Renault Radio Connect R & GO User manual

Radio Connect R & GO
s R a s / l
G / R c s n RR si et t
n e en om t ell

1
English ..................................................................
Român ...................................................................
Türkçe ...................................................................
ελληνικά ................................................................
GB
RO
TR
GR

GB.1
Contents
Translated from French. Copying or translation, in part or in full, is forbidden unless prior written permission has been obtained
from the vehicle manufacturer.
User precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . GB.2
General description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . GB.4
Introduction to the controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . GB.6
Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . GB.15
Using voice recognition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . GB.16
Listen to the radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . GB.18
Listening to a CD/MP3 player . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . GB.21
Auxiliary audio sources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . GB.24
Pairing/unpairing a phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . GB.27
Connecting/disconnecting a phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . GB.30
Making/receiving a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . GB.33
System settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . GB.36
R & GO: General description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . GB.39
R & GO: Navigation function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . GB.45
R & GO: Multimedia function. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . GB.48
R & GO: Vehicle function. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . GB.51
R & GO: Telephone function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . GB.53
R & GO: Calendar function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . GB.55
R & GO: Adjusting settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . GB.56
Operating faults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . GB.58

GB.2
USER PRECAUTIONS (1/2)
It is essential to follow the precautions below when using the system, both in the interest of safety and to prevent material damage.
You must always comply with the laws of the country in which you are travelling.
Precautions when operating the audio system
– Operate the controls (on the dash or near the steering wheel) and read the information on the screen only when road
conditions allow.
– Set the volume to a reasonable level so that outside noise can be heard.
Precautions concerning the equipment
– Do not attempt to dismantle or modify the system, as there is a risk of damage to equipment and fire.
– Contact a representative of the manufacturer in the event of malfunction and for all operations involving disassembly.
– Do not insert foreign objects, or damaged or soiled CDCD MP3s into the player.
– Only use 12 cm diameter circular CDCD MP3s.
– When handling discs, hold them by the inner or outer edges, without touching the non-printed face of the CDCD MP3.
– Do not stick paper to the CDCD MP3.
– After prolonged use, remove the CD CD MP3 from the player with care as it may be hot.
– Never expose CDs/CD MP3s to heat or direct sunlight.
– Do not use products containing alcohol and/or spray fluids on the area.
Precautions when using the phone
– There are laws which govern the use of phones in vehicles. They do not necessarily authorise the use of hands-free phone
systems under all driving conditions: drivers must be in control of their vehicles at all times.
– Using a phone whilst driving is a significant distraction and risk factor during all stages of use (dialling, communicating,
searching for a number in the handset memory, etc.).
Maintenance of the fascia
– Use a soft cloth and, if necessary, a small amount of soapy water. Rinse with a soft, slightly damp cloth, then dry with a soft,
dry cloth.
– Do not press on the display on the front panel, and do not use any alcohol-based products.

GB.3
USER PRECAUTIONS (2/2)
The description of the models given in this manual is based on the specifications at the time of writing. This manual covers
all existing functions for the models described. Whether or not they are fitted depends on the equipment model, op-
tions selected and the country where they are sold. This manual may also contain information about functions to be
introduced later in the model year.
Depending on the make and model of your telephone, some functions may be partially or completely incompatible with your
vehicle’s multimedia system.
Throughout the manual, the Approved Dealer is that of the vehicle manufacturer.

GB.4
GENERAL DESCRIPTION (1/2)
Introduction
The audio system has the following
functions:
– FM (RDS) and AM radio;
– terrestrial digital radio (DR);
– CD/CD MP3 player;
– management of auxiliary audio
sources;
– Bluetooth® hands-free phone
system.
Radio and CD/CD MP3
functions
The radio allows you to listen to radio
stations and play CDs in different audio
formats.
The radio stations are classed by wave-
length: FM (frequency modulation) and
AM (amplitude modulation).
The DR system (DAB, DAB+, T-DMB
format) provides better sound repro-
duction.
The RDS system makes it possible to
display the name of some stations or
messages sent by FM stations to be
displayed:
– traffic bulletins(TA);
– emergency messages.
Auxiliary audio function
You can listen to your personal stereo
directly through your vehicle’s spea-
kers. There are several ways of connec-
ting your personal stereo, depending
on the type of device you have:
– USB socket;
– Jack socket;
– Bluetooth® connection.
For more information on the list of com-
patible devices, contact an authorised
dealer.

GB.5
GENERAL DESCRIPTION (2/2)
Hands-free phone function
The Bluetooth® hands-free system
provides the following features without
having to handle your phone:
– Pair up to 5 phones;
– send/receive/reject a call;
– transfer the phone’s or SIM card’s
contact list (depending on the
phone);
– view the system’s call log (depend-
ing on the phone);
– dial voicemail.
Bluetooth® function
This function enables the audio system
to recognise and control your portable
audio player or mobile phone using
Bluetooth® pairing.
You can activate/deactivate the
Bluetooth® function in the “Bluetooth”
menu:
– display the settings menu by pres-
sing 9;
– select «Bluetooth» by turning and
pressing 5;
– select «ON»/«Off».
Your hands-free phone
system is only intended to
facilitate communication by
reducing the risk factors,
without removing them completely.
You must always comply with the
laws of the country in which you are
travelling.
ON
OFF

GB.6
INTRODUCTION TO THE CONTROLS (1/9)
1
12
6
5
4
Steering column controls
System panels
17
19
15
22
21
3
19
18
20
15 1716
23
1
13
2
2
11
11
8
6
4
10 7
3
97
1413
A
B
C

GB.7
INTRODUCTION TO THE CONTROLS (2/9)
4
11
3
5
9
1
10
11
8
77
13
14
7
5
9
1
7 813
10
3
4
14
6
12
24 6
Steering column controlsSystem panels
15 16 17
25
19
22 23
2
2
11
17
19
18
23
15
16

GB.8
INTRODUCTION TO THE CONTROLS (3/9)
System panels
15
2
25 12
4
10
3
14
7
26 6
11
Steering column controls
9
11
17
19
15
22
27
23
15
2
25 12
4
10
3
14
7
28 6
11
9
11
D

GB.9
29
30
Steering wheel controls
30
30
INTRODUCTION TO THE CONTROLS (4/9)
System panel Steering wheel controls
51
11
7
36
9
8
13
414 1024
2
30

GB.10
INTRODUCTION TO THE CONTROLS (5/9)
AUDIO function TELEPHONE function
1– Press: on/off.
– Rotation: adjust the volume of the audio source currently in use.
2Information display.
3– Short press: choose the radio source and the waveband: FM1 →FM2 →DR1 →DR2 →AM.
– Long press: updating of the list of radio stations.
4Select the desired audio source (if connected): CD / CD MP3 →iPod1/USB1 →iPod2/USB2 →device
Bluetooth® →AUX (Jack socket).
5– Press: confirm an action.
– Rotation: navigate through the menus or lists.
6– Return to previous screen/previous level when browsing through menus;
– Cancel current action.
7
– Short press: change tracks (CD/CD MP3, on some port-
able audio players) or change radio frequencies.
– Maintained press: fast forward/rewind a CD/CD MP3 track
on some audio players, or scroll through the radio stations
until the button is released.
8USB socket for iPod® or auxiliary audio sources.
9– Short press: access the custom settings menu. – Press and hold: activates the “Text” function (only for front
panels Aand B).

GB.11
INTRODUCTION TO THE CONTROLS (6/9)
AUDIO function TELEPHONE function
10
– Short press: access the «Phone» menu.
– Long press: redial the last number.
When receiving a call:
– short press: answer the call;
– long press: reject the call.
During a call: end the call in progress.
11 Short press: recall a pre-programmed station.
Press and hold: store a radio station.
12 Eject a CD/CD MP3.
13 Auxiliary input.
14 Activate the “Text” function.
15 Select the audio source: FM1 →FM2 →DR1 →DR2 → AM →CD / CD MP3 →iPod1/USB1 →iPod2/USB2 →
Bluetooth® Device →AUX (jack input).
16 – Short press: access the “Phone” menu.
– Long press: redial the last number.
17 Increase the volume of the audio source currently in use.
18 – Mute the radio source currently playing; – mute the sound and pause the playback of the CD/CD
MP3, USB, iPod® or Bluetooth® device.
Long press: redial the last number.
When receiving a call:
– short press: answer the call;
– long press: reject the call.
During a call: end the call in progress.

GB.12
INTRODUCTION TO THE CONTROLS (7/9)
AUDIO function TELEPHONE function
19 Decrease the volume of the audio source currently in use.
17 +19
(Only for controls Cand D)
– Mute the radio source currently playing;
– mute the sound and pause the playback of the CD/CD MP3, USB, iPod® or Bluetooth® device.
20
Rotate:
– radio: browse through the radio list;
– media: previous/next track.
Rotate:
– «Phone» menu: browse through the list.
– Short press: confirm an action.
Long press:
– return to previous screen/previous level when browsing
through menus;
– cancel current action.
– Short press: confirm an action.
Long press:
– return to previous screen/previous level when brows-
ing through menus;
– cancel current action.
21
– Short press: access the «Phone» menu.
– Long press: redial the last number.
When receiving a call:
– short press: answer the call;
– long press: reject the call.
During a call: end the call in progress.

GB.13
INTRODUCTION TO THE CONTROLS (8/9)
AUDIO function TELEPHONE function
22
– Short press: confirm an action.
Long press:
– return to previous screen/previous level when browsing
through menus;
– cancel current action.
– Short press: confirm an action.
Long press:
– return to previous screen/previous level when brows-
ing through menus;
– cancel current action.
23
Rotate:
– radio: browse through the list of radio stations stored pre-
viously;
– media: previous/next track.
Rotate:
– «Phone» menu: browse through the list.
24 Remove the phone support cover by turning it counter-clockwise.
25 – Mute the radio source currently playing; – mute the sound and pause the playback of the CD/CD
MP3, USB, iPod® or Bluetooth® device.
26 Activate/deactivate the automatic search for and playing of traffic information as soon as it is broadcast by certain radio
stations in FM or DR mode.

GB.14
INTRODUCTION TO THE CONTROLS (9/9)
AUDIO function TELEPHONE function
27
– Short press: access the “Phone” menu.
When receiving a call:
– short press: answer the call;
– long press: reject the call.
During a call: end the call in progress.
– Long press: activate voice recognition.
– Short press: deactivate voice recognition.
28 To activate random playback of all the tracks on the CD/
CD MP3.
29
When receiving a call:
– short press: answer the call;
– long press: reject the call.
During a call: end the call in progress.
30 – Short press: activate voice recognition.
– Short press: deactivate voice recognition.

GB.15
OPERATION
On and off
Briefly press control knob 1on the
audio system front panel to switch on
your system.
The audio system can be used with the
vehicle ignition off. It will operate for
twenty minutes. Press control knob 1
on the audio system front panel to op-
erate the system for a further twenty
minutes.
To switch off the audio system, briefly
press control knob 1on the audio
system front panel.
CHOOSING THE SOURCE
To scroll through the various audio
sources, press button 4repeatedly on
the audio system front panel or 15 on
the steering column control. The audio
sources scroll in the following order:
CD/CD MP3 →iPod1/USB1 →iPod2/
USB2 →BT Streaming (Bluetooth®) →
AUX.
Note: To display the telephone menu,
press button 10 on the audio system
front panel or 16, 21 or 27 on the steer-
ing column control.
When you insert a new medium (CD/
CD MP3, USB, AUX) while the radio is
on, the source will switch automatically
and begin to play.
You may also select the radio source by
pressing button 3 on the audio system
front panel or 15 on the steering column
control. Repeatedly pressing button 3
on the audio system front panel scrolls
through the wavelengths in the follow-
ing order: FM1 →FM2 →DR1 →DR2
→AM →FM1 etc.
To change media and radio source,
press button 15 on the steering column
control.
VOLUME
Adjust the volume by turning control
knob 1on the audio system front panel
or by pressing button 17 or 19 on the
steering column control.
The display reads “Volume” followed
by the current setting value (from 00 to
31).
Mute
Briefly press button 18 or 25,or
press 17 and 19 together on the steer-
ing column control. The message
“MUTE” is displayed on the screen.
Briefly press button 18, 25, 17 or 19
on the steering column control again
to resume playing the current audio
source.
You can also disable the mute function
by turning control knob 1on the audio
system front panel.

GB.16
Voice recognition system
Using a compatible smartphone, your
audio system enables you to use the
voice recognition system. This makes it
possible to control the functions of your
smartphone by voice, while keeping
your hands on the steering wheel.
Note: your smartphone’s voice recog-
nition system only enables you to use
the functions of your telephone. It does
not enable you to interact with the other
functions of your audio system such as
the radio, the Driving eco² etc.
Note: when using voice recognition,
the language set on your telephone will
be the language used by your audio
system.
Note: If you try to use your vehicle’s
voice recognition system with a paired
smartphone that does not have voice
recognition, a message will be dis-
played on the audio system screen to
notify you.
USING VOICE RECOGNITION (1/2)
30
27
Using voice recognition with
your phone
Activation
To activate the voice recognition
system, you must:
– get a 3G, 4G or Wifi connection with
your smartphone;
– activate the Bluetooth® on your
smartphone and make it visible to
other devices (please refer to your
telephone manual for instructions);
– pair and connect your smartphone to
the audio system (please refer to the
section on “Pairing, unpairing a tel-
ephone”);
– press and hold the 27 button on the
steering column control or tap the 30
button on the steering wheel.
An audible signal indicates that voice
recognition is activated.
