WALL INSET MEDICINE CABINET

Date: 8-Oct-13 www. rejuvenation.com Page 2 of 4
Rev:
Important Safety Instructions:
•Note: Professional installation required
•Please read all instructions carefully before assembling.
•For your safety, assembly by two or more adults is strongly recommended.
•Keep instructions for future use.
•Use only vendor supplied hardware to assemble. Using unauthorized hardware could jeopardize the structural
integrity of the item.
•This hanging system is meant for drywall/stud mounting only.
•If walls are concrete, brick or plaster, please consult your local hardware store for assistance.
•Maximum total weight capacity for this product is 80 pounds (31.4 kg) in total, 20 pounds (9 kg) maximum per
glass shelf. Do not exceed the load capacity.
Pre-assembly:
•Remove all parts and hardware from the box and lay out on a clear carpeted or scratch-free work surface, as
this will avoid damaging parts during assembly. The shipping box provides an ideal work surface.
•Do not dispose of any packaging or contents of the shipping carton until assembly is completed to avoid
accidentally discarding small parts or hardware.
•Use the parts and hardware lists below to identify and separate each of the pieces included.
•The illustrations provided allow for easier assembly when used in conjunction with the assembly instructions.
•The use of power tools to aid in assembly is not recommended. Power tools can damage hardware and split
wood.
Parts Included:
(A) Cabinet 1 x
(B) Glass Shelf 3 x
Hardware Included:
(C)
Rubber Pad
(D)
Wood Screw
Dia. 4 x 38mm
(E)
Shelf Pin
2 x 4 x 12 x
Tools Required (not included):
Phillips Head Screwdriver
A
B

Date: 8-Oct-13 www. rejuvenation.com Page 3 of 4
Rev:
Assembly Instruction Steps:
1. MOUNT CABINET TO THE WALL
1) Mark the desired location on the wall for installation.
2) After verifying the dimensions of the recessed portion of the cabinet, use appropriate tools to cut a
rectangle in the wall covering (sheetrock) measuring approximately 19.09 inches wide and 24.6 inches high.
Use the level to make sure that the cutout is true and level.
Note to the professional installer: Once the sheetrock cutout is removed, it is likely that at least one wall
stud will interfere with the inserted portion of this cabinet (A) and that some internal framing will be required.
This will likely include cutting a section from the interfering stud and adding stud sections to ensure that
there is wood support located adjacent each side of this cabinet (A) when it is inserted.
3) After the appropriate stud cutting and framing has been done, insert the cabinet (A) into the recess and
ensure that it fits snugly and is true. Adjust and shim as necessary and make sure that the outer molding of
the cabinet (A) lies flush against the wall surface.
4) While holding the cabinet (A) firmly in the recess, insert mounting screws (D) into the holes located along
the inside side panels of the cabinet (A). Using a Phillips head screwdriver, screw each of the mounting
screws (D) into the adjacent wall studs or wood support structure until tight.
Note: Cabinet cannot be rotated to adjust door opening direction.
A
Wall
Wall
D

Date: 8-Oct-13 www. rejuvenation.com Page 4 of 4
Rev:
2. To install the shelf: Insert the shelf pin (E) into the pre-drilled holes on the interior side of the cabinet (A) at
desired level. Gently place glass shelf (B) onto the shelf pin (E). Repeat this step for the other shelf.
Optional: Attach the rubber pad (C) into the magnet in the wooden cabinet (A).
Care Instructions:
•Dust often using a clean, soft, dry and lint-free cloth.
•Blot spills immediately and wipe with a clean, damp, cloth.
•We do not recommend the use of chemical cleansers, abrasives or furniture polish on our lacquered finish.
•Hardware may loosen over time. Periodically check to make sure all connections are tight.
Re-tighten if necessary.
Thank ou for our purchase
