resideo PROSIXLEDKP-EU Series Assembly instructions

PROSIXLEDKP-EU SERIES
Wireless Keypad
Installation and Setup Guide
The PROSIXLEDKP-EU is a wireless keypad for use with Control Panels that support SiX™ series devices. Up to eight (8) Keypads
can be used on the system.
Note: Installation shall be done in accordance with local regulations.
ItemFunction
Speaker Sounds status tones

Power LED

System Status LED

System Trouble LED

AWAY 
Arm Away key

HOME 
Arm Home (Stay) key

NIGHT 
Arm Night (Stay) key

OFF 
OFF key

SELECT 
Select key

SCROLL 
Scroll key
Local Programming key (2-second hold)

MAX 
Arm Maximum key (No Delay)

TEST 
System Test key

BYPASS 
Bypass Zone key

INSTANT 
Arm Instant key (No Delay)

CODE 
Add Security Codes key

CHIME 
Chime Mode key

READY 
Check Zones key

# 
Quick Arm key

Disarm/Cancel Key
Panic Alarm key
Fire Panic key
Police Panic key
Medical Panic key
Keys 0 - 9 Numeric keys used to enter security code(s).
Prox Tag reader (RFID)



KEYPAD OPERATION 
For operating instructions, refer to the Control Panel instructions.
LEDs Off Red Green Flashing Red
POWER Battery - OK Battery - Low
STATUS Not Ready to Arm Armed Ready to Arm Alarm/Alarm Memory
TROUBLE System Trouble -- Device Trouble


KEYPAD MOUNTING
The keypads can be surface mounted directly to a wall as follows:
1. Separate the keypad front panel [A] to the rear mounting plate [B].
2. Mount the mounting plate to the wall using the screws [C]. Insert the tamper screw [D] as shown.
Note: Mounting screws not provided. Use 3.5mm – 4mm wood screws (with plastic wall anchors, if necessary).
3. Pull out the battery activation tab [E] from the back of the keypad front panel.
4. Align the case with the cleats [F] and snap into place and secure with bottom screw [G] (provided).
AUTHENTICATING KEYPAD USER
For security purposes, a user (or installer) of the keypad must be authenticated prior to being able to access/view any of the keypad
status indicators. To authenticate a user, perform the following steps.
Note: No status indicators will be displayed, even if the system is armed, until a valid PIN (or Prox Tag) is entered.
1. At the keypad, enter the PIN (or swipe the Prox Tag) for the user.

2. After a successful authentication, enter the command starting with "1" = arm if the panel is DISARMED or "5" if the panel is
ARMED.

ENROLLING KEYPAD
The keypad must be enrolled in the Control Panel before it can be used.
Registration and programming are conducted through the AlarmNet 360™
cloud-based management platform, using the Resideo Pro App. After
accessing the customer account, perform the following steps.
1. From the Select “KEYPADS”.
2. Select “ADD KEYPAD”.
3. Select “Learn” and wait for the Control Panel to be in learning mode.
4. Activate the keypad by pressing any key:
The keypad automatically attempts to pair with the Control Panel.
The top three status LEDs [A] and bottom four Panic keys [B] will
come on (red).
If enrollment is not successful, press any of the keys on the keypad to
restart the pairing process or disconnect and reconnect power.
5. After a successful pairing, the top three status LEDs and bottom four
Panic keys will go off and two beeps will sound to confirm the pairing.
6. After enrollment, program and save the keypad’s zone options (zone
descriptor, etc.)
Note: Make sure to assign a descriptor to the keypad for easy identification
when keypad events occur.
IMPORTANT: After enrolled, the keypad cannot be used with another
Control Panel until it is un-enrolled (deleted) from the current
panel through the AlarmNet 360™ cloud-based management platform.
Note: For detailed programming instructions refer to the Installation
Instructions for the Control Panel with which this device is used.

[C]
PROSiXLEDKP-EU-002-V0
[D]
[F]
[C]
[B]
[E]
[A]
[G]


BATTERY REPLACEMENT
1. At the bottom of the keypad, remove the screw that secures the front
cover to the rear mounting bracket.
2. Remove the batteries, wait 10 seconds, then insert three new 3V
Lithium batteries (see Specifications for replacement batteries).
3. Align the case with the cleats and snap into place and secure with bottom
screw
BATTERY CAUTION: Risk of fire, explosion, and burns. Do not recharge,
disassemble, heat above 55°C, or incinerate. Dispose of used batteries
properly. Keep away from children.
Note: Constant exposure to high or low temperature or high humidity may
reduce battery life.
PANIC KEYS
This keypad also features panic keys. These keys
may be programmed for Fire, Police, and Medical
alarms. Panic activation requires a 2-button
sequence. After the first button in the sequence is
pressed, you can cancel the panic by pressing any
key other than one of the panic keys.
Panic There are 3 ways to generate an alarm:
1. Press Panic and within 10 seconds press the
desired panic key (Fire, Police, Medical).
2. Press desired panic key and within 10 seconds
press the Panic button.
3. Press desired panic key and within 10 seconds
press the same key.
Fire
Police
Medical
SPECIFICATIONS:
Dimensions (mm) / Weight: 153 (H) x 98 (W) x 34 (D) / 283 g
Frequency of Operation: 2.4 GHz
Tamper: Wall (audible alert and signal sent to Control Panel)
Sounder: Piezoelectric
Batteries: Three (3) - 3V Lithium batteries
EVE CR123A
Panasonic CR123A
Duracell DL123A
(xxxx-xxxxxx)
www.cnpp.com
www.marque-nf.com
The product should not be disposed of with other household waste. Check for the nearest authorized collection centers or
authorized recyclers. The correct disposal of end-of-life equipment will help prevent potential negative consequences for the
environment and human health.
This system must be checked by a qualified technician at least once every three (3) years.
Any attempt to reverse-engineer this device by decoding proprietary protocols, de-compiling firmware, or any similar actions is strictly prohibited.
REFER TO THE INSTALLATION INSTRUCTIONS FOR THE CONTROL WITH WHICH THIS DEVICE IS USED, FOR DETAILS REGARDING
LIMITATIONS OF THE ENTIRE ALARM SYSTEM


