resideo PROSIXLCDKP-EU Series Assembly instructions

PROSIXLCDKP-EU SERIES
Wireless Keypad
Installation and Setup Guide
The PROSIXLCDKP-EU is a wireless keypad for use with Control Panels that support SiX™ series devices. Up to eight (8)
Keypads per partition can be used on the system.
Note: Installation shall be done in accordance with local regulations.
Item/Key
Function
Display Window
Liquid Crystal Display (LCD) displays
protection point identification, system status,
and messages.
Power LED
System Status LED
System Trouble LED
AWAY
Arm Away key
HOME
Arm Home (Stay) key
NIGHT
Arm Night (Stay) key
OFF
Off key
SELECT
Select key
SCROLL
•Scroll key
•Local Programming key (2-second hold)
MAX
Arm (Away) Maximum key (no entry delay)
TEST
System Test key
BYPASS
Bypass Zone key
INSTANT
Arm (Home) Instant key (no entry delay)
CODE
Add Security Codes key
CHIME
Chime Mode key
READY
Check Zones key
Disarm/Cancel Key
Prox Tag reader (RFID)
Panic Alarm key
Panic key + Fire Panic key
Panic key + Police Panic key
Panic key + Medical Panic key
Keys 0 - 9
Numeric keys used to enter security code(s).
KEYPAD OPERATION
For operating instructions, refer to the Control Panel instructions.
LEDs
Off
Red - Steady
Green - Steady
Red - Flashing
POWER
Battery - OK
Battery - Low
STATUS
Not Ready to Arm
Armed
Ready to Arm
Alarm Detected
TROUBLE
No Trouble Present
System Trouble Present
--
Device Trouble Present
Note: When the system is in Programming Mode, the Trouble and Status LEDs alternately flash Red and Green.

KEYPAD MOUNTING
The keypads can be surface mounted directly to a wall as follows:
1. Separate the keypad front panel [A] to the rear mounting plate [B].
2. Mount the mounting plate to the wall using the screws [C]. Insert the tamper screw [D] as shown.
Note: Mounting screws not provided. Use 3.5mm –4mm wood screws (with plastic wall anchors, if necessary).
3. Pullout the battery activation tab [E] from the back of the keypad front panel.
4. Align the case with the cleats [F] and snap into place and secure with bottom screw [G] (provided).
ENROLLING KEYPAD
The keypad must be enrolled in the Control Panel before it can be used.
Registration and programming are conducted through the AlarmNet
360™ cloud-based management platform. After accessing the customer
account, perform the following steps.
1. Select “KEYPADS”.
2. Select “ADD KEYPAD”.
3. Select “LEARN” and wait for the Control Panel to be in learning
mode.
4. Activate the keypad by pressing any key:
•The keypad automatically attempts to pair with the Control Panel.
•The top three status LEDs [A] and bottom four Panic keys [B] will
come on (red).
•If enrollment is not successful, press any of the keys on the
keypad to restart the pairing process or remove and reinstall
batteries.
5. After a successful pairing, the keypad’s LCD display will turn off, and
the three status LEDs [A] and four Panic keys will [B] will turn off a
few seconds later to confirm the pairing.
6. After enrollment, program and save the keypad’s zone options (zone
descriptor, etc.)
Note: Make sure to assign a descriptor to the keypad for easy
identification when keypad events occur.
IMPORTANT:After enrolled, the keypad cannot be used with another
Control Panel until it is un-enrolled (deleted) from the current
panel through the AlarmNet 360™ cloud-based management
platform.
Note: For detailed programming instructions refer to the Installation
Instructions for the Control Panel with which this device is used.
AUTHENTICATING KEYPAD USER
For security purposes, a user (or installer) of the keypad must be authenticated prior to being able to access/view
any of the keypad displays. To authenticate a user, perform the following steps.
Note: Nothing will be displayed, even if the system is armed, until a valid PIN (or Prox Tag) is entered +press any key.
1. At the keypad, enterthe PIN (or swipe the Prox Tag) for the user.
2. After a successful authentication, enter the 4/6-digit code +
•The system is disarmed and alarm sounding is silenced.
•To clear the memory of alarm display (if present), enter 4/6-digit code + again.

PANIC ALARM KEYS
This keypad features three Emergency Panics for 24-
hour silent, audible, fire or medical / personal
alarms. These emergency Panic keys may be
programmed for Fire, Police, and Medical alarms.
Panic activation requires a 2-button sequence. After
the first button in the sequence is pressed, you can
cancel the emergency by pressing any key other than
one of the Panic keys.
Note: Only the Audible Alarm option can be used as a
holdup alarm.
Panic
There are 3 ways to generate an emergency Panic alarm:
1. Press Panic and within 10 seconds press the desired
emergency key (Fire, Police, Medical).
2. Press desired emergency key and within 10 seconds
press the Panic button.
3. Press desired emergency key and within 10 seconds
press the same key.
Fire
Police
Medical
KEYPAD PROGRAMMING MODE
This mode displays keypad programmed information and provides access to Default and Reset options. Enter the INSTALLER code
+1 to disarm. Press and hold the "3" key for 2 seconds to enter PROGRAMMING mode. The system will exit PROGRAMMING mode
after 10 seconds of inactivity. Press the "3" key to scroll or "*" key to exit.
Display
Meaning/Option
Display
Meaning/Option
App: / Boot:
Displays the keypad’s current App and Boot
versions
Partition= / Keypad ID=
Displays Partition assignment and Keypad ID
programmed in the control panel.
RF6:
Displays the keypad’s SiX software version and
the keypad MAC ID
Reset Keypad
Prompts to Reset Keypad. 2=CONFIRM
(restart)
Default Keypad
Prompts to Default Keypad. 2 = CONFIRM to
remove keypad from control panel.
Note: If the keypad is repowered within 24
hours, it will re-pair with the control panel. After
24 hours, it will need to be re-enrolled.
A: None
(Future Use)
B: None
(Future Use)
BATTERY REPLACEMENT
1. At the bottom of the keypad, remove the screw that
secures the front cover to the rear mounting bracket.
2. Remove the batteries, wait 10 seconds, then insert three
new 3V Lithium batteries (see Specifications for
replacement batteries).
3. Align the case with the cleats and snap into place and secure
with bottom screw
BATTERY CAUTION: Risk of fire, explosion, and burns. Do not
recharge, disassemble, heat above 55°C, or incinerate. Dispose
ofused batteries properly. Keep away from children.
Note: Constant exposure to high or low temperature or high
humidity may reduce battery life.
SPECIFICATIONS
Dimensions (mm) / Weight: 161 (H) x 97 (W) x 34 (D) / 285 g
RF Frequency: 2.4GHz (<20 dBm)
Batteries: Three (3) - 3V Lithium:
•EVE CR-123A
•Panasonic CR123A
•Duracell DL123A
Tamper: Wall (audible alert and signal sent to Control Panel)
Sounder: Piezoelectric
The product should not be disposed of with other household waste. Check for the nearest authorized collection
centers or authorized recyclers. The correct disposal of end-of-life equipment will help prevent potential negative
consequences for the environment and human health.
This system must be checked by a qualified technician at least once every three (3) years.
Any attempt to reverse-engineer this device by decoding proprietary protocols, de-compiling firmware, or any similar actions is strictly prohibited.
REFER TO THE INSTALLATION INSTRUCTIONS FOR THE CONTROL WITHWHICH THIS DEVICE IS USED, FOR DETAILS REGARDING
LIMITATIONS OF THE ENTIRE ALARM SYSTEM.
IP 31

SUPPORT & WARRANTY INFORMATION
For the latest documentation, warranty, and support, please go to: www.resideo.com
Sécurité Communications SAS (SECOM)
1198, Avenue du Docteur Maurice Donat
06250 Mougins - FRANCE
Ademco 1 Ltd., 200 Berkshire Place
Winnersh Triangle, Berkshire,
RG41 5RD –UNITED KINGDOM
PROSIXLCDKP-EU
R800-26496B03/22 Rev B
