building or
structure used in whole or in part for residential purposes.
(c) MANUFACTURER REQUIREMENTS - GAS EQUIPMENT VENTING SYSTEM PROVIDED. When the manufacturer of Product
Approved side wall horizontally vented gas equipment provides a venting system design or venting system components with the equipment, the
instructions provided by the manufacturer for installation of the equipment and the venting system shall include:
1. Detailed instructions for the installation of the venting system design or the venting system components; and
2. A complete parts list for the venting system design or venting system.
(d) MANUFACTURER REQUIREMENTS - GAS EQUIPMENT VENTING SYSTEM NOT PROVIDED. When the manufacturer of a
Product Approved side wall horizontally vented gas fueled equipment does not provide the parts for venting the flue gases, but identifies
"special venting systems", the following requirements shall be satisfied by the manufacturer:
1. The referenced "special venting system" instructions shall be included with the appliance or equipment installation instructions; and
2. The "special venting systems" shall be Product Approved by the Board, and the instructions for that system shall include a parts list and
detailed installation instructions.
(e) A copy of all installation instructions for all Product Approved side wall horizontally vented gas fueled equipment, all venting instructions,
all parts lists for venting instructions, and/or all venting design instructions shall remain with the appliance or equipmentat the completion of
the installation.
MA Code - CO Detector
(for the State of Massachusetts only)
Regency Bellavista® B41XTCE-10 Gas Fireplace | 7
| 7
dimensions
UNIT DIMENSIONS
28-1/2"
38-3/8"
22.674
46-11/16"
25-9/16"
16-7/16"
32-5/8"
38-1/4"
36-3/8"
26-3/16"
3-1/4"
49-1/4"
11-5/8"
7-5/16"
1-9/16"
1-1/2"
35"
44-1/4"
3-5/8" 29-1/8"
23-7/16"
38-7/16"
[1185mm]
[974mm]
46-11/16"
[1185mm]
[976mm]
[889mm]
[738mm]
[92mm]
[594mm]
[649mm]
[664mm]
[1251mm]
[38mm]
[1123mm]
[417mm]
[829mm]
[185mm]
[294mm]
[724mm]
[39mm]
[923mm]
[971mm]
8| Regency Bellavista® B41XTCE-10 Gas Fireplace
|
8installation
3) See general construction and assembly
instructions. The appliance and vent should
be enclosed.
4) This appliance must be connected to the
outside of the building envelope. Never vent
instructions.
5)
6)
a wall or siding.
7)
be replaced prior to operating the appliance.
8)
is unfamiliar with the operation to use the
9) Wear gloves and safety glasses for protection
while doing required maintenance.
10) Be aware of electrical wiring locations in
walls and ceilings when cutting holes for
termination.
11)
for servicing should be replaced prior to
operating this appliance.
12)
practice to have all of your gas appliances
13)
14)
used in this appliance.
15)
Emissions from burning wood or gas could
other reproductive harm.
IMPORTANT MESSAGE
SAVE THESE
INSTRUCTIONS
The B41XTCE-10 Gas Fireplace must be
installed in accordance with these instructions.
Carefully read all the instructions in this manual
determine the need for a permit prior to starting
compliance with manufacturers instructions and
all applicable codes.
BEFORE YOU START
Safe installation and operation of this appliance
required by the Canadian Safety Standards
the following:
GENERAL SAFETY
INFORMATION
1) The appliance installation must conform
2)
electrically grounded in accordance with local
Code.
CLOTHING OR OTHER FLAMMABLE
MATERIAL SHOULD NOT BE PLACED
ON OR NEAR THE APPLIANCE.
CHILDREN AND ADULTS SHOULD
BE ALERTED TO THE HAZARDS OF
HIGH SURFACETEMPERATURES, ES-
PECIALLY THE FIREPLACE GLASS,
AND SHOULD STAY AWAY TO AVOID
BURNS OR CLOTHING IGNITION.
INSTALLATION AND REPAIR SHOULD
BE DONE BY AN AUTHORIZED
SERVICE PERSON. THE APPLIANCE
SHOULD BE INSPECTED BEFORE
USE AND AT LEAST ANNUALLY BY A
PROFESSIONAL SERVICE PERSON.
MORE FREQUENT CLEANING MAY
BE REQUIRED DUE TO EXCESSIVE
LINT FROM CARPETING, BEDDING
MATERIAL, ETC. IT IS IMPERATIVE
THAT CONTROL COMPARTMENTS,
BURNERS AND CIRCULATING AIR
PASSAGEWAYS OF THE APPLIANCE
BE KEPT CLEAN.
DUE TO HIGH TEMPERATURES, THE
APPLIANCE SHOULD BE LOCATED
OUT OF TRAFFIC AND AWAY FROM
FURNITURE AND DRAPERIES.
WARNING: FAILURETO INSTALLTHIS
APPLIANCE CORRECTLY WILL VOID
YOUR WARRANTY AND MAY CAUSE
A SERIOUS HOUSE FIRE.
YOUNG CHILDREN SHOULD BE CARE-
FULLY SUPERVISEDWHENTHEY ARE
IN THE SAME AREA AS THE APPLI-
ANCE. TODDLERS,YOUNG CHILDREN
AND OTHERS MAY BE SUSCEPTIBLE
TO ACCIDENTAL CONTACT BURNS.
A PHYSICAL BARRIERS IS RECOM-
MENDED IF THERE ARE AT RISK INDI-
VIDUAL INTHE HOUSE. TO RESTRICT
ACCESS TO A FIREPLACE OR STOVE,
INSTALL AN ADJUSTABLE SAFETY
GATE TO KEEP TODDLERS, YOUNG
CHILDREN AND OTHER AT RISK IN-
DIVIDUALS OUT OF THE ROOM AND
AWAY FROM HOT SURFACES.
IF THE BARRIER BECOMES
DAMAGED, THE BARRIER
SHALL BE REPLACED WITH THE
MANUFACTURER'S BARRIER FOR
THIS APPLIANCE.
ANY SAFETY SCREEN, GUARD, OR
BARRIER REMOVED FOR SERVICING
THE APPLIANCE, MUST BE
REPLACED PRIOR TO OPERATING
THE APPLIANCE.
A BARRIER DESIGNED TO REDUCE
THE RISK OF BURNS FROMTHE HOT
VIEWING GLASS IS PROVIDED WITH
THIS APPLIANCE AND SHALL BE
INSTALLED FOR THE PROTECTION
OF CHILDREN AND OTHER AT-RISK
INDIVIDUALS
Regency Bellavista® B41XTCE-10 Gas Fireplace | 9
| 9
installation
This includes:
1)
appliance for 15 minutes.
2)
CAUTION: Any alteration to the product that
causes sooting or carboning that results
in damage is not the responsibility of the
manufacturer.
LOCATING YOUR
GAS FIREPLACE
A) Flat on Wall
B) Flat on Wall Corner
C)
D) Corner
1)
ensure that the clearances are met.
2)
installed on a metal or wood panel extending
the full width and depth of the appliance.
3) The B41XTCE Gas Fireplace can be installed
in a recessed position or framed out into the
INSTALLATION
CHECKLIST
1) Locate appliance
2)
Note: M u s t b e d o n e b e f o r e i n s t a l l i n g u n i t i n t o
place.
3)
4)
5)
6)
to the following sections:
e. Standard Flush Door
f. Remote Control
7)
4) This appliance is Listed for bedroom
installations using the standard Remote
codes before installation.
5) The B41XTCE Gas Fireplace are approved
section for details.
6) We recommend that you plan your installation
on paper using exact measurements for
clearances and floor protection before
review your plans before installation.
Note: For vent terminations refer to
"Exterior Vent Termination Locations"
section.
Diagram 1
10 | Regency Bellavista® B41XTCE-10 Gas Fireplace
|
10 installation
NOT be
recessed into combustible construction.
WARNING
Fire hazard is an extreme risk
if these clearances (air space) to combustible materials are not
system be installed only in accordance with these instructions.
CLEARANCES
The clearances listed below are Minimum distances unless otherwise stated:
NOTE:
recommended
Clearance: Dimension Measured From:
A: Mantel Height (min.) Top of Fireplace Opening
B: Sidewall Side of Fireplace Opening
C: Ceiling Top of Fireplace Opening
D: Mantel Depth (max.)
from Top of Fireplace Opening
E: Alcove Width
F: Alcove Depth
Notes: 0"
Minimum Vent Clearances
to Combustibles
Alcove
E
F
C
D
A
E
F
C
Close to Ceiling
F
E
Diagram 2 Diagram 3
Diagram 4
Regency Bellavista® B41XTCE-10 Gas Fireplace | 11
| 11
installation
MANTEL CLEARANCES
Note: Ensure the paint that is used on the mantel and the facing is "heat resistant" or the paint may discolour.
Combustible mantel clearances from top of front facing are
shown in the diagram on the right.
Note: A non-combustible mantel may be installed at a lower height if the framing is made of metal studs covered with a non-combustible
board.
Mantel Clearances
B41XTCE
A B C D
From Top of
Fireplace Opening
Combustible
Mantel Clearances
2
0
12 64
810
0
Top of
Fireplace
Opening
12
1"
7
A
BC
Non-combustible
Header
(steel stud)
on edge
14
To Floor
12
24
Inches
D
6 Non-combustible
Standoff
12 | Regency Bellavista® B41XTCE-10 Gas Fireplace
|
12 installation
MANTEL LEG CLEARANCES
NON-COMBUSTIBLE REQUIREMENTS
38-7/16"
976mm
29"
[737mm]
NO FACING OR
FINISHING MATERIAL
IN THIS AREA
No Combustible
Materials in this Area
44-1/4"
[1124mm]
46-11/16"
[1186mm]
3-9/16"
[91mm]
11-5/8"
[295mm]
4-1/8"
[105mm]
6" [152mm]
50-1/4"
[1276mm]
NON-COMBUSTIBLE BOARD SUPPLIED W/UNIT
9 Side Wall
(Measured from side of
Fireplace Opening)
7
4
Mantel leg
Mantel leg
Allowable mantel leg
projection.
3"
1-1/2"
NOTE: The 6" x 46-11/16" supplied with the unit is secured directly above the unit as shown above.
**All other non-combustible material is supplied by others.
Diagram 5
Diagram 6
Regency Bellavista® B41XTCE-10 Gas Fireplace | 13
| 13
installation
FRAMING
Framing Dimensions Description B41XTCE
M Framing Width
N
P Corner Facing Wall Width
Q Corner Facing Wall Width
Framed Chase Ceiling - Rear
Framed Chase Ceiling - Top
T
Gas Connection Width
W
M
N
O
Q
P
R
U
V
T
Opening for gas
connection
11" (279mm)
dia. Hole through
wall Vent.
Non-Combustible
Header
(steel stud) on edge
Drywall
(or other
facing)
WNon-Combustible Facing
S
S
Non-Combustible
Header
(steel stud)
on edge
Diagram 7
14 | Regency Bellavista® B41XTCE-10 Gas Fireplace
|
14 installation
FRAMING & FINISHING
1. Frame in the enclosure for the unit with framing material.
Note: When constructing the framed opening, please ensure there is access to install the gas lines when the unit is installed.
2. For exterior walls, insulate the enclosure to the same degree as the rest of the house; apply vapour barrier and drywall, as per local installation codes. (Do
WARNING: Failure to insulate and add vapor barriers to the inside of the exterior wall will result in operational and performance problems in-
issues.
3. The unit does not have to be completely enclosed in a chase. You must maintain clearances from the vent to combustible materials: See "Clearances"
section. Combustible materials can be laid against the side and back standoffs and the stove base.
4. Tile Finish Option 1: Drywall may be installed onto the unit as shown below to create a surface to apply finishing materials such as tile, slate, etc.
Drywall cannot extend beyond the metal surface of the unit.
5. Tile Finish Option 2: If applying a non-combustible finishing material (tile,slate,etc) the material can be installed directly onto the metal surface (clean front)
of the unit in the area shown below.
1/2" DRYWALL
NON-COMBUSTIBLE FACING
FOR CLEAN LOOK (ie. painted finish)
(SUPPLIED BY OTHERS)
46-11/16"
[1186mm]
1/2" DRYWALL
DO NOT EXTEND
DRYWALL ONTO METAL
SURFACE OF UNIT.
WOOD STUD
44-1/4"
[1124mm]
6"
[152mm] NON COMBUSTIBLE BOARD SUPPLIED W/UNIT
38-7/16"
976mm
29"
[737mm]
Combustible and Non-combustible Facing and Finishing
Materials around unit.
CLEAN FINISH
TILE FINISH
6. If applying a non-combustible facing it may be installed over the metal surface (clean front) of the unit in the area shown below.
Combustible
Material
Non-combustible
Finishing Materia
l(ie. tile)
Non-combustible Material (6" x 46-11/16")
Finishing Material
(ie. tile)
Nailing Strip -1/2" back from unit face
Combustible
Material
Non-combustible Supplied with Unit
1-1/2
(38mm)
Ensure finished
material is
brought to lip
Combustible
Material
Non-combustible
Finishing Material
Non-combustible Material (6" x 46-11/16")
Finishing Material Nailing Strip-flush with unit face
Combustible
Material
Non-combustible Supplied with Unit
1-1/2
(38mm)
Ensure finished
material is
brought to lip
NOTE: The 6" x 46-11/16" non combustible material supplied with this unit can be replaced if trying to achieve a clean finish. A large piece of non
combustible material (ie. 4' x 8' x 1/2" can be used to eliminate taped seams on or near unit.
Diagram 8 Diagram 9
Diagram 10 Diagram 11
Regency Bellavista® B41XTCE-10 Gas Fireplace | 15
| 15
installation
38-7/16"
976mm
29"
[737mm]
NO FACING OR
FINISHING MATERIAL
IN THIS AREA
No Combustible
Materials in this Area
44-1/4"
[1124mm]
46-11/16"
[1186mm]
3-9/16"
[91mm]
11-5/8"
[295mm]
4-1/8"
[105mm]
6" [152mm]
50-1/4"
[1276mm]
NON-COMBUSTIBLE BOARD SUPPLIED W/UNIT
J Style trim or metal
corner bead may be
used to finish edges
No Combustible
Materials in this Area
29"
[737mm]
38-7/16"
976mm
7. Non-combustible material (ie. tile, slate, etc) may be brought up to the edge of the glass door of the unit. Minimum clearances must be adhered to, this
will assure ease of glass door removal and access to the lower panel.
NOTE: Non-combustible finishing materials may be of any thickness desired.
Minimum Clearances for Finishing Materials Trim materials
Note: All non-combustible facing material should butt up cleanly
to the flanges around the firebox opening.
Rough edges may be visible from an angle.
To maintain a clean finished edge - facing material edges
may be finished with a J-style trim or metal cornerbead (both
materials available at your local building or hardware store).
IMPORTANT: Materials used must be NON-COMBUSTIBLE.
IMPORTANT FINISHING DETAIL NOTE:
Diagram 12 Diagram 13
Diagram 14
16 | Regency Bellavista® B41XTCE-10 Gas Fireplace
|
16 installation
UNIT ASSEMBLY PRIOR TO INSTALLATION
BEFORE YOU START
is moved into position.
Nailing strip for
Tile Finish (set
back 1/2")
Nailing strip for
Clean Finish (set
1. There are 8 (eight) side nailing strips and one top nailing strip available on the unit. One set of four (4) are for a clean finish installation, the other set are
for a tile finish installation as they are set back 1/2" (13mm). The top nailing strip is adjustable to 1/2" (13mm).
2. Bend the required four (4) nailing strips to 90º.
3. Attach top nailing strip with one (1) screw (located at the back of the nailing strip). Adjust to required position, flush or back 1/2" and tighten screw.
Nailing strip for
Tile Finish (set
back 1/2")
Nailing strip for
Clean Finish (set
Adjustable Top
Nailing Strip
NAILING STRIPS
TOP STANDOFF ASSEMBLY
top line up.
Diagram 15
Diagram 16 Diagram 17
Regency Bellavista® B41XTCE-10 Gas Fireplace | 17
| 17
installation
CONVERSION TO TOP VENT
Note: This conversion must be done prior to the unit being placed in position.
Top Collar Assembly Kit Includes:
1
1
1
1
29
1 Restrictor
1
1
1
1
1)
-
ing the 10 screws.
remove top insulation cover plate
- by removing 2 screws as shown and discard.
Exhaust
Assembly
Intake Collar
Assembly
Before proceeding to Step 8
Flush
Door
Swing door out
from
the bottom
and lift up off
of door frame
slide the square piece of insulation
out and discard.
Diagram 18
Diagram 19
Diagram 20
Diagram 21
Diagram 22
Diagram 23
Diagram 24
18 | Regency Bellavista® B41XTCE-10 Gas Fireplace
|
18 installation
10) place the exhaust assembly into position
12)
13) Set vent restrictor accordingly - see next page.
11)
over tighten.
Intake Collar
Assembly
Exhaust
Assembly
completely remove the insulation
under the cover plate as shown and discard.
IMPORTANT:
Diagram 25
Diagram 26
Diagram 27
Diagram 28
Diagram 29
Diagram 30
Regency Bellavista® B41XTCE-10 Gas Fireplace | 19
| 19
installation
VENT RESTRICTOR & BAFFLE INSTALLATION
NOTE: THE VENT RESTRICTOR & BAFFLE MUST BE INSTALLED PRIOR TO OPTIONAL PANEL INSTALLATION.
Vent Restrictor installed on Top
Exhaust Assembly
6) From inside
1)
2) Go to venting arrangements section to determine if a vent restrictor
setting is required.
Note: The vent restrictor does not apply to rear vent applications.
3)
4)
as per diagram 32.
5)
SET 3
THIS HOLE SETS THE
VENT RESTRICTOR
AT 1-1/2
SET 2
THIS HOLE SETS THE
VENT RESTRICTOR
AT 2-1/2
SET 1
THIS HOLE SETS THE
VENT RESTRICTOR
AT 3-1/2
NO VENT RESTRICTOR
Factory setting
VENTING INTRODUCTION
draws outside combustion air into the combustion chamber thereby eliminating the need to use heated room air for combustion and losing warm room air
up the chimney.
Diagram 31
Diagram 32
Diagram 33
20 | Regency Bellavista® B41XTCE-10 Gas Fireplace
|
20 installation
EXTERIOR VENT TERMINATION REQUIREMENTS
Canada1USA2
A Clearance above grade, veranda, porch, deck, or balcony 12"(30cm) 12"(30cm)
B Clearance to window or door that may be opened 12"(30cm) 9" (23cm)
C Clearance to permanently closed window * *
D
from the center line of the terminal (check with the local code)
24"(60cm) 24"(60cm)
E 19-1/2"(50cm) 20"(51cm)
F Clearance to outside corner: with AstroCap XL Termination Cap. 13"(33cm) 13"(33cm)
Clearance to outside corner: with all other approved Termination Caps. 13"(33cm) 13"(33cm)
G Clearance to inside corner: with AstroCap XL Termination Cap 5-1/2"(14cm) 5-1/2"(14cm)
Clearance to inside corner: with all other approved Termination Caps. 7"(18cm) 7"(18cm)
H Clearance to each side of center line extended above meter/regulator assembly 36"(90cm)a*
J Clearance to service regulator vent outlet 36"(90cm) *
K Clearance to non-mechanical air supply inlet to building or the combustion air inlet to any other appliance 12"(30cm) 9" (23cm)
L Clearance to a mechanical air supply inlet #3' (91cm) above if within 10' (3m) horizontally. 72"(1.8m) 36"(90cm)b
M Clearance above paved sidewalk or a paved driveway located on public property 84"(2.1m)*
N Clearance under veranda, porch, deck, or balcony 12"(30cm)‡*
1 In accordance with current CSA B149.1,
2 In accordance with the current
A vent shall not terminate directly above a sidewalk or paved driveway which is located between two single family dwellings and serves both dwellings
*
a 3 feet (91cm) within a height of 15 feet (4.5m) above the meter / regulator assembly
b 3 feet (91cm) above - if within 10 feet (3m) horizontally
Other manuals for Bellavista B41XTCE
2
This manual suits for next models
2
Table of contents
Other Regency Fireplace Products Indoor Fireplace manuals
Regency Fireplace Products
Regency Fireplace Products Horizon HZO42-NG Quick start guide
Regency Fireplace Products
Regency Fireplace Products City Series User manual
Regency Fireplace Products
Regency Fireplace Products H2103 Quick start guide
Regency Fireplace Products
Regency Fireplace Products Contura RC500E Quick start guide
Regency Fireplace Products
Regency Fireplace Products Greenfire GFi350LNG-R Quick start guide
Regency Fireplace Products
Regency Fireplace Products P121-NG Quick start guide
Regency Fireplace Products
Regency Fireplace Products U900E-NG11 Quick start guide
Regency Fireplace Products
Regency Fireplace Products Regency Gi29LU Quick start guide
Regency Fireplace Products
Regency Fireplace Products Bellavista B36XTCE Quick start guide
Regency Fireplace Products
Regency Fireplace Products Horizon HZ42E-NG Quick start guide
Regency Fireplace Products
Regency Fireplace Products Pro HI500 Quick start guide
Regency Fireplace Products
Regency Fireplace Products Bellavista B41XTE-NG11 Quick start guide
Regency Fireplace Products
Regency Fireplace Products Alterra F175B-2 Quick start guide
Regency Fireplace Products
Regency Fireplace Products Energy U31-NG10 Repair manual
Regency Fireplace Products
Regency Fireplace Products I31-NG3 Service manual
Regency Fireplace Products
Regency Fireplace Products H2104 Service manual
Regency Fireplace Products
Regency Fireplace Products H2100 Quick start guide
Regency Fireplace Products
Regency Fireplace Products Panorama PG36 Series Quick start guide
Regency Fireplace Products
Regency Fireplace Products Classic I2453M Quick start guide
Regency Fireplace Products
Regency Fireplace Products Albany F200B-2 Quick start guide
Regency Fireplace Products
Regency Fireplace Products Liberty LRI4E-NG Quick start guide
Regency Fireplace Products
Regency Fireplace Products Greenfire GF900C-NG1 Quick start guide
Regency Fireplace Products
Regency Fireplace Products Grandview G800EH Quick start guide
Regency Fireplace Products
Regency Fireplace Products P36-NG4 Natural Gas Quick start guide
Popular Indoor Fireplace manuals by other brands
Ayce
Ayce DF-HT5390P Original instruction
Inca Metal Cutting
Inca Metal Cutting DCF42 Installation and operating instructions
Superior
Superior MHW36R Installation and operation instructions
Faber
Faber e-MatriX heat 800/500 I installation manual
Magiglo
Magiglo DUO POWER SV Series User, installation & servicing instructions
Travis Industries
Travis Industries 564 HO installation manual
NetZero
NetZero Kalfire E-one AA-11-05387-E-one 130F Installation and operation manual
Life Smart
Life Smart FP2042 quick start guide
Quality Craft
Quality Craft QCM995P-47ACH instruction manual
Heat & Glo
Heat & Glo MTL-INSERT owner's manual
Heat & Glo
Heat & Glo EXCLAIM-36 owner's manual
Vanguard
Vanguard 107156-01E.pdf OWNER'S OPERATION AND INSTALLATION MANUAL
metrofires
metrofires ECO Mega Smart Built-In installation & owner's operation manual
Focal Point
Focal Point TUSCANY Installation and user instructions
Comfortflame
Comfortflame Westerly32ZMN Installation and operation instructions
Heat & Glo
Heat & Glo 6000CL-IPI-S owner's manual
HAMPTON BAY
HAMPTON BAY HG35-NG1 Owners & installation
RealFlame
RealFlame 1290E-W user guide
