Rehasense NAVIGATOR User manual

Issue 12 / 2016
Art. No.: SM00003EN 1/11 Service Manual Navigator ENG
more than mobility
SERVICE MANUAL
Navigator
High support rollator

Issue 12 / 2016
Art. No.: SM00003EN 2/11 Service Manual Navigator ENG
0 Content
1. Cleaning
2. Technical data
3. Maintenance
4. Refurbishment
5. How to deposit the product
6. Warranty
7. Spare parts
8. Exchange of spare parts – instructions
1 Cleaning
General:
•Clean the device regularly and keep it clean.
•Lighter dirt and dust can be removed with a wet cloth.
•Larger parts of dirt can be removed with a non-corroding, mild washing agent and warm water.
•Do not use harsh abrasives or bleach based cleaners, as this may cause damage or discolouration.
•Dry parts with a soft cloth.
Wheels:
•Clean wheels with warm water and a mild cleanser. Dry with a clean rag.
•Lubricate with multi-purpose oil periodically or if wheels begin to squeak.
Wheel axles:
•The area between the fork and the front wheel should be kept clean, because dirt and hair
accumulating there and can cause faster wear of caster bearings.
•To do so, one should disassemble the front caster by disassembling it from the fork (according to
the instruction in paragraph 8.10), to remove all dirt, and then preserve the metal elements of the
wheel (i.e. to apply technical grease).
Brakes:
•If not working correctly the brakes should be adjusted according to the instructions
in paragraph 8.2.
2 Technical data
„NAVIGATOR“ high support rollator
Max. load
150 kg
Max. load of the bag
5 kg
Total weight with accessories
9.6 kg & shopping bag 0,3 kg
Length
66 cm
Width
Opened 62 cm / Folded 24 cm
Seat Width
46 cm
Height of armrests (adjustable)
90 – 115 cm
Seat height
62 cm
Brakes
2 handbrakes with locking function

Issue 12 / 2016
Art. No.: SM00003EN 3/11 Service Manual Navigator ENG
3 Maintenance
•Ensure that every part of the rollator is secure at ALL times.
•Check all screws for tightness. Tighten if necessary.
•Replace any broken, damaged or worn items immediately.
4 Refurbishment
The walker is suitable for re-use. Before passing on to another user it must be subject to an inspection by the
specialist dealer.
The following points have to be checked:
•Visual inspection of the frame
•Secure seating of nuts and bolts
•Condition of the plastic elements
•Condition of wheels and ball bearings
•Effectiveness and condition of the brakes
When a part is damaged or broken it must be replaced. It is recommended to replace the wheels whenever a
change. All loose bolts and nuts must be tightened.
The product must be thoroughly cleaned and disinfected prior to reuse.
It is recommended to remove the seat and the shopping bag before cleaning and to replace with new.
WARNING!It is forbidden to re-use the rollator when the frame is bent or broken.
The instruction manual must accompany the rollator with every change.
5 How to deposit the product
The device should not be deposited with normal garbage. It should be delivered to the deposit station for re-
use or recycling.
6 Warranty
The manufacturer offers a 2 year guarantee for errors in production and 5 years guarantee on the aluminium
frame. The guarantee is not valid by misuse of the product.

Issue 12 / 2016
Art. No.: SM00003EN 4/11 Service Manual Navigator ENG
7 Spareparts
7.1 General
Pos
Description Qty
Left Right
0Sub assembled armrest ROL18N ROL18M
1Arm pad
Height adjustable tube L size 2
Heigh adjustable tube M size 2
Brake cable:d5.0x1000-d1.5x1155mm for L-size
Brake cable,d5.0x840mm-d1.5x995mm for rollator M size
4Brake block set ; left + right side as one set 2
Complete cross brace for L size
Complete cross brace for M size
Complete cross brace for S size
Complete locking mechanism for cross brace for L size
Complete locking mechanism for cross brace for M size
Complete locking mechanism for cross brace for S size
7Shafts for shopping basket (set of 2) 1
8Lock system shaft assembly 1
9Black seat with pull strap and rings 1
10 Black step pedal 2
11 Front wheel 2
12 Rear wheel 2
13 Black front fork 2
Article No.
2
3
69100X-RS
2
69100Z-RS
ROL407
ROL4077
ROL1DR-RS
5
ROL1DS-RS
1
ROL1DT-RS
ROL1DU-RS
6
ROL1DW-RS
1
ROL1DX-RS
ROL1DY-RS
ROL20W-RS
ROL20A-RS
ROL10F-RS
ROL117-RS
ROL30H-RS
ROL30J-RS
2
ROL167
ROL11Z-RS

Issue 12 / 2016
Art. No.: SM00003EN 5/11 Service Manual Navigator ENG
14 Push handle with brake 2
15 Connecting clamp with pad mounting plate, inclusive lever 2
Standard shopping bag for L,M size
Standard shopping bag for S size
Side frame L size Wine Red ROL18L ROL18K
Side frame M size Wine Red ROL1CL ROL1CN
Side frame S size Wine Red ROL18K ROL18H
Side frame L size Sober Grey ROL191 ROL192
Side frame M size Sober Grey ROL1CM ROL1CP
Side frame S size Sober Grey ROL1BL ROL18J
ROL408
ROL409
16
ROL1AA
1
ROLSAA
17
2
2
5
3
4
6
7
8
10
1
11 12
9
13
14
15
16
17

Issue 12 / 2016
Art. No.: SM00003EN 6/11 Service Manual Navigator ENG
8 Exchange of spareparts
8.1 Replacement of brake cable
[Instruction with Router Rollator push handles]
8.2 Replacement of brake block

Issue 12 / 2016
Art. No.: SM00003EN 7/11 Service Manual Navigator ENG
8.3 Replacement of cross brace
[Instruction with Router Router rollator push handles]

Issue 12 / 2016
Art. No.: SM00003EN 8/11 Service Manual Navigator ENG
8.4 Replacement of locking mechanism
8.5 Replacement of shafts

Issue 12 / 2016
Art. No.: SM00003EN 9/11 Service Manual Navigator ENG
8.6 Replacement of shafts on rollators with button lock system
[Instruction with Router Rollator push handles]
8.7 Replacement of seat
[Instruction with Router Rollator push handles]

Issue 12 / 2016
Art. No.: SM00003EN 10/11 Service Manual Navigator ENG
8.8 Replacement of step pedal
8.9 Replacement of front fork

Issue 12 / 2016
Art. No.: SM00003EN 11/11 Service Manual Navigator ENG
8.10 Replacement of front wheel
8.11 Replacement of rear wheel
